GLOWWORM
ULTRACOM 2 35 STORE 2011 2015 - (10 Hydraulic Pipe Work)
Appliance Code: 47-019-15

Appliance Diagram


10 Hydraulic Pipe Work diagram for Glowworm Ultracom 2 35 Store 2011 2015Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 0020125445, Pipe tank 42L PIPE TANK 42L
Glowworm part no. 0020125445		 £19.13
2 Part number 2000801956, O-ring (PK10) O-RING (PK10)
Glowworm part no. 2000801956		 £9.48
3 Part number 0020018450, Clip (PK10) CLIP (PK10)
Glowworm part no. 0020018450		 £33.09
3   CLIP DOMESTIC HOT WATER SENSOR (PK10)
Glowworm part no. 0020022948		 £5.66
4 Part number 0020125476, Gasket (x10) GASKET (X10)
Glowworm part no. 0020125476		 £11.12
5 Part number 0020018462, Clip (PK10) CLIP (PK10)
Glowworm part no. 0020018462		 £16.42
5   CLIP PACK 10
Glowworm part no. 0020040035		 £11.66
6 Part number 2000802473, O-ring heat Ex / Pipe (PK10) O-RING HEAT EX / PIPE (PK10)
Glowworm part no. 2000802473		 £6.61
7 Part number 2000801958, NOW USE S5485200 sealing washer (Pack of 100) NOW USE S5485200 SEALING WASHER (PACK OF 100)
Glowworm part no. 2000801958
7 Part number S5485200, Sealing ring (PK100) SEALING RING (PK100)
Glowworm part no. S5485200		 £13.40
8 Part number 0020125455, Pipe inter-tank 42L PIPE INTER-TANK 42L
Glowworm part no. 0020125455		 £23.35
9 Part number 2000802474, NOW USE S1037900 CLIP HEAT EX / PIPE (X10) NOW USE S1037900 CLIP HEAT EX / PIPE (X10)
Glowworm part no. 2000802474
9 Part number S1037900, Clip, (PK10) CLIP, (PK10)
Glowworm part no. S1037900		 £7.05
10 Part number 0020125443, Pipe telescopic / heat exchangeur PIPE TELESCOPIC / HEAT EXCHANGEUR
Glowworm part no. 0020125443
11 Part number 0020125441, Pipe heat exchanger / filter PIPE HEAT EXCHANGER / FILTER
Glowworm part no. 0020125441		 £9.44
12 Part number 0020125440, NOW USE 0020105940 FILTER NOW USE 0020105940 FILTER
Glowworm part no. 0020125440
12   FILTER
Glowworm part no. 0020105940		 £47.16
13 Part number 2000801954, NOW USE S5466500 o-ring (20 pieces) NOW USE S5466500 O-RING (20 PIECES)
Glowworm part no. 2000801954
13 Part number S5466500, O-ring (PK20) O-RING (PK20)
Glowworm part no. S5466500		 £15.83
14   PIPE FILTER / 3 WAY VALVE
Glowworm part no. 0020125442		 £18.45
15 Part number 2000801951, NOW USE S5466200clip 10mm NOW USE S5466200CLIP 10MM
Glowworm part no. 2000801951
15 Part number S5466200, Clip 10mm (PK10) CLIP 10MM (PK10)
Glowworm part no. S5466200		 £9.67
16   NOW USE S1075600 BYPASS PIPE
Glowworm part no. 0020018580
16 Part number S1075600, Pipe bypass PIPE BYPASS
Glowworm part no. S1075600		 £9.47
18 Part number 0020097203, O-ring (PK10) O-RING (PK10)
Glowworm part no. 0020097203		 £6.61
19   HOSE
Glowworm part no. 0020125450		 £9.89
20 Part number 2000801947, NOW USE S5465700 clip pressure relief valve NOW USE S5465700 CLIP PRESSURE RELIEF VALVE
Glowworm part no. 2000801947
20 Part number S5465700, Clip 18mm (PK10) CLIP 18MM (PK10)
Glowworm part no. S5465700		 £10.81
21 Part number 2000801953, NOW USE S5466400 o-ring 13mm cv-filter (20 pieces) NOW USE S5466400 O-RING 13MM CV-FILTER (20 PIECES)
Glowworm part no. 2000801953
21 Part number S5466400, O-Ring (PK20) O-RING (PK20)
Glowworm part no. S5466400		 £17.50
22   CLIP FOR BYPASS
Glowworm part no. 2000801961		 £8.80
22 Part number S5490900, OBSOLETE Clip 13.5mm (PK15) OBSOLETE CLIP 13.5MM (PK15)
Glowworm part no. S5490900		 £13.34
23 Part number 0020125453, Hose tank / 3 way valve HOSE TANK / 3 WAY VALVE
Glowworm part no. 0020125453		 £41.57
24 Part number 0020125454, Hose tank / 3 way valve HOSE TANK / 3 WAY VALVE
Glowworm part no. 0020125454		 £42.42
25 Part number 0020125452, Hose pump / tank 42L HOSE PUMP / TANK 42L
Glowworm part no. 0020125452		 £46.37
27 Part number 2000801950, O-ring for pipe (PK20) O-RING FOR PIPE (PK20)
Glowworm part no. 2000801950		 £10.83
29   NOW USE 05459000 CLIP
Glowworm part no. 0020018605
29 Part number 05459000, CLIP PACK (PK15) CLIP PACK (PK15)
Glowworm part no. 05459000		 £17.05
30 Part number 0020097306, Sealing ring pack (PK10) SEALING RING PACK (PK10)
Glowworm part no. 0020097306		 £19.22
31 Part number 0020125444, PIPE PUMP PIPE PUMP
Glowworm part no. 0020125444		 £14.51
32 Part number 0020018829, Screw AF M4x12 (PK10) SCREW AF M4X12 (PK10)
Glowworm part no. 0020018829		 £6.61
33 Part number 0020125446, Pipe expansion vessel 12L PIPE EXPANSION VESSEL 12L
Glowworm part no. 0020125446		 £19.19
