IDEAL
MEXICO HE 30 - (Short Parts List)
Appliance Code: 41-429-99

Appliance Diagram


Short Parts List diagram for Ideal Mexico HE 30Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   FRONT CASING PAINTED KIT
Ideal part no. 174074		 £91.66
2   CASE SEALING PANEL KIT
Ideal part no. 174075		 £63.99
3   TOP PANEL PAINTED KIT
Ideal part no. 174076		 £93.64
3   INFILL PANEL
Ideal part no. 174900		 £15.52
4   SIDE PANEL LH PAINTED KIT
Ideal part no. 174077		 £63.99
5   SIDE PANEL RH PAINTED KIT
Ideal part no. 174078		 £63.39
6   LOWER FRONT PANEL PAINTED KIT
Ideal part no. 174079		 £37.57
14   BURNER KIT MEX HE/ICOS HE 30-36
Ideal part no. 174080		 £212.50
15 Part number 173520, COMBUSTION CHBR INSULATION KIT HE SERIES COMBUSTION CHBR INSULATION KIT HE SERIES
Ideal part no. 173520		 £69.02
17 Part number 170908, INJECTOR & HOUSING KIT ICOS/ISAR/SYSTEM INJECTOR & HOUSING KIT ICOS/ISAR/SYSTEM
Ideal part no. 170908		 £13.56
19 Part number 172625, FAN KIT (FIME FAN PX130/0158) FAN KIT (FIME FAN PX130/0158)
Ideal part no. 172625		 £147.55
22 Part number 174081, GAS VALVE KIT MEX HE GAS VALVE KIT MEX HE
Ideal part no. 174081		 £175.08
25 Part number 174087, DRY FIRE THERMISTOR KIT DRY FIRE THERMISTOR KIT
Ideal part no. 174087		 £16.64
26 Part number 174088, THERMISTOR - BOILER CONTROL KIT THERMISTOR - BOILER CONTROL KIT
Ideal part no. 174088		 £10.75
27 Part number 174089, OVERHEAT THERMOSTAT KIT OVERHEAT THERMOSTAT KIT
Ideal part no. 174089		 £9.50
28 Part number 173528, IGNITION ELECTRODE KIT - PRE XH IGNITION ELECTRODE KIT - PRE XH
Ideal part no. 173528		 £23.90
28 Part number 175406, IGNITION ELECTRODE KIT IGNITION ELECTRODE KIT
Ideal part no. 175406		 £22.56
29 Part number 173529, FLAMESENSING ELECTRODE KIT FLAMESENSING ELECTRODE KIT
Ideal part no. 173529		 £22.48
34 Part number 174090, S TRAP KIT - MEXICO HE S TRAP KIT - MEXICO HE
Ideal part no. 174090		 £32.79
36   S TRAP HOSE KIT - MEXICO HE
Ideal part no. 174091		 £12.91
37 Part number 174152, USER CONTROLS KIT USER CONTROLS KIT
Ideal part no. 174152		 £102.84
38 Part number 174980, PCB/USER RETRO KIT-HEAT ONLY HE V9 PCB/USER RETRO KIT-HEAT ONLY HE V9
Ideal part no. 174980		 £359.21
39 Part number 170931, FUSE PCB KIT M SERIES FUSE PCB KIT M SERIES
Ideal part no. 170931		 £14.88
41 Part number 173537, MAINS SWITCH KIT MAINS SWITCH KIT
Ideal part no. 173537		 £17.21
42 Part number 174095, SPARK GENERATOR ASSEMBLY(MEX HE30-36) SPARK GENERATOR ASSEMBLY(MEX HE30-36)
Ideal part no. 174095		 £58.60
45 Part number 174096, GASKET KIT SERVICING(MEX HE30-36) GASKET KIT SERVICING(MEX HE30-36)
Ideal part no. 174096		 £61.36
46 Part number 174093, BURNER GASKET(MEX HE30-36) BURNER GASKET(MEX HE30-36)
Ideal part no. 174093		 £29.95
54 Part number 174086, BURNER EARTH PIN KIT MEX HE 36 BURNER EARTH PIN KIT MEX HE 36
Ideal part no. 174086		 £9.18
68 Part number 173510, IGNITION LEAD - HE SERIES IGNITION LEAD - HE SERIES
Ideal part no. 173510		 £16.44
69 Part number 174083, DETECTION LEAD MEX HE 30 - 36 DETECTION LEAD MEX HE 30 - 36
Ideal part no. 174083		 £23.02
