IDEAL
COMBI ESP30 - (Gas Management ABK Onwards)
Appliance Code: 47-349-13

Appliance Diagram


Gas Management ABK Onwards diagram for Ideal Combi ESP30Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

201 Part number 177541, GAS LINE GASKETS KIT (ABS & ABY ONWARDS) GAS LINE GASKETS KIT (ABS & ABY ONWARDS)
Ideal part no. 177541		 £66.39
202   GAS LINE FIXINGS KIT (ABS & ABY ONWARDS)
Ideal part no. 177542		 £22.20
203 Part number 175526, GAS COCK VALVE PACK GAS COCK VALVE PACK
Ideal part no. 175526		 £20.23
203 Part number 176562, GAS COCK TEST NIPPLE SCREW GAS COCK TEST NIPPLE SCREW
Ideal part no. 176562		 £5.67
204 Part number 177543, PIPE GAS INLET (ABS & ABY ONWARDS) PIPE GAS INLET (ABS & ABY ONWARDS)
Ideal part no. 177543		 £29.63
205 Part number 177544, GAS VALVE KIT (ABS & ABY ONWARDS) GAS VALVE KIT (ABS & ABY ONWARDS)
Ideal part no. 177544		 £114.65
205 Part number 177582, GAS VALVE KIT (LPG) (ABK ONWARDS) GAS VALVE KIT (LPG) (ABK ONWARDS)
Ideal part no. 177582		 £135.14
205 Part number 177706, CLIP GAS VALVE (ABS & ABY ONWARDS) CLIP GAS VALVE (ABS & ABY ONWARDS)
Ideal part no. 177706		 £4.68
206 Part number 177545, PIPE GAS INJECTOR (ABS & ABY ONWARDS) PIPE GAS INJECTOR (ABS & ABY ONWARDS)
Ideal part no. 177545		 £18.42
208 Part number 175611, NOW USE 181959 INJECTOR 30KW NOW USE 181959 INJECTOR 30KW
Ideal part no. 175611
208   INJECTOR 30KW
Ideal part no. 181959		 £10.92
211 Part number 177547, INJECTOR ASSEMBLY KIT 30KW (NG) (ABS ONWARDS) INJECTOR ASSEMBLY KIT 30KW (NG) (ABS ONWARDS)
Ideal part no. 177547		 £31.07
211 Part number 177549, INJECTOR & HOUSING KIT (LPG) INJECTOR & HOUSING KIT (LPG)
Ideal part no. 177549		 £30.58
214 Part number 175567, VENTURI VENTURI
Ideal part no. 175567		 £25.49
215 Part number 175569, FAN KIT FAN KIT
Ideal part no. 175569		 £166.14
216 Part number 175570, GASKET - FAN GASKET - FAN
Ideal part no. 175570		 £18.36
217 Part number 175571, BURNER KIT BURNER KIT
Ideal part no. 175571		 £109.53
218 Part number 175572, GASKET - BURNER GASKET - BURNER
Ideal part no. 175572		 £20.59
221 Part number 175574, SEAL - SUMP CLEANOUT COVER SEAL - SUMP CLEANOUT COVER
Ideal part no. 175574		 £7.09
221   OBSOLETE SUMP CLEAN OUT COVER & GASKET (UP TO XO)
Ideal part no. 175953
221 Part number 175954, CLEAN OUT COVER & GASKET-SUMP From XT prefix CLEAN OUT COVER & GASKET-SUMP FROM XT PREFIX
Ideal part no. 175954		 £13.41
222 Part number 175896, SUMP KIT XN, XO ONWARDS SUMP KIT XN, XO ONWARDS
Ideal part no. 175896		 £56.37
223 Part number 175575, MANIFOLD-SUMP SEAL MANIFOLD-SUMP SEAL
Ideal part no. 175575		 £7.58
223 Part number 175576, FLUE MANIFOLD FLUE MANIFOLD
Ideal part no. 175576		 £39.29
223 Part number 175579, FLUE MANIFOLD TOP-LOWER SEAL FLUE MANIFOLD TOP-LOWER SEAL
Ideal part no. 175579		 £7.58
224 Part number 175578, FLUE MANIFOLD TOP (COMBI PRE ZY - COMBI E/ES PRE AAQ) FLUE MANIFOLD TOP (COMBI PRE ZY - COMBI E/ES PRE AAQ)
Ideal part no. 175578		 £41.38
224 Part number 176986, FLUE MANIFOLD TOP (COMBI ZY ONWARDS - COMBI ES AAQ ONWARDS) FLUE MANIFOLD TOP (COMBI ZY ONWARDS - COMBI ES AAQ ONWARDS)
Ideal part no. 176986		 £43.46
227 Part number 175581, CLAMP RETAINING - FLUE TURRET (COMBI PRE ZY - COMBI E/ES PRE AAQ) CLAMP RETAINING - FLUE TURRET (COMBI PRE ZY - COMBI E/ES PRE AAQ)
Ideal part no. 175581		 £8.37
227 Part number 175983, CLAMP RETAINING FLUE TURRET (COMBI ZY ONWARDS - COMBI ES AAQ ONWARDS) CLAMP RETAINING FLUE TURRET (COMBI ZY ONWARDS - COMBI ES AAQ ONWARDS)
Ideal part no. 175983		 £7.10
228 Part number 175582, HOSE - CONDENSATE INTERNAL HOSE - CONDENSATE INTERNAL
Ideal part no. 175582		 £9.51
229 Part number 175583, SIPHON TRAP KIT SIPHON TRAP KIT
Ideal part no. 175583		 £23.10
231 Part number 175586, CONDENSATE OUTLET CONNECTION CONDENSATE OUTLET CONNECTION
Ideal part no. 175586		 £7.74
232 Part number 175620, TURRET/MANIFOLD GASKET TURRET/MANIFOLD GASKET
Ideal part no. 175620		 £12.77
233 Part number 175640, FLUE SENSING NIPPLE KIT FLUE SENSING NIPPLE KIT
Ideal part no. 175640		 £27.87
306 Part number 175591, ELECTRODE - IGNITION ELECTRODE - IGNITION
Ideal part no. 175591		 £23.26
306 Part number 178950, GASKET IGNITION ELECTRODE GASKET IGNITION ELECTRODE
Ideal part no. 178950		 £3.59
307 Part number 175592, ELECTRODE - DETECTION ELECTRODE - DETECTION
Ideal part no. 175592		 £16.88
307   GASKET DETECTION ELECTRODE
Ideal part no. 178949		 £3.59
308 Part number 175593, IGNITOR UNIT (PRE ADP) IGNITOR UNIT (PRE ADP)
Ideal part no. 175593		 £35.17
308 Part number 178205, IGNITOR UNIT CLIP ON (ADP ONWARDS) IGNITOR UNIT CLIP ON (ADP ONWARDS)
Ideal part no. 178205		 £33.25
309 Part number 175594, THERMISTOR - NO FLOW THERMISTOR - NO FLOW
Ideal part no. 175594		 £10.81
401 Part number 177566, HEAT ENGINE KIT (ABS & ABY ONWARDS) HEAT ENGINE KIT (ABS & ABY ONWARDS)
Ideal part no. 177566		 £416.91
506   BRACKET GAS VALVE KIT (ABS & ABY ONWARDS)
Ideal part no. 177569		 £19.95
