IDEAL
C32 COMBI - (Casing)
Appliance Code: 47-348-98

Appliance Diagram


Casing diagram for Ideal C32 CombiClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

214 Part number 175583, SIPHON TRAP KIT SIPHON TRAP KIT
Ideal part no. 175583
£23.10
218   FLUE MANIFOLD
Ideal part no. 176918
£42.76
501 Part number 176968, FRONT PANEL DOOR KIT COMBI FRONT PANEL DOOR KIT COMBI
Ideal part no. 176968
£223.33
504   BRACKET - IGNITION
Ideal part no. 176971
£12.66
508   GROMMET - CHASSIS DRAIN
Ideal part no. 176972
£12.49
509 Part number 175639, GROMMET - CHASSIS DRAIN GROMMET - CHASSIS DRAIN
Ideal part no. 175639
£10.81
510   BADGE KIT -COMBI
Ideal part no. 176973
£21.24
511 Part number 176969, HINGES & FIXING KIT HINGES & FIXING KIT
Ideal part no. 176969
£16.42
513 Part number 175983, CLAMP RETAINING FLUE TURRET (COMBI ZY ONWARDS - COMBI ES AAQ ONWARDS) CLAMP RETAINING FLUE TURRET (COMBI ZY ONWARDS - COMBI ES AAQ ONWARDS)
Ideal part no. 175983
£7.10
