IDEAL
MINI HE C28 - (Controls VJ)
Appliance Code: 47-348-39

Appliance Diagram


Controls VJ diagram for Ideal Mini HE C28Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 172494, SAFETY VALVE (BI1131 100) SAFETY VALVE (BI1131 100)
Ideal part no. 172494		 £21.18
2 Part number 075474, 1/2 IN SAFETY VLV CONNECTION BI1001 127 1/2 IN SAFETY VLV CONNECTION BI1001 127
Ideal part no. 075474		 £5.54
3 Part number 172495, SAFETY VALVE CON.PIPE (BI1131 106) SAFETY VALVE CON.PIPE (BI1131 106)
Ideal part no. 172495		 £7.62
4 Part number 075480, O RING GASKET 1 78 X 15 6 BI1001 131 O RING GASKET 1 78 X 15 6 BI1001 131
Ideal part no. 075480		 £2.10
5 Part number 075409, DRAINAGE VALVE 1/4IN C80FF BI1011 104 DRAINAGE VALVE 1/4IN C80FF BI1011 104
Ideal part no. 075409		 £10.20
6 Part number 173820, O RING GASKET 17.04X4.00(BI1212 112) O RING GASKET 17.04X4.00(BI1212 112)
Ideal part no. 173820		 £2.73
7 Part number 075472, SCREW M5X16mm HEX SKT BZP RPH BI1001 125 SCREW M5X16MM HEX SKT BZP RPH BI1001 125
Ideal part no. 075472		 £2.49
8   RETURN GROUP KIT (BI1131 503)
Ideal part no. 174019		 £127.21
8   RETURN GROUP KIT (BI1271 502)
Ideal part no. 174460		 £131.07
9 Part number 075415, 3/4IN FLAT GASKET C80FF BI1001 108 3/4IN FLAT GASKET C80FF BI1001 108
Ideal part no. 075415		 £2.36
11   SCREW M6 X 8MM BZP RPH BI1001 123
Ideal part no. 075471		 £2.32
12 Part number 075414, 1/2IN FLAT GASKET BI1001 106 1/2IN FLAT GASKET BI1001 106
Ideal part no. 075414		 £3.06
13 Part number 172501, FLOW LIMITER 12L (BI1091 103) FLOW LIMITER 12L (BI1091 103)
Ideal part no. 172501		 £8.49
14 Part number 075479, O RING GASKET 2 62 X 20 63 BI1001 130 O RING GASKET 2 62 X 20 63 BI1001 130
Ideal part no. 075479		 £2.21
15 Part number 172502, MAGNETIC FLOW SWITCH & FILTER BI1091 502 MAGNETIC FLOW SWITCH & FILTER BI1091 502
Ideal part no. 172502		 £53.32
15 Part number 174461, MAGNETIC FLO SW & FILTER KIT(BI1271 501) MAGNETIC FLO SW & FILTER KIT(BI1271 501)
Ideal part no. 174461		 £83.40
16 Part number 172503, DHW FLOW SWITCH (BI1091 104) DHW FLOW SWITCH (BI1091 104)
Ideal part no. 172503		 £55.90
16 Part number 174462, D.H.W. FLOW SWITCH (BI1271 101) D.H.W. FLOW SWITCH (BI1271 101)
Ideal part no. 174462		 £42.51
17 Part number 173785, DHW HEAT EXCHANGER & 4 O RINGS C95FF DHW HEAT EXCHANGER & 4 O RINGS C95FF
Ideal part no. 173785		 £183.30
18 Part number 075412, BY-PASS PIPE O RING C80FF BI1001 115 BY-PASS PIPE O RING C80FF BI1001 115
Ideal part no. 075412		 £3.06
19 Part number 172504, BY-PASS PIPE (BI1131 101) BY-PASS PIPE (BI1131 101)
Ideal part no. 172504
19   BY - PASS PIPE (BI1271 100)
Ideal part no. 174463		 £26.87
20 Part number 075401, DHW HT EXCH O RING C80FFF KI1043 144 DHW HT EXCH O RING C80FFF KI1043 144
Ideal part no. 075401		 £2.76
21 Part number 075411, BY-PASS PIPE FXG FORK C80FF BI1001 111 BY-PASS PIPE FXG FORK C80FF BI1001 111
Ideal part no. 075411		 £2.68
22 Part number 075478, O RING GASKET 1 78 X 14 BI1001 129 O RING GASKET 1 78 X 14 BI1001 129
Ideal part no. 075478		 £2.21
23 Part number 172505, DIVERTER VALVE ACTUATOR (BI1101 102) DIVERTER VALVE ACTUATOR (BI1101 102)
Ideal part no. 172505		 £90.84
24 Part number 172506, DVTR.V.ACTUATOR FIX G SP G(BI1101 101) DVTR.V.ACTUATOR FIX G SP G(BI1101 101)
Ideal part no. 172506		 £2.47
25 Part number 172507, DIVERTER VALVE KIT (BI1141 501) DIVERTER VALVE KIT (BI1141 501)
Ideal part no. 172507		 £108.82
26 Part number 075483, O RING GASKET 2 62 X 23 47 BI1011 107 O RING GASKET 2 62 X 23 47 BI1011 107
Ideal part no. 075483		 £3.12
27 Part number 172508, O RING GASKET 2.7X13.6(BI1011 117) O RING GASKET 2.7X13.6(BI1011 117)
Ideal part no. 172508		 £2.32
28 Part number 174020, FLOW GROUP KIT (BI1141 504) FLOW GROUP KIT (BI1141 504)
Ideal part no. 174020		 £272.47
28 Part number 174464, FLOW GROUP KIT (BI1251 501) FLOW GROUP KIT (BI1251 501)
Ideal part no. 174464		 £296.56
29 Part number 173822, O RING GASKET 9.25X1.78(KI1001 128) O RING GASKET 9.25X1.78(KI1001 128)
Ideal part no. 173822		 £2.32
30 Part number 172496, SENSOR (BI1001 117) SENSOR (BI1001 117)
Ideal part no. 172496		 £17.55
31 Part number 075421, CH PRESSURE SWITCH MEMBRANE BI1011 103 CH PRESSURE SWITCH MEMBRANE BI1011 103
Ideal part no. 075421		 £9.73
32 Part number 075487, CH PRESSURE SWITCH DISK BI1011 111 CH PRESSURE SWITCH DISK BI1011 111
Ideal part no. 075487		 £9.48
33 Part number 075422, CH PRESS SWITCH SPRING C80FF BI1011 110 CH PRESS SWITCH SPRING C80FF BI1011 110
Ideal part no. 075422		 £16.44
34 Part number 075486, SCREW M4 X 12 SCH S/S B1011 109 SCREW M4 X 12 SCH S/S B1011 109
Ideal part no. 075486		 £2.11
35 Part number 075484, MICROSWITCH GUIDE BUSH BI1011 502 MICROSWITCH GUIDE BUSH BI1011 502
Ideal part no. 075484		 £21.67
36 Part number 075419, MICROSWITCH KIT RC80FF BI1011 505 MICROSWITCH KIT RC80FF BI1011 505
Ideal part no. 075419		 £24.30
37 Part number 075420, M/SWITCH FXG CLIP C80FF BI1011 105 M/SWITCH FXG CLIP C80FF BI1011 105
Ideal part no. 075420		 £2.32
38   OBSOLETE SCREW 2 9X13 AB S/TAP BZP RCH BI1011 108
Ideal part no. 075485
39   BY-PASS KIT (BI1141 505)
Ideal part no. 174021		 £10.29
41 Part number 173993, RECUPERATOR MINI HE(BI1262 122) RECUPERATOR MINI HE(BI1262 122)
Ideal part no. 173993		 £409.29
42 Part number 174010, O RING GASKET 2.62x17.86 (BI1262 112) O RING GASKET 2.62X17.86 (BI1262 112)
Ideal part no. 174010
43 Part number 172516, MAIN EXCHANGER CON.CLIP (BI1172 101) MAIN EXCHANGER CON.CLIP (BI1172 101)
Ideal part no. 172516		 £3.06
44 Part number 174011, SPRING CLIP (BI1262 117) SPRING CLIP (BI1262 117)
Ideal part no. 174011		 £2.21
45   RECUPERATOR INLET PIPE-UPPER(BI1262 109)
Ideal part no. 174023		 £17.31
46 Part number 075447, PRIMARY H/E GROMMET C80FF BI1002 113 PRIMARY H/E GROMMET C80FF BI1002 113
Ideal part no. 075447		 £11.61
47   CONDENSATE DRAINAGE PIPE(BI1262 110)
Ideal part no. 174024		 £14.72
48 Part number 173819, O RING GASKET 16.0X1.9(BI1262 114) O RING GASKET 16.0X1.9(BI1262 114)
Ideal part no. 173819
49   RECUPERATOR INLET PIPE-LOWER(BI1262 108)
Ideal part no. 174025		 £24.58
50   MAIN H/E + 2 O-RINGS MINI HE C24
Ideal part no. 173991		 £261.27
50   MAIN H/E + 2 O-RINGS MINI HE C28
Ideal part no. 173992
51   O/H THERMOSTAT FIXING CLIP (BI1182 100)
Ideal part no. 173498		 £2.11
52 Part number 172512, O/HEAT STAT (BI1172 105) O/HEAT STAT (BI1172 105)
Ideal part no. 172512		 £12.66
53 Part number 172497, O RING GASKET 17.04X3.53(KI1043 114) O RING GASKET 17.04X3.53(KI1043 114)
Ideal part no. 172497
54 Part number 173242, MAIN EXCH CONNECTION CLIP(BI1182 106) MAIN EXCH CONNECTION CLIP(BI1182 106)
Ideal part no. 173242		 £2.32
55 Part number 173813, AUTOMATIC AIR VENT (BI1212 107) AUTOMATIC AIR VENT (BI1212 107)
Ideal part no. 173813		 £23.22
56 Part number 173814, PUMP CONNECTION FORK (BI1262 116) PUMP CONNECTION FORK (BI1262 116)
Ideal part no. 173814		 £8.49
57 Part number 174205, CONDENSATE TRAP (BI1442 104) CONDENSATE TRAP (BI1442 104)
Ideal part no. 174205		 £48.34
57 Part number 174206, CONDENSATE CONNECTION HOSE (BI1262 128) CONDENSATE CONNECTION HOSE (BI1262 128)
Ideal part no. 174206		 £10.41
58 Part number 173816, FORK (BI1262 120) FORK (BI1262 120)
Ideal part no. 173816		 £23.48
59   FORK (KI1042 101)
Ideal part no. 173817		 £3.43
60   FORK (KI1042 115)
Ideal part no. 172518		 £2.11
61   S-TAP SCREW 5.0X16.0 (BI1262 115)
Ideal part no. 173818		 £1.17
62 Part number 174004, PUMP + O RINGS MINI HE PUMP + O RINGS MINI HE
Ideal part no. 174004		 £274.46
63 Part number 174013, PUMP MOTOR - WILO 12/6 (BI1262 119) PUMP MOTOR - WILO 12/6 (BI1262 119)
Ideal part no. 174013		 £260.64
64 Part number 172523, PUMP GASKET(FRONT) (BI1172 113) PUMP GASKET(FRONT) (BI1172 113)
Ideal part no. 172523
65   MAIN EXCHANGER OUTLET PIPE (BI1262 106)
Ideal part no. 174026		 £32.09
66 Part number 075436, PROBE HOLDER BI1105 108 PROBE HOLDER BI1105 108
Ideal part no. 075436		 £2.11
67 Part number 173821, O RING GASKET 9.92X2.62(BI1262 113) O RING GASKET 9.92X2.62(BI1262 113)
Ideal part no. 173821		 £2.73
68   EXPN VESSEL CONNECTION PIPE(BI1262 105)
Ideal part no. 174027		 £13.18
69 Part number 173256, FLAT GASKET 3/8ins(15X8.5mm)(BI1202 105) FLAT GASKET 3/8INS(15X8.5MM)(BI1202 105)
Ideal part no. 173256		 £3.59
70 Part number 172529, EXPANSION VESSEL CIMM (BI1172 103) EXPANSION VESSEL CIMM (BI1172 103)
Ideal part no. 172529		 £86.00
71 Part number 174028, RECUPERATOR OUTLET PIPE (BI1262 107) RECUPERATOR OUTLET PIPE (BI1262 107)
Ideal part no. 174028		 £21.00
72 Part number 075692, INJECTORS+GASKETS C95FF KI1064 505 INJECTORS+GASKETS C95FF KI1064 505
Ideal part no. 075692		 £31.73
72   INJECTORS FOR LPG MINI HE (BI1003 509)
Ideal part no. 173982		 £26.67
73 Part number 075535, MAIN BURNER C95FF KI1004 147 MAIN BURNER C95FF KI1004 147
Ideal part no. 075535		 £97.37
73 Part number 173149, FLOW/RETURN PIPE (BOILER) FLOW/RETURN PIPE (BOILER)
Ideal part no. 173149		 £12.90
74 Part number 172531, DETECTION ELECTRODE (BI1123 102) DETECTION ELECTRODE (BI1123 102)
Ideal part no. 172531		 £12.15
75 Part number 172532, IGNITION ELECTRODE RIGHT (BI1123 103) IGNITION ELECTRODE RIGHT (BI1123 103)
Ideal part no. 172532		 £9.92
76 Part number 172533, IGNITION ELECTRODE LEFT (BI1123 101) IGNITION ELECTRODE LEFT (BI1123 101)
Ideal part no. 172533		 £9.92
77   GROMMET C80FF BI1002 115
Ideal part no. 075662		 £2.19
78 Part number 075511, SCREW NO6B 3 5 X 9 5 C80FF BI1013 115 SCREW NO6B 3 5 X 9 5 C80FF BI1013 115
Ideal part no. 075511		 £2.11
79   OBSOLETE SCREW M4X8 H/ST BZB RPH C80FF BI1013 111
Ideal part no. 075500
80   M4 X 8 P/P HD SCREW ZP DES SPEC 0250
Ideal part no. 002515		 £2.22
80   NO 8X10 PP SCW S/TAP ZP AB DES SPEC 0250
Ideal part no. 003886		 £2.22
81 Part number 172611, GAS VALVE + 2 GASKETS GAS VALVE + 2 GASKETS
Ideal part no. 172611		 £220.76
81 Part number 174465, GAS VALVE + 2 GASKETS GAS VALVE + 2 GASKETS
Ideal part no. 174465		 £267.48
81 Part number 173503, GAS VALVE COILS (0967005) GAS VALVE COILS (0967005)
Ideal part no. 173503		 £85.46
82   PIPE-GAS VALVE TO MANIFOLD (BI1213 100)
Ideal part no. 174029		 £11.52
82   GAS PIPE TO THE MANIFOLD (BI1243 101)
Ideal part no. 174467		 £13.39
83 Part number 003847, NO 8X10 PP SCW S/TAP ZP B DES SPEC 0250 NO 8X10 PP SCW S/TAP ZP B DES SPEC 0250
Ideal part no. 003847		 £2.32
84   GAS MFLD + INJ LPG - 28KW (BI1213 102)
Ideal part no. 174031		 £55.23
84   GAS MAN.& INJ NG 28KW-POL.(BI1183 105)
Ideal part no. 172539		 £67.35
85   C.H. CONNECTION PIPE (BI1124 100)
Ideal part no. 174032		 £8.36
86 Part number 172542, TAP 3/4IN C.H. (BI1084 105) TAP 3/4IN C.H. (BI1084 105)
Ideal part no. 172542		 £33.20
87 Part number 172543, TAP 1/2IN D.H.W. (BI1084 101) TAP 1/2IN D.H.W. (BI1084 101)
Ideal part no. 172543		 £27.15
88 Part number 172544, TAP 3/4IN GAS (BI1084 100) TAP 3/4IN GAS (BI1084 100)
Ideal part no. 172544		 £22.67
89 Part number 172708, FILLING LOOP KIT(COMPLETE) (BI1084 112) FILLING LOOP KIT(COMPLETE) (BI1084 112)
Ideal part no. 172708		 £40.06
90 Part number 075513, 1/2 IN NUT C80FF BI1004 101 1/2 IN NUT C80FF BI1004 101
Ideal part no. 075513		 £2.68
91   PIPE 15MM DIA (BENT) D.H.W. (BI1124 102)
Ideal part no. 174033		 £6.78
92   PIPE 22 MM DIA GAS (BI1014 112)
Ideal part no. 174034		 £6.74
93 Part number 174035, PIPE 15mm DIA (STRT) D.H.W. (BI1124 103) PIPE 15MM DIA (STRT) D.H.W. (BI1124 103)
Ideal part no. 174035		 £3.45
94 Part number 172548, IGNITION PCB (BI1305 101) IGNITION PCB (BI1305 101)
Ideal part no. 172548		 £172.00
95 Part number 172550, O RING GASKET 1.78X6.75(BI1475 119) O RING GASKET 1.78X6.75(BI1475 119)
Ideal part no. 172550		 £2.32
96 Part number 172551, PRESSURE GAUGE (BI1475 108) PRESSURE GAUGE (BI1475 108)
Ideal part no. 172551		 £46.44
97 Part number 173988, CONTROL PANEL DOOR MINI HE(BI1655 100) CONTROL PANEL DOOR MINI HE(BI1655 100)
Ideal part no. 173988		 £37.80
99 Part number 172707, INFILL PANEL (BI1505 103) INFILL PANEL (BI1505 103)
Ideal part no. 172707		 £7.13
100 Part number 172554, CONTROL KNOB (BI1475 102) CONTROL KNOB (BI1475 102)
Ideal part no. 172554		 £2.47
101 Part number 172555, KNOB SHAFT (BI1475 105) KNOB SHAFT (BI1475 105)
Ideal part no. 172555
102   CONTROL PANEL PLUG (BI1475 110)
Ideal part no. 172556		 £2.09
103   CONTROL PANEL BOX-MINI HE (BI1655 101)
Ideal part no. 173990		 £38.43
103   CONTROL PANEL BOX (BI1655 105)
Ideal part no. 174468		 £40.16
104   CABLE HOLDER (KI1066 208)
Ideal part no. 172559		 £2.02
105   TERMINAL BLOCK (BI1475 109)
Ideal part no. 172560		 £3.71
106   SCREW 3 5X16 ZP BS1706 C80FF BI1165 101
Ideal part no. 075518		 £2.02
107 Part number 174017, LOGIC PCB (BI1655 103) LOGIC PCB (BI1655 103)
Ideal part no. 174017		 £193.80
107 Part number 174469, ELECTRONIC CTRL - IGNITION PCB (BI2015 100) ELECTRONIC CTRL - IGNITION PCB (BI2015 100)
Ideal part no. 174469		 £282.71
108 Part number 172562, 1.6 AMP FUSE (BI1005 105) 1.6 AMP FUSE (BI1005 105)
Ideal part no. 172562
108 Part number 174470, FUSE 3.15AF (BI1295 108) FUSE 3.15AF (BI1295 108)
Ideal part no. 174470		 £2.47
109   SERVICE PANEL COVER (BI1475 111)
Ideal part no. 172563		 £3.39
110 Part number 172564, CONTROL PANEL COVER (BI1475 112) CONTROL PANEL COVER (BI1475 112)
Ideal part no. 172564		 £8.43
111   SCREW 3-5X9-5 S/TAP ST STL (BI1615 104)
Ideal part no. 174036		 £2.02
112 Part number 174037, FAN CABLE (BI1615 100) FAN CABLE (BI1615 100)
Ideal part no. 174037		 £47.21
112 Part number 174471, FAN CABLE (BI1765 116) FAN CABLE (BI1765 116)
Ideal part no. 174471		 £51.75
113   DETECTION TO TRAP WIRING (BI1615 101)
Ideal part no. 174007		 £4.76
114   TRAP TO EARTH WIRING(BI1615 102)
Ideal part no. 174008		 £2.11
115   FLAME DETN ELECTRODE CABLE(BI1615 103)
Ideal part no. 174009		 £4.21
115   FLAME DETN ELECT CABLE (BI1765 101)
Ideal part no. 174472		 £4.28
116 Part number 172566, IGNITION ELECTRODE LEAD (BI1485 101) IGNITION ELECTRODE LEAD (BI1485 101)
Ideal part no. 172566		 £3.82
116   IGTN ELECTRODE CABLE (BI1765 102)
Ideal part no. 174473		 £3.96
117 Part number 172568, PUMP-DIVERTER VALVE CABLE(BI1485 103) PUMP-DIVERTER VALVE CABLE(BI1485 103)
Ideal part no. 172568		 £10.44
117 Part number 174474, PUMP- DIVR- GASV CABLE (BI1765 103) PUMP- DIVR- GASV CABLE (BI1765 103)
Ideal part no. 174474		 £31.24
118 Part number 172570, TIME SWITCH CABLE (BI1485 111) TIME SWITCH CABLE (BI1485 111)
Ideal part no. 172570		 £9.82
119 Part number 172571, ELEC.CON.PCB-IGN.CON.CBL(BI1485 104) ELEC.CON.PCB-IGN.CON.CBL(BI1485 104)
Ideal part no. 172571		 £4.79
120 Part number 172572, DHW FLOW SW.& TEMP.PRB CABLE(BI1485 105) DHW FLOW SW.& TEMP.PRB CABLE(BI1485 105)
Ideal part no. 172572
121 Part number 172573, CH/F/S-TEMP.PRB&MOD TR CABLE(BI1485 106) CH/F/S-TEMP.PRB&MOD TR CABLE(BI1485 106)
Ideal part no. 172573		 £16.01
121   FL SW-TEMP PRB&MODTR CABLE (BI1765 105)
Ideal part no. 174475		 £41.57
122 Part number 172574, POWER SUPPLY & EXT.CTRL CABLE BI1485 107 POWER SUPPLY & EXT.CTRL CABLE BI1485 107
Ideal part no. 172574		 £11.17
122   POWER SUPPLY&EXT CTRL CABLE(BI1675 106)
Ideal part no. 174476		 £9.43
123   M5 X 10 P/P HD SCREW ZP DES SPEC 0250
Ideal part no. 003252		 £2.35
125   M5 HEX NUT ZP DES SPEC 0250
Ideal part no. 002586		 £2.22
126   EARTH WIRING (BI1485 108)
Ideal part no. 172575		 £2.11
126   EARTH WIRING (BI1765 108)
Ideal part no. 174477		 £2.02
127 Part number 172576, GAS VALVE CABLE (BI1485 109) GAS VALVE CABLE (BI1485 109)
Ideal part no. 172576		 £6.56
128 Part number 075689, TURRET SEALING GASKET C80FF BI1016 104 TURRET SEALING GASKET C80FF BI1016 104
Ideal part no. 075689		 £5.73
129 Part number 174006, FLUE OUTLET GASKET MINI HE(BI1536 101) FLUE OUTLET GASKET MINI HE(BI1536 101)
Ideal part no. 174006
130 Part number 174050, WALL MOUNTING PLATE (BI1124 104) WALL MOUNTING PLATE (BI1124 104)
Ideal part no. 174050		 £11.35
131 Part number 173136, AIR PRESSURE SWITCH C6065FH1185 1.38mbar AIR PRESSURE SWITCH C6065FH1185 1.38MBAR
Ideal part no. 173136		 £106.45
132   VENTURI DEVICE TUBE (BI1256 101)
Ideal part no. 172594
133 Part number 174005, FAN OUTLET GASKET MINI HE(BI1536 102) FAN OUTLET GASKET MINI HE(BI1536 102)
Ideal part no. 174005
134 Part number 173984, FAN MINI HE C28(BI1406 101) FAN MINI HE C28(BI1406 101)
Ideal part no. 173984		 £151.22
135   FLUE HOOD MINI HE C28 (BI1406 122)
Ideal part no. 174042		 £48.00
136   SIDE CASE PANEL MINI HE (BI1406 106)
Ideal part no. 173987		 £55.53
137   AIR DEFLECTOR - RIGHT (BI1406 114)
Ideal part no. 174043		 £32.11
138 Part number 172583, COMBUSTION CH.SIDE PANEL (BI1326 100) COMBUSTION CH.SIDE PANEL (BI1326 100)
Ideal part no. 172583		 £46.92
139   COMB CHR FRT PNL MINI HEC28 (BI1406 119)
Ideal part no. 174045		 £75.52
141   FRONT CASE PANEL MINI HE(BI1426 100)
Ideal part no. 173989		 £68.89
142 Part number 170977, SIGHT GLASS INCL FRAME (BI1206 118) SIGHT GLASS INCL FRAME (BI1206 118)
Ideal part no. 170977		 £11.01
144   SEALED CHAMBER LID (BI1406 105)
Ideal part no. 174046		 £56.05
145 Part number 173986, SEALED CHBR GASKETS MINI HE(BI1406 500) SEALED CHBR GASKETS MINI HE(BI1406 500)
Ideal part no. 173986		 £16.66
146 Part number 172585, COMB.CH.REAR PNL C28/S28 (BI1326 108) COMB.CH.REAR PNL C28/S28 (BI1326 108)
Ideal part no. 172585		 £14.96
147   FAN HOLDER BRACKET (BI1406 120)
Ideal part no. 174047		 £82.08
148   FAN INLET GASKET MINI HE(BI1406 111)
Ideal part no. 174014		 £11.39
149 Part number 173251, VENTURI (BI1366 100) VENTURI (BI1366 100)
Ideal part no. 173251		 £16.52
150 Part number 075506, FLUE PRESS SWITCH TUBE C80FF BI1016 107 FLUE PRESS SWITCH TUBE C80FF BI1016 107
Ideal part no. 075506		 £22.41
151 Part number 075497, AIR SWITCH P/TEST POINT C80FF BI1036 101 AIR SWITCH P/TEST POINT C80FF BI1036 101
Ideal part no. 075497
152 Part number 173985, FLUE THERMOSTAT MINI HE(BI1262 104) FLUE THERMOSTAT MINI HE(BI1262 104)
Ideal part no. 173985		 £66.95
153   4 X 6 P/P HD SCREW DES SPEC 0250
Ideal part no. 003203		 £2.36
154   AIR RESTRICTOR 50DIA (BI1406 115)
Ideal part no. 174048		 £14.94
154   AIR RESTRICTOR 55DIA (BI1406 116)
Ideal part no. 174049		 £14.94
155   GASKET-AIR INTAKE TWIN KIT(BI1016 101)
Ideal part no. 172592		 £2.21
156   TWIN FLUE COVER PLATE (BI1366 114)
Ideal part no. 174300		 £3.33
158   FLUE TEMP PROBE NTC (BI1342 100)
Ideal part no. 174478		 £72.70
300   HARDWARE PACK (BI1124 500)
Ideal part no. 174052		 £119.39


Heating spares made simple this website is secured by Geotrust

 HSP K J Plumbing Factors

Copyright ©2020 >Heating Spare Parts - All Rights Reserved

Site Map | About Us | Parts Lists & Diagrams | Privacy Policy | Terms & Conditions

Facebook Twitter
