GLOWWORM
SPACE SAVER 60 R MKII 1988 AVA - (Appliance Overview)
Appliance Code: 41-313-61

Appliance Diagram


Appliance Overview diagram for Glowworm Space Saver 60 R MKII 1988 AVAClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   OBSOLETE SIDE SURROUND-PNTD SS6BC8BR
Glowworm part no. 429759
1   OBSOLETE USER INSTR- SSMK2R 9/92
Glowworm part no. 206799
1   OBSOLETE FITTERS INSTR- SS60RMK2 9/92
Glowworm part no. 206806
2   OBSOLETE COMB CHAMBER SHIELD (NPF) SS6B
Glowworm part no. 418096
3   OBSOLETE BURNER-AERO AC07/052008LR
Glowworm part no. 203216
4   OBSOLETE CASE TRAY ASSY - SS60R&BR
Glowworm part no. 429772
5   OBSOLETE OUTER CASE-SPARE-SS60RMK2
Glowworm part no. 2000800129
6 Part number 208243, NOW USE S208243 SCREW-NO.10 X 3/4 REC NOW USE S208243 SCREW-NO.10 X 3/4 REC
Glowworm part no. 208243
6 Part number S208243, Screw ( no.10 X 3/4 ) SCREW ( NO.10 X 3/4 )
Glowworm part no. S208243
8 Part number 411194, NOW USE S411194 SIGHT GLASS NOW USE S411194 SIGHT GLASS
Glowworm part no. 411194
8 Part number S411194, SIGHT GLASS SIGHT GLASS
Glowworm part no. S411194		 £6.80
9 Part number 51936004, ADHESIVE RING ADHESIVE RING
Glowworm part no. 51936004
9 Part number S51936004, ADHESIVE RING ADHESIVE RING
Glowworm part no. S51936004
10   NOW USE S58921016 PUSH ON FIX-SPIRE-SF02938/17/4
Glowworm part no. 58921016
10   PUSH ON FIX
Glowworm part no. S58921016
11   SIGHT WINDOW FRAME
Glowworm part no. SAA049M
12   OBSOLETE FLUE BAFFLE (NPF) SS6C
Glowworm part no. 418470
13 Part number SK2330, Screw (No8 X 3/8) SCREW (NO8 X 3/8)
Glowworm part no. SK2330
14   NUT - SPIRE CAPT NO8
Glowworm part no. SK9327		 £4.91
15   OBSOLETE D/DIVERTER ASY. (SW) SS6C
Glowworm part no. 418457
17   OBSOLETE CLEANING DOOR ASSY
Glowworm part no. 418459
18   NOW USE 2000802764 SCREW-NO.8 X 1/2 REC
Glowworm part no. 208393
18 Part number 2000802764, Screw (PK2) SCREW (PK2)
Glowworm part no. 2000802764		 £6.61
19   OBSOLETE H/E ASSY-PNTD SS60MK2/2+R
Glowworm part no. 418471
20 Part number 409234, PHIAL POCKET KIT-SPARES PHIAL POCKET KIT-SPARES
Glowworm part no. 409234
20 Part number 409233, PHIAL POCKET KIT PHIAL POCKET KIT
Glowworm part no. 409233
21   OBSOLETE PHIAL RET ANGLE(1XB) SS3456R
Glowworm part no. 429558
22   OBSOLETE COMB CHAMB SPARE SS60MK2+R
Glowworm part no. 800053
26   NUT
Glowworm part no. SK7557
27 Part number 203416, OBSOLETE PILOT BURNER-27T1D1M7215S3X QC OBSOLETE PILOT BURNER-27T1D1M7215S3X QC
Glowworm part no. 203416
27 Part number S203416, OBSOLETE Pilot burner OBSOLETE PILOT BURNER
Glowworm part no. S203416
28 Part number 208238, NOW USE S208238 SCREW-M5X8MM MS PN REC NOW USE S208238 SCREW-M5X8MM MS PN REC
Glowworm part no. 208238
28 Part number S208238, Screw ( M5X8mm ) SCREW ( M5X8MM )
Glowworm part no. S208238		 £6.61
29 Part number 900500, ELECTRODE-ALTERNATIVES ELECTRODE-ALTERNATIVES
Glowworm part no. 900500
29 Part number S900500, Electrode ELECTRODE
Glowworm part no. S900500
30 Part number SK6219, Nut NUT
Glowworm part no. SK6219
31 Part number SK2674, Thermocouple THERMOCOUPLE
Glowworm part no. SK2674
32 Part number SK3580, Clip - securing CLIP - SECURING
Glowworm part no. SK3580		 £6.61
33   OBSOLETE INSUL-6MM C/C FRONT
Glowworm part no. 210001
33   OBSOLETE INSUL-6MM C/C FRONT
Glowworm part no. S210001
34   INSUL-6MM C/C REAR
Glowworm part no. 210000
34   INSULATION -6MM COMBUSTION CHAMBER REAR
Glowworm part no. S210000
35   SCREW -M5
Glowworm part no. SK8209
37 Part number SWW4617, Ignition lead IGNITION LEAD
Glowworm part no. SWW4617
38 Part number 900501, NOW USE S900501 PIEZO GENERATOR-ALTERNATIVE NOW USE S900501 PIEZO GENERATOR-ALTERNATIVE
Glowworm part no. 900501
38 Part number S900501, Piezo generator PIEZO GENERATOR
Glowworm part no. S900501
39   OBSOLETE CNTRL BOX-SPARE-SS60R(B&C)&80B
Glowworm part no. 429662
40   TSTAT&SCRWS-CL6 P0146-000
Glowworm part no. 202519
40 Part number S202519, Thermostat and screws THERMOSTAT AND SCREWS
Glowworm part no. S202519
41 Part number 426526, OBSOLETE CONTROL KNOB ASSY OBSOLETE CONTROL KNOB ASSY
Glowworm part no. 426526
41 Part number S426526, OBSOLETE Control knob OBSOLETE CONTROL KNOB
Glowworm part no. S426526
42 Part number 208308, NOW USE S208308 SCREW-M4X10MM+5DG MS PN NOW USE S208308 SCREW-M4X10MM+5DG MS PN
Glowworm part no. 208308
42 Part number S208308, Screw (M4x10mm) SCREW (M4X10MM)
Glowworm part no. S208308		 £6.61
43   OBSOLETE GROMMET-ROBERT MOSS 15069
Glowworm part no. 204243
45 Part number 429568, OBSOLETE Cover-gas valve OBSOLETE COVER-GAS VALVE
Glowworm part no. 429568
47 Part number 429549, Gas section GAS SECTION
Glowworm part no. 429549
48 Part number 208040, NOW USE S208040 O RING-H/WELL 22.0 X 2.5 NOW USE S208040 O RING-H/WELL 22.0 X 2.5
Glowworm part no. 208040
48 Part number S208040, O ring O RING
Glowworm part no. S208040		 £6.61
49 Part number 900307, NOW USE S900307 G/COCK-FLANGED-ALTERNATIVES QC NOW USE S900307 G/COCK-FLANGED-ALTERNATIVES QC
Glowworm part no. 900307
49 Part number S900307, Gas Cock - flanged GAS COCK - FLANGED
Glowworm part no. S900307
50 Part number 208241, NOW USE S208241 SCREW-M4-GAS MANIFOLD NOW USE S208241 SCREW-M4-GAS MANIFOLD
Glowworm part no. 208241
50 Part number S208241, SCREW-M4-GAS MANIFOLD SCREW-M4-GAS MANIFOLD
Glowworm part no. S208241		 £6.97
51 Part number 12621, NOW USE 2000800884 NIPPLE-TEST 1/8 NOW USE 2000800884 NIPPLE-TEST 1/8
Glowworm part no. 12621
51 Part number 2000800884, Test nipple & screw TEST NIPPLE & SCREW
Glowworm part no. 2000800884		 £6.52
52   NOW USE S78129 SCREW-2BA
Glowworm part no. 78129
52   SCREW
Glowworm part no. S78129
53   OBSOLETE GAS VALVE HARNESS
Glowworm part no. 429778
54   OBSOLETE GAS MANIFOLD QC
Glowworm part no. 203134
55   INJECTOR-3.8MM HOLE
Glowworm part no. SK8277
56   SCREW - M4X10MM
Glowworm part no. SK6359
58 Part number SK6469, Washer WASHER
Glowworm part no. SK6469
59   OBSOLETE NUT-M6 HEX FULL BZP
Glowworm part no. SK6069
60   CLIP - EDGE CABLE
Glowworm part no. SK6899
61   OBSOLETE SCREW-M8X12MM MS HX HD ZP
Glowworm part no. SFF0003
62 Part number 51062003, NOW USE S51062003 NUT-SPIRE CAPT NO.10 NOW USE S51062003 NUT-SPIRE CAPT NO.10
Glowworm part no. 51062003
62 Part number S51062003, Nut- spire capt no.10 NUT- SPIRE CAPT NO.10
Glowworm part no. S51062003		 £4.29
63   OBSOLETE BLR/SUPP FRAME SPARE SS60RMK2
Glowworm part no. 800054
65   OBSOLETE SCREW-NO.12 X 1 REC
Glowworm part no. 208200
66   OBSOLETE GAS VALVE SUPP BRKT(2XB) SSCR
Glowworm part no. 429569
67   OBSOLETE SCREW-NO.10 X 1/2 REC
Glowworm part no. 50759002
67   OBSOLETE SCREW-NO.10 X 1/2 REC
Glowworm part no. S50759002
68   OBSOLETE WALL FRAME ASSY
Glowworm part no. 429668
69   OBSOLETE PILOT SHIELD ASSY
Glowworm part no. SAA029S
70   OBSOLETE INSUL-5MM H/SHIELD
Glowworm part no. 210031
71   OBSOLETE PILOT WINDOW-MICA(BS5804)
Glowworm part no. 412855
