Quickly locate your appliance and order replacement parts using our secure online payment facility.
Created by Gas Engineers, for Gas Engineers • We only sell Genuine Boiler Spares • HSP - Where The Trade Buy
You can then pinch & zoom to adjust the size.
| 0 | BASE F/CONT PNL 82190506 Ideal part no. 170216 |
£131.95 | ||
| 0 | OBSOLETE COMP WIRING HARNESS 82198964 Ideal part no. 170227 |
|||
| 0 | MAINS F/CONT PNL 82194907 Ideal part no. 170235 |
£104.86 | ||
| 0 | SENSOR FORM 82194901 Ideal part no. 170228 |
£94.15 | ||
| 0 | BAG OF SCREWS 82298933 Ideal part no. 170370 |
£93.15 | ||
| 0 | BAG OF SCREWS 82298934 Ideal part no. 170371 |
£90.02 | ||
| 0 | BAG OF SCREWS 82298935 Ideal part no. 170372 |
£83.26 | ||
| 0 | RH WIRING DUCT 7 SECT 82298826 Ideal part no. 170362 |
£144.63 | ||
| 0 | BRUSH HANDLE 1300 LG 97505060 Ideal part no. 067800 |
£65.45 | ||
| 0 |  |
METAL BRUSH 60X95 97505025 Ideal part no. 067799 |
£82.97 | |
| 0 | PUTTY FOR NIPPLE 300G 94305027 Ideal part no. 170249 |
£204.13 | ||
| 0 |  |
COMP LOWER BAFFLE 82290024 Ideal part no. 170305 |
£81.62 | |
| 0 |  |
COMP UPPER BAFFLE 190 82290022 Ideal part no. 170301 |
£59.15 | |
| 0 | COMP UPPER BAFFLE 82290023 Ideal part no. 170303 |
£66.16 | ||
| 0 | EXT F/BRUSH ROD 650 97505048 Ideal part no. 170316 |
£43.14 | ||
| 0 | F/SWITCH(88024724)VROY GT 14SE Ideal part no. 170299 |
£568.20 | ||
| 0 | F/SWITCH(88024703)VROY GT 7SEC Ideal part no. 170292 |
£556.48 | ||
| 0 | F/SWITCH(88024710)VROY GT 9SEC Ideal part no. 170294 |
£556.48 | ||
| 0 | F/SWITCH(88024711) Ideal part no. 170293 |
£665.32 | ||
| 0 | F/SWITCH(88024722)VROY GT 11SE Ideal part no. 170296 |
£556.48 | ||
| 0 | F/SWITCH(88024723)VROY GT 13SE Ideal part no. 170298 |
£568.20 | ||
| 0 | F/SWITCH(82294705)VROY GT 12SE Ideal part no. 170297 |
£568.20 | ||
| 0 | F/SWITCH(88024712)VROY GT 10SE Ideal part no. 170295 |
£556.48 | ||
| 2 | REAR SECTION ASSY VICEROY GT Ideal part no. 075224 |
£2,750.87 | ||
| 3 | NORMAL CENTRE SECTION ASSY Ideal part no. 075225 |
£3,037.69 | ||
| 4 | SPECIAL CENTRE SECT ASSY Ideal part no. 075226 |
£2,677.44 | ||
| 5 | FRONT SECTION ASSY VICEROY GT Ideal part no. 075227 |
£2,322.83 | ||
| 6 | NIPPLES VIC ES 80050200 Ideal part no. 065853 |
£111.05 | ||
| 7 | COMP ASSY ROD D14 82298920 Ideal part no. 170251 |
£21.90 | ||
| 7 | COMP ASSY ROD D14 82298919 Ideal part no. 170250 |
£17.02 | ||
| 7 | COMP ASSY ROD D14 82298921 Ideal part no. 170252 |
£24.15 | ||
| 9 | ATTACHMENT BRKT 97525232 Ideal part no. 170253 |
£17.02 | ||
| 10 | THERMOCORD SEAL 10 DIA 95086032 Ideal part no. 170133 |
£37.03 | ||
| 11 | WATER FLOW FLANGE/GSKT82298923 Ideal part no. 170254 |
£247.14 | ||
| 11 | WATER FLOW FLNG/GSKT 82298918 Ideal part no. 170255 |
£289.03 | ||
| 12 | RETURN FLG/PIPE GSKT82298922 Ideal part no. 170256 |
£216.94 | ||
| 12 | RTN FLANGE/PIPE/GSKT 81048965 Ideal part no. 067888 |
£256.76 | ||
| 13 |  |
FLANGE GSKT VICE ES 95014135 Ideal part no. 065894 |
£50.33 | |
| 15 | 2 1/2IN PLUG HARR ES 80130028 Ideal part no. 065859 |
£45.55 | ||
| 16 | T/STAT POCKET 85000027 VISC ES Ideal part no. 065862 |
£44.41 | ||
| 17 | NIPPLE VISCOUNT 80060212 Ideal part no. 065863 |
£129.62 | ||
| 19 | PLT F/COMB CHMR DR 82290532 Ideal part no. 170265 |
£227.57 | ||
| 20 | RAISED INSULATION 97550258 Ideal part no. 170273 |
£30.55 | ||
| 21 | PROTECTION F/BNR DR 97550259 Ideal part no. 170274 |
£44.40 | ||
| 22 | BNR DR INSULATION 97550260 Ideal part no. 170275 |
£215.44 | ||
| 23 | ADDED HINGE 82290204 Ideal part no. 170276 |
£95.39 | ||
| 24 | BURNER DOOR AXLE 97560213 Ideal part no. 170277 |
£9.19 | ||
| 25 | BURNER DOOR HINGE 82290205 Ideal part no. 170278 |
£54.80 | ||
| 26 | RAMP 82290206 Ideal part no. 170279 |
£11.53 | ||
| 27 |  |
SIGHT GLASS & GASKETS 80157700 Ideal part no. 065898 |
£33.20 | |
| 29 | RH CLEANING DOOR 82298905 Ideal part no. 170281 |
£560.66 | ||
| 30 | LH CLEANING DOOR 82298906 Ideal part no. 170282 |
£473.69 | ||
| 31 |  |
CLEANING DR INSUL 97550256 Ideal part no. 170283 |
£72.09 | |
| 32 | CLEANING DR PROTECT 97550257 Ideal part no. 170284 |
£42.72 | ||
| 33 | HINGE F/CLEAN DR 82290202 Ideal part no. 170285 |
£30.56 | ||
| 34 | PIN F/CLEANING DR 97560214 Ideal part no. 170286 |
£9.85 | ||
| 35 | COMP SMOKE BOX 82298907 Ideal part no. 170287 |
£267.17 | ||
| 36 | RH CLEANING TRAP 82298908 Ideal part no. 170288 |
£104.14 | ||
| 37 | LH CLEANING TRAP 82298909 Ideal part no. 170289 |
£101.11 | ||
| 38 | FLUE NOZZLE D2508T010 82298916 Ideal part no. 170290 |
£149.54 | ||
| 38 | FLUE NOZZLE D300 82298917 Ideal part no. 170291 |
£132.79 | ||
| 40 |  |
UPPER BAFFLE 190 82290010 Ideal part no. 170300 |
£124.45 | |
| 41 |  |
UPPER BAFFLE 240 82290011 Ideal part no. 170302 |
£151.36 | |
| 42 |  |
LOWER BAFFLE 82290012 Ideal part no. 170304 |
£167.35 | |
| 46 | FRT BODY INSUL 82294004 Ideal part no. 170310 |
£256.07 | ||
| 47 | BODY INSUL WDTH 600 82294018 Ideal part no. 170312 |
£268.87 | ||
| 47 | BODY INSUL WDTH 600 82294015 Ideal part no. 170311 |
£268.87 | ||
| 47 | BODY INSUL WDTH 900 82294012 Ideal part no. 170314 |
£472.57 | ||
| 47 | BODY INSUL WDTH 800 82294009 Ideal part no. 170313 |
£472.57 | ||
| 48 | REAR INSULATION 82294005 Ideal part no. 170315 |
£227.91 | ||
| 61 | COMPLETE BACK SIDE 82190500 Ideal part no. 170217 |
£123.22 | ||
| 62 | FRONT PANEL 82198951 Ideal part no. 170218 |
£290.42 | ||
| 63 | SIDE PANEL 82190509 Ideal part no. 170219 |
£24.80 | ||
| 64 | LATERAL CHEECK 97550142 Ideal part no. 170220 |
£41.56 | ||
| 65 |  |
OBSOLETE TEMPERATURE GAUGE 95365157 Ideal part no. 065873 |
£82.68 | |
| 66 | TEST SWITCH 95325156 HARR GT Ideal part no. 170221 |
£18.09 | ||
| 67 | TWO POLE SWITCH 85000035 Ideal part no. 067567 |
£11.18 | ||
| 68 | BNR & PUMP SWITCH (95325103) Ideal part no. 170027 |
£10.14 | ||
| 69 |  |
T/STAT ES 85000031 BUCC Ideal part no. 065868 |
£331.18 | |
| 70 |  |
CONTROL THERMOSTAT 95363348 Ideal part no. 170222 |
£91.00 | |
| 71 | OBSOLETE T/STAT ES 85000020 BUC Ideal part no. 065865 |
|||
| 72 |  |
CONTROL KNOB W/STOP(82198931) Ideal part no. 170224 |
£42.20 | |
| 73 | 5A FUSE 95340074 Ideal part no. 170225 |
|||
| 74 | FUSE HOLDER (96550023) Ideal part no. 067628 |
|||
| 75 | INDICATOR LIGHT 95216258 Ideal part no. 065880 |
£7.63 | ||
| 76 | RED NEON 95216213 Ideal part no. 170226 |
£67.26 | ||
| 80 | CONTROL PANEL BASE 82190508 Ideal part no. 170231 |
£81.65 | ||
| 81 | CONTROL PANEL COVER 82190502 Ideal part no. 170232 |
£61.78 | ||
| 82 | FRONT PANEL 82198979 Ideal part no. 170233 |
£234.10 | ||
| 83 | CONTROL PANEL SIDE PLT 97550143 Ideal part no. 170234 |
£13.30 | ||
| 100 | COMP UPPER FRT PNL 82291006 Ideal part no. 170325 |
£293.43 | ||
| 101 | RH LWR FRT PANEL 82291001 Ideal part no. 170326 |
£182.22 | ||
| 102 | LH LWR FRT PANEL 82291003 Ideal part no. 170327 |
£191.33 | ||
| 103 | UPPER FRT BNR PANEL 82291004 Ideal part no. 170328 |
£113.50 | ||
| 104 | LWR FRT BNR PANEL 82291005 Ideal part no. 170329 |
£115.49 | ||
| 105 | FRONT CASING BRKT 82298834 Ideal part no. 170330 |
£148.42 | ||
| 106 | LOWER FRT CROSS BAR 82290537 Ideal part no. 170331 |
£521.81 | ||
| 107 | UPPER LH C.BRKT 82298807 Ideal part no. 170332 |
£96.51 | ||
| 108 | UPPER RH C.BRKT 82298808 Ideal part no. 170333 |
£104.50 | ||
| 109 | LOWER CASING BRKT 82298010 Ideal part no. 170334 |
£25.87 | ||
| 110 | LEFT/RIGHT H.S.PNL 82290508 Ideal part no. 170335 |
£246.99 | ||
| 111 | FRT LH SIDE PANEL 82298810 Ideal part no. 170336 |
£252.05 | ||
| 112 | LH SIDE PNL W.610 82298816 Ideal part no. 170338 |
£311.55 | ||
| 112 | LH SIDE PNL W.930 82298814 Ideal part no. 170339 |
£318.66 | ||
| 112 | LH SIDE PNL W.770 82298812 Ideal part no. 170337 |
£318.66 | ||
| 113 | FRT RH SIDE PNL 82298811 Ideal part no. 170340 |
£252.05 | ||
| 114 | RH SIDE PNL W.930 82298815 Ideal part no. 170343 |
£318.66 | ||
| 114 | RH SIDE PNL W.770 82298813 Ideal part no. 170342 |
£318.66 | ||
| 114 | RH SIDE PNL W.610 82298817 Ideal part no. 170341 |
£296.71 | ||
| 115 | LH UPPER REAR PNL 82298835 Ideal part no. 170344 |
£138.56 | ||
| 116 | RH UPPER REAR PNL 82298836 Ideal part no. 170345 |
£131.96 | ||
| 117 | LOWER REAR PANEL 82298012 Ideal part no. 170346 |
£117.09 | ||
| 118 | COMP UPPER CROSS BAR 82298837 Ideal part no. 170347 |
£155.83 | ||
| 119 | FRONT TOP 82298809 Ideal part no. 170348 |
£243.58 | ||
| 120 | RUBB PROFILE F/WIRING 97550187 Ideal part no. 170202 |
£9.67 | ||
| 121 | CENTRE TOP 82290515 Ideal part no. 170350 |
£150.55 | ||
| 122 | REAR TOP WIDTH 330 82290511 Ideal part no. 170352 |
£158.08 | ||
| 122 | REAR TOP WIDTH 170 82290518 Ideal part no. 170351 |
£112.88 | ||
| 122 | REAR TOP WIDTH 490 82290514 Ideal part no. 170353 |
£204.46 | ||
| 123 | LH WIRING DUCT 8 SECT 82298819 Ideal part no. 170355 |
£144.63 | ||
| 123 | LH WIRING DUCT 7 SECT 82298818 Ideal part no. 170354 |
£144.63 | ||
| 123 | LH WIRING DUCT 13SECT 82298824 Ideal part no. 170360 |
£191.63 | ||
| 123 | OBSOLETE LH WIRING DUCT 9 SECT 82298820 Ideal part no. 170356 |
|||
| 123 | LH WIRING DUCT 12SECT 82298823 Ideal part no. 170359 |
£167.69 | ||
| 123 | LH WIRING DUCT 11SECT 82298822 Ideal part no. 170358 |
£146.07 | ||
| 123 | LH WIRING DUCT 10SECT 82298821 Ideal part no. 170357 |
£150.66 | ||
| 124 | LH WIRING DUCT 14SECT 82298825 Ideal part no. 170361 |
£192.98 | ||
| 124 | RH WIRING DUCT 8 SECT 82298827 Ideal part no. 170363 |
£144.63 | ||
| 124 |  |
RH WIRING DUCT 13SECT 82298832 Ideal part no. 170368 |
£191.63 | |
| 124 | RH WIRING DUCT 12SECT 82298831 Ideal part no. 170367 |
£167.69 | ||
| 124 | RH WIRING DUCT 14SECT 82298833 Ideal part no. 170369 |
£192.98 | ||
| 124 | RH WIRING DUCT 11SECT 82298830 Ideal part no. 170366 |
£153.37 | ||
| 124 |  |
OBSOLETE RH WIRING DUCT 10SECT 82298829 Ideal part no. 170365 |
||
