IDEAL
CF 500 BOILER - (Boiler Casing)
Appliance Code: CF 500

Appliance Diagram


Boiler Casing diagram for Ideal CF 500 BoilerClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0   OBSOLETE WATER LEVEL SET (95360150)
Ideal part no. 067953

0   OBSOLETE SAFETY VALVE (80058950)
Ideal part no. 067954

0   OBSOLETE MANOMETER & VALVE(80058933)
Ideal part no. 067955

1   OBSOLETE LH FRT SECTION 82058901
Ideal part no. 067692

2   OBSOLETE LH FRT SECTION 82058903
Ideal part no. 067693

3   OBSOLETE RH FT SECTION 82058902
Ideal part no. 067694

4   OBSOLETE CENTRE SECTION (81050001)
Ideal part no. 067935

5   NIPPLES VIC ES 80050200
Ideal part no. 065853
£111.05
6   OBSOLETE LH REAR SECTION (82058904)
Ideal part no. 067897

7   OBSOLETE RH END SECTION (82058905)
Ideal part no. 067898

8   OBSOLETE FLUEWAY BAFFLE 247M (80050051)
Ideal part no. 067412

9   OBSOLETE FLUEWAY BAFFLE 372M (80050052)
Ideal part no. 067413

10   OBSOLETE FLUEWAY BAFFLE 205.5 (80050053)
Ideal part no. 067414

11   OBSOLETE FLUEWAY BAFFLE CF500 (80050054)
Ideal part no. 067415

12   OBSOLETE LOWER SEAM COVER PLT(80050049)
Ideal part no. 067410

13   OBSOLETE UPPER SEAM COVER PLT(80050050)
Ideal part no. 067411

14   SQUARE FLANGE & GSKT(80048971)
Ideal part no. 067899

15   2IN TAPPED FLANGE&GSKT(80048972)
Ideal part no. 069451
£236.50
16   OBSOLETE S/DOOR +FRAME CF700 82078910
Ideal part no. 067518

17   OBSOLETE VIEW WINDOW F/DOOR(80170008)
Ideal part no. 067900

18   OBSOLETE LOW CLEAN DOOR (80060041)
Ideal part no. 067422

19   OBSOLETE BRACKET CF700/500 (80068944)
Ideal part no. 067437

20   OBSOLETE DOOR LATCH&SPEC SCREW(80068943)
Ideal part no. 067436

21   OBSOLETE SMALL CLEANING DOOR(80050018)
Ideal part no. 067409

22   OBSOLETE HINGE PIN (80068905)
Ideal part no. 067432

23   OBSOLETE OIL FIRING PLATE (82058926)
Ideal part no. 067901

24   OBSOLETE BURNER PLT INSUL (97550250)
Ideal part no. 067647

25   OBSOLETE UP REAR SECT COVER(81050008)
Ideal part no. 067902

26   OBSOLETE LOW REAR SECT COVER(81050009)
Ideal part no. 067903

27   OBSOLETE REAR CLOSURE PLT (81050010)
Ideal part no. 067904

28   OBSOLETE NORMAL SMOKE HOOD (81058904)
Ideal part no. 067905

29   OBSOLETE DOOR LATCH CF500 (80048919)
Ideal part no. 067408

30   OBSOLETE FLOW HEADER & GSKTS(82058968)
Ideal part no. 067906

31   OBSOLETE RET HEADER & GSKTS(82058948)
Ideal part no. 067907

32   OBSOLETE FLANGE & PIPE 76.1(97549170)
Ideal part no. 067908

32   OBSOLETE FLANGE & PIPE 88.9(97549171)
Ideal part no. 067909

32   OBSOLETE FLANGE & PIPE 114.3(97549172)
Ideal part no. 067910

32   OBSOLETE FLANGE&PIPE 76.1127(97549173)
Ideal part no. 067911

33   OBSOLETE ASSY TIE RODS 19 SEC(81058969)
Ideal part no. 067925

33   OBSOLETE ASSY TIE RODS 20 SEC(81058970)
Ideal part no. 067926

33   OBSOLETE ASSY TIE RODS 7 SEC(81058957)
Ideal part no. 067913

33   OBSOLETE ASSY TIE RODS 8 SEC(81058958)
Ideal part no. 067914

33   OBSOLETE ASSY TIE RODS 6 SEC(81058956)
Ideal part no. 067912

33   OBSOLETE ASSY TIE RODS 12 SEC(81058962)
Ideal part no. 067918

33   OBSOLETE ASSY TIE RODS 13 SEC(81058963)
Ideal part no. 067919

33   OBSOLETE ASSY TIE RODS 11 SEC(81058961)
Ideal part no. 067917

33   OBSOLETE ASSY TIE RODS 9 SEC(81058959)
Ideal part no. 067915

33   OBSOLETE ASSY TIE RODS 10 SEC(81058960)
Ideal part no. 067916

33   OBSOLETE ASSY TIE RODS 17 SEC(81058967)
Ideal part no. 067923

33   OBSOLETE ASSY TIE RODS 18 SEC(81058968)
Ideal part no. 067924

33   OBSOLETE ASSY TIE RODS 16 SEC(81058966)
Ideal part no. 067922

33   OBSOLETE ASSY TIE RODS 14 SEC(81058964)
Ideal part no. 067920

33   OBSOLETE ASSY TIE RODS 15 SEC(81058965)
Ideal part no. 067921

34   OBSOLETE TOP CVR PLT F&R (80058955)
Ideal part no. 067417

35   OBSOLETE CLEAN TRAP FRAME (80058956)
Ideal part no. 067418

36   OBSOLETE TOP CVR PLT LENGE (80058957)
Ideal part no. 067419

37   OBSOLETE LENGE CLEAN DOOR (80058960)
Ideal part no. 067420

38   OBSOLETE CLEAN TRAP CVR (80058961)
Ideal part no. 067421

39 Part number 065894, FLANGE GSKT VICE ES 95014135 FLANGE GSKT VICE ES 95014135
Ideal part no. 065894
£50.33
41   OBSOLETE LATCH HANDLE (97540026)
Ideal part no. 067641

42   OBSOLETE HANDLE PIN (97560210)
Ideal part no. 067927

45   OBSOLETE LOWER DOOR 80058922
Ideal part no. 067709

46   OBSOLETE DOOR PLT & 2 LATCHES(80058923)
Ideal part no. 067931

47   OBSOLETE LH C.O.DOOR COMP (80058924)
Ideal part no. 067932

48   OBSOLETE RH C.O.DOOR COMP (80058925)
Ideal part no. 067933

49   OBSOLETE ACH DOOR LATCH CF500(80068930)
Ideal part no. 067435

51   OBSOLETE ARCH BRICK SUPP BRKT(80050083)
Ideal part no. 067416

52   OBSOLETE LARGE BRICK CF500 (97350095)
Ideal part no. 067629

53   OBSOLETE SMALL BRICK CF500 (97350097)
Ideal part no. 067630

54   OBSOLETE BUTTERFLY (81050006)
Ideal part no. 067453

55   OBSOLETE DAWPER POTITIAN FLA (82050010)
Ideal part no. 067513

56   OBSOLETE DAMPER HANDLE (97560035)
Ideal part no. 067934

61   OBSOLETE ASH PIT DOOR COMP (80058915)
Ideal part no. 067937

62   OBSOLETE CLOSURE PLATE COMP(80058912)
Ideal part no. 067938

64   OBSOLETE GRATE BARS & LEVER(80058939)
Ideal part no. 067939

65   OBSOLETE CONN BAR W/3 HOLES(97515100)
Ideal part no. 067940

65   OBSOLETE CONN BAR W/2 HOLES(97515130)
Ideal part no. 067946

65   OBSOLETE CONN BAR W/7 HOLES(97515120)
Ideal part no. 067944

65   OBSOLETE CONN BAR W/8 HOLES(97515125)
Ideal part no. 067945

65   OBSOLETE CONN BAR W/6 HOLES(97515115)
Ideal part no. 067943

65   OBSOLETE CONN BAR W/4 HOLES(97515105)
Ideal part no. 067941

65   OBSOLETE CONN BAR W/5 HOLES(97515110)
Ideal part no. 067942

66   OBSOLETE BIG CNTRL BAR&SCREW(80058940)
Ideal part no. 067947

67   OBSOLETE SMAL CNTRL BAR&SCREW(80058941)
Ideal part no. 067948

68   OBSOLETE ROCK GRATE LEVER(80058942)
Ideal part no. 067949

69   OBSOLETE ROCK GRATE LEVER EXT(97515310)
Ideal part no. 067950

70   OBSOLETE FRT FIRE PLATE (80050043)
Ideal part no. 067951

71   OBSOLETE VERT FIRE GRILL&PIN(80058944)
Ideal part no. 067952

75   OBSOLETE REF BRICK 40X15X3(97350355)
Ideal part no. 067928

76   OBSOLETE REF BRICK 40X20X3(97350360)
Ideal part no. 067929

77   OBSOLETE REF BRICK 50X15X4(97350380)
Ideal part no. 067930

78   OBSOLETE INSUL LINING BRICK (97350385)
Ideal part no. 067633
