HAMWORTHY
P 100LL LOWLINE FULLY AUTOMATIC,
P 100LL LOWLINE PERMANENT PILOT - (Gas Train P95 - P120 NG)
Appliance Code: P 100LL

Appliance Diagram


Gas Train P95 - P120 NG diagram for Hamworthy P 100LL Lowline Fully AutomaticClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

Part number 330502041, 1/8BSPT GAS TEST POINT 1/8BSPT GAS TEST POINT
Hamworthy part no. 330502041
£19.47
  GAS BURNER MANIFOLD 5PORTSINGLE GAS
Hamworthy part no. 532704024
£92.23
  CAP SCREW M5 X 12
Hamworthy part no. 748010342
£12.45
  M5 X 35 HT CAP SCREW
Hamworthy part no. 748010425
£12.62
33A Part number 533903015, COMPACT GAS VALVE VR4605P2023U COMPACT GAS VALVE VR4605P2023U
Hamworthy part no. 533903015
£173.57
34A Part number 533903016, GAS VALVE 1/2" COMPACT AUTO VR4605E1001U GAS VALVE 1/2" COMPACT AUTO VR4605E1001U
Hamworthy part no. 533903016

35C   GAS VALVE LEAD AND PLUG - HONEYWELL P95-P120NG
Hamworthy part no. 563901091
36C   0 RING BS215 NITRILE NBR75
Hamworthy part no. 742122069
£12.51
37B   TOP GAS MANIFOLD TWIN GAS VALVE ASSY WIT
Hamworthy part no. 561909031
£77.29
38B   BOTTOM GAS MANIFOLD P95 120FA WSX
Hamworthy part no. 532704027
£63.50
40B   RP1"BSPT F/F BALL VALVE
Hamworthy part no. 339012158
£52.24
