GLOWWORM
FLEXICOM 18 SX - (Electrics From Date Code 24/07)
Appliance Code: 41-315-72

Appliance Diagram


Electrics From Date Code 24/07 diagram for Glowworm Flexicom 18 SXClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   COMPANY PLAQUE
Glowworm part no. 0020020688
£10.29
1   COMPANY PLAQUE
Glowworm part no. 0020020689
£10.29
2 Part number 0020020696, Front panel FRONT PANEL
Glowworm part no. 0020020696
£79.43
3   SIDE PANEL
Glowworm part no. 0020020698
£56.67
4 Part number 801700, SCREW 4.2X13.5MM SCREW 4.2X13.5MM
Glowworm part no. 801700
£6.61
5 Part number 0020020705, Support, wall hanging SUPPORT, WALL HANGING
Glowworm part no. 0020020705
£38.23
6 Part number 0020020719, cover, rear (flue outlet) COVER, REAR (FLUE OUTLET)
Glowworm part no. 0020020719
£14.69
7 Part number 0020026459, Gasket GASKET
Glowworm part no. 0020026459
£6.61
8 Part number 0020020720, screw SCREW
Glowworm part no. 0020020720
£6.61
8 Part number 0020020725, NOW USE 0020020720 screw NOW USE 0020020720 SCREW
Glowworm part no. 0020020725

9 Part number 0020020714, cover, top (flue outlet) COVER, TOP (FLUE OUTLET)
Glowworm part no. 0020020714
£18.55
10   PLATE, FIXING JIG SUPPORT
Glowworm part no. 0020020787
£35.07
11 Part number 0020014192, Gasket, red large GASKET, RED LARGE
Glowworm part no. 0020014192
£6.61
12 Part number 0020014187, cable bushing CABLE BUSHING
Glowworm part no. 0020014187
£10.91
13 Part number 0020020707, Heat exchanger + sump HEAT EXCHANGER + SUMP
Glowworm part no. 0020020707
£562.13
14 Part number 0020020708, elbow, flow and return ELBOW, FLOW AND RETURN
Glowworm part no. 0020020708
£34.03
15 Part number 0020020711, Washer WASHER
Glowworm part no. 0020020711
£6.61
16 Part number 0020020742, clip (tube) CLIP (TUBE)
Glowworm part no. 0020020742
£6.61
17 Part number 0020018447, Screw (PK10) SCREW (PK10)
Glowworm part no. 0020018447
£6.39
17 Part number 0020020743, NOW USE 0020018447 screw NOW USE 0020018447 SCREW
Glowworm part no. 0020020743

18 Part number 0020020723, condensate trap CONDENSATE TRAP
Glowworm part no. 0020020723
£26.20
19 Part number 0020020724, O-ring O-RING
Glowworm part no. 0020020724
£6.61
21 Part number 0020020726, Pipe, condense drain PIPE, CONDENSE DRAIN
Glowworm part no. 0020020726
£10.55
22 Part number 0020013712, FLOAT FLOAT
Glowworm part no. 0020013712
£6.61
23 Part number 0020020728, burner BURNER
Glowworm part no. 0020020728
£202.29
24 Part number 0020020729, Gasket (burner) GASKET (BURNER)
Glowworm part no. 0020020729
£15.57
25 Part number 0020020730, nut, extended M5 NUT, EXTENDED M5
Glowworm part no. 0020020730
£6.61
26 Part number 0020020731, electrode ELECTRODE
Glowworm part no. 0020020731
£15.93
27 Part number 0020020732, Gasket (electrode) GASKET (ELECTRODE)
Glowworm part no. 0020020732
£6.61
28 Part number 0020020734, fan FAN
Glowworm part no. 0020020734
£191.48
29 Part number 0020020735, gas section GAS SECTION
Glowworm part no. 0020020735
£191.48
30 Part number 801648, O-ring for venturi plate O-RING FOR VENTURI PLATE
Glowworm part no. 801648
£6.61
31 Part number 0020020737, screw SCREW
Glowworm part no. 0020020737
£6.61
32 Part number 0020020739, Gasket (fan) GASKET (FAN)
Glowworm part no. 0020020739
£6.80
33 Part number 0020026402, Nut NUT
Glowworm part no. 0020026402
£6.61
34 Part number 0020020748, Pipe, flow PIPE, FLOW
Glowworm part no. 0020020748
£31.80
35   PIPE, RETURN
Glowworm part no. 0020020750
£15.91
36   PIPE, GAS
Glowworm part no. 0020020756
£31.19
37 Part number 0020026403, NOW USE 2000801883 seal NOW USE 2000801883 SEAL
Glowworm part no. 0020026403

37 Part number 2000801883, Sealing ring 3/4 (PK10) SEALING RING 3/4 (PK10)
Glowworm part no. 2000801883
£30.91
38 Part number 0020026404, O-ring O-RING
Glowworm part no. 0020026404
£6.57
39 Part number 0020020749, Pipe, flow PIPE, FLOW
Glowworm part no. 0020020749
£24.83
40 Part number 0020020757, Gasket (pipe flange) GASKET (PIPE FLANGE)
Glowworm part no. 0020020757
£6.61
41   CLIP, FAN MOUNTING
Glowworm part no. 0020020733
£16.34
42   CLIP (ZIG IGNITOR)
Glowworm part no. 0020020764
£7.81
43 Part number SK7959, Screw, M3x6mm SCREW, M3X6MM
Glowworm part no. SK7959
£6.61
44   CLIP, FAN FIXING
Glowworm part no. 0020020738
£10.29
45 Part number 0020020740, Nut NUT
Glowworm part no. 0020020740
£6.61
46   FLUEWAY TOP BAFFLE
Glowworm part no. 0020020717
£56.67
47   NOW USE 0020055401 ABSORBER CPL., REAR
Glowworm part no. 0020020713

47   SILENCER
Glowworm part no. 0020055401
£59.28
48   NOW USE 0020055401 ABSORBER CPL., FRONT
Glowworm part no. 0020020715

48   SILENCER
Glowworm part no. 0020055401
£59.28
49 Part number 0020020721, Gasket (flue hood front) GASKET (FLUE HOOD FRONT)
Glowworm part no. 0020020721
£10.33
50 Part number 0020020718, flue duct front assembly FLUE DUCT FRONT ASSEMBLY
Glowworm part no. 0020020718
£33.26
51 Part number 0020026460, Lip seal LIP SEAL
Glowworm part no. 0020026460
£6.62
52 Part number 0020038076, Gasket exchanger / flue GASKET EXCHANGER / FLUE
Glowworm part no. 0020038076
£7.89
52 Part number 2000801616, NOW USE 0020038076 FLUE SEAL NOW USE 0020038076 FLUE SEAL
Glowworm part no. 2000801616

53 Part number 0020020716, flue duct top assembly FLUE DUCT TOP ASSEMBLY
Glowworm part no. 0020020716
£58.23
55 Part number 0020020744, expansion vessel EXPANSION VESSEL
Glowworm part no. 0020020744
£102.11
56   CLIP, FIXING BRACKET
Glowworm part no. 0020020745
£9.64
57 Part number 0020020746, nut NUT
Glowworm part no. 0020020746
£6.61
58   SCREW
Glowworm part no. 0020020747
£6.61
59 Part number 0020020752, Pipe, EV PIPE, EV
Glowworm part no. 0020020752
£18.55
60 Part number 0020020753, O-ring O-RING
Glowworm part no. 0020020753
£6.61
61 Part number 0020014164, Wire retaining clip (PK10) WIRE RETAINING CLIP (PK10)
Glowworm part no. 0020014164
£8.47
61 Part number 0020020754, NOW USE 0020014164 CLIP NOW USE 0020014164 CLIP
Glowworm part no. 0020020754

62 Part number 0020020755, Washer WASHER
Glowworm part no. 0020020755
£6.61
63 Part number 0020014183, O-ring (PK10) O-RING (PK10)
Glowworm part no. 0020014183
£11.19
64 Part number 0020014178, filter FILTER
Glowworm part no. 0020014178
£12.13
65 Part number 0020014167, support SUPPORT
Glowworm part no. 0020014167
£96.15
66 Part number 0020014182, Gasket Type-C (PK10) GASKET TYPE-C (PK10)
Glowworm part no. 0020014182
£10.61
67 Part number 0020014165, Screw (PK10) SCREW (PK10)
Glowworm part no. 0020014165
£8.41
68 Part number 0020014161, automatic air vent AUTOMATIC AIR VENT
Glowworm part no. 0020014161
£21.92
69 Part number 801672, O RING O RING
Glowworm part no. 801672
£6.61
70 Part number 0020014185, Clip (PK10) CLIP (PK10)
Glowworm part no. 0020014185
£18.28
71 Part number 0020014173, NOW USE 0020047005 pressure relief valve(3 bar) NOW USE 0020047005 PRESSURE RELIEF VALVE(3 BAR)
Glowworm part no. 0020014173

71 Part number 0020047005, Pressure relief valve, 3 bar PRESSURE RELIEF VALVE, 3 BAR
Glowworm part no. 0020047005
£14.99
72 Part number 0020014171, pump PUMP
Glowworm part no. 0020014171

72 Part number 0020014180, NOW USE 0020014171 pump motor NOW USE 0020014171 PUMP MOTOR
Glowworm part no. 0020014180

73 Part number 0020014171, pump PUMP
Glowworm part no. 0020014171

74   SCREW (PK10)
Glowworm part no. 0020014189
£8.76
75 Part number 0020014170, NOW USE 0020038628 clip NOW USE 0020038628 CLIP
Glowworm part no. 0020014170

75 Part number 0020038628, CLIP CLIP
Glowworm part no. 0020038628
£5.80
76 Part number 0020014172, support SUPPORT
Glowworm part no. 0020014172
£33.12
78 Part number 0020014181, pipe PIPE
Glowworm part no. 0020014181
£22.30
79 Part number 0020014186, Nut (PK4) NUT (PK4)
Glowworm part no. 0020014186
£7.49
80 Part number 0020014193, Sealing ring (PK10) SEALING RING (PK10)
Glowworm part no. 0020014193
£6.61
81 Part number 0020014183, O-ring (PK10) O-RING (PK10)
Glowworm part no. 0020014183
£11.19
82 Part number 0020014191, Connection piece (dummy 3-way valve) CONNECTION PIECE (DUMMY 3-WAY VALVE)
Glowworm part no. 0020014191
£82.81
83 Part number 0020014169, bypass BYPASS
Glowworm part no. 0020014169
£31.19
84 Part number 0020014195, O-ring (PK10) O-RING (PK10)
Glowworm part no. 0020014195
£6.61
85 Part number 0020014164, Wire retaining clip (PK10) WIRE RETAINING CLIP (PK10)
Glowworm part no. 0020014164
£8.47
86 Part number 0020014166, Gasket, C-Type, (PK10) GASKET, C-TYPE, (PK10)
Glowworm part no. 0020014166
£10.01
87 Part number 0020014179, pipe PIPE
Glowworm part no. 0020014179
£18.73
88 Part number 0020014190, NOW USE 0020079644 CH PRESSURE SENSOR NOW USE 0020079644 CH PRESSURE SENSOR
Glowworm part no. 0020014190

88 Part number 0020079644, Sensor SENSOR
Glowworm part no. 0020079644
£26.42
89 Part number 0020014177, O-ring (PK10) O-RING (PK10)
Glowworm part no. 0020014177
£6.61
90 Part number 0020020763, igniter IGNITER
Glowworm part no. 0020020763
£28.53
91 Part number 0020020766, casing (installer housing) CASING (INSTALLER HOUSING)
Glowworm part no. 0020020766
£10.55
92   STRIP, 8 POLE CONNECTOR
Glowworm part no. 0020020767
£7.81
93   STRIP, 5 POLE TERM 230V EARTH
Glowworm part no. 0020020768
£6.61
94   STRIP, 3 POLE TERM 230V N L E
Glowworm part no. 0020020769
£6.61
95   COVER (INSTALLER HOOD)
Glowworm part no. 0020020770
£6.61
96 Part number 0020020774, Support (PK2) SUPPORT (PK2)
Glowworm part no. 0020020774
£6.61
97   SCREW
Glowworm part no. 0020020776
£6.61
98 Part number 0020020773, Screw torx 4.2x13.5mm SCREW TORX 4.2X13.5MM
Glowworm part no. 0020020773
£6.61
99 Part number 0020025181, control box front (combi/system) CONTROL BOX FRONT (COMBI/SYSTEM)
Glowworm part no. 0020025181
£21.13
100 Part number 0020025184, control box rear CONTROL BOX REAR
Glowworm part no. 0020025184
£10.76
101 Part number 0020025183, appliance interface harness APPLIANCE INTERFACE HARNESS
Glowworm part no. 0020025183
£13.27
102 Part number 0020023825, PCB main PCB MAIN
Glowworm part no. 0020023825
£192.24
103 Part number 0020023826, appliance interface APPLIANCE INTERFACE
Glowworm part no. 0020023826
£117.50
104   CLIP (HARNESS)
Glowworm part no. 0020020784
£6.61
105 Part number 0020020777, cable tree (mains inlet harness) CABLE TREE (MAINS INLET HARNESS)
Glowworm part no. 0020020777
£15.60
106 Part number 0020020778, Cable tree (combustion harness) CABLE TREE (COMBUSTION HARNESS)
Glowworm part no. 0020020778
£29.44
107   CABLE TREE (24V DC ROOM STAT HARNESS)
Glowworm part no. 0020020779
£12.67
108 Part number 0020020780, cable tree (zig harness) CABLE TREE (ZIG HARNESS)
Glowworm part no. 0020020780
£14.81
109 Part number 0020020783, cable (ignition lead assembly) CABLE (IGNITION LEAD ASSEMBLY)
Glowworm part no. 0020020783
£44.25
110 Part number 0020020782, Gasket (control box front) GASKET (CONTROL BOX FRONT)
Glowworm part no. 0020020782
£6.61
111 Part number 0020020781, NOW USE S5739800 temperature monitor NOW USE S5739800 TEMPERATURE MONITOR
Glowworm part no. 0020020781

111 Part number S5739800, Temperature sensor TEMPERATURE SENSOR
Glowworm part no. S5739800
£23.87
112 Part number 0020026405, NOW USE 0020079603 fuse NOW USE 0020079603 FUSE
Glowworm part no. 0020026405

112 Part number 0020079603, Fuse 2,0 A T2H (PK10) FUSE 2,0 A T2H (PK10)
Glowworm part no. 0020079603
£14.09
113 Part number 0020014404, harness HARNESS
Glowworm part no. 0020014404
£18.73
114 Part number 0020026408, Tap, central heating TAP, CENTRAL HEATING
Glowworm part no. 0020026408
£48.27
115 Part number 0020026409, Gas tap GAS TAP
Glowworm part no. 0020026409
£45.61
116 Part number 0020026410, clip CLIP
Glowworm part no. 0020026410
£6.61
119 Part number 0020020788, Pipe pack PIPE PACK
Glowworm part no. 0020020788
£49.28
121   SUPPORT, HEAT EXCHANGER TOP
Glowworm part no. 0020020712
£8.01
122 Part number 0020026406, Gasket kit GASKET KIT
Glowworm part no. 0020026406
£9.32
123 Part number 0020054162, Resonator RESONATOR
Glowworm part no. 0020054162
£13.72
124 Part number 0020054164, Heat exchanger HEAT EXCHANGER
Glowworm part no. 0020054164
£554.40
125 Part number 0020054165, Silencer SILENCER
Glowworm part no. 0020054165
£46.65
128 Part number 0020037300, housing HOUSING
Glowworm part no. 0020037300
£60.68
129 Part number 0020038262, Box BOX
Glowworm part no. 0020038262
£33.89
130 Part number 0020038263, fitting FITTING
Glowworm part no. 0020038263
£6.61
131 Part number 0020038381, Gasket GASKET
Glowworm part no. 0020038381
£6.61
132   SILENCER
Glowworm part no. 0020055401
£59.28



Heating spares made simple this website is secured by Geotrust
