GLOWWORM
ULTRACOM 2 30 SXI 2010 - 2015 - (09 Hydraulics)
Appliance Code: 41-019-14

Appliance Diagram


09 Hydraulics diagram for Glowworm Ultracom 2 30 SXI 2010 - 2015Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 0020097218, NOW USE 0010035668 HYDRAULIC BLOCK PUMP NOW USE 0010035668 HYDRAULIC BLOCK PUMP
Glowworm part no. 0020097218
1   PUMP - HIGH EFFICIENCY (REQUIRES CONVERSIOIN CABLE 0010032761)
Glowworm part no. 0010035668		 £261.56
2 Part number 0020014169, bypass BYPASS
Glowworm part no. 0020014169		 £31.19
3 Part number 0020097220, NOW USE 0010035666 Motor pump NOW USE 0010035666 MOTOR PUMP
Glowworm part no. 0020097220
3 Part number 0010035666, PUMP, HIGH-EFFICIENCY (REQUIRES CONVERSION CABLE 0010032761) PUMP, HIGH-EFFICIENCY (REQUIRES CONVERSION CABLE 0010032761)
Glowworm part no. 0010035666		 £226.03
4 Part number 0020014164, Wire retaining clip (PK10) WIRE RETAINING CLIP (PK10)
Glowworm part no. 0020014164		 £8.47
5 Part number 0020014195, O-ring (PK10) O-RING (PK10)
Glowworm part no. 0020014195		 £6.61
6 Part number 0020097228, Screw (PK10) SCREW (PK10)
Glowworm part no. 0020097228		 £6.61
7 Part number 0020097185, Screw (PK10) SCREW (PK10)
Glowworm part no. 0020097185		 £6.61
8 Part number 0020097231, Valve for 3WV, dummy VALVE FOR 3WV, DUMMY
Glowworm part no. 0020097231		 £6.61
9 Part number 0020097224, O-ring (PK10) O-RING (PK10)
Glowworm part no. 0020097224		 £6.61
10 Part number 0020097226, O-ring (PK10) O-RING (PK10)
Glowworm part no. 0020097226		 £6.61
11 Part number 0020014176, Clip (PK10) CLIP (PK10)
Glowworm part no. 0020014176		 £12.38
12 Part number 0020097210, PLUG PLUG
Glowworm part no. 0020097210		 £7.14
13 Part number 0020097234, O-ring (PK10) O-RING (PK10)
Glowworm part no. 0020097234		 £6.74
14 Part number 2000801948, O-ring, (PK20) O-RING, (PK20)
Glowworm part no. 2000801948		 £12.05
15 Part number 0020014166, Gasket, C-Type, (PK10) GASKET, C-TYPE, (PK10)
Glowworm part no. 0020014166		 £10.01
16 Part number 0020097197, Clip (PK10) CLIP (PK10)
Glowworm part no. 0020097197		 £7.14
17 Part number 0020097212, Plug, pressure sensor PLUG, PRESSURE SENSOR
Glowworm part no. 0020097212		 £6.61
18 Part number 0020097203, O-ring (PK10) O-RING (PK10)
Glowworm part no. 0020097203		 £6.61
19 Part number 0020097193, Screw M5x33 (PK10) SCREW M5X33 (PK10)
Glowworm part no. 0020097193		 £6.74
20 Part number 0020038229, nut NUT
Glowworm part no. 0020038229		 £6.61
21 Part number 0020014182, Gasket Type-C (PK10) GASKET TYPE-C (PK10)
Glowworm part no. 0020014182		 £10.61
21 Part number 2000801949, NOW USE 0020014182 gasket plate heat exchanger (20 pcs.) NOW USE 0020014182 GASKET PLATE HEAT EXCHANGER (20 PCS.)
Glowworm part no. 2000801949
22 Part number 0020018569, NOW USE S1024500 automatic air vent NOW USE S1024500 AUTOMATIC AIR VENT
Glowworm part no. 0020018569
22 Part number S1024500, Automatic de-aerator AUTOMATIC DE-AERATOR
Glowworm part no. S1024500		 £22.24
23 Part number 2000801956, O-ring (PK10) O-RING (PK10)
Glowworm part no. 2000801956		 £9.48
