GLOWWORM
BETACOM 30C - (Assembly 1)
Appliance Code: 47-019-09

Appliance Diagram


Assembly 1 diagram for Glowworm Betacom 30CClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   FRONT PANEL - 24KW
Glowworm part no. 0020061546
1   FRONT PANEL - 28KW
Glowworm part no. 0020061547		 £64.54
2   SIDE PANEL
Glowworm part no. 0020061548		 £69.26
3   HANGING BRACKET
Glowworm part no. 0020061549		 £15.78
4   INSULATION PLATE
Glowworm part no. 0020061550		 £9.81
5   SCREW 3,9X13 (PK10)
Glowworm part no. 0020061551		 £6.61
6 Part number 0020061552, Combustion Front - 24Kw COMBUSTION FRONT - 24KW
Glowworm part no. 0020061552		 £45.95
6   COMBUSTION FRONT - 28KW
Glowworm part no. 0020061553		 £45.95
7   NOW USE 0020080622 CONDENSING TRAP CAP
Glowworm part no. 0020063473
7   CONDENSATE CAP
Glowworm part no. 0020080622		 £13.00
8   COPPER GASKET (PK10)
Glowworm part no. 0020063461		 £6.61
10   COMB. CHAMBER PANEL REAR
Glowworm part no. 0020063457		 £19.83
10   COMBUSTION REAR
Glowworm part no. 0020063458		 £29.84
11   COMB. CHAMBER PANEL - RIGHT
Glowworm part no. 0020061554
12   COMB. CHAMBER PANEL - LEFT
Glowworm part no. 0020061555		 £23.89
13   ISOLATION PLATE FRONT - 24KW (PK5)
Glowworm part no. 0020061556		 £18.59
13 Part number 0020061557, Isolation Plate Front - 28Kw ISOLATION PLATE FRONT - 28KW
Glowworm part no. 0020061557		 £23.89
14   ISOLATION PLATE REAR - 24KW
Glowworm part no. 0020061558		 £19.83
14   ISOLATION PLATE REAR - 28KW
Glowworm part no. 0020061559		 £23.89
15   ISOLATION PLATE SIDE
Glowworm part no. 0020061560		 £10.77
16   DEFLECTOR - RIGHT
Glowworm part no. 0020061561		 £6.61
17   DEFLECTOR - LEFT
Glowworm part no. 0020061562		 £10.77
20   BURNER - 24KW
Glowworm part no. 0020061564		 £128.68
20   BURNER - 28KW
Glowworm part no. 0020061565		 £128.68
21   INJECTOR 24KW (1.20 MM)
Glowworm part no. 0020061567		 £45.95
21   INJECTOR 28KW (1.15 MM)
Glowworm part no. 0020061568		 £45.95
22   BURNER RAIL (24 KW)
Glowworm part no. 0020061569		 £63.79
22 Part number 0020061570, Burner rail ( 28 KW ) BURNER RAIL ( 28 KW )
Glowworm part no. 0020061570		 £76.82
23   IGNITION ELECTRODE - RIGHT
Glowworm part no. 0020061571		 £19.83
24   IGNITION ELECTRODE - LEFT
Glowworm part no. 0020061572		 £19.83
25 Part number 0020061573, Control Electrode CONTROL ELECTRODE
Glowworm part no. 0020061573		 £20.96
27   SCREW (PK10)
Glowworm part no. 0020063469		 £6.61
28   NOW USE 0020061576 SCREW (PK10)
Glowworm part no. 0020063480
28   SCREW 3,9X6,5 (PK10)
Glowworm part no. 0020061576		 £6.61
36   CHASSIS LOWER - 24 KW
Glowworm part no. 0020061594		 £45.95
37   SCREW 4X10 (PK10)
Glowworm part no. 0020061596		 £6.61
38   SCREW 4,8X12,5 PT (PK10)
Glowworm part no. 0020061597		 £5.58
39   CIRCULATION PUMP
Glowworm part no. 0020061598
40   NIPPLE (3/4)
Glowworm part no. 0020061599		 £15.78
41   CLIP FOR PUMP CONNECTION NUT (PK10)
Glowworm part no. 0020061600		 £6.61
42   CLIP FOR EXPANSION VESSEL (PK10)
Glowworm part no. 0020061601		 £58.46
43 Part number 0020061602, Gas Valve GAS VALVE
Glowworm part no. 0020061602		 £216.15
44 Part number 0020061603, Gasket 24x18x1.5 3/4 (PK10) GASKET 24X18X1.5 3/4 (PK10)
Glowworm part no. 0020061603		 £6.61
45   PIPE - GAS
Glowworm part no. 0020061604		 £38.19
46   SEAL FOR GAS PIPE CONN (PK10)
Glowworm part no. 0020061605		 £7.16
49 Part number 0020061608, Flow Sensor and cable FLOW SENSOR AND CABLE
Glowworm part no. 0020061608		 £53.88
50   PIPE - DRAIN
Glowworm part no. 0020061609		 £10.77
51   NOW USE 0020064054 3 WAY VALVE FRONT PLUG
Glowworm part no. 0020064053
51   3 WAY VALVE SHAFT (PK5)
Glowworm part no. 0020064054		 £39.43
52 Part number 0020061610, Safety valve SAFETY VALVE
Glowworm part no. 0020061610		 £28.05
53   HYDROBLOCK (RETURN GROUP)
Glowworm part no. 0020061611		 £81.25
54   GASKET (PK10)
Glowworm part no. 0020061612		 £6.61
55 Part number 0020064048, O-Ring (PK10) O-RING (PK10)
Glowworm part no. 0020064048		 £6.61
56 Part number 0020061615, Plate To Plate - 28Kw PLATE TO PLATE - 28KW
Glowworm part no. 0020061615		 £176.32
56 Part number 0020061614, Plate To Plate - 24Kw PLATE TO PLATE - 24KW
Glowworm part no. 0020061614		 £133.47
57   OBSOLETE O-RING (PK10)
Glowworm part no. 0020061616
58 Part number 0020064049, Hydroblock Flow HYDROBLOCK FLOW
Glowworm part no. 0020064049		 £239.16
59 Part number 0020061613, NOW USE 0020118638 Ntc Sensor NOW USE 0020118638 NTC SENSOR
Glowworm part no. 0020061613
59 Part number 0020118638, Sensor - ntc immersion (-40c to 110c) SENSOR - NTC IMMERSION (-40C TO 110C)
Glowworm part no. 0020118638		 £32.06
60   CLIP (PK10)
Glowworm part no. 0020064051		 £3.38
61   SCREW, 5X18 (PK10)
Glowworm part no. 0020061620		 £6.61
62 Part number 0020061621, NOW USE 0020118640 3 Way Valve Motor NOW USE 0020118640 3 WAY VALVE MOTOR
Glowworm part no. 0020061621
62 Part number 0020118640, Diverter Valve Motor 3WV ELBI DIVERTER VALVE MOTOR 3WV ELBI
Glowworm part no. 0020118640		 £67.15
63   3 WAY VALVE SHAFT (PK5)
Glowworm part no. 0020064054		 £39.43
64   NOW USE 0020080621CONDENSATE TRAP
Glowworm part no. 0020061627
64   CONDENSATE TRAP
Glowworm part no. 0020080621		 £20.47
65   CONDENSATE HOSE - 50 CM
Glowworm part no. 0020061628		 £6.61
66   NOW USE 0020061630 HYDROBLOCK TURBINE
Glowworm part no. 0020061629
66 Part number 0020061630, Hydroblock Return Group - All Plastics HYDROBLOCK RETURN GROUP - ALL PLASTICS
Glowworm part no. 0020061630		 £40.42
67 Part number 0020061630, Hydroblock Return Group - All Plastics HYDROBLOCK RETURN GROUP - ALL PLASTICS
Glowworm part no. 0020061630		 £40.42
68   SCREW M4X15 (PK10)
Glowworm part no. 0020061577		 £6.61
69 Part number 0020061578, Fan FAN
Glowworm part no. 0020061578		 £246.32
72 Part number 0020061581, NOW USE 0020118646 Ntc NOW USE 0020118646 NTC
Glowworm part no. 0020061581
72   SENSOR - NTC SURFACE TYPE -5C TO 105C
Glowworm part no. 0020118646		 £20.88
73 Part number 0020061582, Fan Hood - 24 Kw FAN HOOD - 24 KW
Glowworm part no. 0020061582		 £38.19
73 Part number 0020061583, Fan Hood - 28 Kw FAN HOOD - 28 KW
Glowworm part no. 0020061583		 £56.75
74   THERMOSTAT
Glowworm part no. 0020061584		 £18.18
75   CLIP FOR THERMOSTAT (PK10)
Glowworm part no. 0020061585		 £6.61
76   OBSOLETE CLIP FOR COPPER PIPES (PK10)
Glowworm part no. 0020061586
77   PIPE - INLET
Glowworm part no. 0020061587		 £29.84
78   O-RING FOR COPPER PIPES (PK10)
Glowworm part no. 0020061588		 £6.61
79 Part number 0020061589, Heat Exchanger 24 Kw HEAT EXCHANGER 24 KW
Glowworm part no. 0020061589		 £285.13
79   HEAT EXCHANGER 28 KW
Glowworm part no. 0020061590		 £367.74
80   OUTLET PIPE-CENTRAL HEATING
Glowworm part no. 0020061591		 £23.89
82   SCREW M5X50 (PK10)
Glowworm part no. 0020061631		 £6.61
83   HEAT EXCHANGER TOP
Glowworm part no. 0020061632		 £60.68
84   CLIP (PK10)
Glowworm part no. 0020061633		 £6.61
85 Part number 0020061634, Heat Exchanger Complete HEAT EXCHANGER COMPLETE
Glowworm part no. 0020061634		 £112.26
88   GASKET
Glowworm part no. 0020061636		 £9.81
89   HEAT EXCHANGER BOTTOM
Glowworm part no. 0020061637		 £29.84
90   PIPE - OUTLET
Glowworm part no. 0020061638		 £19.83
91   PIPE - INLET
Glowworm part no. 0020061639		 £19.83
92 Part number 0020064057, Gasket GASKET
Glowworm part no. 0020064057		 £35.64
93   DRAIN HOSE
Glowworm part no. 0020061641		 £15.78
94 Part number 0020061642, Clip (Pk10) CLIP (PK10)
Glowworm part no. 0020061642		 £7.17
100   EXPANSION VESSEL 7 LT
Glowworm part no. 0020061657		 £145.70
101   CHASSIS 24 KW
Glowworm part no. 0020061658		 £86.69
101   CHASSIS 28 KW
Glowworm part no. 0020061659		 £121.30
102 Part number 0020061660, Flexible Hose FLEXIBLE HOSE
Glowworm part no. 0020061660		 £15.78
105   CASING 24 KW
Glowworm part no. 0020061661		 £86.69
105   CASING 28 KW
Glowworm part no. 0020061662		 £99.59
108   GASKET (PK10)
Glowworm part no. 0020061663		 £6.61
109   FRONT COVER 24 KW
Glowworm part no. 0020061664		 £86.69
110 Part number 0020064058, Air Pressure Switch AIR PRESSURE SWITCH
Glowworm part no. 0020064058		 £41.13
111   VALVE SET
Glowworm part no. 0020061672		 £145.70
113   PLASTIC COVER
Glowworm part no. 0020064059		 £6.61
114   HOSE
Glowworm part no. 0020064060		 £8.68
115   CAP
Glowworm part no. 0020064061		 £6.61
118   GASKET (PK10)
Glowworm part no. 0020061671		 £25.57
125   NOW USE 0020084807 CONTROL KNOB
Glowworm part no. 0020061643
125   CONTROL KNOB (PK10)
Glowworm part no. 0020084807		 £11.20
126   SPINDLE GREY PK 10
Glowworm part no. 0020061644		 £6.61
127 Part number 0020061645, NOW USE 0020118643 Button NOW USE 0020118643 BUTTON
Glowworm part no. 0020061645
127 Part number 0020118643, Spindle white (PK10) SPINDLE WHITE (PK10)
Glowworm part no. 0020118643		 £9.96
128   CONTROL PANEL
Glowworm part no. 0020061646		 £23.89
129   INTERFACE BOARD
Glowworm part no. 0020061647		 £57.10
130   PRESSURE GAUGE
Glowworm part no. 0020061648		 £56.75
131   TIMER
Glowworm part no. 0020061649		 £104.78
132   HARNESS
Glowworm part no. 0020061650		 £114.41
133   INTERFACE HARNESS
Glowworm part no. 0020061651		 £19.83
134 Part number 0020061652, Cover Rear COVER REAR
Glowworm part no. 0020061652		 £19.83
135   COVER MIDDLE
Glowworm part no. 0020061653		 £19.83
136   PCB
Glowworm part no. 0020061654		 £252.70
137   SCREW 3,5X8 (PK10)
Glowworm part no. 0020061655		 £6.61
138   SCREW (PK10)
Glowworm part no. 0020063474		 £6.61
151   GASKET (PK5)
Glowworm part no. 0020064063		 £11.07
152   FLUE ADAPTER
Glowworm part no. 0020063479		 £23.89
153   PIPE - OUTLET
Glowworm part no. 0020064050		 £19.83
154   GASKET (PK10)
Glowworm part no. 0020064052		 £6.61
155 Part number 0020063470, O-Ring (PK10) O-RING (PK10)
Glowworm part no. 0020063470		 £6.61
156   NOW USE 0020061588 O RING (PK10)
Glowworm part no. 0020061640
156   O-RING FOR COPPER PIPES (PK10)
Glowworm part no. 0020061588		 £6.61
157   M5 NUT (PK10)
Glowworm part no. 0020063484		 £6.61
158   GASKET - DRAIN PIPE (PK10)
Glowworm part no. 0020061622		 £6.61
163   SUPPORT BRACKET
Glowworm part no. 0020063481		 £6.61
164   SUPPORT BRACKET
Glowworm part no. 0020063482		 £6.61
165   RESTRICTOR - AIR 24KW
Glowworm part no. 0020063477		 £9.81
165   RESTRICTOR - AIR 28KW
Glowworm part no. 0020063478		 £10.77
167   PLATE - REAR PATCH 24-28 KW BURNER
Glowworm part no. 0020063466		 £15.78
168   PLATE - BURNER FRONT 24KW
Glowworm part no. 0020063467		 £15.78
168   PLATE - BURNER FRONT 28KW
Glowworm part no. 0020064047		 £15.78
171   THERMOSTAT
Glowworm part no. 0020061592		 £18.18
172   CLIP FOR THERMOSTAT (PK10)
Glowworm part no. 0020061593		 £6.61
173 Part number 0020063476, Gasket (Pk10) GASKET (PK10)
Glowworm part no. 0020063476		 £25.57
173 Part number 0020063468, Gasket - Fan hood GASKET - FAN HOOD
Glowworm part no. 0020063468		 £6.61
174   ELBOW (PK5)
Glowworm part no. 0020063485		 £58.46
175   SCREW 3,5X20 (PK10)
Glowworm part no. 0020061656		 £6.61
175   SCREW (PK10)
Glowworm part no. 0020063471
176   SCREW (PK10)
Glowworm part no. 0020063472		 £6.61
181   SCREW (PK10)
Glowworm part no. 0020064064		 £6.61
182 Part number 0020064065, Gasket (Pk5) GASKET (PK5)
Glowworm part no. 0020064065		 £17.10
184   SUPPORT RING (PK10)
Glowworm part no. 0020064062		 £15.55


Heating spares made simple this website is secured by Geotrust

 HSP K J Plumbing Factors

Copyright ©2020 >Heating Spare Parts - All Rights Reserved

Site Map | About Us | Parts Lists & Diagrams | Privacy Policy | Terms & Conditions

Facebook Twitter
