GLOWWORM
SPACE SAVER COMPLHEAT 30 1992 AVA - (Flue)
Appliance Code: 41-319-42

Appliance Diagram


Flue diagram for Glowworm Space Saver Complheat 30 1992 AVAClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   OBSOLETE INST INSTR-SSCOMP30>50 6/93
Glowworm part no. 220241
1   OBSOLETE INSTR USER SSCOMP 6/93
Glowworm part no. 220244
1   OBSOLETE OUTER CASE ASSY-SSCOMP30/40/50
Glowworm part no. 2000800356
2   OBSOLETE INSTRUCTION SLIDE ASSY
Glowworm part no. 446587
3   OBSOLETE NAME STRIP-PRINTED
Glowworm part no. 446570
4   OBSOLETE FRONT COVER-SPARE-KFB20-50
Glowworm part no. 2000800167
5   OBSOLETE CASE ADJ.RAIL (2XB) KFB50
Glowworm part no. 440076
6   SCREW - M5X10MM
Glowworm part no. SK9324
7 Part number 208308, NOW USE S208308 SCREW-M4X10mm+5DG MS PN NOW USE S208308 SCREW-M4X10MM+5DG MS PN
Glowworm part no. 208308
7 Part number S208308, Screw (M4x10mm) SCREW (M4X10MM)
Glowworm part no. S208308		 £6.61
8   OBSOLETE CASE TOP (1XBEND) SSCOMP50
Glowworm part no. 446524
9 Part number SK2330, Screw (No8 X 3/8) SCREW (NO8 X 3/8)
Glowworm part no. SK2330
10   BLANKING PLATE ASSY - PNTD
Glowworm part no. 440004
10   BLANKING PLATE
Glowworm part no. S440004
11   GASKET-1.7MM WEBGLASS 230 BL/PLT
Glowworm part no. 212165
11   GASKET -1.7MM BLANKING PLATE
Glowworm part no. S212165
12 Part number SK6219, Nut NUT
Glowworm part no. SK6219
13 Part number 208243, NOW USE S208243 SCREW-NO.10 X 3/4 REC NOW USE S208243 SCREW-NO.10 X 3/4 REC
Glowworm part no. 208243
13 Part number S208243, Screw ( no.10 X 3/4 ) SCREW ( NO.10 X 3/4 )
Glowworm part no. S208243
14 Part number 51062003, NOW USE S51062003 NUT-SPIRE CAPT NO.10 NOW USE S51062003 NUT-SPIRE CAPT NO.10
Glowworm part no. 51062003
14 Part number S51062003, Nut- spire capt no.10 NUT- SPIRE CAPT NO.10
Glowworm part no. S51062003		 £4.29
15   OBSOLETE WATER COCK-ANGLED 22MM DIA
Glowworm part no. 204915
16   NOW USE S432776 C.H. COCK BRACKET(4STTPF) S/FL
Glowworm part no. 432776
16   BRACKET-CENTRAL HEATING COCK
Glowworm part no. S432776		 £4.91
17 Part number SK8019, Screw ( M5X10mm ) SCREW ( M5X10MM )
Glowworm part no. SK8019		 £6.61
18   OBSOLETE H/EXCH &PLUGS ASSY SSCOMP30>50
Glowworm part no. 446556
19   OBSOLETE PLUG 3/4" BSP
Glowworm part no. 204009
20   OBSOLETE H/E BAFF ASSY (SW) STAMP-KFB30
Glowworm part no. 440115
21   OBSOLETE PHIAL POCKET&SPLIT PIN SSCOMP
Glowworm part no. 800333
22 Part number 208390, NOW USE S208390 SPLIT PIN-1.6 X 25mm NOW USE S208390 SPLIT PIN-1.6 X 25MM
Glowworm part no. 208390
22 Part number S208390, Split pin - 1.6 X 25mm SPLIT PIN - 1.6 X 25MM
Glowworm part no. S208390
23   NOW USE S208547 SCREW-M6X10MM-THREAD CUTTING
Glowworm part no. 208547
23   SCREW -M6X10MM-THREAD CUTTING
Glowworm part no. S208547
24   OBSOLETE COMBUSTION CHAMBER ASSY
Glowworm part no. 446560
25   OBSOLETE INSUL-C/C REAR
Glowworm part no. 210156
26   OBSOLETE INSUL-C/C SIDE
Glowworm part no. 210157
28 Part number SFF0652, Screw, no6 x 3/8 SCREW, NO6 X 3/8
Glowworm part no. SFF0652
31   OBSOLETE SCREW-M5X20MM MS HX REC
Glowworm part no. 208493
32   OBSOLETE FRONT/REAR COVER (SW) KFB50
Glowworm part no. 440025
33   OBSOLETE SPACING BRACKET (NPF) KFB50
Glowworm part no. 440078
34   OBSOLETE INSULATION-H/E REAR
Glowworm part no. 210162
35   SCREW -M4X6MM
Glowworm part no. SK6212
36   OBSOLETE SCREW-M5X6MM MS PN REC
Glowworm part no. SK7318
37   SCREW -M5X10MM
Glowworm part no. SK6214		 £6.61
39   SEAL-10DIAX255MM C/C ROPE
Glowworm part no. 212171
39   SEAL-10DIAX255MM COMBUSTION CHAMBER ROPE
Glowworm part no. S212171
40   OBSOLETE INSULATION-CC FRONT
Glowworm part no. 210169
44   NOW USE S440077 RR FLUE CLEAN PLT(NPF) MICRON
Glowworm part no. 440077
44   REAR FLUE CLEANING PLATE
Glowworm part no. S440077
45   OBSOLETE CASE BODY SUB ASSY-SSCMP30>50
Glowworm part no. 800357
46   OBSOLETE SPACER-MILD STEEL
Glowworm part no. 204884
47   OBSOLETE FLW PIPE&SLG WSHRS-SSCOMP30>50
Glowworm part no. 2000800358
48   OBSOLETE RTN PIPE&SLG WSHRS-SSCOMP30>50
Glowworm part no. 2000800359
49 Part number 230037, NOW USE S230037 WASHER-SEALING NOW USE S230037 WASHER-SEALING
Glowworm part no. 230037
49 Part number S230037, Washer sealing WASHER SEALING
Glowworm part no. S230037
50 Part number 212128, NOW USE S212128 WASHER-SEALING 15ODX7IDX2mm NOW USE S212128 WASHER-SEALING 15ODX7IDX2MM
Glowworm part no. 212128
50 Part number S212128, Washer sealing 15X7X2mm WASHER SEALING 15X7X2MM
Glowworm part no. S212128
51 Part number 2000800153, Auto air vent AUTO AIR VENT
Glowworm part no. 2000800153
52   OBSOLETE RETAINER-PHIAL
Glowworm part no. 410939
53 Part number 204154, NOW USE S204154 LOCK NUT-M36 X 8 NOW USE S204154 LOCK NUT-M36 X 8
Glowworm part no. 204154
53 Part number S204154, LOCK NUT-M36 X 8 LOCK NUT-M36 X 8
Glowworm part no. S204154		 £6.58
54 Part number 51987004, OBSOLETE WASHER-FIBRE 48OD OBSOLETE WASHER-FIBRE 48OD
Glowworm part no. 51987004
55 Part number 440178, OBSOLETE FAN ASSY-KFB30 OBSOLETE FAN ASSY-KFB30
Glowworm part no. 440178
56   OBSOLETE SENSING NIPPLE
Glowworm part no. 204888
57 Part number 204162, NOW USE S204162 WASHER-COPPER-14.2X10X2.2mm NOW USE S204162 WASHER-COPPER-14.2X10X2.2MM
Glowworm part no. 204162
57 Part number S204162, WASHER-COPPER-14.2X10X2.2mm WASHER-COPPER-14.2X10X2.2MM
Glowworm part no. S204162		 £4.91
58   OBSOLETE FLUE CONN/MFLD-SPARE-KFB20>70
Glowworm part no. 800239
59 Part number 208540, NOW USE S208540 HOSE CLIP SIZE 70 NOW USE S208540 HOSE CLIP SIZE 70
Glowworm part no. 208540
59 Part number S208540, HOSE CLIP SIZE 70 HOSE CLIP SIZE 70
Glowworm part no. S208540		 £7.97
60   OBSOLETE NUT-M8X1.0 BRASS SPECIAL
Glowworm part no. 204140
61 Part number SWW8303, Lead LEAD
Glowworm part no. SWW8303
62   OBSOLETE FLUE HOOD ASSY-SPARE-KFB 20/30
Glowworm part no. 2000800177
63   OBSOLETE G/FIBRE ROPE-8DIAX615MM
Glowworm part no. 212162
64 Part number 230023, OBSOLETE GASKET-1.7mm WEBGLASS 230 FAN OBSOLETE GASKET-1.7MM WEBGLASS 230 FAN
Glowworm part no. 230023
64 Part number S230023, OBSOLETE GASKET-1.7mm WEBGLASS 230 FAN OBSOLETE GASKET-1.7MM WEBGLASS 230 FAN
Glowworm part no. S230023
66   OBSOLETE SCREW-M4 X 8MM REC PNSSM
Glowworm part no. 208356
67   OBSOLETE BODY-BULKHEAD FITTG-M8X1MM
Glowworm part no. 204867
68   NOW USE S204889 FLUE HOOD SCREW-BRASS
Glowworm part no. 204889
68   SCREW - FLUE HOOD BRASS
Glowworm part no. S204889
69   OBSOLETE OLIVE - 6MM
Glowworm part no. 204870
70   OBSOLETE TUBING NUT-M8X1MM
Glowworm part no. 204869
71   OBSOLETE FLUE HOOD SENSING TUBE-SPARE
Glowworm part no. 2000800348
72 Part number 208536, NOW USE S208536 SILICONE TUBE-40mm CLEAR SA160 NOW USE S208536 SILICONE TUBE-40MM CLEAR SA160
Glowworm part no. 208536
72 Part number S208536, Silicone tube -40mm clear SILICONE TUBE -40MM CLEAR
Glowworm part no. S208536		 £4.91
73   SILICONE TUBE-190MM RED SA160
Glowworm part no. 208535
73   SILICONE TUBE-190MM RED
Glowworm part no. S208535
74   PIPE CLIP
Glowworm part no. 204221
74   CLIP - PIPE
Glowworm part no. S204221
75   PIN-PIPE CLIP-FASTEX
Glowworm part no. 204222
75   PIN-PIPE CLIP
Glowworm part no. S204222
76   OBSOLETE LWR FRT PANEL ASSY-SSCMP30>50
Glowworm part no. 2000800361
77   OBSOLETE SEAL-ASTG22
Glowworm part no. 210165
78   OBSOLETE BURNER-AERO-AC07/052045
Glowworm part no. 230001
79 Part number 203604, GAS COCK-1/2" BSP M/F-GASCON GAS COCK-1/2" BSP M/F-GASCON
Glowworm part no. 203604
79 Part number S203604, Gas cock GAS COCK
Glowworm part no. S203604
81 Part number 800442, Gas section GAS SECTION
Glowworm part no. 800442		 £122.45
82 Part number 208040, NOW USE S208040 O RING-H/WELL 22.0 X 2.5 NOW USE S208040 O RING-H/WELL 22.0 X 2.5
Glowworm part no. 208040
82 Part number S208040, O ring O RING
Glowworm part no. S208040		 £6.61
83 Part number 800375, NOW USE S800375 DOUBLE SOLENOID FOR 830 TANDEM NOW USE S800375 DOUBLE SOLENOID FOR 830 TANDEM
Glowworm part no. 800375
83 Part number S800375, Double solenoid DOUBLE SOLENOID
Glowworm part no. S800375
84   OBSOLETE MAN.ASSY-PNTD (203145) KFB
Glowworm part no. 442056
85   OBSOLETE GASKET-1.7MM WEBGLASS 230 MFD
Glowworm part no. 210171
86 Part number 203099, INJECTOR-2.7mm INJECTOR-2.7MM
Glowworm part no. 203099
86 Part number S203099, Injector INJECTOR
Glowworm part no. S203099
87 Part number 208241, NOW USE S208241 SCREW-M4-GAS MANIFOLD NOW USE S208241 SCREW-M4-GAS MANIFOLD
Glowworm part no. 208241
87 Part number S208241, SCREW-M4-GAS MANIFOLD SCREW-M4-GAS MANIFOLD
Glowworm part no. S208241		 £6.97
88 Part number 432784, SIGHT GLASS FRAME(3STNPF) S/FL SIGHT GLASS FRAME(3STNPF) S/FL
Glowworm part no. 432784
88 Part number S432784, Frame - Sight glass FRAME - SIGHT GLASS
Glowworm part no. S432784
89 Part number 208302, NOW USE S208302 SIGHT GLASS NOW USE S208302 SIGHT GLASS
Glowworm part no. 208302
89 Part number S208302, SIGHT GLASS SIGHT GLASS
Glowworm part no. S208302		 £6.61
90 Part number 208093, NOW USE S208093 GASKET-SIGHT GLASS NOW USE S208093 GASKET-SIGHT GLASS
Glowworm part no. 208093
90 Part number S208093, GASKET-SIGHT GLASS GASKET-SIGHT GLASS
Glowworm part no. S208093		 £6.61
91   SCREW-M4X8MM MS PN REC
Glowworm part no. 403014
91   SCREW - M4X8MM
Glowworm part no. S403014
92 Part number 2000800166, OBSOLETE PILOT TUBE-SPARE-KFB 20>70 OBSOLETE PILOT TUBE-SPARE-KFB 20>70
Glowworm part no. 2000800166
93 Part number 417019, NUT-COMP-4mm-SIT 0.958.030 NUT-COMP-4MM-SIT 0.958.030
Glowworm part no. 417019
93 Part number S417019, Nut - Compression 4mm NUT - COMPRESSION 4MM
Glowworm part no. S417019
94 Part number 203509, NOW USE S203509 PILOT INJTR-SPARE-JOHNSON 4212 NOW USE S203509 PILOT INJTR-SPARE-JOHNSON 4212
Glowworm part no. 203509
94 Part number S203509, Injector, pilot INJECTOR, PILOT
Glowworm part no. S203509		 £11.80
95 Part number 203428, OBSOLETE P/BNR-J/SON 27B4J5R4212S2G QC OBSOLETE P/BNR-J/SON 27B4J5R4212S2G QC
Glowworm part no. 203428
96 Part number 212176, GASKET-1.7mm PLT BRNR KFB GASKET-1.7MM PLT BRNR KFB
Glowworm part no. 212176
96 Part number S212176, Gasket-1.7mm GASKET-1.7MM
Glowworm part no. S212176
97   OBSOLETE ELECTRODE TYPE P621
Glowworm part no. 800188
97   OBSOLETE ELECTRODE
Glowworm part no. S800188
98   OBSOLETE IGNITION LEAD ASSY 350MM
Glowworm part no. SWW4610
99   OBSOLETE THERMOSTAT KNOB SPARE-CP
Glowworm part no. 800206
100   NOW USE S204677 COMPRESSION RING-SCB1609/17/00
Glowworm part no. 204677
100   COMPRESSION RING
Glowworm part no. S204677		 £4.91
101   OBSOLETE NEON ASSY
Glowworm part no. 446555
102   OBSOLETE PRESS GAUGE&INSUL SLV-SSCOMP
Glowworm part no. 2000800340
103   OBSOLETE SLEEVE-MARFLEX SRG725 - 16DIA
Glowworm part no. 202185
104   OBSOLETE THERMO CLAMP 24DIA (NPF) SSCOM
Glowworm part no. 446540
105   OBSOLETE NUT-SPIRE CAPT NO6
Glowworm part no. 51173003
106   SCREW-NO.6X3/4 REC BZP
Glowworm part no. 50812002
106   SCREW - NO.6X3/4
Glowworm part no. S50812002
107   OBSOLETE THERMO CLAMP 30DIA (NPF) SSCOM
Glowworm part no. 446541
108   CLIP - EDGE CABLE
Glowworm part no. SK6899
109   OBSOLETE CLIP-PLASKLIP TYPE NX
Glowworm part no. SK8363
110   OBSOLETE STANDOFF LOCK CLIP-RICHCO
Glowworm part no. 230227
111 Part number 900817, NOW USE S900817 PCB-ALTERNATIVE-KFB SEE REMS NOW USE S900817 PCB-ALTERNATIVE-KFB SEE REMS
Glowworm part no. 900817
111 Part number S900817, Printed circuit board (5 wire-1 fuse) PRINTED CIRCUIT BOARD (5 WIRE-1 FUSE)
Glowworm part no. S900817		 £162.29
112   TERMINAL BLOCK ASSY
Glowworm part no. 443176
112   TERMINAL BLOCK
Glowworm part no. S443176
113   NOW USE S230226 SCREW-NO.4X3/4 PLASTITE-RECPAN
Glowworm part no. 230226
113   SCREW -NO.4X3/4 PLASTITE
Glowworm part no. S230226
114   OBSOLETE TSTAT-RANCO K36-P1302-000
Glowworm part no. 230211
115   OBSOLETE STAT-PUMP OVER RUN K36 P2304
Glowworm part no. 202546
116   OBSOLETE CONTROL BRACKET (INS) SSCOMP50
Glowworm part no. 446565
117   SCREW - M4X10MM
Glowworm part no. SK6359
118 Part number 230000, OBSOLETE A/P SWITCH-YAMATAKE C6065A1002 OBSOLETE A/P SWITCH-YAMATAKE C6065A1002
Glowworm part no. 230000
119   OBSOLETE HINGE MNTG BRKT ASSY-SSCOMP
Glowworm part no. 2000800341
120   OBSOLETE SILICONE TUBE-120MM CLEARSA160
Glowworm part no. 208538
121   OBSOLETE SILICONE TUBE-120MM RED SA160
Glowworm part no. 208545
121   OBSOLETE SILICONE TUBE-120MM RED SA160
Glowworm part no. S208545
122 Part number SK9221, Clip - strain relief CLIP - STRAIN RELIEF
Glowworm part no. SK9221		 £4.91
123 Part number SK5877, Screw, no8 x 5/8 SCREW, NO8 X 5/8
Glowworm part no. SK5877
124   OBSOLETE CONTROLS FASCIA ASSY-SSCOMP
Glowworm part no. 800342
125   OBSOLETE PCB POST-RICHCO REF.TCBS-6-19
Glowworm part no. 230152
126   NOW USE S204200 CLIP-CABLE
Glowworm part no. 204200
126   CLIP CABLE
Glowworm part no. S204200
127   OBSOLETE THERMOSTAT BRKT (1XB) SSCOMP50
Glowworm part no. 446542
129   OBSOLETE BOILER SUB ASSY - STAGE 1
Glowworm part no. 446550
130 Part number SK6361, Shake proof washer (M4) SHAKE PROOF WASHER (M4)
Glowworm part no. SK6361
131 Part number SK6218, Nut - M4 NUT - M4
Glowworm part no. SK6218		 £6.61
132   OBSOLETE CON BRKT PIV PIN (CH) SSCOMP50
Glowworm part no. 446516
133   OBSOLETE CAP-COLES BROS BLACK-2006/3
Glowworm part no. 204202
134   OBSOLETE INFILL EDGE TRIM
Glowworm part no. 212183
135   OBSOLETE CONTROLS HARNESS
Glowworm part no. 446566
136   OBSOLETE PLUG & CABLE ASSY (TAGGED)
Glowworm part no. 446558
137   OBSOLETE FAN HARNESS
Glowworm part no. 446576
138   OBSOLETE ANGLED CABLE ENTRY-500508
Glowworm part no. 204270
139   OBSOLETE CABLE ENTRY SEC. PART-500505
Glowworm part no. 204271
140   OBSOLETE PRESSURE SWITCH HARNESS
Glowworm part no. 440110
141   OBSOLETE WIRE TIE-RICHCO OR HEYCO
Glowworm part no. 204253
142 Part number 204215, NOW USE S204215 WASHER-SEALING-AF2000-11.3X4 NOW USE S204215 WASHER-SEALING-AF2000-11.3X4
Glowworm part no. 204215
142 Part number S204215, Washer sealing WASHER SEALING
Glowworm part no. S204215
143   OBSOLETE EXPANSION VESSEL QC
Glowworm part no. 208567
144   OBSOLETE E.V. SUPP BRKT (PF) SSCOMP
Glowworm part no. 446505
147 Part number 212129, WASHER-SEALING 28X21.5X2mm WASHER-SEALING 28X21.5X2MM
Glowworm part no. 212129
147 Part number S212129, Washer sealing 28X21.5X2mm WASHER SEALING 28X21.5X2MM
Glowworm part no. S212129
148   OBSOLETE PUMP AND WASHERS-SPARE
Glowworm part no. 2000800343
149 Part number 900701, PUMP WASHER-ALTERNATIVES PUMP WASHER-ALTERNATIVES
Glowworm part no. 900701
149 Part number S900701, Washer - Pump WASHER - PUMP
Glowworm part no. S900701
151   OBSOLETE NUT-PUMP-BRASS CZ122
Glowworm part no. 204501
152   OBSOLETE BULKHEAD/PUMP ADAPTER
Glowworm part no. 230194
152   OBSOLETE M36/M36 BULKHEAD CONNECTOR
Glowworm part no. 230195
153 Part number 2000800150, Water pressure switch WATER PRESSURE SWITCH
Glowworm part no. 2000800150
154   NOW USE S204212 O RING-5.1X1.6MM 0051-16-MN70
Glowworm part no. 204212
154   O RING -5.1X1.6MM
Glowworm part no. S204212		 £4.91
155   OBSOLETE VOLUME VESSEL-SPARE-SSCMP30>50
Glowworm part no. 2000800362
156 Part number 2000800149, Pressure relief valve PRESSURE RELIEF VALVE
Glowworm part no. 2000800149
157 Part number 212143, NOW USE S212143 WASHER-SEALING 18X15X2mm NOW USE S212143 WASHER-SEALING 18X15X2MM
Glowworm part no. 212143
157 Part number S212143, Washer 18x15x2mm WASHER 18X15X2MM
Glowworm part no. S212143
158   OBSOLETE BYPASS VALVE DTB 30-55
Glowworm part no. 2000800669
159   OBSOLETE INLET M/FOLD&WSHRS-SSCMP30>50
Glowworm part no. 800364
160   OBSOLETE EV PIPE C/W WASHERS-SSCMP30>50
Glowworm part no. 2000800365
161 Part number 208342, NOW USE 0020247022 WASHER-SEALING-AF2000-15ODX6ID NOW USE 0020247022 WASHER-SEALING-AF2000-15ODX6ID
Glowworm part no. 208342
161 Part number S208342, NOW USE 0020247022 Washer NOW USE 0020247022 WASHER
Glowworm part no. S208342
161 Part number 0020247022, Washer (PK10) WASHER (PK10)
Glowworm part no. 0020247022		 £8.19
162   OLIVE-PRESSURE RELIEF VALVE
Glowworm part no. S208541		 £4.91
162   NOW USE S208541 OLIVE-P.R.V.-CALEFFI 41073 QC
Glowworm part no. 208541
163   NOW USE S208542 NUT-P.R.V.-CALEFFI 31216 QC
Glowworm part no. 208542
163   NUT-PRESSURE RELIEF VALVE
Glowworm part no. S208542		 £4.91
164   OBSOLETE P.R.V O/LT PIPE (BND+TRM) SSCP
Glowworm part no. 446535
165 Part number 209174, WALL LINER-KFB WALL LINER-KFB
Glowworm part no. 209174
165 Part number S209174, Wall liner WALL LINER
Glowworm part no. S209174
166 Part number S209148, Flue duct FLUE DUCT
Glowworm part no. S209148
166 Part number 209148, FLUE DUCT-ALUM DRAWN TUBE FLUE DUCT-ALUM DRAWN TUBE
Glowworm part no. 209148
167 Part number 440096, OBSOLETE Terminal OBSOLETE TERMINAL
Glowworm part no. 440096
168   OBSOLETE SEALANT PACK-KFB
Glowworm part no. 440192
170   OBSOLETE SIDE FLUE CONN ASSY (F) KFB50
Glowworm part no. 440094
170 Part number 212140, SEAL-35X15X340mm WALL SEAL-35X15X340MM WALL
Glowworm part no. 212140
170 Part number S212140, SEAL-35X15X340mm WALL SEAL-35X15X340MM WALL
Glowworm part no. S212140
171 Part number S210164, Gasket - flue GASKET - FLUE
Glowworm part no. S210164
171 Part number 210164, GASKET-1.7mm WEBGLASS 230 FLUE GASKET-1.7MM WEBGLASS 230 FLUE
Glowworm part no. 210164
172 Part number 208294, NOW USE S208294 SCREW-M5X14mm+5DG MS PN NOW USE S208294 SCREW-M5X14MM+5DG MS PN
Glowworm part no. 208294
172 Part number S208294, Screw ( M5X14mm ) SCREW ( M5X14MM )
Glowworm part no. S208294		 £6.61
174   OBSOLETE SCREW-M5 X 10MM REC
Glowworm part no. 208226
175   OBSOLETE BURNER SUPPORT
Glowworm part no. 204875


Heating spares made simple this website is secured by Geotrust

 HSP K J Plumbing Factors

Copyright ©2020 >Heating Spare Parts - All Rights Reserved

Site Map | About Us | Parts Lists & Diagrams | Privacy Policy | Terms & Conditions

Facebook Twitter
