IDEAL
EXCEL CF 50 - (Boiler Assembly 1)
Appliance Code: 41-415-50

Appliance Diagram


Boiler Assembly 1 diagram for Ideal Excel CF 50Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0 Part number 002921, OBSOLETE O RING 31.34 I/D X 3.53 DES 0038 EP70 OBSOLETE O RING 31.34 I/D X 3.53 DES 0038 EP70
Ideal part no. 002921
0   OBSOLETE C/O COVER ASS:EXL CF50/60 (A)
Ideal part no. 131321
1   OBSOLETE HT EXCHANGER XL CF 50/60.
Ideal part no. 078722
2   OBSOLETE CENTRE FLUEWAY BAFF ASS XLCF30/60
Ideal part no. 131346
3   OBSOLETE HT EXCH INSUL ASSY XL RS50/60
Ideal part no. 078701
5   OBSOLETE COMB CHBR ASS EXCEL CF50/60
Ideal part no. 078728
6   OBSOLETE COMB CHBR INSUL XL 50/60CF
Ideal part no. 078730
7   OBSOLETE SIGHT GLASS ASSY - BNR BOX
Ideal part no. 079333
8   OBSOLETE BNR MANIFOLD-VLV TO BNR W/FTGS
Ideal part no. 078713
10   OBSOLETE PILOT PIPE ASSY XL
Ideal part no. 078731
11   OBSOLETE MAIN BNR 118.500.024 XL CF50
Ideal part no. 013486
12 Part number 003965, OBSOLETE INJECTOR BNR BRAY CAT 16 SIZE 1600 OBSOLETE INJECTOR BNR BRAY CAT 16 SIZE 1600
Ideal part no. 003965
14 Part number 078716, PILOT BURNER - HONEYWELL PILOT BURNER - HONEYWELL
Ideal part no. 078716		 £21.73
15 Part number 003825, INJECTOR PILOT HONEYWELL 45900421-029 INJECTOR PILOT HONEYWELL 45900421-029
Ideal part no. 003825		 £5.68
17 Part number 078560, H/WELL VALVE 1049 C/W O RINGS H/WELL VALVE 1049 C/W O RINGS
Ideal part no. 078560
18   OBSOLETE GASCOCK ASSY 004913/924/919
Ideal part no. 077012
19 Part number 003939, SPARK GENERATOR 60080/002 SPARK GENERATOR 60080/002
Ideal part no. 003939
20   OBSOLETE IGN ELECTRODE VERNITRON NO 609
Ideal part no. 004364
21 Part number 002700, NOW USE Q309A2747 THERMOCOUPLE 750MM NOW USE Q309A2747 THERMOCOUPLE 750MM
Ideal part no. 002700
21 Part number Q309A2747, Q309A2747 - thermocouple Q309A2747 - THERMOCOUPLE
Baxi part no. Q309A2747		 £9.18
23   OBSOLETE CTRL BOX:EXCEL CF
Ideal part no. 131406
24   OBSOLETE PCB 8A BOARD (404202)
Ideal part no. 060556
25   OBSOLETE DOUBLE POLE ROCKER SWITCH C1470
Ideal part no. 004352
26   OBSOLETE WIRE ENDED NEON ASS ELAN/EXCEL
Ideal part no. 058566
27   OBSOLETE PLASTIC CAN SUPPRESSOR STC NO
Ideal part no. 004033
28   OBSOLETE HIGH THERMOSTAT 2455R-821-5
Ideal part no. 013554
29 Part number 013472, OBSOLETE LOW SETTING STAT ELM 2455R-821 OBSOLETE LOW SETTING STAT ELM 2455R-821
Ideal part no. 013472
30   OBSOLETE PUMP O/RUN STAT T20600D 042 75
Ideal part no. 013556
31   OBSOLETE T/STAT WIRING HRNS XL CF30/60
Ideal part no. 131366
32   OBSOLETE BLR CASING EXCEL CF50/60
Ideal part no. 131324
33   OBSOLETE FACIA PANEL-BRWN:EXC RS50/60
Ideal part no. 130084
34   OBSOLETE CTRL CSG BTM PNL XL RS/CF50/60
Ideal part no. 130631
35   OBSOLETE CONT CSG DOOR W/SLEEVE XL
Ideal part no. 079666
36   OBSOLETE WALL MNTG PLT W/FTG XLCF50
Ideal part no. 078737
37   OBSOLETE PROGRAMMER KIT:EXCEL MK1
Ideal part no. 130779
38   OBSOLETE SET SIDE TRIMS XL RS/CF
Ideal part no. 079260
