FERROLI
F24E (03/2000) - (Water Line)
Appliance Code: 47-267-31

Appliance Diagram


Water Line diagram for Ferroli F24E (03/2000)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

15   FLUE GAS BAFFLE MODENA/DOMINA (806302)
Ferroli part no. 32913020		 £1.76
19 Part number 34007880, NUT - 1/2" JIG VALVE NUT - 1/2" JIG VALVE
Ferroli part no. 34007880		 £2.52
20 Part number 34007430, NUT - 3/4" JIG VALVE NUT - 3/4" JIG VALVE
Ferroli part no. 34007430		 £1.62
24 Part number 34300392, NOW USE 39805640 SPRING - THERMOSTAT NOW USE 39805640 SPRING - THERMOSTAT
Ferroli part no. 34300392
24 Part number 39805640, SPRING - THERMOSTAT SPRING - THERMOSTAT
Ferroli part no. 39805640		 £5.89
25 Part number 34300450, SPRING - EXPANSION VESSEL SPRING - EXPANSION VESSEL
Ferroli part no. 34300450		 £1.17
26 Part number 34300460, SPRING - HEAT EXCHANGER SPRING - HEAT EXCHANGER
Ferroli part no. 34300460		 £24.60
27 Part number 34300510, SPRING - THERMOSTAT SPRING - THERMOSTAT
Ferroli part no. 34300510		 £0.46
29 Part number 39812310, FILTER - DHW FILTER - DHW
Ferroli part no. 39812310		 £6.93
34 Part number 35100970, GASKET - CONICAL RUBBER INSERT LEFT E50 GASKET - CONICAL RUBBER INSERT LEFT E50
Ferroli part no. 35100970		 £1.28
37 Part number 39807230, O-RING KIT- (10) PUMP ASSEMBLY (17mm) O-RING KIT- (10) PUMP ASSEMBLY (17MM)
Ferroli part no. 39807230		 £8.19
45 Part number 35101850, NOW USE 39822800 GASKET - PUMP /EXPANSION VESSEL NOW USE 39822800 GASKET - PUMP /EXPANSION VESSEL
Ferroli part no. 35101850
45 Part number 39822800, GASKET - PUMP /EXPANSION VESSEL GASKET - PUMP /EXPANSION VESSEL
Ferroli part no. 39822800		 £9.29
52 Part number 39805620, SENSOR - 10K NTC PAIR (WET) SENSOR - 10K NTC PAIR (WET)
Ferroli part no. 39805620		 £21.97
54 Part number 39800160, THERMOSTAT - 88 DEG CH LIMIT THERMOSTAT - 88 DEG CH LIMIT
Ferroli part no. 39800160		 £7.38
55 Part number 39800170, THERMOSTAT - 100C LIMIT THERMOSTAT - 100C LIMIT
Ferroli part no. 39800170		 £8.13
56 Part number 39805910, FLOW METER - ANGLED FLOW METER - ANGLED
Ferroli part no. 39805910		 £51.19
58 Part number 39806180, SENSOR - LOW WATER PRESSURE KIT SENSOR - LOW WATER PRESSURE KIT
Ferroli part no. 39806180		 £28.50
68 Part number 39808300, PUMP ASSEMBLY - C/H ( UNIVERSAL KIT ) PUMP ASSEMBLY - C/H ( UNIVERSAL KIT )
Ferroli part no. 39808300		 £250.71
71 Part number 39804890, EXPANSION VESSEL - ( 8 LITRE ) EXPANSION VESSEL - ( 8 LITRE )
Ferroli part no. 39804890		 £117.44
73 Part number 39801250, RESTRICTOR - FLOW ( 7/LPM) RESTRICTOR - FLOW ( 7/LPM)
Ferroli part no. 39801250		 £5.91
74 Part number 39807480, HEAT EXCHANGER HEAT EXCHANGER
Ferroli part no. 39807480
78 Part number 39805920, SAFETY VALVE - C/W MANIFOLD SAFETY VALVE - C/W MANIFOLD
Ferroli part no. 39805920		 £67.09
79 Part number 38410940, PIPE - FLOW METER TO HX ( MF03 VERSION ) PIPE - FLOW METER TO HX ( MF03 VERSION )
Ferroli part no. 38410940		 £20.45
