GLOWWORM
HIDEAWAY 70 CF 1985 AVA - (Boiler Assembly)
Appliance Code: 41-313-82

Appliance Diagram


Boiler Assembly diagram for Glowworm Hideaway 70 CF 1985 AVAClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   OBSOLETE FITTERS INS-HA70/80 11/91
Glowworm part no. 206938
1   OBSOLETE FITTERS INS-HA90/100/120 11/91
Glowworm part no. 206937
1   OBSOLETE FITTERS INS-HA70/80B 2/91
Glowworm part no. 206940
1   OBSOLETE USER INSTRUCTIONS-HA70>120B&C 2/91
Glowworm part no. 206941
1   OBSOLETE SPRS BOILER SUB ASY HA90/100BF
Glowworm part no. 2000800741
2 Part number 411402, NOW USE S411402 SCREW-M6X10MM MS PN REC BZP NOW USE S411402 SCREW-M6X10MM MS PN REC BZP
Glowworm part no. 411402
2 Part number S411402, Screw - M6X10mm SCREW - M6X10MM
Glowworm part no. S411402
5   INSUL-6MM C/C SIDE
Glowworm part no. 210058
5   SCREW -M5
Glowworm part no. SK8209
5   INSULATION-6MM-COMBUSTION CHAMBER SIDE
Glowworm part no. S210058
9   OBSOLETE SCREW-M5X16MM MS HX HD ZP
Glowworm part no. SK6533
10 Part number SK6262, Shake proof washer (M5) SHAKE PROOF WASHER (M5)
Glowworm part no. SK6262
11 Part number SK6219, Nut NUT
Glowworm part no. SK6219
16   OBSOLETE SCREW-NO.12 X 1/2 REC
Glowworm part no. 208350
17   G/FIBRE ROPE-10X1462MM LOOP
Glowworm part no. 212024
17   G/FIBRE ROPE-10X1462MM LOOP
Glowworm part no. S212024
18   OBSOLETE HEAT SHIELD KIT HA100-120B
Glowworm part no. 424804
19 Part number 403215, NOW USE S403215 NUT-WING M5 ZP NOW USE S403215 NUT-WING M5 ZP
Glowworm part no. 403215
19 Part number S403215, Nut-wing M5 NUT-WING M5
Glowworm part no. S403215
20   OBSOLETE BASE PROT TRAY ASSY (SW) HA02B
Glowworm part no. 424812
21   NUT
Glowworm part no. SK6516
22   OBSOLETE MAN.ASSY-PNTD-(203124) HA100BC
Glowworm part no. 442019
23   OBSOLETE GAS MANIFOLD BRKT (F) HA8C02BC
Glowworm part no. 424864
24   INJECTOR-3.7MM HOLE
Glowworm part no. 203001
24 Part number S203001, Injector INJECTOR
Glowworm part no. S203001
26   G/FIBRE ROPE-10X1138MM LOOP
Glowworm part no. 212025
26 Part number S212025, G/FIBRE ROPE-10X1138MM LOOP G/FIBRE ROPE-10X1138MM LOOP
Glowworm part no. S212025
27 Part number 208302, NOW USE S208302 SIGHT GLASS NOW USE S208302 SIGHT GLASS
Glowworm part no. 208302
27 Part number S208302, SIGHT GLASS SIGHT GLASS
Glowworm part no. S208302		 £6.61
28 Part number 208093, NOW USE S208093 GASKET-SIGHT GLASS NOW USE S208093 GASKET-SIGHT GLASS
Glowworm part no. 208093
28 Part number S208093, GASKET-SIGHT GLASS GASKET-SIGHT GLASS
Glowworm part no. S208093		 £6.61
29   OBSOLETE SIGHT GLASS COV(PC) CV/HABCBBU
Glowworm part no. 424508
30 Part number SFF0652, Screw, no6 x 3/8 SCREW, NO6 X 3/8
Glowworm part no. SFF0652
31 Part number 203414, PILOT BRACKET PBRNR PILOT BRACKET PBRNR
Glowworm part no. 203414
31 Part number S203414, Bracket - Pilot BRACKET - PILOT
Glowworm part no. S203414
32   NOW USE S424548 PILOT SHLD(BO.PF)HA45BC+78902B
Glowworm part no. 424548
32   SHIELD - PILOT
Glowworm part no. S424548		 £4.91
33   SCREW (M5X12MM)
Glowworm part no. SK9419
34   OBSOLETE BURNER SUPP BRKT (PCF) HA4568B
Glowworm part no. 424679
35   OBSOLETE DOOR STIFFENING ANG(NPF) HA02B
Glowworm part no. 424874
36   BURNER ASSY-AC07/05/2028
Glowworm part no. 203262
36   BURNER
Glowworm part no. S203262
37   OBSOLETE CTRL BOX ASSY-HA70>120B&C
Glowworm part no. 424659
38   OBSOLETE CONT.BOX SUPP.BRKT(NPF)HA802BC
Glowworm part no. 424844
39   SCREW - M4X10MM
Glowworm part no. SK6359
40   OBSOLETE PLUG & CABLE ASSY
Glowworm part no. 424860
40   OBSOLETE PLUG + CABLE
Glowworm part no. S424860
41   NOW USE S204226 BUSH-RELIEF - SRB011-BLK
Glowworm part no. 204226
41   BUSH RELIEF
Glowworm part no. S204226
42   NOW USE S202511 TSTAT-RANCO CL6 P0129-000
Glowworm part no. 202511
42 Part number S202511, Thermostat THERMOSTAT
Glowworm part no. S202511		 £139.08
43 Part number 202019, OBSOLETE SOCKET-ELKAY 6603-2 OBSOLETE SOCKET-ELKAY 6603-2
Glowworm part no. 202019
43 Part number S202019, OBSOLETE Electrical Socket OBSOLETE ELECTRICAL SOCKET
Glowworm part no. S202019
44 Part number 202018, PLUG-ELKAY 6603-1 PLUG-ELKAY 6603-1
Glowworm part no. 202018
44 Part number S202018, Electrical Plug ELECTRICAL PLUG
Glowworm part no. S202018
45 Part number 900501, NOW USE S900501 PIEZO GENERATOR-ALTERNATIVE NOW USE S900501 PIEZO GENERATOR-ALTERNATIVE
Glowworm part no. 900501
45 Part number S900501, Piezo generator PIEZO GENERATOR
Glowworm part no. S900501
46   OBSOLETE NUT-SPIRE CAPT NO8
Glowworm part no. 208303
47 Part number SK2330, Screw (No8 X 3/8) SCREW (NO8 X 3/8)
Glowworm part no. SK2330
48   OBSOLETE SCREW-M4X16MM MS PN REC ZP
Glowworm part no. SK6213
49 Part number SK6361, Shake proof washer (M4) SHAKE PROOF WASHER (M4)
Glowworm part no. SK6361
50 Part number SK6218, Nut - M4 NUT - M4
Glowworm part no. SK6218		 £6.61
52   CONTROL KNOB/CLIP
Glowworm part no. FF2228
53 Part number 403095, OBSOLETE CLIP- D-SPIRE OBSOLETE CLIP- D-SPIRE
Glowworm part no. 403095
53 Part number S403095, D clip for control knob D CLIP FOR CONTROL KNOB
Glowworm part no. S403095
54   OBSOLETE BURNER BAFFLE (NPF) HA02B
Glowworm part no. 425572
55   OBSOLETE GAS VALVE ELBOW-ALTERNATIVES
Glowworm part no. 900400
55   OBSOLETE ELBOW - GAS VALVE
Glowworm part no. S900400
56 Part number 900307, NOW USE S900307 G/COCK-FLANGED-ALTERNATIVES QC NOW USE S900307 G/COCK-FLANGED-ALTERNATIVES QC
Glowworm part no. 900307
56 Part number S900307, Gas Cock - flanged GAS COCK - FLANGED
Glowworm part no. S900307
57 Part number 2000800001, Gas section GAS SECTION
Glowworm part no. 2000800001		 £107.59
58   NOW USE S212031 O RING-33MM ID X 2MM SECT
Glowworm part no. 212031
58   O RING -33MM ID X 2MM SECT
Glowworm part no. S212031
60 Part number 203508, PLT INJTR-0.27MM-SIT 0.977.113 PLT INJTR-0.27MM-SIT 0.977.113
Glowworm part no. 203508
60 Part number S203508, Injector, pilot INJECTOR, PILOT
Glowworm part no. S203508		 £15.68
62 Part number 417019, NUT-COMP-4MM-SIT 0.958.030 NUT-COMP-4MM-SIT 0.958.030
Glowworm part no. 417019
62 Part number S417019, Nut - Compression 4mm NUT - COMPRESSION 4MM
Glowworm part no. S417019
63   OBSOLETE NUT-TUBING-4MM-SIT 0.958.013
Glowworm part no. 204157
63   OBSOLETE NUT-TUBING-4MM
Glowworm part no. S204157
64   OBSOLETE OLIVE-4MM-SIT 0.957.009
Glowworm part no. 204158
64   OBSOLETE OLIVE 4MM
Glowworm part no. S204158
65 Part number 900001, NOW USE S900001 THERMOCOUPLE-ALTERNATIVES NOW USE S900001 THERMOCOUPLE-ALTERNATIVES
Glowworm part no. 900001
65 Part number S900001, Thermocouple THERMOCOUPLE
Glowworm part no. S900001		 £27.04
66 Part number 202605, NOW USE S202605 ELECTRODE NOW USE S202605 ELECTRODE
Glowworm part no. 202605
66 Part number S202605, ELECTRODE ELECTRODE
Glowworm part no. S202605		 £20.30
67   NOW USE S202606 ELECTRODE RETAINING NUT
Glowworm part no. 202606
67   ELECTRODE RETAINING NUT
Glowworm part no. S202606		 £4.91
68 Part number SWW4609, Ignition lead IGNITION LEAD
Glowworm part no. SWW4609
69 Part number 208294, NOW USE S208294 SCREW-M5X14MM+5DG MS PN NOW USE S208294 SCREW-M5X14MM+5DG MS PN
Glowworm part no. 208294
69 Part number S208294, Screw ( M5X14mm ) SCREW ( M5X14MM )
Glowworm part no. S208294		 £6.61
70   OBSOLETE CASING BRACKET (FORM) HABC
Glowworm part no. 424525
71   OBSOLETE REAR CASING BRKT (PCF) HA-B
Glowworm part no. 424630
73   PLUG -1 BSP TAPER - RECESSED
Glowworm part no. SK1092		 £5.15
74   OBSOLETE DIPTUBE ASSYHA100-120/100-120B
Glowworm part no. 442104
74   OBSOLETE PLUG-1/2 RECESSED
Glowworm part no. SK166
75 Part number 208368, DOOR STUD-FOREST SBV 38471406 DOOR STUD-FOREST SBV 38471406
Glowworm part no. 208368
75 Part number S208368, Door stud DOOR STUD
Glowworm part no. S208368
76   CLIP - EDGE CABLE
Glowworm part no. SK6899
77   NUT - SPIRE CAPT NO8
Glowworm part no. SK9327		 £4.91
78 Part number 409233, PHIAL POCKET KIT PHIAL POCKET KIT
Glowworm part no. 409233
78 Part number 208390, NOW USE S208390 SPLIT PIN-1.6 X 25MM NOW USE S208390 SPLIT PIN-1.6 X 25MM
Glowworm part no. 208390
78 Part number S208390, Split pin - 1.6 X 25mm SPLIT PIN - 1.6 X 25MM
Glowworm part no. S208390
79   OBSOLETE FRONT PANEL ASSY
Glowworm part no. 424819
80   OBSOLETE DOOR FASCIA
Glowworm part no. 205108
81   WASHER
Glowworm part no. SK6297
82   OBSOLETE EXTRUSION-DOOR TRIM
Glowworm part no. 209057
83   OBSOLETE SIDE PANEL ASSY RH
Glowworm part no. 424561
83   OBSOLETE SIDE PANEL ASSY RH
Glowworm part no. S424561
84   OBSOLETE SIDE PANEL ASSY LH
Glowworm part no. 424567
85 Part number 424530, OBSOLETE LOUVRE-PNTD HABC OBSOLETE LOUVRE-PNTD HABC
Glowworm part no. 424530
86   OBSOLETE TOP PANEL-PNTD HA02B
Glowworm part no. 424774
87   OBSOLETE CASING STRAP (PC) HA02B
Glowworm part no. 424821
88   OBSOLETE PLINTH FASCIA-PNTD-PH HA02BC
Glowworm part no. 424772
88   OBSOLETE PLINTH FASCIA-PNTD-PH HA02BC
Glowworm part no. S424772
89   OBSOLETE T/FRAME & I/DUCT ASY(SW) HA02B
Glowworm part no. 424884
90   OBSOLETE CORNER POST-153MM LG
Glowworm part no. 209068
91   NOW USE S208378 SCREW-M5X10MM S/ST WSHD
Glowworm part no. 208378
91   SCREW ( M5X10MM )
Glowworm part no. S208378		 £4.91
92   OBSOLETE SIDE O/LET GD ASSY HA45100120B
Glowworm part no. 424670
93   OBSOLETE T/BAFF & O/DUCT ASSY(SW) HA02B
Glowworm part no. 424879
94   OBSOLETE TERMINAL END PLATE (NPF) HA02B
Glowworm part no. 424887
120   OBSOLETE SAFETY DEVICE
Glowworm part no. 2000800723
121   OBSOLETE KNURLED NUT
Glowworm part no. 208414
122   LEAD
Glowworm part no. SWX5100		 £9.63
123   OBSOLETE SCREW-M4 X 12MM REC PNSSM
Glowworm part no. 403170
123   OBSOLETE SCREW-M4 X 12MM REC PNSSM
Glowworm part no. S403170
124   OBSOLETE SCREW-M5 X 12MM HX HD ST/STEEL
Glowworm part no. 208528
125   OBSOLETE NUT-M4 HEX FULL SS
Glowworm part no. 208664
126   OBSOLETE NUT-M5 HEX FULL SS
Glowworm part no. 208667
127   INTERRUPTER
Glowworm part no. 202422
127 Part number S202422, INTERRUPTER INTERRUPTER
Glowworm part no. S202422
