INTERGAS
32 - (Burner Unit From March 2016)
Appliance Code: 47-291-09

Appliance Diagram


Burner Unit From March 2016 diagram for Intergas 32Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 800327, NOW USE 086454 Burner KIT NOW USE 086454 BURNER KIT
Intergas part no. 800327

1   BURNER KIT
Intergas part no. 086454
£228.00
2 Part number 877847, Burner Seal BURNER SEAL
Intergas part no. 877847
£4.00
3 Part number 909427, INSULATION PACKAGE INSULATION PACKAGE
Intergas part no. 909427
£97.50
4 Part number 876607, INSULATION FRONT PLATE INSULATION FRONT PLATE
Intergas part no. 876607
5 Part number 620274, Seal Ring for 40kw SEAL RING FOR 40KW
Intergas part no. 620274
£17.20
5 Part number 876597, NOW USE 620274 Seal Ring Front plate 36kW- NOW USE 620274 SEAL RING FRONT PLATE 36KW-
Intergas part no. 876597

6   REPLACEMENT SET FRONT PLATE
Intergas part no. 081287
7 Part number 875917, O-Ring 6x1.5 Silicone O-RING 6X1.5 SILICONE
Intergas part no. 875917
£3.00
8 Part number 362217, Plate Screw T20 PLATE SCREW T20
Intergas part no. 362217
£3.00
9 Part number 873577, Burner Spring BURNER SPRING
Intergas part no. 873577
£3.00
10 Part number 390087, Starlock 4mm STARLOCK 4MM
Intergas part no. 390087
£3.00
11 Part number 305157, Shoulder bolt incl. dry-l SHOULDER BOLT INCL. DRY-L
Intergas part no. 305157
£3.00
