You can then pinch & zoom to adjust the size.
| 3 | OBSOLETE ASSY INNER CASE Main part no. 402A3379 |
|||
| 4 | SCREW FIXING Main part no. 402C1714 |
|||
| 5 | OBSOLETE O RING ANGUS R2015 GRADE P5 Main part no. 400A00157 |
|||
| 6 | OBSOLETE LIGHTING WINDOW ASSY ROUND Main part no. 307A251 |
|||
| 15 |  |
OBSOLETE SCREW NO.8X3/8 PN HD POZI Main part no. S/108/12 |
||
| 17 | OBSOLETE SIDE INSULATION Main part no. 402C428 |
|||
| 18 | OBSOLETE FRONT INSULATION Main part no. 402C429 |
|||
| 19 | OBSOLETE REAR INSULATION Main part no. 402C430 |
|||
| 27 | OBSOLETE H/E ASSY. 52FINS Main part no. 402A156 |
|||
| 28 | OBSOLETE INLET PIPE ASSY Main part no. 402A397 |
|||
| 30 | OBSOLETE LOCKNUT 28MM Main part no. 402C416 |
|||
| 31 | OBSOLETE NUT 28MM Main part no. 402C417 |
|||
| 31 | OBSOLETE BLANKING CAP Main part no. 403C269 |
|||
| 32 | OBSOLETE NUT 22MM UNION Main part no. 402C168 |
|||
| 34 | OBSOLETE 22MM OLIVE. Main part no. 402C169 |
|||
| 35 | OBSOLETE LIMIT STAT Main part no. 403A025 |
|||
| 37 |  |
LIMIT STAT HI BROWN Main part no. 402S184 |
£13.60 | |
| 38 |  |
LIMIT STAT LO WHITE Main part no. 402S185 |
£11.21 | |
| 45 | OBSOLETE GAS TUBE FLUE DUCT Main part no. 305C232 |
|||
| 55 | OBSOLETE BURNER AND PILOT ASSY Main part no. 402A403 |
|||
| 56 | OBSOLETE BURNER Main part no. 402S445 |
|||
| 57 | OBSOLETE INJECTOR BURNER CAT 10/22 Main part no. 402S644 |
|||
| 58 |  |
OBSOLETE PILOT ASSY. Main part no. 402A045 |
||
| 59 | OBSOLETE PILOT BASE PLATE ASSY. Main part no. 402A164 |
|||
| 60 |  |
PILOT TOP SOCKET IB 3254 Main part no. 402S420 |
||
| 61 |  |
INJECTOR PILOT CAT 968/5 Main part no. 402S388 |
||
| 62 |  |
SPARK ELECTRODE. Main part no. 308S116 |
||
| 63 | OBSOLETE SCREW Main part no. 11/11592 |
|||
| 65 | OBSOLETE SHIELD PILOT Main part no. 402C146 |
|||
| 68 | OBSOLETE O RING Main part no. 402S098 |
|||
| 70 | OBSOLETE PILOT TUBE Main part no. 402C427 |
|||
| 76 | OBSOLETE COCK GAS Main part no. 305S899 |
|||
| 79 | OBSOLETE GASKET Main part no. 402C387 |
|||
| 80 |  |
IGNITOR LEAD Main part no. 402S089 |
||
| 81 |  |
SPARK GENERATOR Main part no. 402S083 |
||
| 81 | OBSOLETE CONT.BOX BLK.PLATE. Main part no. 402C140 |
|||
| 82 | OBSOLETE FLUE HOOD Main part no. 403A014 |
|||
| 83 |  |
NUT M5 FULL BRASS Main part no. 635506 |
||
| 83 | OBSOLETE FLUE HOOD INSPECTION COVER Main part no. 403C135 |
|||
| 85 | OBSOLETE TIE ROD Main part no. 402C419 |
|||
| 94 | OBSOLETE EXPANSION VESSEL SUPPO Main part no. 403C149 |
|||
| 96 | OBSOLETE SHIELD HEAT Main part no. 402C197 |
|||
| 98 |  |
FOAM SEAL Main part no. 307C798 |
||
| 101 | OBSOLETE TRANSFORMER SPECIAL Main part no. 403S159 |
|||
| 102 | OBSOLETE COMPONENT MOUNTING BKT Main part no. 403A018 |
|||
| 104 | OBSOLETE WIRING HARNESS Main part no. 403A036 |
|||
| 105 | OBSOLETE WIRING HARNESS SENSOR/STAT & 3 Main part no. 403A034 |
|||
| 106 | OBSOLETE WIRING HARNESS PUMP & 3 WAY VA Main part no. 403A033 |
|||
| 107 | OBSOLETE WIRING HARNESS Main part no. 403A035 |
|||
| 113 | OBSOLETE PRINTED CIRCUIT BOARD Main part no. 403A227 |
|||
| 115 | OBSOLETE FUSE 2AMP Main part no. 403S225 |
|||
| 115 | OBSOLETE FUSE 1AMP Main part no. 403S226 |
|||
| 118 | OBSOLETE BROWN SWITCH GREEN BEZEL 3 WAY Main part no. 403S217 |
|||
| 119 | OBSOLETE BROWN SWITCH RED BEZEL 3 WAY Main part no. 403S218 |
|||
| 120 | OBSOLETE BROWN SWITCH GREEN BEZEL 2 WAY Main part no. 403S219 |
|||
| 126 | OBSOLETE GASKET Main part no. 403S332 |
|||
| 130 | OBSOLETE MAINS ISOLATING VALVE Main part no. 403S293 |
|||
| 130 | OBSOLETE WATER INLET PIPE ASSY Main part no. 403A075 |
|||
| 131 | OBSOLETE WATER OUTLET PIPE ASSY Main part no. 403A076 |
|||
| 132 | OBSOLETE SUPPLY PIPE ASSY Main part no. 403A077 |
|||
| 133 | OBSOLETE PIPE ASSY Main part no. 403A078 |
|||
| 137 | OBSOLETE PRESSURE RELIEF VALVE Main part no. 403S082 |
|||
| 137 | OBSOLETE RUBBER WASHER 30MM O/D Main part no. 403C144 |
|||
| 137 | OBSOLETE WASHER Main part no. 403C146 |
|||
| 138 | OBSOLETE DIVERTER VALVE Main part no. 403S083 |
|||
| 139 | OBSOLETE LOCKNUT M20 Main part no. 403C097 |
|||
| 140 | OBSOLETE NUT COMPRESSION M20 Main part no. 403C098 |
|||
| 141 | OBSOLETE OLIVE 15MM I/D Main part no. 403C102 |
|||
| 147 | WASHER Main part no. 403C145 |
£3.73 | ||
| 147 | OBSOLETE WASHER Main part no. 403C258 |
|||
| 152 | OBSOLETE LOCKNUT 22MM Main part no. 402C066 |
|||
| 153 | OBSOLETE DATA LABEL Main part no. 403C154 |
|||
| 162 | OBSOLETE ASSY WALL MOUNTING PLATE Main part no. 402A406 |
|||
| 163 | OBSOLETE OUTER WALL FLUE 4/6 BF 231602 Main part no. 305A360 |
|||
| 165 | OBSOLETE FLUE TERMINAL Main part no. 305A361 |
|||
| 167 | OBSOLETE OUTER WALL FLUE 9/15BF 231604 Main part no. 305A362 |
|||
| 168 | OBSOLETE INNER WALL FLUE 9/15BF 231587 Main part no. 305A366 |
|||
| 169 | OBSOLETE OUTER WALL FLUE 15/24 BF 23160 Main part no. 305A363 |
|||
| 171 | OBSOLETE NUT LONG M6 Main part no. 307C188 |
|||
| 172 | OBSOLETE SEALING STRIP ASSY FLUE Main part no. 305A592 |
|||
| 175 | OBSOLETE TAP Main part no. 403S267 |
|||
| 177 | OBSOLETE WASHER M20 Main part no. 403C147 |
|||
