IDEAL
TURBO 2 - 24 - (Burner Control Ass 1)
Appliance Code: 41-429-44

Appliance Diagram


Burner Control Ass 1 diagram for Ideal Turbo 2 - 24Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0   OBSOLETE H/WARE PK TURBO 2-18/24
Ideal part no. 137709
0   OBSOLETE TERM END PLT ASSY TURBO 2
Ideal part no. 079781
1   OBSOLETE HT EXCH ASSY TURBO2-24
Ideal part no. 079619
2   OBSOLETE COMB/CHAMBER COMP TURBO 2 18
Ideal part no. 079415
3   OBSOLETE HT EXCHANGER TUBE TURBO2-24
Ideal part no. 079620
4   OBSOLETE HEAE EXCH HEAD TURBO 2 18/24
Ideal part no. 079419
5   OBSOLETE H/EXCH CVR PLT TURBO 2 18/24
Ideal part no. 079421
6   OBSOLETE HT EXCH COWLS (PAIR) TURBO 2
Ideal part no. 079403
7   OBSOLETE HT EXCH BNR BOX GSKT TURBO 2
Ideal part no. 079406
8   OBSOLETE HT EXCH GSKT SET TURBO 2 18/24
Ideal part no. 079422
9   OBSOLETE FLOW PIPE TURBO 2
Ideal part no. 132440
10   OBSOLETE RETURN PIPE TURBO 2
Ideal part no. 132439
11 Part number 135517, OBSOLETE FAN ASSY TURBO 2 SIFAN OBSOLETE FAN ASSY TURBO 2 SIFAN
Ideal part no. 135517
12   OBSOLETE FAN ORIFICE PLT TURBO 2-24
Ideal part no. 120599
13   OBSOLETE INJECTOR PIPE ASS TURBO 2-24
Ideal part no. 005048
14   OBSOLETE INJECTOR BNR BRAY CAT 10 SIZE 2300
Ideal part no. 004760
15   OBSOLETE BNR BOX ASS TURBO 2 18/24
Ideal part no. 135449
17   OBSOLETE BNR DIFFUS BOX&GSKT TUR2 18/24
Ideal part no. 079429
18   OBSOLETE BNR BOX INSUL (SET) TURBO 2
Ideal part no. 079430
19   OBSOLETE SIGHT GLASS ASSY - BNR BOX
Ideal part no. 079333
20 Part number 079401, PILOT BNR H/WELL & INJ TURBO 2 PILOT BNR H/WELL & INJ TURBO 2
Ideal part no. 079401		 £23.18
21   OBSOLETE INJECTOR PILOT H/WELL 45900421-017B TRB2
Ideal part no. 004755
22   OBSOLETE SPARK/SENSING ELECTRODE TURBO 2
Ideal part no. 004739
23   OBSOLETE LOWER PILOT PIPE ASS TURBO 2
Ideal part no. 079431
24   OBSOLETE PILOT PIPE ASS TURBO 2
Ideal part no. 079433
26   OBSOLETE LOWER SUMP ASS TURBO 2-24
Ideal part no. 137606
27   GSKT-LOWER SUMP TURBO 2
Ideal part no. 079407
28   OBSOLETE UPPER SUMP ASS TURBO 2 18-18P
Ideal part no. 135446
29   OBSOLETE UPPER SUMP/HT EXCH GSKT TURBO2
Ideal part no. 079436
30   OBSOLETE SUMP DRAIN PIPE W/SYPHON TURBO
Ideal part no. 079474
31   OBSOLETE SYPHON AND GASKET TURBO 2
Ideal part no. 079443
32   OBSOLETE CTRL BOX ASS TURBO 2
Ideal part no. 135516
33 Part number 013850, OBSOLETE LIMIT STAT OBSOLETE LIMIT STAT
Ideal part no. 013850
34 Part number 013851, BLR STAT 2455R 98 728 BLR STAT 2455R 98 728
Ideal part no. 013851		 £14.99
35   OBSOLETE NEON + LEADS SUB ASS TURBO2
Ideal part no. 135529
35   OBSOLETE TML STRIP WIRING HRNS TURBO 2
Ideal part no. 135528
36 Part number 060550, PCB 7B BOARD (401201) PCB 7B BOARD (401201)
Ideal part no. 060550
36 Part number 132789, PCB 7B W/LINK XL30/60F PCB 7B W/LINK XL30/60F
Ideal part no. 132789
37 Part number 004853, GAS VALVE VR4700A4008U TURBO 2 GAS VALVE VR4700A4008U TURBO 2
Ideal part no. 004853		 £268.37
40   OBSOLETE ELBOW 1/2 INCH RC HONEYWELL 45900400
Ideal part no. 004569
41 Part number 135518, OBSOLETE AIR PRESSURE SWITCH TURBO 2 OBSOLETE AIR PRESSURE SWITCH TURBO 2
Ideal part no. 135518
42   OBSOLETE HIGH PRESS SENSING LINE TURBO2
Ideal part no. 079438
44   OBSOLETE GASCOCK ASSY 004913/924/919
Ideal part no. 077012
45   OBSOLETE GAS PIPE S/ASS PTD TURBO 2
Ideal part no. 131582
46   OBSOLETE BLR CSG TURBO 2
Ideal part no. 135096
47   OBSOLETE GLASS FASCIA PANEL TURBO 2
Ideal part no. 133440
48   OBSOLETE DOOR CATCH ASS EL NF/EL2
Ideal part no. 132927
49   OBSOLETE CTRL CSG BTM PNL S/ASS PTD TUR
Ideal part no. 135202
50   OBSOLETE SET OF FACIA TRIMS TURBO 2
Ideal part no. 079441
51   OBSOLETE BACK PNL ASSY TURBO 2
Ideal part no. 135339
52   OBSOLETE CASING SEALING PACK TURBO 2
Ideal part no. 079442
53   OBSOLETE H/WARE PK ELAN CF
Ideal part no. 132961
54   OVERHAUL GASKET SET TURBO(KIT)
Ideal part no. 079570
55   OBSOLETE CASING SIGHT GLASS ASSY TURBO 2
Ideal part no. 079633
56   OBSOLETE SUMP FAN TURBO 2 24
Ideal part no. 137616
58 Part number 005026, OBSOLETE L/STAT TURBO 2-24 OBSOLETE L/STAT TURBO 2-24
Ideal part no. 005026
