GLOWWORM
ULTIMATE 24 H - (Hydraulics Sealed System Kit)
Appliance Code: 41-019-15

Appliance Diagram


Hydraulics Sealed System Kit diagram for Glowworm Ultimate 24 HClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

93 Part number 0020061275, Pressure Relief Valve PRESSURE RELIEF VALVE
Glowworm part no. 0020061275
£29.84
94 Part number 0020020753, O-ring O-RING
Glowworm part no. 0020020753
£6.61
95   PIPE
Glowworm part no. 0020061272
£15.91
97   AIR VENT
Glowworm part no. 0020061276
£31.46
98   CONNECTOR
Glowworm part no. 0020061271
£28.56
99   TUNDISH
Glowworm part no. 0020038186
£31.37
100   ADAPTER
Glowworm part no. 0020061274
£17.01
101   T-PIECE
Glowworm part no. 0020061269
£48.78
102 Part number 801675, CLIP 10MM DIA CLIP 10MM DIA
Glowworm part no. 801675
£6.61
104   FILLING LOOP
Glowworm part no. 0020061270
£108.14
105 Part number 2000801911, NOW USE S5720500 SYSTEM PRESSURE SENSOR NOW USE S5720500 SYSTEM PRESSURE SENSOR
Glowworm part no. 2000801911

105 Part number S5720500, Pressure Sensor PRESSURE SENSOR
Glowworm part no. S5720500
£27.02
107 Part number 0020014177, O-ring (PK10) O-RING (PK10)
Glowworm part no. 0020014177
£6.61
109 Part number 0020018576, flexible hose FLEXIBLE HOSE
Glowworm part no. 0020018576
£15.97
109   NOW USE 0020018576 EV PIPE
Glowworm part no. 0020061277

110 Part number 0020018451, Expansion vessel 8L EXPANSION VESSEL 8L
Glowworm part no. 0020018451
£166.74
111   CABLE TREE (HARNESS)
Glowworm part no. 0020061273
£22.30
