ICOS M3080 - (Service Fault Finding 2)
Appliance Code: 41-391-49

Appliance Diagram

Service Fault Finding 2 diagram for Ideal Icos M3080 Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1	OBSOLETE FRONT CASING KIT ICOS/CLASSIC M Ideal part n^o. 170897
2	CASE SEALING PANEL KIT ICOS/ICOS SYSTEM Ideal part n^o. 170898	£124.70
3	SUMP COVER PLATE KIT ICOS/ISAR/ICOS SYST Ideal part n^o. 170899	£13.91
4	OBSOLETE BOTTOM COVER PANEL KIT ICOS Ideal part n^o. 170900
5	FLUE SENSING NIPPLE KIT M SERIES Ideal part n^o. 170901	£9.88
6	RETURN PIPE KIT ICOS Ideal part n^o. 170903	£43.80
7	FLOW PIPE KIT ICOS Ideal part n^o. 170902	£33.20
8	OBSOLETE FLUE MANIFOLD KIT ICOS/ISAR/ICOS SYSTEM Ideal part n^o. 170904
8	OBSOLETE FLUE MANIFOLD KIT PRE WM Ideal part n^o. 172484
9	FLUE MFD/PIPEWORK FIXING KIT ICOS/ISAR/SYS Ideal part n^o. 170958	£30.08
10	INTERPANEL KIT ICOS Ideal part n^o. 170959	£16.88
11	BURNER KIT M SERIES Ideal part n^o. 170905	£87.83
12	OBSOLETE COMB CHAMBER INSULATION KIT M SERDOMS Ideal part n^o. 170906
13	HEAT ENGINE KIT ICOS Ideal part n^o. 170907	£705.68
14	INJECTOR & HOUSING KIT ICOS/ISAR/SYSTEM Ideal part n^o. 170908	£13.56
15	NOW USE 170915 VENTURI KIT M SERIES Ideal part n^o. 170910
15	VENT/ORIFICE PLATE KIT ICOS/ISAR/ICOS S Ideal part n^o. 170915	£12.83
16	FAN KIT ICOS/ISAR/ICOS SYSTEM Ideal part n^o. 170909	£200.33
16	FAN KIT (FIME FAN PX130/0158) Ideal part n^o. 172625	£147.55
17	GAS PIPE KIT ICOS Ideal part n^o. 170911
18	GAS COCK KIT Ideal part n^o. 170912	£25.42
19	GAS VALVE KIT ISAR/ICOS/ICOS SYSTEM Ideal part n^o. 170913	£152.96
20	FAN FIXING KIT M SERIES Ideal part n^o. 170914	£11.86
21	VENT/ORIFICE PLATE KIT ICOS/ISAR/ICOS S Ideal part n^o. 170915	£12.83
22	DRY FIRE STAT KIT ICOS/ISAR/ICOS SYSTEM Ideal part n^o. 170916	£24.60
23	THERMISTOR (BOILER CONTROL) KIT M SERIES Ideal part n^o. 170917	£15.17
24	OVERHEAT THERMOSTAT KIT M SERIES Ideal part n^o. 170918	£15.22
25	IGNITION ELECTRODE KIT ICOS/CLASSIC M Ideal part n^o. 170919	£48.22
26	FLAME SENSING ELECTRODE KIT M SERIES Ideal part n^o. 170920	£35.28
27	MAINS INPUT HARNESS KIT M SERIES Ideal part n^o. 170921	£14.21
28	GAS VALVE EARTH LEAD KIT M SERIES Ideal part n^o. 170922
29	OBSOLETE FAN HARNESS KIT ICOS Ideal part n^o. 170923
31	OBSOLETE GAS VALVE/THERMISTOR HARNESS KIT ICOS Ideal part n^o. 170925
32	NOW USE 174244 S TRAP KIT ICOS/ISAR/ICOS SYSTEM Ideal part n^o. 170926
32	KIT - TRAP & SEAL Ideal part n^o. 174244	£28.45
33	OBSOLETE CONTROLS ASSEMBLY KIT ICOS Ideal part n^o. 172487
33	OBSOLETE CONTROLS ASSEMBLY KIT ICOS/CLASSIC M Ideal part n^o. 170927
34	CONTROLS HINGE KIT ICOS/CLASSIC M Ideal part n^o. 170928	£9.54
35	USER CONTROLS KIT ICOS/ICOS SYST/CLASS M Ideal part n^o. 170929	£109.17
35	POTENTIOMETER KNOB KIT M SERIES Ideal part n^o. 172491	£5.24
36	PCB PRIMARY CONTROLS KIT Ideal part n^o. 172490	£292.44
36	OBSOLETE PRIMARY CTRL/EMC RETR KIT ICOS/CLASSIC M Ideal part n^o. 157984
36	EMC FILTER KIT ICOS Ideal part n^o. 172603	£30.67
37	FUSE PCB KIT M SERIES Ideal part n^o. 170931	£14.88
38	USER CONTROLS HOUSING KIT ICOS/CLS M Ideal part n^o. 170932	£16.18
39	MAINS SWITCH KIT M SERIES Ideal part n^o. 170933	£24.38
41	CASE SENSING NIPPLE KIT (TUBE 110MM) Ideal part n^o. 170935
42	SIGHT GLASS KIT M SERIES Ideal part n^o. 170949	£18.28
43	OBSOLETE JACKING SCREW KIT ICOS/CLASSIC M Ideal part n^o. 170936
44	WALL MTG PLT ICOS/CLASSIC M/EXCEL HE Ideal part n^o. 170937	£9.72
45	GASKET KIT SERVICING M SERIES Ideal part n^o. 170938	£38.64
46	OBSOLETE INSTALL/SERVICING INSTRUCTIONS PK ICOS Ideal part n^o. 170939
47	GASKET KIT COMPLETE BOILER M SERIES Ideal part n^o. 170940	£92.30
48	BOILER FIXINGS KIT M SERIES Ideal part n^o. 170941	£35.11
49	OBSOLETE HARDWARE PACK KIT ICOS/ISAR/ICOS SYSTEM Ideal part n^o. 170961
50	DRAIN NIPPLE KIT ICOS Ideal part n^o. 170962	£11.07
52	SEAL KIT (CASE SEALING PANEL) M SERIES Ideal part n^o. 171014	£17.70
53	TURRET GASKET KIT M SERIES Ideal part n^o. 171022	£18.95
54	JUMPER LINK KIT ICOS/ICOS SYSTEM/CLASS M Ideal part n^o. 171021	£9.63
76	CONTROL BOX EARTH HARNESS KIT M SERIES Ideal part n^o. 171155	£4.55
78	INSULATION RETAINER-IONISATION KIT Ideal part n^o. 171845	£9.70
84	3/4 INCH STRAIGHT ADAPTER Ideal part n^o. 154925	£7.76
300	TURRET CLAMP Ideal part n^o. 138419	£3.41
300	OBSOLETE FLUE PIPE SPARES KIT Ideal part n^o. 172846
300	INSTALL/SERVICING INSTRUCTION PK ICOS SYSTEM Ideal part n^o. 171080	£9.74
