GLOWWORM
ULTRACOM 38 CXI - (PCB)
Appliance Code: 47-019-03

Appliance Diagram


PCB diagram for Glowworm Ultracom 38 CXIClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

48 Part number 0020152564, Electrode (kit) ELECTRODE (KIT)
Glowworm part no. 0020152564		 £41.16
48 Part number 2000802462, NOW USE 0020152564 ignition rod NOW USE 0020152564 IGNITION ROD
Glowworm part no. 2000802462
49 Part number 801638, GASKET ELECTRODE GASKET ELECTRODE
Glowworm part no. 801638		 £6.39
50 Part number 801639, screw electrode SCREW ELECTRODE
Glowworm part no. 801639		 £6.61
70 Part number 0020038062, Casing CASING
Glowworm part no. 0020038062		 £25.46
71 Part number 0020038061, display DISPLAY
Glowworm part no. 0020038061		 £185.69
72   BACK PANEL
Glowworm part no. 0020038063		 £12.93
73 Part number 0020023825, PCB main PCB MAIN
Glowworm part no. 0020023825		 £192.24
74 Part number 0020025183, appliance interface harness APPLIANCE INTERFACE HARNESS
Glowworm part no. 0020025183		 £13.27
75 Part number 0020026405, NOW USE 0020079603 fuse NOW USE 0020079603 FUSE
Glowworm part no. 0020026405
75 Part number 0020079603, Fuse 2,0 A T2H (PK10) FUSE 2,0 A T2H (PK10)
Glowworm part no. 0020079603		 £14.09
76 Part number 801655, ZIG IGNITOR ZIG IGNITOR
Glowworm part no. 801655		 £37.25
77 Part number SK7959, Screw, M3x6mm SCREW, M3X6MM
Glowworm part no. SK7959		 £6.61
78 Part number 0020020781, NOW USE S5739800 temperature monitor NOW USE S5739800 TEMPERATURE MONITOR
Glowworm part no. 0020020781
78 Part number S5739800, Temperature sensor TEMPERATURE SENSOR
Glowworm part no. S5739800		 £23.87
79 Part number 0020038263, fitting FITTING
Glowworm part no. 0020038263		 £6.61
80 Part number 0020037300, housing HOUSING
Glowworm part no. 0020037300		 £60.68
81 Part number 0020038262, Box BOX
Glowworm part no. 0020038262		 £33.89
82 Part number 0020014190, NOW USE 0020079644 CH PRESSURE SENSOR NOW USE 0020079644 CH PRESSURE SENSOR
Glowworm part no. 0020014190
82 Part number 0020079644, Sensor SENSOR
Glowworm part no. 0020079644		 £26.42
83 Part number 0020037306, cable tree (harness) CABLE TREE (HARNESS)
Glowworm part no. 0020037306		 £12.35
84 Part number 0020037302, NOW USE 0020152565 ELECTRODE KIT NOW USE 0020152565 ELECTRODE KIT
Glowworm part no. 0020037302
84 Part number 0020152565, Electrode (kit) ELECTRODE (KIT)
Glowworm part no. 0020152565		 £44.14
85 Part number 0020037305, cable tree (harness) CABLE TREE (HARNESS)
Glowworm part no. 0020037305		 £27.37
90 Part number 0020014160, sensor NTC (DHW outlet pipe) SENSOR NTC (DHW OUTLET PIPE)
Glowworm part no. 0020014160		 £8.96
91 Part number 0020041285, harness HARNESS
Glowworm part no. 0020041285		 £42.89
131 Part number 0020014177, O-ring (PK10) O-RING (PK10)
Glowworm part no. 0020014177		 £6.61
