IDEAL
LOGIC COMBI 35 - (Gas Management)
Appliance Code: 47-348-58

Appliance Diagram


Gas Management diagram for Ideal Logic Combi 35Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

204 Part number 175561, PIPE - GAS INLET (AAV & AAB ONLY) PIPE - GAS INLET (AAV & AAB ONLY)
Ideal part no. 175561		 £22.05
205 Part number 175562, GAS VALVE KIT (PRE ABS) GAS VALVE KIT (PRE ABS)
Ideal part no. 175562		 £203.49
205 Part number 176590, GAS VALVE KIT (LPG) (PRE ABK - BRASS WATERSET) GAS VALVE KIT (LPG) (PRE ABK - BRASS WATERSET)
Ideal part no. 176590		 £149.94
206 Part number 175563, PIPE - GAS INJECTOR (AAC & AAB ONLY) PIPE - GAS INJECTOR (AAC & AAB ONLY)
Ideal part no. 175563		 £15.75
208 Part number 175612, INJECTOR 35KW INJECTOR 35KW
Ideal part no. 175612		 £28.22
211 Part number 175614, INJECTOR ASSEMBLY KIT 35KW INJECTOR ASSEMBLY KIT 35KW
Ideal part no. 175614		 £30.47
211 Part number 176591, INJECTOR & HOUSING KIT (LPG) INJECTOR & HOUSING KIT (LPG)
Ideal part no. 176591		 £31.48
214 Part number 175567, VENTURI VENTURI
Ideal part no. 175567		 £25.49
215 Part number 175569, FAN KIT FAN KIT
Ideal part no. 175569		 £166.14
216 Part number 175570, GASKET - FAN GASKET - FAN
Ideal part no. 175570		 £18.36
217 Part number 175571, BURNER KIT BURNER KIT
Ideal part no. 175571		 £109.53
218 Part number 175572, GASKET - BURNER GASKET - BURNER
Ideal part no. 175572		 £20.59
221 Part number 175896, SUMP KIT XN, XO ONWARDS SUMP KIT XN, XO ONWARDS
Ideal part no. 175896		 £56.37
221 Part number 175954, CLEAN OUT COVER & GASKET-SUMP From XT prefix CLEAN OUT COVER & GASKET-SUMP FROM XT PREFIX
Ideal part no. 175954		 £13.41
223 Part number 175576, FLUE MANIFOLD FLUE MANIFOLD
Ideal part no. 175576		 £39.29
224 Part number 175578, FLUE MANIFOLD TOP (COMBI PRE ZY - COMBI E/ES PRE AAQ) FLUE MANIFOLD TOP (COMBI PRE ZY - COMBI E/ES PRE AAQ)
Ideal part no. 175578		 £41.38
224 Part number 176986, FLUE MANIFOLD TOP (COMBI ZY ONWARDS - COMBI ES AAQ ONWARDS) FLUE MANIFOLD TOP (COMBI ZY ONWARDS - COMBI ES AAQ ONWARDS)
Ideal part no. 176986		 £43.46
227 Part number 175581, CLAMP RETAINING - FLUE TURRET (COMBI PRE ZY - COMBI E/ES PRE AAQ) CLAMP RETAINING - FLUE TURRET (COMBI PRE ZY - COMBI E/ES PRE AAQ)
Ideal part no. 175581		 £8.37
227 Part number 175983, CLAMP RETAINING FLUE TURRET (COMBI ZY ONWARDS - COMBI ES AAQ ONWARDS) CLAMP RETAINING FLUE TURRET (COMBI ZY ONWARDS - COMBI ES AAQ ONWARDS)
Ideal part no. 175983		 £7.10
229 Part number 175583, SIPHON TRAP KIT SIPHON TRAP KIT
Ideal part no. 175583		 £23.10
230 Part number 175583, SIPHON TRAP KIT SIPHON TRAP KIT
Ideal part no. 175583		 £23.10
230 Part number 175584, OBSOLETE SIPHON TRAP CAP AND SEAL OBSOLETE SIPHON TRAP CAP AND SEAL
Ideal part no. 175584
231 Part number 175586, CONDENSATE OUTLET CONNECTION CONDENSATE OUTLET CONNECTION
Ideal part no. 175586		 £7.74
232 Part number 175620, TURRET/MANIFOLD GASKET TURRET/MANIFOLD GASKET
Ideal part no. 175620		 £12.77
233 Part number 175640, FLUE SENSING NIPPLE KIT FLUE SENSING NIPPLE KIT
Ideal part no. 175640		 £27.87
