BAXI
WM 38/3 RS - (Optional Extras)
Appliance Code: 41-077-35

Appliance Diagram


Optional Extras diagram for Baxi WM 38/3 RSClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   OBSOLETE PANEL FRONT 100342 41-077-35 364-426
Baxi part no. 100342

2   OBSOLETE TRIM-FACIA-WM383/303/203/RS
Baxi part no. 102253

3   OBSOLETE PANEL DOOR 100343 41-077-35 364-428
Baxi part no. 100343

4   OBSOLETE ASSY PANEL SIDE
Baxi part no. 100301

5 Part number 112000, STUD-FOREST-FAST-SRV-1762-17-0 STUD-FOREST-FAST-SRV-1762-17-0
Baxi part no. 112000
£2.50
6 Part number 062452, WASHER SHAKEPROOF INT-M5-ZN PD WASHER SHAKEPROOF INT-M5-ZN PD
Baxi part no. 062452
£3.12
7   NUT-HEXAGON-M5-STEEL-
Baxi part no. 062440
£3.01
8 Part number 102012, NUT-CAPT-U-TYPE-No8 ZNPD CHRM NUT-CAPT-U-TYPE-NO8 ZNPD CHRM
Baxi part no. 102012
£3.12
9   OBSOLETE CATCH-MAG DOOR-WM532-381RS
Baxi part no. 102104

10   OBSOLETE PANEL TOP AND BOTTOM 100344 41-077-35 364
Baxi part no. 100344

11   OBSOLETE TRIM-TOP-WM-383-303-203-RS
Baxi part no. 100345

12   NUT-WING-M6-ZN-PD
Baxi part no. 112028

13 Part number 062549, SCR-ST-No8x1/2 POZI FLANGE SCR-ST-NO8X1/2 POZI FLANGE
Baxi part no. 062549
£3.12
14   OBSOLETE BOX-COMBUSTION-WM38/3RS
Baxi part no. 100346

15   OBSOLETE BRKT-SUPPORT-O/CASE ASSY-LH
Baxi part no. 100318

16   OBSOLETE NUT CAPTIVE - U TYPE NO 8
Baxi part no. 102247

17 Part number 062548, SCR-ST-No 8x3/8in POZI FL.HD A SCR-ST-NO 8X3/8IN POZI FL.HD A
Baxi part no. 062548
£3.01
18   OBSOLETE SUPPORT COMBUSTION BOX LH 100320 41-077-34
Baxi part no. 100320

19   OBSOLETE CABLE/PIPE CLIP (EDGE TYPE) - SPRING STEEL
Baxi part no. 082240

20   CLIP-CABLE-F/E-T/CARR 23790-11
Baxi part no. 062539

20 Part number 062325, CLIP-CABLE-GT CLIP-CABLE-GT
Baxi part no. 062325

21   OBSOLETE SUPPORT COMBUSTION BOX RH 100321 41-077-34
Baxi part no. 100321

22   ASSY PANEL/INSULATION (SPARES)
Baxi part no. 100352
£37.77
23   SCR-ST-NO8X3/4-PAN HD POZ ZNPD
Baxi part no. 062706
£2.42
24   OBSOLETE INSULATION SIDE WM 513 RS
Baxi part no. 102224

25   WASHER-RETAINING-SPECIAL-ST/S
Baxi part no. 110011
£15.01
26   OBSOLETE ASSY PANEL/INSULATION LH
Baxi part no. 100353

27   OBSOLETE STRAP-CONNECTING
Baxi part no. 100354

28   OBSOLETE ASSY INSULATION/CARRIER
Baxi part no. 100355

29   OBSOLETE BRKT-SUPP-O/CASE ASSY RH.51/3
Baxi part no. 100319

30   OBSOLETE DOOR-COMB BOX UPPER-ASSEMBLY
Baxi part no. 100356

31   OBSOLETE KIT-GSKT-DOOR-C.BOX20-30-383RS
Baxi part no. 100377

32   OBSOLETE PANEL-INSL-COMB BOX DOOR-UPPER
Baxi part no. 100357

33 Part number 102028, SEAL-THERMOSTAT PHIAL. SEAL-THERMOSTAT PHIAL.
Baxi part no. 102028
£8.26
34   OBSOLETE PLATE-WALL-MOUNTING-WM-383-RS
Baxi part no. 100347

35 Part number 062441, NUT-FULL HEX-6MM ZINC PLTD NUT-FULL HEX-6MM ZINC PLTD
Baxi part no. 062441
£3.01
36   OBSOLETE WASHER PLAIN-6MM ID-ZINC PL
Baxi part no. 062463

39   OBSOLETE DOOR-COMB.BOX-LOWER-WM 38/3 RS
Baxi part no. 100358

41   OBSOLETE PANEL-INSL-COMB BOX DOOR-LOWER
Baxi part no. 100359

42 Part number 062532, SCR-TF-M4x8mm-PAN POZI ZN PD SCR-TF-M4X8MM-PAN POZI ZN PD
Baxi part no. 062532
£3.01
43   OBSOLETE SHIELD-PILOT-WM-513-RS
Baxi part no. 100307

44   OBSOLETE KIT-SIGHT WINDOW-WM513RS
Baxi part no. 100329

45   OBSOLETE BURNER-BLR-AEROMATIC-383/303RS
Baxi part no. 102262

46 Part number 100133, OBSOLETE KIT-GASK-BLR-BNR-WM-532-381RS OBSOLETE KIT-GASK-BLR-BNR-WM-532-381RS
Baxi part no. 100133

47   OBSOLETE KIT-PIPE-BOILER FEED
Baxi part no. 100360

48   OBSOLETE NUT-LOCK-M16
Baxi part no. 102115

49   OBSOLETE INJECTOR-BOILER-WM 383 RS.
Baxi part no. 102263

50 Part number 062695, NOW USE 7211908 WASHER COPPER INJECTOR SEALING NOW USE 7211908 WASHER COPPER INJECTOR SEALING
Baxi part no. 062695

50 Part number 7211908, WASHER COPPER SEALING WASHER COPPER SEALING
Baxi part no. 7211908
£3.14
51   OBSOLETE SUPPORT-BURNER-WM-513-RS
Baxi part no. 100309

53   OBSOLETE GASKET-PIPE BURNER FEED
Baxi part no. 102250

54   OBSOLETE CLAMP-GAS-BNR-FEED-PIPE-513-RS
Baxi part no. 100310

55   OBSOLETE SUPPORT-VALVE-INLET-ALUM.
Baxi part no. 102232

56   OBSOLETE O RING-21.9MM ID X 2.62MM-TH
Baxi part no. 102233

57   SCR-SET-M4X12MM-PAN HD PZ ZNPD
Baxi part no. 062726

58   OBSOLETE COVER ELECTRICAL CONNECTION
Baxi part no. 100372

59   OBSOLETE HI-LO TAPPING SCREW NO. 5 X 25 RECESSED PA
Baxi part no. 404204

61   OBSOLETE SUPPORT-VALVE-OUTLET-BRASS
Baxi part no. 102237

63 Part number 062240, OBSOLETE NIPPLE PRES TEST OBSOLETE NIPPLE PRES TEST
Baxi part no. 062240

64 Part number 5110466, GAS TAP C/W NUT & TAIL PIECE GAS TAP C/W NUT & TAIL PIECE
Baxi part no. 5110466
£46.03
64 Part number 102205, NOW USE 5110466 TAP SERVICE NOW USE 5110466 TAP SERVICE
Baxi part no. 102205

65 Part number 040456, KIT-PIEZO IGN-BERM 552 KIT-PIEZO IGN-BERM 552
Baxi part no. 040456

66   OBSOLETE BRKT-IGNITOR SUPPORT-WM 513 RS
Baxi part no. 100336

67 Part number 102143, LEAD-ELECTRODE-BER552-WM381RS LEAD-ELECTRODE-BER552-WM381RS
Baxi part no. 102143

68 Part number 102024, ELECTRODE-PILOT-IGNITION ELECTRODE-PILOT-IGNITION
Baxi part no. 102024
£7.03
69 Part number 062638, OBSOLETE BURNER PILOT OBSOLETE BURNER PILOT
Baxi part no. 062638

70 Part number 402560, OBSOLETE PILOT INJECTOR (STD) OBSOLETE PILOT INJECTOR (STD)
Baxi part no. 402560

70 Part number 112011, OBSOLETE INJECTOR-PILOT H/WELL-.38/.36A OBSOLETE INJECTOR-PILOT H/WELL-.38/.36A
Baxi part no. 112011

71   OBSOLETE KIT-PIPE-PILOT FEED
Baxi part no. 100361

72 Part number 102005, THERM-18/24HWELL-Q309A2721 STD THERM-18/24HWELL-Q309A2721 STD
Baxi part no. 102005
£19.17
73   OBSOLETE KIT-TERMINAL STRIP-WM 51/3 RS
Baxi part no. 100332

74   OBSOLETE SOCKET-3 PIN WITH LEADS
Baxi part no. 100333

75   OBSOLETE COVER ELECTRICAL-TERM STRIP
Baxi part no. 102240

76   OBSOLETE WASHER-ANTI-LOSS
Baxi part no. 112030

77   OBSOLETE WASHER SHAKEPROOF.INT-M4 ZN PD
Baxi part no. 062451

78   OBSOLETE KIT-WIRES-WM 51/3 RS
Baxi part no. 100335

79   OBSOLETE PLUG-3 PIN WITH LEADS
Baxi part no. 100334

80   OBSOLETE CAPACITOR ASSY-WM-3-SERIES
Baxi part no. 100375

81   OBSOLETE HOUSING THERMOSTAT-WM513RS
Baxi part no. 102241

82 Part number 102027, THERMOSTAT KIT K36P1324 THERMOSTAT KIT K36P1324
Baxi part no. 102027
£20.57
83   OBSOLETE COVER-THERMOSTAT-HOUSING
Baxi part no. 102242

84   OBSOLETE KNOB-THERMOSTAT-WM513-RS
Baxi part no. 102243

85 Part number 100159, BOILER ASSEMBLY WM 381-281 RS BOILER ASSEMBLY WM 381-281 RS
Baxi part no. 100159

85 Part number 040064BAX, OBSOLETE BOILER-ASSEMBLY-B401 OBSOLETE BOILER-ASSEMBLY-B401
Baxi part no. 040064BAX

86 Part number 042889, OBSOLETE POCKET-THERMOSTAT 1/4in BSP OBSOLETE POCKET-THERMOSTAT 1/4IN BSP
Baxi part no. 042889

86 Part number 042889BAX, OBSOLETE POCKET-THERMOSTAT 1/4in BSP OBSOLETE POCKET-THERMOSTAT 1/4IN BSP
Baxi part no. 042889BAX

87 Part number 062636BAX, OBSOLETE GASKET-BOILER BER 401(Brown) OBSOLETE GASKET-BOILER BER 401(BROWN)
Baxi part no. 062636BAX

87 Part number 062636, OBSOLETE GASKET-BOILER BER 401 OBSOLETE GASKET-BOILER BER 401
Baxi part no. 062636

88   KIT-DRAW BAR-BOILER SECURING
Baxi part no. 040890

89   OBSOLETE BAFFLE-HEAT EXCH-TOP-B401
Baxi part no. 040052

89   OBSOLETE PLATE-BLR CLAMPING.WM-532RS
Baxi part no. 100113

90   OBSOLETE BAFFLE-H-EXCH-CEN-WM-383-RS
Baxi part no. 100349

92 Part number 062637, OBSOLETE GROMMET BOILER END SEAL OBSOLETE GROMMET BOILER END SEAL
Baxi part no. 062637
£4.44
93 Part number 040515, OBSOLETE KIT-ADAPTER-INJECTOR TEE OBSOLETE KIT-ADAPTER-INJECTOR TEE
Baxi part no. 040515

98   OBSOLETE TERM-FLUE-STND-WM-513-383-RS
Baxi part no. 100315

100   OBSOLETE KIT-TRIM-FLUE TERMINAL-51/3RS.
Baxi part no. 100316

101   OBSOLETE ADAPTER-1IN BSP-TO-28MM
Baxi part no. 102216

102   OBSOLETE INJECTOR-TEE-GRAVITY-KIT
Baxi part no. 102222

106   OBSOLETE KIT-FLUE-EXT-WM-513-RS
Baxi part no. 100337

107   OBSOLETE GUARD - FLUE TERMINAL - TOWER FLUES 102127
Baxi part no. 102127

108   OBSOLETE KIT-HIGH LIMIT-CUT OFF-SER3 WM
Baxi part no. 100405

109   OBSOLETE THERMOSTAT-HIGH LIMIT-EX 10115
Baxi part no. 102289
