IDEAL
LOGIC SYSTEM S24IE - (Controls)
Appliance Code: 41-750-75

Appliance Diagram


Controls diagram for Ideal Logic System S24IEClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

135 Part number 179031, PRESSURE GAUGE KIT PRESSURE GAUGE KIT
Ideal part no. 179031
£17.21
302 Part number 179038, PCB KM821 I2 KIT PCB KM821 I2 KIT
Ideal part no. 179038
£131.22
310 Part number 179043, KNOB POTENTIOMETER WHITE KNOB POTENTIOMETER WHITE
Ideal part no. 179043
£4.23
316 Part number 179051, MAINS LEAD 3 core into boiler with connector MAINS LEAD 3 CORE INTO BOILER WITH CONNECTOR
Ideal part no. 179051
£9.39
317   HARNESS MAINS VOLTAGE
Ideal part no. 179056
£26.55
317   CONNECTOR RAST5 INDIRECT 3 WAY SPARE
Ideal part no. 179598
£4.66
318   HARNESS LOW VOLTAGE IE
Ideal part no. 179054
£33.85
319 Part number 179050, HARNESS ROOM STAT LINK HARNESS ROOM STAT LINK
Ideal part no. 179050
£5.77
324 Part number 179072, CONTROL BOX LID KIT CONTROL BOX LID KIT
Ideal part no. 179072
£31.76
325   CONTROL BOX FRONT
Ideal part no. 179041
£34.71
