IDEAL
CONCORD WCF 440 - (Burner Control Ass 1)
Appliance Code: 41-407-50

Appliance Diagram


Burner Control Ass 1 diagram for Ideal Concord WCF 440Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0   OBSOLETE M8 TDOM RODS W2000 & FAN
Ideal part no. 049578

0   OBSOLETE T/STAT L7-P4001 RANCO LO7
Ideal part no. 004706

0   OBSOLETE 50GRM HERMITITE
Ideal part no. 003717

0   OBSOLETE MOTOR MK2 REF.81443803.
Ideal part no. 065389

0   OBSOLETE MAIN IMPELLER REF.7300705.
Ideal part no. 065391

0   OBSOLETE COOLING IMPELLER REF.7885408.
Ideal part no. 065390

0 Part number 002921, OBSOLETE O RING 31.34 I/D X 3.53 DES 0038 EP70 OBSOLETE O RING 31.34 I/D X 3.53 DES 0038 EP70
Ideal part no. 002921

0   OBSOLETE HINGE CLIP KITS WRS/CF MK 4.
Ideal part no. 058768

0   OBSOLETE MICRO SWITCH REF.9010312.
Ideal part no. 065394

0   OBSOLETE TERMINAL GRILLE
Ideal part no. 057388

0   H/WARE PK WCF440/450/460
Ideal part no. 012944

0   OBSOLETE CONVERSION KIT CON CF 445P
Ideal part no. 131391

0   OBSOLETE H/WARE PK:WCF 240/255 A & B
Ideal part no. 012536

0   M8 HEX NUT ZP DES SPEC 0250
Ideal part no. 003380
£2,36
0   M8 FORM A WASHER ZP DES SPEC 0250
Ideal part no. 003381
£2,73
1   OBSOLETE DUAL HT EXCH WRS/CF
Ideal part no. 076663

2   OBSOLETE FLUEWAY BAFFLE:WLX CF40/60
Ideal part no. 057014

3   OBSOLETE BLR INSUL W/STRAP WRS440
Ideal part no. 078251

4   OBSOLETE COLL HOOD ASSY WCF240
Ideal part no. 076350

5   OBSOLETE M6 TEE BOLT ASSY PAIR WRS440
Ideal part no. 077866

6   OBSOLETE C/O COVER ASS W2000 CF
Ideal part no. 052247

7   OBSOLETE DIST TUBE ASS WRS/WLX/W2000
Ideal part no. 049586

8   OBSOLETE SIGHT GLASS ASSY - BNR BOX
Ideal part no. 079333

9   OBSOLETE GAS MANIFOLD ASS:WLX 40/60
Ideal part no. 056123

10 Part number 077362, OBSOLETE PILOT PIPE WLX RS/CF40/50 OBSOLETE PILOT PIPE WLX RS/CF40/50
Ideal part no. 077362

11   OBSOLETE MAIN BURNER MK9 AB16638
Ideal part no. 053546

14 Part number 003825, INJECTOR PILOT HONEYWELL 45900421-029 INJECTOR PILOT HONEYWELL 45900421-029
Ideal part no. 003825
£5,68
15   OBSOLETE PILOT BURNER WITH INJECTOR
Ideal part no. 078253

16   OBSOLETE PILOT BRKT SHIELD WRS 240A/255
Ideal part no. 053536

17 Part number 003114, GAS VALVE 1/2INCOMPACT V4600A1023U GAS VALVE 1/2INCOMPACT V4600A1023U
Ideal part no. 003114
£225,72
19 Part number 003248, O-RING 25.0 I/D X 4.0 DES 0038 MN70 O-RING 25.0 I/D X 4.0 DES 0038 MN70
Ideal part no. 003248
£8,80
20   OBSOLETE SPARK GENERATOR 60038 RH OUTLE
Ideal part no. 053541

21   OBSOLETE ELECTRODE/LEAD 240A/255A
Ideal part no. 077364

22 Part number 000842, THERMOCOUPLE+600mm LEAD Q309A2739 THERMOCOUPLE+600MM LEAD Q309A2739
Ideal part no. 000842
£20,99
23   OBSOLETE BNR ASS:WLX CF40
Ideal part no. 057032

24   OBSOLETE CTRL BOX WRS MK 2A/4.
Ideal part no. 053540

25 Part number 003209, OBSOLETE T/STAT CL6 PO 105 W 48IN C OBSOLETE T/STAT CL6 PO 105 W 48IN C
Ideal part no. 003209

26   OBSOLETE CONTROL KNOB T/STAT RANCO 83151-31
Ideal part no. 002434

27   OBSOLETE T/STAT POCKET W/PIN WLX
Ideal part no. 079646

28   OBSOLETE SUPPRESSOR HRNS ASS MEX
Ideal part no. 058887

29   OBSOLETE PLUG-BULGIN PX0587/ASHLY C4000
Ideal part no. 003069

30   OBSOLETE BOILER CASING ASSY WCF MK 4.
Ideal part no. 056979

31   OBSOLETE CTRL POD ASS WRS/CF MK4.
Ideal part no. 056980

33   OBSOLETE RH SIDE PLT PTD:WRS/CF MK4
Ideal part no. 132320

34   OBSOLETE LH SIDE PLT PTD:WRS/CF MK4
Ideal part no. 132321

35   OBSOLETE WALL MNTG PLT ASSY WCF40/55
Ideal part no. 077858

36   OBSOLETE BK PANEL ASSY WLX/WCF
Ideal part no. 053649

37   OBSOLETE RC1/2 X R1/2 SPRING LD ELBOW GAS COCK
Ideal part no. 003860

38   OBSOLETE BALLOFIX VALVE 1.5INX28 NO 5306
Ideal part no. 003834

40   OBSOLETE PROGRAMMER ASS WLX
Ideal part no. 057080

41   OBSOLETE PROGRAMMER RWB 4 STELRAD
Ideal part no. 012698

42   OBSOLETE PROGRAMMER HOUSING ASS WRS/CF
Ideal part no. 132309
