GLOWWORM
SAXONY 2 BBU FF - (Casing 1)
Appliance Code: 37-047-11

Appliance Diagram


Casing 1 diagram for Glowworm Saxony 2 BBU FFClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   OBSOLETE COMB INSTR-361BKDPA4100/PSW21
Glowworm part no. 221648
2   OBSOLETE WALL SEALING PLATE (4XB) OPUS
Glowworm part no. 448076
4   OBSOLETE C/CHAMB BTTM PLT (FM)OP/OPL/CH
Glowworm part no. 451479
5   OBSOLETE FUEL EFFECT BED PACK-SEE REMS
Glowworm part no. 210211
5   OBSOLETE FUEL EFFECT BED
Glowworm part no. S210211
7   OBSOLETE FLUE SPIGOT ASSY(SW) HGB/OPUS
Glowworm part no. 433300
8   OBSOLETE SUPPLY TUBE (NUT&FORM) OPUS
Glowworm part no. 448098
9 Part number S451457, Sensing tube fittings SENSING TUBE FITTINGS
Glowworm part no. S451457
9 Part number 451457, SENSING TBE MOUNTING BRKT ASSY SENSING TBE MOUNTING BRKT ASSY
Glowworm part no. 451457
10 Part number 451461, UPPER SENSING TUBE-(F) UPPER SENSING TUBE-(F)
Glowworm part no. 451461
10 Part number S451461, Upper sensing tube UPPER SENSING TUBE
Glowworm part no. S451461
12   OBSOLETE FIREFRONT UPPER SENSG TBE ASSY
Glowworm part no. 451458
13   SCREW ( M4 X 6MM )
Glowworm part no. S208365
13   SCREW-M4 X 6MM REC
Glowworm part no. 208365
14   OBSOLETE SPARES-CANOPY TOP CHARTWELL
Glowworm part no. 2000800777
15   OBSOLETE CANOPY BODY-PWDR SAX3
Glowworm part no. 451402
16   OBSOLETE SPARES-LOWER FRONT ASSY SAXONY
Glowworm part no. 2000801214
17 Part number S208294, Screw ( M5X14mm ) SCREW ( M5X14MM )
Glowworm part no. S208294		 £6.61
17 Part number 208294, NOW USE S208294 SCREW-M5X14mm+5DG MS PN NOW USE S208294 SCREW-M5X14MM+5DG MS PN
Glowworm part no. 208294
18   OBSOLETE LOWER FRONT PIN
Glowworm part no. 208577
19   OBSOLETE BRASS KNOB-25 DIA REF LBO 0500
Glowworm part no. 209294
20   OBSOLETE BRASS KNOB-38 DIA REF LBO 0500
Glowworm part no. 209295
21   OBSOLETE BACKING PLATE-32 DIA LBO 0500
Glowworm part no. 209297
22   OBSOLETE BACKING PLATE-25 DIA LBO 0500
Glowworm part no. 209298
24   OBSOLETE UPPER SIDE S/ASSY LH-PNT SAX
Glowworm part no. 451419
25   OBSOLETE UPPER SIDE ASSY - RH SAXONY
Glowworm part no. 2000459543
26   OBSOLETE PLINTH ASSY CHART/SAX BBU
Glowworm part no. 451486
27   OBSOLETE LOWER SIDE ASSY L.H. SAXONY
Glowworm part no. 459362
28   OBSOLETE LOWER SIDE ASSY R.H. SAXONY
Glowworm part no. 459363
29   OBSOLETE LEG LH - PWDR VPC/SAX
Glowworm part no. 451406
30   OBSOLETE LEG RH - PWDR VPC/SAX
Glowworm part no. 451407
31   UNION NUT 3/8 BSPF
Glowworm part no. 12248
31   UNION NUT 3/8 BSPF
Glowworm part no. S12248
32   OBSOLETE 9V BATTERY-ALTERNATIVES
Glowworm part no. 900822
34   NOW USE S208225 SCREW-NO.10 X 1 1/2 REC
Glowworm part no. 208225
34   SCREW ( NO.10 X 1 1/2 )
Glowworm part no. S208225
35 Part number S208342, NOW USE 0020247022 Washer NOW USE 0020247022 WASHER
Glowworm part no. S208342
35 Part number 0020247022, Washer (PK10) WASHER (PK10)
Glowworm part no. 0020247022		 £8.19
35 Part number 208342, NOW USE 0020247022 WASHER-SEALING-AF2000-15ODX6ID NOW USE 0020247022 WASHER-SEALING-AF2000-15ODX6ID
Glowworm part no. 208342
38   OBSOLETE KNURLED SCREW
Glowworm part no. 208665
39   NOW USE S900851 LIQUID COAL ALTERNATIVES
Glowworm part no. 900851
39   LIQUID COAL
Glowworm part no. S900851		 £5.96
41   OBSOLETE CONTROL KNOB ASSY BLKASH
Glowworm part no. 448103
42   OBSOLETE BEZEL - PRINTED SAXONY
Glowworm part no. 459368
43   OBSOLETE REAR SURR SIDE EXTN-PWDR CHART
Glowworm part no. 451469
44 Part number SK2330, Screw (No8 X 3/8) SCREW (NO8 X 3/8)
Glowworm part no. SK2330
45   OLIVE - 3/8 DIA
Glowworm part no. SK4740
46   OBSOLETE WASHER-M4 FORM A PLN ZP
Glowworm part no. SK6558
47   OBSOLETE SCREW-M5X25MM MS HX HD BZP
Glowworm part no. SK7231
48   SCREW - M4X10MM
Glowworm part no. SK6359
51 Part number 208526, NOW USE S208526 PUSH-ON-FIX SFO 3103/17/0 NOW USE S208526 PUSH-ON-FIX SFO 3103/17/0
Glowworm part no. 208526
51 Part number S208526, Push on fix PUSH ON FIX
Glowworm part no. S208526		 £6.61
52   OBSOLETE OXYPILOT ASSY CHART BBU
Glowworm part no. 451476
54   SCREW - M4X8MM
Glowworm part no. S403014
54   SCREW-M4X8MM MS PN REC
Glowworm part no. 403014
55   OBSOLETE INJECTOR-BRAY CAT18/180 QC
Glowworm part no. S230169
55   OBSOLETE INJECTOR-BRAY CAT18/180 QC
Glowworm part no. 230169
56   OBSOLETE INJECTOR 18/320 QC
Glowworm part no. S230201
56   OBSOLETE INJECTOR 18/320 QC
Glowworm part no. 230201
57   OBSOLETE BURNER ASSY OPUS/OPULENCE
Glowworm part no. 2000800448
58   NOW USE S204848 NUT-UNION-OLIVE TYPE 3/16
Glowworm part no. 204848
58   NUT-UNION-OLIVE TYPE 3/16
Glowworm part no. S204848		 £4.29
59   OBSOLETE OLIVE-3/16
Glowworm part no. SK3022
60   OBSOLETE BLEED RESTRICTOR
Glowworm part no. 204926
61   OBSOLETE INLET SUPPLY TUBE ASSY OPUS
Glowworm part no. 448053
62 Part number 448055, OBSOLETE SUPPLY TUBE ASSY-BTM INJ OPUS OBSOLETE SUPPLY TUBE ASSY-BTM INJ OPUS
Glowworm part no. 448055
62 Part number S448055, OBSOLETE SUPPLY TUBE ASSY-BTM INJ OPUS OBSOLETE SUPPLY TUBE ASSY-BTM INJ OPUS
Glowworm part no. S448055
63   OBSOLETE SUPPLY TUBE ASSY-TOP INJ OPUS
Glowworm part no. 448057
64   OBSOLETE BLEED TUBE (F) OPUS
Glowworm part no. 448059
65   OBSOLETE SPARES-PILOT PIPE CHARTWELL BBU
Glowworm part no. 2000800782
66   MICRO SWITCH-OTEHALL 383190
Glowworm part no. 202014
66   MICRO SWITCH
Glowworm part no. S202014
67   OBSOLETE PUSH ON FIX-MECHFAST M/F 6493
Glowworm part no. 208582
68   OBSOLETE INSULATION PLATE-MARANYL AD197
Glowworm part no. 210074
69   OBSOLETE CAM (NPF) FBL/OPUS
Glowworm part no. 440469
70   OBSOLETE WASHER-S/PROOF M3 ZP EXT TEETH
Glowworm part no. SK6362
72   OBSOLETE NUT-M3 HEX FULL ZP
Glowworm part no. SK6363
73   OBSOLETE SCREW-M3X20MM MS PN REC ZP
Glowworm part no. K6675
74 Part number 2000800783, Control tap CONTROL TAP
Glowworm part no. 2000800783		 £100.69
75   OBSOLETE BULKHEAD FITTING-CHAR/OPUS/OPL
Glowworm part no. 204972
77 Part number S208737, SILICONE TUBE-40mm CLEAR SILICONE TUBE-40MM CLEAR
Glowworm part no. S208737		 £6.61
77 Part number 208737, NOW USE S208737 SILICONE TUBE-40mm CLEAR NOW USE S208737 SILICONE TUBE-40MM CLEAR
Glowworm part no. 208737
78   OBSOLETE AIR GUIDE ASSY CHART BBU
Glowworm part no. 451470
80   OBSOLETE HEAT EXCH & PRESTIK OPUS/OPUL
Glowworm part no. 2000800451
81 Part number SFF0828, OBSOLETE HYLOMAR SILICONE - 40ML TUBE OBSOLETE HYLOMAR SILICONE - 40ML TUBE
Glowworm part no. SFF0828
82   NOW USE S213045 SCREW-NO.8X3/4 TYPE AB RH ZP
Glowworm part no. 213045
82   SCREW-NO.8X3/4
Glowworm part no. S213045
84   OBSOLETE SIDE REFLECTOR-LH(NPF)OPUS/VIC
Glowworm part no. 448046
85   OBSOLETE SIDE REFLECTOR-RH(NPF)OPUS/VIC
Glowworm part no. 448047
86   OBSOLETE BACK REFLECTOR(2ST NPF)OPUS/VI
Glowworm part no. 448048
87   OBSOLETE SENSING TUBE CONNECTOR
Glowworm part no. 204969
88   OBSOLETE LOCKNUT-3/8 BSP
Glowworm part no. 204196
88   OBSOLETE LOCKNUT-3/8 BSP
Glowworm part no. S204196
89   OBSOLETE LOWER SENSING TBE - NUT & SIZE
Glowworm part no. 451499
90 Part number S208308, Screw (M4x10mm) SCREW (M4X10MM)
Glowworm part no. S208308		 £6.61
90 Part number 208308, NOW USE S208308 SCREW-M4X10mm+5DG MS PN NOW USE S208308 SCREW-M4X10MM+5DG MS PN
Glowworm part no. 208308
91   OBSOLETE NUT-UNION 3/8 TUBE
Glowworm part no. SK8149
92 Part number SK8019, Screw ( M5X10mm ) SCREW ( M5X10MM )
Glowworm part no. SK8019		 £6.61
93   SCREW - M5X10MM
Glowworm part no. S208610
93   SCREW-M5X10MM+5DG MSZP HEX REC
Glowworm part no. 208610
95   OBSOLETE BURNER BAFFLE(1XBEND) OPUS/VIC
Glowworm part no. 448061
96   SCREW -M4X6MM
Glowworm part no. SK6212
97   OBSOLETE WASHER-PLAIN 1/4 PWALI
Glowworm part no. 451475
98   OBSOLETE D/DIVERTER EXTN ASSY (SW) OPUS
Glowworm part no. 448067
99   OBSOLETE LOWER FRNT BAFF BRKT ASS SAX
Glowworm part no. 451426
100   OBSOLETE WALL PROTECT. PLATE SEAL 264MM
Glowworm part no. 212201
101   OBSOLETE WALL PROTECT. PLATE SEAL 160MM
Glowworm part no. 212202
102   OBSOLETE INSULATION-WALL PROTECT. PLATE
Glowworm part no. 210201
103   OBSOLETE HINGE PIN
Glowworm part no. 208578
104 Part number SK6218, Nut - M4 NUT - M4
Glowworm part no. SK6218		 £6.61
105   GLASS FRAME SEAL QC
Glowworm part no. 212204
105   GLASS FRAME SEAL
Glowworm part no. S212204
106   OBSOLETE AERATION PLATE ASSY (SW) OPUS
Glowworm part no. 448050
108   OBSOLETE IGNITER BRKT(VEE\INS)OP\OPL\CH
Glowworm part no. 451473
109 Part number S202179, OBSOLETE Ignitor (9V) OBSOLETE IGNITOR (9V)
Glowworm part no. S202179
109 Part number 202179, OBSOLETE RV IGNITOR(9V) REF RV0681 OO16 OBSOLETE RV IGNITOR(9V) REF RV0681 OO16
Glowworm part no. 202179
110   LEAD
Glowworm part no. SWX0403		 £4.29
111   OBSOLETE GLASS FRAME ASSY SAXGF
Glowworm part no. 451438
112   OBSOLETE CANOPY HEAT SHIELD ASSY - PNTD
Glowworm part no. 451429
113   OBSOLETE CANOPY BAFFLE (PNT) SAX3
Glowworm part no. 451430
114   CLIP
Glowworm part no. S204631
114   CLIP-CTRL KNOB-TRW 17020-07
Glowworm part no. 204631
115 Part number S204968, Sensing tube Adapter and O rings SENSING TUBE ADAPTER AND O RINGS
Glowworm part no. S204968
115 Part number 204968, NOW USE S204968 SENSING TBE ADPTR C/W O RINGS NOW USE S204968 SENSING TBE ADPTR C/W O RINGS
Glowworm part no. 204968
116 Part number S417019, Nut - Compression 4mm NUT - COMPRESSION 4MM
Glowworm part no. S417019
116 Part number 417019, NUT-COMP-4mm-SIT 0.958.030 NUT-COMP-4MM-SIT 0.958.030
Glowworm part no. 417019
117   OBSOLETE TBE NUT/OLIVE-4MM 45900402-019
Glowworm part no. 204965
118 Part number S210214, Fuel effect piece no 1 FUEL EFFECT PIECE NO 1
Glowworm part no. S210214		 £40.28
118 Part number 210214, NOW USE S210214 FUEL EFFECT PIECE NO 1 OPUS NOW USE S210214 FUEL EFFECT PIECE NO 1 OPUS
Glowworm part no. 210214
119   NOW USE S210215 FUEL EFFECT PIECE NO 2 OPUS
Glowworm part no. 210215
119   FUEL EFFECT PIECE NO 2
Glowworm part no. S210215		 £40.28
120 Part number S210216, Fuel effect piece no 3 FUEL EFFECT PIECE NO 3
Glowworm part no. S210216		 £40.28
120 Part number 210216, NOW USE S210216 FUEL EFFECT PIECE NO 3 OPUS NOW USE S210216 FUEL EFFECT PIECE NO 3 OPUS
Glowworm part no. 210216
121 Part number 210217, NOW USE S210217 FUEL EFFECT PIECE NO 4 OPUS NOW USE S210217 FUEL EFFECT PIECE NO 4 OPUS
Glowworm part no. 210217
121 Part number S210217, Fuel effect piece no 4 FUEL EFFECT PIECE NO 4
Glowworm part no. S210217		 £40.28
122 Part number S210218, Fuel effect piece no 5 FUEL EFFECT PIECE NO 5
Glowworm part no. S210218		 £40.28
122 Part number 210218, NOW USE S210218 FUEL EFFECT PIECE NO 5 OPUS NOW USE S210218 FUEL EFFECT PIECE NO 5 OPUS
Glowworm part no. 210218
123   NOW USE S208608 SCREW-NO8 X 1/4 REC PAN B ZP
Glowworm part no. 208608
123   SCREW - NO8 X 1/4
Glowworm part no. S208608
124   OBSOLETE SPARES-BODY ASSY CHARTWELL BBU
Glowworm part no. 2000800784
125   OBSOLETE SPARES-HEAT EXCH CANOPY
Glowworm part no. 2000800780


Heating spares made simple this website is secured by Geotrust

 HSP K J Plumbing Factors

Copyright ©2020 >Heating Spare Parts - All Rights Reserved

Site Map | About Us | Parts Lists & Diagrams | Privacy Policy | Terms & Conditions

Facebook Twitter
