BAXI
WM 51/3 RS - (Boiler)
Appliance Code: 41-077-34

Appliance Diagram


Boiler diagram for Baxi WM 51/3 RSClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   OBSOLETE PANEL - FRONT 100304 41-077-34 364-492
Baxi part no. 100304

2   OBSOLETE TRIM-FACIA-RIDGED-603-513 RS
Baxi part no. 102296

3   OBSOLETE PANEL DOOR 100305 41-077-34 364-493
Baxi part no. 100305

4   OBSOLETE ASSY PANEL SIDE
Baxi part no. 100301

5 Part number 112000, STUD-FOREST-FAST-SRV-1762-17-0 STUD-FOREST-FAST-SRV-1762-17-0
Baxi part no. 112000
£2.50
6 Part number 062452, WASHER SHAKEPROOF INT-M5-ZN PD WASHER SHAKEPROOF INT-M5-ZN PD
Baxi part no. 062452
£3.12
7   NUT-HEXAGON-M5-STEEL-
Baxi part no. 062440
£3.01
8 Part number 102012, NUT-CAPT-U-TYPE-No8 ZNPD CHRM NUT-CAPT-U-TYPE-NO8 ZNPD CHRM
Baxi part no. 102012
£3.12
9   OBSOLETE CATCH-MAG DOOR-WM532-381RS
Baxi part no. 102104

10   OBSOLETE ASSY CABINET COMPLETE WM 513RS
Baxi part no. 100303

11   OBSOLETE TRIM-TOP-WM-513-RS
Baxi part no. 100306

12   NUT-WING-M6-ZN-PD
Baxi part no. 112028

13 Part number 062549, SCR-ST-No8x1/2 POZI FLANGE SCR-ST-NO8X1/2 POZI FLANGE
Baxi part no. 062549
£3.12
14   OBSOLETE BOX COMBUSTION - WM513RS
Baxi part no. 100317

15   OBSOLETE BRKT-SUPPORT-O/CASE ASSY-LH
Baxi part no. 100318

16   OBSOLETE NUT CAPTIVE - U TYPE NO 8
Baxi part no. 102247

17 Part number 062548, SCR-ST-No 8x3/8in POZI FL.HD A SCR-ST-NO 8X3/8IN POZI FL.HD A
Baxi part no. 062548
£3.01
18   OBSOLETE SUPPORT COMBUSTION BOX LH 100320 41-077-34
Baxi part no. 100320

19   OBSOLETE CABLE/PIPE CLIP (EDGE TYPE) - SPRING STEEL
Baxi part no. 082240

20   CLIP-CABLE-F/E-T/CARR 23790-11
Baxi part no. 062539

20 Part number 062325, CLIP-CABLE-GT CLIP-CABLE-GT
Baxi part no. 062325

21   OBSOLETE SUPPORT COMBUSTION BOX RH 100321 41-077-34
Baxi part no. 100321

22   OBSOLETE PANEL-INSULATION-ASSY-REAR
Baxi part no. 100322

23   SCR-ST-NO8X3/4-PAN HD POZ ZNPD
Baxi part no. 062706
£2.42
24   OBSOLETE INSULATION SIDE WM 513 RS
Baxi part no. 102224

25   WASHER-RETAINING-SPECIAL-ST/S
Baxi part no. 110011
£15.01
26   OBSOLETE ASSY STRAP CONNECTING 513 RS
Baxi part no. 100323

27   OBSOLETE PANEL INSULATION WM 513 RS
Baxi part no. 100324

28   OBSOLETE BRKT-SUPP-O/CASE ASSY RH.51/3
Baxi part no. 100319

29   OBSOLETE PANEL DOOR BOX-COM UPPER
Baxi part no. 100325

30   OBSOLETE KIT-GASKET-C/BOX DOOR WM51/3RS
Baxi part no. 100376

31   OBSOLETE ASSY INSULATION/CARRIER DOOR
Baxi part no. 100326

32 Part number 102028, SEAL-THERMOSTAT PHIAL. SEAL-THERMOSTAT PHIAL.
Baxi part no. 102028
£8.26
33   OBSOLETE PLATE WALL MOUNTING
Baxi part no. 100313

34 Part number 062441, NUT-FULL HEX-6MM ZINC PLTD NUT-FULL HEX-6MM ZINC PLTD
Baxi part no. 062441
£3.01
35   OBSOLETE WASHER PLAIN-6MM ID-ZINC PL
Baxi part no. 062463

36   OBSOLETE SCREW - COACH - 1/4IN X 2 1/4IN SQ HD ZN P
Baxi part no. 364517

37   OBSOLETE PLUG - PLASTIC - TP3 364502 41-077-34 364
Baxi part no. 364502

38   OBSOLETE ASSY DOOR LOWER BOX-COM 513RS
Baxi part no. 100328

40   OBSOLETE PANEL-INSL-DOOR-COMB BOX-LOWER
Baxi part no. 100327

41 Part number 062532, SCR-TF-M4x8mm-PAN POZI ZN PD SCR-TF-M4X8MM-PAN POZI ZN PD
Baxi part no. 062532
£3.01
42   OBSOLETE SHIELD-PILOT-WM-513-RS
Baxi part no. 100307

43   OBSOLETE KIT-SIGHT WINDOW-WM513RS
Baxi part no. 100329

44 Part number 102252, OBSOLETE BURNER-BOILER-AERO-WM513-RS OBSOLETE BURNER-BOILER-AERO-WM513-RS
Baxi part no. 102252

45 Part number 100133, OBSOLETE KIT-GASK-BLR-BNR-WM-532-381RS OBSOLETE KIT-GASK-BLR-BNR-WM-532-381RS
Baxi part no. 100133

46   OBSOLETE PIPE-BOILER BURNER WITH NUT
Baxi part no. 100330

47   OBSOLETE NUT-LOCK-M16
Baxi part no. 102115

48   OBSOLETE INJECTOR-NG-BOILER-BNR-3.4MM
Baxi part no. 102230

49 Part number 062695, NOW USE 7211908 WASHER COPPER INJECTOR SEALING NOW USE 7211908 WASHER COPPER INJECTOR SEALING
Baxi part no. 062695

49 Part number 7211908, WASHER COPPER SEALING WASHER COPPER SEALING
Baxi part no. 7211908
£3.14
50   OBSOLETE SUPPORT-BURNER-WM-513-RS
Baxi part no. 100309

52   OBSOLETE GASKET-PIPE BURNER FEED
Baxi part no. 102250

53   OBSOLETE CLAMP-GAS-BNR-FEED-PIPE-513-RS
Baxi part no. 100310

54   OBSOLETE SUPPORT-VALVE-INLET-ALUM.
Baxi part no. 102232

55   OBSOLETE O RING-21.9MM ID X 2.62MM-TH
Baxi part no. 102233

56   SCR-SET-M4X12MM-PAN HD PZ ZNPD
Baxi part no. 062726

57   OBSOLETE COVER-ELEC-ASSY-WM513RS
Baxi part no. 100371

58   OBSOLETE HI-LO TAPPING SCREW NO. 5 X 25 RECESSED PA
Baxi part no. 404204

60   OBSOLETE SUPPORT-VALVE-OUTLET-BRASS
Baxi part no. 102237

61 Part number 062240, OBSOLETE NIPPLE PRES TEST OBSOLETE NIPPLE PRES TEST
Baxi part no. 062240

62 Part number 102205, NOW USE 5110466 TAP SERVICE NOW USE 5110466 TAP SERVICE
Baxi part no. 102205

62 Part number 5110466, GAS TAP C/W NUT & TAIL PIECE GAS TAP C/W NUT & TAIL PIECE
Baxi part no. 5110466
£46.03
63 Part number 040456, KIT-PIEZO IGN-BERM 552 KIT-PIEZO IGN-BERM 552
Baxi part no. 040456

64   OBSOLETE BRKT-IGNITOR SUPPORT-WM 513 RS
Baxi part no. 100336

65 Part number 102143, LEAD-ELECTRODE-BER552-WM381RS LEAD-ELECTRODE-BER552-WM381RS
Baxi part no. 102143

66 Part number 102024, ELECTRODE-PILOT-IGNITION ELECTRODE-PILOT-IGNITION
Baxi part no. 102024
£7.03
67 Part number 062638, OBSOLETE BURNER PILOT OBSOLETE BURNER PILOT
Baxi part no. 062638

68 Part number 112011, OBSOLETE INJECTOR-PILOT H/WELL-.38/.36A OBSOLETE INJECTOR-PILOT H/WELL-.38/.36A
Baxi part no. 112011

68 Part number 402560, OBSOLETE PILOT INJECTOR (STD) OBSOLETE PILOT INJECTOR (STD)
Baxi part no. 402560

69   OBSOLETE KIT-PIPE PILOT FEED WITH N & O
Baxi part no. 100331

70 Part number 102005, THERM-18/24HWELL-Q309A2721 STD THERM-18/24HWELL-Q309A2721 STD
Baxi part no. 102005
£19.17
71   OBSOLETE KIT-TERMINAL STRIP-WM 51/3 RS
Baxi part no. 100332

72   OBSOLETE SOCKET-3 PIN WITH LEADS
Baxi part no. 100333

73   OBSOLETE COVER ELECTRICAL-TERM STRIP
Baxi part no. 102240

74   OBSOLETE WASHER-ANTI-LOSS
Baxi part no. 112030

75   OBSOLETE WASHER SHAKEPROOF.INT-M4 ZN PD
Baxi part no. 062451

76   OBSOLETE KIT-WIRES-WM 51/3 RS
Baxi part no. 100335

77   OBSOLETE PLUG-3 PIN WITH LEADS
Baxi part no. 100334

78   OBSOLETE CAPACITOR ASSY-WM-3-SERIES
Baxi part no. 100375

79   OBSOLETE HOUSING THERMOSTAT-WM513RS
Baxi part no. 102241

80 Part number 102027, THERMOSTAT KIT K36P1324 THERMOSTAT KIT K36P1324
Baxi part no. 102027
£20.57
81   OBSOLETE COVER-THERMOSTAT-HOUSING
Baxi part no. 102242

82   OBSOLETE KNOB-THERMOSTAT-WM513-RS
Baxi part no. 102243

83 Part number 226216, OBSOLETE KIT-BOILER REPLACEMENT-LARGE OBSOLETE KIT-BOILER REPLACEMENT-LARGE
Baxi part no. 226216

84 Part number 102029BAX, OBSOLETE GASKET-BOILER(Blue) OBSOLETE GASKET-BOILER(BLUE)
Baxi part no. 102029BAX

84 Part number 102029, OBSOLETE GASKET-BOILER OBSOLETE GASKET-BOILER
Baxi part no. 102029

85 Part number 042889, OBSOLETE POCKET-THERMOSTAT 1/4in BSP OBSOLETE POCKET-THERMOSTAT 1/4IN BSP
Baxi part no. 042889

85 Part number 042889BAX, OBSOLETE POCKET-THERMOSTAT 1/4in BSP OBSOLETE POCKET-THERMOSTAT 1/4IN BSP
Baxi part no. 042889BAX

86   KIT-DRAW BAR-BOILER SECURING
Baxi part no. 040890

87   OBSOLETE PLATE-BLR CLAMPING.WM-532RS
Baxi part no. 100113

88 Part number 040665, OBSOLETE BAFFLE-HEAT EXCH-COMB BOX OBSOLETE BAFFLE-HEAT EXCH-COMB BOX
Baxi part no. 040665

89   OBSOLETE BAFFLE-HEAT-EXCH-CENTRE-513RS
Baxi part no. 100311

91 Part number 062637, OBSOLETE GROMMET BOILER END SEAL OBSOLETE GROMMET BOILER END SEAL
Baxi part no. 062637
£4.44
92 Part number 040515, OBSOLETE KIT-ADAPTER-INJECTOR TEE OBSOLETE KIT-ADAPTER-INJECTOR TEE
Baxi part no. 040515

97   OBSOLETE TERM-FLUE-STND-WM-513-383-RS
Baxi part no. 100315

98   OBSOLETE KIT-TRIM-FLUE TERMINAL-51/3RS.
Baxi part no. 100316
