GLOWWORM
COORDINATE LFC FIRE ONLY 1986 AVA - (Fire Assembly 3)
Appliance Code: 37-315-02

Appliance Diagram


Fire Assembly 3 diagram for Glowworm Coordinate LFC Fire Only 1986 AVAClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

4 Part number SK2330, Screw (No8 X 3/8) SCREW (NO8 X 3/8)
Glowworm part no. SK2330
7   SCREW -M5X10MM
Glowworm part no. SK6214		 £6.61
8 Part number SK6219, Nut NUT
Glowworm part no. SK6219
10   OBSOLETE BOLT-M5 X 95MM HEX A-LIST
Glowworm part no. 403218
12   OBSOLETE D/DIV BAFF NPR RY/FT/FLCO+
Glowworm part no. 411530
13   OBSOLETE DRAUGHT DIV BAFFLE NPF LFC LFL
Glowworm part no. M9391
15   OBSOLETE INSULATION CLIP (PC) FD
Glowworm part no. 424110
18   OBSOLETE INSULATION-25MM G/FIBRE BOARD
Glowworm part no. 210084
19   OBSOLETE SEALING STRIP-588MMSEALS
Glowworm part no. 413815
20   OBSOLETE INSUL-C/C BASE-5MM THICK QC
Glowworm part no. 210053
22   OBSOLETE GAS TAP & PIEZO-G1/10701/3 QC
Glowworm part no. 203612
23   OBSOLETE PIEZO UNIT SPARK
Glowworm part no. 202707
24   SCREW - M4X10MM
Glowworm part no. SK6359
25 Part number SK6361, Shake proof washer (M4) SHAKE PROOF WASHER (M4)
Glowworm part no. SK6361
26   OBSOLETE ELBOW-1/8
Glowworm part no. 204193
27   OBSOLETE SUPP TUBE ASSY-BTM INJTR
Glowworm part no. 424042
29   OBSOLETE BURNER-BRAY BRNRS QC
Glowworm part no. 203244
30 Part number SWW4606, OBSOLETE Ignition lead OBSOLETE IGNITION LEAD
Glowworm part no. SWW4606
31 Part number S202607, ELECTRODE ELECTRODE
Glowworm part no. S202607
31   ELECTRODE
Glowworm part no. 202607
32 Part number SK6218, Nut - M4 NUT - M4
Glowworm part no. SK6218		 £6.61
33 Part number 12604, OBSOLETE INJECTOR-BRAY 18 260 OBSOLETE INJECTOR-BRAY 18 260
Glowworm part no. 12604
34   OBSOLETE INJECTOR-BRAY 77 150 QC
Glowworm part no. 203036
35   OBSOLETE THERMOCOUPLE-ALTERNATIVES QC
Glowworm part no. 900002
35   OBSOLETE THERMOCOUPLE
Glowworm part no. S900002
36   OBSOLETE WASHER-S/PROOF M8
Glowworm part no. 403219
37   OBSOLETE NUT-M8X1MM HEX LOCK BZP
Glowworm part no. 403225
38 Part number 208308, NOW USE S208308 SCREW-M4X10MM+5DG MS PN NOW USE S208308 SCREW-M4X10MM+5DG MS PN
Glowworm part no. 208308
38 Part number S208308, Screw (M4x10mm) SCREW (M4X10MM)
Glowworm part no. S208308		 £6.61
39 Part number S403215, Nut-wing M5 NUT-WING M5
Glowworm part no. S403215
39 Part number 403215, NOW USE S403215 NUT-WING M5 ZP NOW USE S403215 NUT-WING M5 ZP
Glowworm part no. 403215
41   SCREW-M4 X 6MM REC
Glowworm part no. 208365
41   SCREW ( M4 X 6MM )
Glowworm part no. S208365
42   OBSOLETE GLASS PANEL ASSY
Glowworm part no. 424025
43   OBSOLETE CLIP-IGNITION LEAD
Glowworm part no. 208289
44   OBSOLETE CONNECTING SLEEVE
Glowworm part no. 203815
45   OBSOLETE CONNECTING ROD QC
Glowworm part no. 204706
46 Part number SK5148, Split pin -3/32 dia X 3/4 SPLIT PIN -3/32 DIA X 3/4
Glowworm part no. SK5148
47   OBSOLETE WASHER-1/4 X1 MS PLAIN
Glowworm part no. 208375
47   OBSOLETE WASHER-1/4 X1 MS PLAIN
Glowworm part no. S208375
48 Part number SK8019, Screw ( M5X10mm ) SCREW ( M5X10MM )
Glowworm part no. SK8019		 £6.61
49   CLIP - EDGE CABLE
Glowworm part no. SK6899
50   OBSOLETE SCREW-M4X16MM MS PN REC ZP
Glowworm part no. SK6213
52   OBSOLETE REAR SURR TOP ASSEMBLY--PH LFC
Glowworm part no. 427240
53   NUT - SPIRE CAPT NO8
Glowworm part no. SK9327		 £4.91
54   OBSOLETE SEAL-13X10X510MM STRIP
Glowworm part no. 212053
55   OBSOLETE SEAL-CONTROL KNOB
Glowworm part no. 212059
62   OBSOLETE TRIM-LOWER FRONT (NPF) FLCO+
Glowworm part no. 424094
64   OBSOLETE CASING SIDE SUPP (NPF) FL+
Glowworm part no. 424064
66 Part number SFF0652, Screw, no6 x 3/8 SCREW, NO6 X 3/8
Glowworm part no. SFF0652
69   OBSOLETE SCREW-CASE SECURING
Glowworm part no. 208364
70   OBSOLETE PLUG-HOLE-HEYCO DP-1250
Glowworm part no. 204252
72   OBSOLETE FIRE LIGHT CABLE ASSY-395MM
Glowworm part no. 427220
73   OBSOLETE SUPPLY TUBE-SPARE-CO LFC/LFL
Glowworm part no. 800128
74   NOW USE S204226 BUSH-RELIEF - SRB011-BLK
Glowworm part no. 204226
74   BUSH RELIEF
Glowworm part no. S204226
75   OBSOLETE SWITCH ASSEMBLY
Glowworm part no. 427239
76   OBSOLETE FLUE SPIGOT ASSY (SW) LFC LFL
Glowworm part no. 427226
81   OBSOLETE C/C SIDE CHEEK RH
Glowworm part no. 203707
82   OBSOLETE C/C SIDE CHEEK LH
Glowworm part no. 203708
83   OBSOLETE SUPPORT ROD QC
Glowworm part no. 203709
85   OBSOLETE REAR COAL
Glowworm part no. 203703
86   OBSOLETE UPPER COAL RH QC
Glowworm part no. 203704
87   OBSOLETE UPPER COAL LH
Glowworm part no. 203705
88   OBSOLETE UPPER COAL(CENTRE)
Glowworm part no. 203706
91   OBSOLETE KNOB ASSY-H/CAPPED PERSON
Glowworm part no. 409278
95 Part number 202019, OBSOLETE SOCKET-ELKAY 6603-2 OBSOLETE SOCKET-ELKAY 6603-2
Glowworm part no. 202019
95 Part number S202018, Electrical Plug ELECTRICAL PLUG
Glowworm part no. S202018
95 Part number S202019, OBSOLETE Electrical Socket OBSOLETE ELECTRICAL SOCKET
Glowworm part no. S202019
95 Part number 202018, PLUG-ELKAY 6603-1 PLUG-ELKAY 6603-1
Glowworm part no. 202018
96   OBSOLETE INJECTOR BOX PLT. (PCF) FLCO+
Glowworm part no. 424092
