IDEAL
C40 IE COMBI GEN. 2 - (Water Management)
Appliance Code: 47-349-49

Appliance Diagram


Water Management diagram for Ideal C40 IE Combi Gen. 2Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

108 Part number 179063, PUMP HEAD KIT (VOGUE GEN 2) 59200814 PUMP HEAD KIT (VOGUE GEN 2) 59200814
Ideal part no. 179063
£319.64
108 Part number 179263, PUMP HOUSING IB (99190650) PUMP HOUSING IB (99190650)
Ideal part no. 179263
£84.69
110 Part number 176457, AUTO AIR VENT - GRUNDFOS 59200320 (ABY ONWARDS) AUTO AIR VENT - GRUNDFOS 59200320 (ABY ONWARDS)
Ideal part no. 176457
£44.94
111 Part number 179019, 24VOLT DIVERTER MOTOR PL25LGFB8 99114481 24VOLT DIVERTER MOTOR PL25LGFB8 99114481
Ideal part no. 179019
£69.03
112 Part number 179020, DIVERTER VALVE PADDLE &BODY KIT 99183191 DIVERTER VALVE PADDLE &BODY KIT 99183191
Ideal part no. 179020
£78.78
113 Part number 176610, PRV KIT (ABS & ABY ONWARDS) PRV KIT (ABS & ABY ONWARDS)
Ideal part no. 176610
£41.91
114 Part number 177536, PIPE PRV OUTLET (ABS & ABY ONWARDS) PIPE PRV OUTLET (ABS & ABY ONWARDS)
Ideal part no. 177536
£19.30
115   PIPE FLOW VOGUE C40 S32
Ideal part no. 179114
£18.17
116   PIPE RETURN VOGUE C26 32 40 S18 26 32
Ideal part no. 179119
£22.25
117 Part number 176463, PIPE - EXPANSION VESSEL PIPE - EXPANSION VESSEL
Ideal part no. 176463
£33.83
119   RETURN GROUP KIT COMBI (VOGUE GEN 2)
Ideal part no. 179123
£53.49
120 Part number 179168, FLOW GROUP KIT INC PRESSURE GAUGE FLOW GROUP KIT INC PRESSURE GAUGE
Ideal part no. 179168
£90.74
121   PLATE HEAT EXCHANGER KIT 40KW
Ideal part no. 179124
£127.99
123 Part number 176473, FLOW SENSOR/TURBINE KIT- 59200311 FLOW SENSOR/TURBINE KIT- 59200311
Ideal part no. 176473
£42.85
