IDEAL
I MINI C24 - (Water Management)
Appliance Code: 47-349-30

Appliance Diagram


Water Management diagram for Ideal I Mini C24Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

102 Part number 179015, HYDROBLOCK GASKET KIT HYDROBLOCK GASKET KIT
Ideal part no. 179015		 £11.08
103 Part number 176454, HYDROBLOCK FIXINGS KIT (ABS & ABY ONWARDS) HYDROBLOCK FIXINGS KIT (ABS & ABY ONWARDS)
Ideal part no. 176454		 £18.83
105 Part number 175528, CH FLOW PACK CH FLOW PACK
Ideal part no. 175528		 £40.95
106   PIPEWORK CLIP KIT
Ideal part no. 176045		 £14.75
106   CLIP MANIFOLD
Ideal part no. 177802		 £3.72
108 Part number 177925, PUMP HEAD KIT ErP 98927074 ( ACQ ONWARDS - 2015 ERP) PUMP HEAD KIT ERP 98927074 ( ACQ ONWARDS - 2015 ERP)
Ideal part no. 177925		 £285.72
108 Part number 179263, PUMP HOUSING IB (99190650) PUMP HOUSING IB (99190650)
Ideal part no. 179263		 £84.69
110 Part number 176457, AUTO AIR VENT - GRUNDFOS 59200320 (ABY ONWARDS) AUTO AIR VENT - GRUNDFOS 59200320 (ABY ONWARDS)
Ideal part no. 176457		 £44.94
111 Part number 179019, 24VOLT DIVERTER MOTOR PL25LGFB8 99114481 24VOLT DIVERTER MOTOR PL25LGFB8 99114481
Ideal part no. 179019		 £69.03
112 Part number 179020, DIVERTER VALVE PADDLE &BODY KIT 99183191 DIVERTER VALVE PADDLE &BODY KIT 99183191
Ideal part no. 179020		 £78.78
113 Part number 176610, PRV KIT (ABS & ABY ONWARDS) PRV KIT (ABS & ABY ONWARDS)
Ideal part no. 176610		 £41.91
114 Part number 177536, PIPE PRV OUTLET (ABS & ABY ONWARDS) PIPE PRV OUTLET (ABS & ABY ONWARDS)
Ideal part no. 177536		 £19.30
115 Part number 177537, PIPE FLOW (ABS & ABY ONWARDS) PIPE FLOW (ABS & ABY ONWARDS)
Ideal part no. 177537		 £33.72
116   PIPE RETURN ( ABS & ABY ONWARDS)
Ideal part no. 177538		 £34.50
117 Part number 177539, HOSE EXPANSION VESSEL KIT (ABS & ABY ONWARDS) HOSE EXPANSION VESSEL KIT (ABS & ABY ONWARDS)
Ideal part no. 177539		 £33.83
117 Part number 177707, CLIP EXPANSION VESSEL (ABS & ABY ONWARDS) CLIP EXPANSION VESSEL (ABS & ABY ONWARDS)
Ideal part no. 177707		 £4.44
118 Part number 177540, EXPANSION VESSEL KIT (ABS & ABY ONWARDS) EXPANSION VESSEL KIT (ABS & ABY ONWARDS)
Ideal part no. 177540		 £103.92
119 Part number 176603, RETURN GROUP KIT (ABS ONWARDS) RETURN GROUP KIT (ABS ONWARDS)
Ideal part no. 176603		 £70.59
120 Part number 179168, FLOW GROUP KIT INC PRESSURE GAUGE FLOW GROUP KIT INC PRESSURE GAUGE
Ideal part no. 179168		 £90.74
121 Part number 177529, PLATE HEAT EXCHANGER KIT 59200622 (ACE ONWARDS) PLATE HEAT EXCHANGER KIT 59200622 (ACE ONWARDS)
Ideal part no. 177529		 £109.32
124 Part number 176470, FLOW REGULATOR HE24 - GRUNDFOS 59200313 FLOW REGULATOR HE24 - GRUNDFOS 59200313
Ideal part no. 176470		 £30.49
127 Part number 176473, FLOW SENSOR/TURBINE KIT- 59200311 FLOW SENSOR/TURBINE KIT- 59200311
Ideal part no. 176473		 £42.85
131 Part number 176480, WATER PRESSURE SWITCH-GRUNDFOS 59200312 (ABU ONWARDS) WATER PRESSURE SWITCH-GRUNDFOS 59200312 (ABU ONWARDS)
Ideal part no. 176480		 £41.27
132   HYDROBLOCK COMPLETE KIT 24KW
Ideal part no. 179022		 £330.44
135 Part number 179031, PRESSURE GAUGE KIT PRESSURE GAUGE KIT
Ideal part no. 179031		 £17.21
138 Part number 175929, WASHERS KIT-PIPE-HYDROBLOCK EPDM QTY 10 WASHERS KIT-PIPE-HYDROBLOCK EPDM QTY 10
Ideal part no. 175929		 £21.24
141 Part number 176553, PUMP DRAIN KIT GRUNDFOS 59200316 PUMP DRAIN KIT GRUNDFOS 59200316
Ideal part no. 176553		 £5.04
