GLOWWORM
BETACOM 28A 2011-2012 - (09 Hydraulics)
Appliance Code: 47-019-14

Appliance Diagram


09 Hydraulics diagram for Glowworm Betacom 28A 2011-2012Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 0020079644, Sensor SENSOR
Glowworm part no. 0020079644
£26.42
2 Part number 2000801950, O-ring for pipe (PK20) O-RING FOR PIPE (PK20)
Glowworm part no. 2000801950
£10.83
3   PRESSURE RELIEF VALVE
Glowworm part no. 0020118190
£7.62
4 Part number 0020118194, Hydraulic block HYDRAULIC BLOCK
Glowworm part no. 0020118194
£115.74
5 Part number 0020014164, Wire retaining clip (PK10) WIRE RETAINING CLIP (PK10)
Glowworm part no. 0020014164
£8.47
6   CLIP (PK10)
Glowworm part no. 0020118161
£7.64
7 Part number 0020018450, Clip (PK10) CLIP (PK10)
Glowworm part no. 0020018450
£33.09
7   CLIP DOMESTIC HOT WATER SENSOR (PK10)
Glowworm part no. 0020022948
£5.66
8 Part number 2000802473, O-ring heat Ex / Pipe (PK10) O-RING HEAT EX / PIPE (PK10)
Glowworm part no. 2000802473
£6.61
9 Part number 0020061608, Flow Sensor and cable FLOW SENSOR AND CABLE
Glowworm part no. 0020061608
£53.88
10   CLIP (PK10)
Glowworm part no. 0020118161
£7.64
11 Part number 0020136540, Heat exchanger DHW HEAT EXCHANGER DHW
Glowworm part no. 0020136540
£79.37
12 Part number 0020014678, O-Ring (PK10) O-RING (PK10)
Glowworm part no. 0020014678
£11.38
13 Part number 0020063470, O-Ring (PK10) O-RING (PK10)
Glowworm part no. 0020063470
£6.61
14   SEALING RING FLAT 30X20X2.1 PUMP (PK20)
Glowworm part no. A000035177
£13.68
15 Part number 0020018569, NOW USE S1024500 automatic air vent NOW USE S1024500 AUTOMATIC AIR VENT
Glowworm part no. 0020018569

15 Part number S1024500, Automatic de-aerator AUTOMATIC DE-AERATOR
Glowworm part no. S1024500
£22.24
16   CLIP (PK10)
Glowworm part no. 0020118137
£7.70
17 Part number 0020118139, NOW USE 0010034156 Pump NOW USE 0010034156 PUMP
Glowworm part no. 0020118139

17   PUMP - HIGH EFFICENCY (CABLE 0010032775 AND PLUG 0010026674 MUST BE PURCHASED WITH THIS PART)
Glowworm part no. 0010034156
£321.77
18   SCREW (X10)
Glowworm part no. 0020118177
£7.88
19   NIPPLE
Glowworm part no. 0020118175
£14.56
20 Part number 0020063470, O-Ring (PK10) O-RING (PK10)
Glowworm part no. 0020063470
£6.61
21   SCREW - IGN FLAME ELEC (PK50)
Glowworm part no. 2000801960
£5.13
21 Part number S5490600, Screw (pk50) SCREW (PK50)
Glowworm part no. S5490600
£14.38
22   HYDRAULIC BLOCK 10L
Glowworm part no. 0020118162
£100.76
23 Part number A000024274, Screw M5x20 H/E plate (PK25) SCREW M5X20 H/E PLATE (PK25)
Glowworm part no. A000024274
£31.18
24   CLIP (PK10)
Glowworm part no. 0020064051
£3.38
24   CLIP - 3 WAY VALVE MOTOR PK10
Glowworm part no. 0020118655
£33.68
25 Part number 0020061621, NOW USE 0020118640 3 Way Valve Motor NOW USE 0020118640 3 WAY VALVE MOTOR
Glowworm part no. 0020061621

25 Part number 0020118640, Diverter Valve Motor 3WV ELBI DIVERTER VALVE MOTOR 3WV ELBI
Glowworm part no. 0020118640
£67.15
