HEATLINE
SARGON 30S 2007-2010 - (04 Heat Exchanger)
Appliance Code: 41-157-14

Appliance Diagram


04 Heat Exchanger diagram for Heatline Sargon 30S 2007-2010Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

6   HEAT EXCHANGER
Glowworm part no. D003202070
£919.44
7   FLUE SENSOR, SCREW FIT
Glowworm part no. D003201949
£63.61
8   BRACKET - HEAT EXCHANGER
Glowworm part no. D003201946
£9.70
9   SCREW M 4 X 10 (PK10)
Glowworm part no. D003200201
£6.39
10   DRAIN HOSE
Glowworm part no. D003201955
£22.68
11   FAN
Glowworm part no. D003201367

12   GASKET - FAN (PK10)
Glowworm part no. D003200782
£12.74
13   AIR/GAS MIXER RING - RED
Glowworm part no. D003201366
£62.36
14   SCREW, M5X10 (PK5)
Glowworm part no. D003200701
£9.16
107   FLUE ADAPTER AND SEAL
Glowworm part no. D001060210
£13.08
109   LEAD - IONISATION ELECTRODE
Glowworm part no. D003201986
£27.25
110   LEAD - IGNITION ELECTRODE
Glowworm part no. D003201985
£47.01
