BAXI
GASFLAME WS - (Appliance Overview)
Appliance Code: 32-077-24

Appliance Diagram


Appliance Overview diagram for Baxi Gasflame WSClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0 Part number 230184, NOW USE 230184BAX KNOB CONTROL OUTER ADAPTER NOW USE 230184BAX KNOB CONTROL OUTER ADAPTER
Baxi part no. 230184

0 Part number 230282, NOW USE 230282BAX KIT-KNOB CONTROL ADAPT-GF/LFE3 NOW USE 230282BAX KIT-KNOB CONTROL ADAPT-GF/LFE3
Baxi part no. 230282

0   OBSOLETE FITTING INSTRUCTIONS
Baxi part no. 230280

0 Part number 230272, NOW USE 230272BAX KNOB CONTROL INNER ADAPTER NOW USE 230272BAX KNOB CONTROL INNER ADAPTER
Baxi part no. 230272

0 Part number 230184BAX, KNOB CONTROL OUTER ADAPTER KNOB CONTROL OUTER ADAPTER
Baxi part no. 230184BAX
£13.40
0 Part number 230272BAX, KNOB CONTROL INNER ADAPTER KNOB CONTROL INNER ADAPTER
Baxi part no. 230272BAX
£8.41
0 Part number 230282BAX, KIT-KNOB CONTROL ADAPT-GF/LFE3 KIT-KNOB CONTROL ADAPT-GF/LFE3
Baxi part no. 230282BAX
£20.11
1   OBSOLETE OUTER CASE-GAS FLAME WS
Baxi part no. 090143

2   OBSOLETE BEZEL-CONT KNOB ASSY-GAS FL WS
Baxi part no. 090150

3 Part number 062595, BUTTON-INDIC-UTD.CARR 70270-06 BUTTON-INDIC-UTD.CARR 70270-06
Baxi part no. 062595

4 Part number 042776, OBSOLETE SWITCH-ROCKER-BROWN. OBSOLETE SWITCH-ROCKER-BROWN.
Baxi part no. 042776

5   OBSOLETE SHIELD-HEAT-BEZEL-GAS FL WS
Baxi part no. 090142

5   OBSOLETE DISTANCE PIECE-TOP GAS FL WS
Baxi part no. 090139

6   OBSOLETE DISTANCE PIECE-LH-GAS FLAME WS
Baxi part no. 090140

6   OBSOLETE DISTANCE PIECE-RH-GAS FLAME WS
Baxi part no. 090141

7   SCR-NO 8X14TPIX1/2 HARDTWIN-WD
Baxi part no. 042244
£2.18
8   OBSOLETE LOUVRE-ASSY-LFE SUPER
Baxi part no. 090121

9   OBSOLETE CAP LOUVRE END RH
Baxi part no. 092096

10   OBSOLETE CAP LOUVRE END LH
Baxi part no. 092097

11   OBSOLETE CHANNEL-CASE TOP-GAS FL WS
Baxi part no. 090122

11   OBSOLETE CLIP-EDGE-UTD.CARR REF.37830
Baxi part no. 042924

12   OBSOLETE CANOPY
Baxi part no. 092113

13   OBSOLETE SHIELD HEAT CANOPY LFE
Baxi part no. 223348

14 Part number 062548, SCR-ST-No 8x3/8in POZI FL.HD A SCR-ST-NO 8X3/8IN POZI FL.HD A
Baxi part no. 062548
£3.01
15   OBSOLETE BRKT-HEARTH LOC-RH GAS FL WS
Baxi part no. 090133

16   BRKT-HEARTH LOC-LH GAS FL WS
Baxi part no. 090132
£2.99
17   OBSOLETE LABEL - USERS CAUTION
Baxi part no. 045418

18   OBSOLETE PAPERCLIP - BRASS
Baxi part no. 042934

19   OBSOLETE PANEL - HEARTH
Baxi part no. 092120

20   OBSOLETE KIT-REFLECTOR LAMPS LOWER
Baxi part no. 225694

21 Part number 062683, SCR-ST-NO8x1/4 FLHD-POZI-ZPD B SCR-ST-NO8X1/4 FLHD-POZI-ZPD B
Baxi part no. 062683
£2.53
22   OBSOLETE BOX-ELECTRIC ASSY-GAS FL WS
Baxi part no. 090144

22 Part number 047023, OBSOLETE KIT-RESTOR-FIRE LGT EFFECT-GF OBSOLETE KIT-RESTOR-FIRE LGT EFFECT-GF
Baxi part no. 047023

22   CLIP-RESISTOR
Baxi part no. 043174
£2.20
23 Part number 042260, OBSOLETE LAMP HOLDER WITH RIM OBSOLETE LAMP HOLDER WITH RIM
Baxi part no. 042260

23 Part number 042260POT, LAMP HOLDER LAMP HOLDER
Baxi part no. 042260POT

24 Part number 062560, SCR-TF-M4 x 6mm PAN POZI ZN P SCR-TF-M4 X 6MM PAN POZI ZN P
Baxi part no. 062560
£3.12
25   OBSOLETE OPEN/CLOSED BUSHING FOR 9.5MM HOLE - BLACK
Baxi part no. 082487

26   OBSOLETE KIT-WIRES-GAS FL WS
Baxi part no. 090157

27   OBSOLETE LAMP-25WATT-AMBER
Baxi part no. 092139

29   OBSOLETE REFLECTOR-ASSY-LFE RANGE
Baxi part no. 090156

29   OBSOLETE BRKT-CASE FIXING.GAS FLAME WS
Baxi part no. 090125

30   OBSOLETE COVER-PANEL HEARTH GAS FL.WS
Baxi part no. 092100

31   OBSOLETE TRIM - PANEL - HEARTH
Baxi part no. 092098

32   OBSOLETE TRIM-HEARTH-OUTER LH-GAS FL WS
Baxi part no. 092099

34   CLIP-EDGE-SPR.STEEL
Baxi part no. 102010
£2.04
35   OBSOLETE TRIM-HEARTH-OUTER RH GAS FL WS
Baxi part no. 092101

36   OBSOLETE TRIM HEARTH-RH-GAS FLAME WS
Baxi part no. 090138

38   NUT-FLAT-NO8-LEWIS SPR-401/11
Baxi part no. 042870
£2.25
39   OBSOLETE STRAP-LOWER-GAS FL WS
Baxi part no. 090127

40   OBSOLETE DIFFUSER-LIGHT-GAS FL WS
Baxi part no. 090128

46 Part number 062325, CLIP-CABLE-GT CLIP-CABLE-GT
Baxi part no. 062325

47   OBSOLETE CABLE-CLAMP-ENOTS-340218-03
Baxi part no. 092062

48   OBSOLETE HEAT EXCH ASSY GAS FLAME
Baxi part no. 090083

49   TRIM - HEAT EXCHANGER - G.F.
Baxi part no. 040934

50   OBSOLETE BOX - COMBUSTION
Baxi part no. 090162

51   OBSOLETE STRIP - SEAL RETAINING
Baxi part no. 040978

52   BRKT-BURNER SUPP.ASSY-BER.GF
Baxi part no. 040985
£2.68
53   OBSOLETE GASKET HEAT EXCHANGER
Baxi part no. 229308

54 Part number 043111, SEAL-GLASS FRAME-GF SEAL-GLASS FRAME-GF
Baxi part no. 043111

55   OBSOLETE CHANNEL - GLASS FRAME SUPPORT
Baxi part no. 040936

56 Part number 102012, NUT-CAPT-U-TYPE-No8 ZNPD CHRM NUT-CAPT-U-TYPE-NO8 ZNPD CHRM
Baxi part no. 102012
£3.12
57   SCR-ST-NO8X1/2 PAN POZI S/S A
Baxi part no. 062725

57   OBSOLETE HEAT SHIELD - WALL
Baxi part no. 090155

58   OBSOLETE CHANNEL GLASS FRAME SUPPORT
Baxi part no. 040945

59   SCR-SET-M5X12MM-HX.HD.SLT ZNPD
Baxi part no. 062729
£2.03
60   OBSOLETE PLATE-BACK-GAS FLAME WS
Baxi part no. 090154

61   OBSOLETE DEFLECTOR-HEAT-GAS FL WS
Baxi part no. 090153

61   OBSOLETE TAPPING SCREW ISO NO. 8AB X 19 RECESSED PA
Baxi part no. 062748

61   SCR-ST-NO8X3/8 FL.PZ.CH.BLK.AB
Baxi part no. 062731
£2.47
61   WASHER-PLAIN-5MM ZINC PLTD
Baxi part no. 062447
£2.36
65   OBSOLETE NUT-CAP-U-TYPE 3/16INBSW CH ZP
Baxi part no. 102092

65   OBSOLETE FRAME MOUNTING
Baxi part no. 090145

66   OBSOLETE CABLE CLAMP - ENOTS 34021805
Baxi part no. 092118

68   OBSOLETE PLATE-BACKING-GAS FLAME WS
Baxi part no. 090136

69 Part number 062531, SCR-TF-M5x8mm-PAN POZI ZN PD SCR-TF-M5X8MM-PAN POZI ZN PD
Baxi part no. 062531
£3.12
70   BRKT-GAS TAP MOUNT-BER LFE 3
Baxi part no. 090131
£10.62
71   SCR-SET-M8X35MM-HEX.HD.BLK
Baxi part no. 062749
£2.33
71 Part number 227313, CAP-PROTECTION CAP-PROTECTION
Baxi part no. 227313
£1.87
72   OBSOLETE FULL NUT M8 HEXAGON - STEEL GRADE 8. BS369
Baxi part no. 062723

73 Part number 040955, SPARES Assy Frame/Glass GF SPARES ASSY FRAME/GLASS GF
Baxi part no. 040955
£168.60
74   REFLECTOR-LAMPS-UPPER.-G.F.
Baxi part no. 040944
£7.37
75   OBSOLETE KIT - CLOSURE PLATE
Baxi part no. 090090

77   SCR-NO.8X1.5IN RD HD BLK JAP
Baxi part no. 062319

78 Part number 062320, PLUG WALL FIXING No8-PLASTIC PLUG WALL FIXING NO8-PLASTIC
Baxi part no. 062320
£2.41
79   OBSOLETE PIN SECURING OUTER CASE
Baxi part no. 092123

80 Part number 043115, KNOB-CONTROL ASSY-G.F. KNOB-CONTROL ASSY-G.F.
Baxi part no. 043115
£9.51
81   OBSOLETE PIPE-INLET EXTENSION-GAS FL WS
Baxi part no. 092114

82   OBSOLETE SOCKET-1/4" BSP-GAS FLAME WS
Baxi part no. 092115

83   OBSOLETE ELBOW-INLET-GAS FLAME WS
Baxi part no. 092110

84   OBSOLETE PIPE-INLET FEED ASSY-GAS FL WS
Baxi part no. 092105

85   OBSOLETE FFD/GAS TAP
Baxi part no. 043095

86 Part number 043152, NUT-HEXAGON.LOCK-1/4" BSP NUT-HEXAGON.LOCK-1/4" BSP
Baxi part no. 043152
£3.64
87   PIPE BRNR FEED
Baxi part no. 090146

87   PIPE-BURNER FEED FRNT-GAS F WS
Baxi part no. 092106

88   PIPE-BURNER FEED REAR-GAS F WS
Baxi part no. 092107
£4.27
88   OBSOLETE PIPE BRNR FEED REAR.N&O WS
Baxi part no. 090147

89 Part number 042941, IGNITOR-PIEZO-REF 66111 (VERN) IGNITOR-PIEZO-REF 66111 (VERN)
Baxi part no. 042941

90 Part number 082462, MAGNETIC UNIT-BRAZILIA 8000 C MAGNETIC UNIT-BRAZILIA 8000 C
Baxi part no. 082462

91   OBSOLETE INJ-FIRE-N/GAS CAT 18-220 BRAY
Baxi part no. 092002

92 Part number 043093, OBSOLETE BURNER-AEROMATIC-G.F. OBSOLETE BURNER-AEROMATIC-G.F.
Baxi part no. 043093

93 Part number 082412, OBSOLETE FILTER PILOT OBSOLETE FILTER PILOT
Baxi part no. 082412

95   OBSOLETE PILOT BURNER
Baxi part no. Q359A1074

96 Part number 402560, OBSOLETE PILOT INJECTOR (STD) OBSOLETE PILOT INJECTOR (STD)
Baxi part no. 402560

96 Part number 112011, OBSOLETE INJECTOR-PILOT H/WELL-.38/.36A OBSOLETE INJECTOR-PILOT H/WELL-.38/.36A
Baxi part no. 112011

97 Part number 102050, CONNECTOR REDUCING.6mm-4mm CONNECTOR REDUCING.6MM-4MM
Baxi part no. 102050

99   NUT-FULL HEX-4MM-ZINC PLTD
Baxi part no. 062439
£3.01
100   OBSOLETE WASHER SHAKEPROOF.INT-M4 ZN PD
Baxi part no. 062451

101 Part number 082430, OBSOLETE ELECTRODE-PILOT-IGN-CIRCULATOR OBSOLETE ELECTRODE-PILOT-IGN-CIRCULATOR
Baxi part no. 082430

103 Part number 226262, T/COUPLE-18 -H/WELL Q309A 1954 T/COUPLE-18 -H/WELL Q309A 1954
Baxi part no. 226262
£28.74
104 Part number 043120, OBSOLETE LEAD-ELECTRODE-ASSY-G.F. OBSOLETE LEAD-ELECTRODE-ASSY-G.F.
Baxi part no. 043120

105   OBSOLETE SLEEVE 6MM ELAS.GLS/FIBX260MM
Baxi part no. 040960

106   OBSOLETE COAL BED-G.F.
Baxi part no. 043094
