BAXI
CELCIA INSET 2 - (Coal Bed)
Appliance Code: 37-075-16

Appliance Diagram


Coal Bed diagram for Baxi Celcia Inset 2Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   OBSOLETE FRAME SURROUND ASSY
Baxi part no. 239952
2   OBSOLETE FIREFRONT ASSEMBLY - CS/CELSIA
Baxi part no. 239954
2   OBSOLETE SHIELD CENTRE VIEW
Baxi part no. 239159
3   OBSOLETE CLIP EDGE
Baxi part no. 220449
3   OBSOLETE FINIALS - FS
Baxi part no. 239284
4   OBSOLETE WASHER SHAKEPROOF.INT-M4 ZN PD
Baxi part no. 062451
4   OBSOLETE RING-FIREFRONT
Baxi part no. 233587
4   SCR-SET-M4X12MM-PAN HD PZ ZNPD
Baxi part no. 062726
5 Part number 102012, NUT-CAPT-U-TYPE-No8 ZNPD CHRM NUT-CAPT-U-TYPE-NO8 ZNPD CHRM
Baxi part no. 102012		 £3.12
5   OBSOLETE ASSY BOX COMBUSTION
Baxi part no. 237550
6   OBSOLETE PANEL MOUNTING CONTROLS
Baxi part no. 238721
7   OBSOLETE GAS TAP MOUNTING BRACKET
Baxi part no. 238739
8 Part number 244861, OBSOLETE GAS TAP FFD/IGN FIRE OBSOLETE GAS TAP FFD/IGN FIRE
Baxi part no. 244861
9 Part number 239289, KIT - PIEZO IGNITION KIT - PIEZO IGNITION
Baxi part no. 239289
10 Part number 239413, ELECTRO MAGNET ELECTRO MAGNET
Baxi part no. 239413
11   OBSOLETE BEZEL - INSET 2
Baxi part no. 238751
12   OBSOLETE CONTROL-KNOB-ASSEMBLY
Baxi part no. 236295
13   OBSOLETE BURNER
Baxi part no. 238885
13   OBSOLETE BURNER FIRE ASSEMBLY
Baxi part no. 241537
14 Part number 043152, NUT-HEXAGON.LOCK-1/4" BSP NUT-HEXAGON.LOCK-1/4" BSP
Baxi part no. 043152		 £3.64
14   OBSOLETE ELBOW INLET
Baxi part no. 238889
15 Part number 238943, OBSOLETE PIPE FEED PILOT - ASSEMBLED OBSOLETE PIPE FEED PILOT - ASSEMBLED
Baxi part no. 238943
16   OBSOLETE PIPE FEED GAS TAP - ASSEMBLED
Baxi part no. 238806
17   OBSOLETE PIPE FEED BURNER - ASSEMBLED
Baxi part no. 238804
18 Part number 062532, SCR-TF-M4x8mm-PAN POZI ZN PD SCR-TF-M4X8MM-PAN POZI ZN PD
Baxi part no. 062532		 £3.01
18 Part number 236204, BURNER PILOT SENSING BURNER PILOT SENSING
Baxi part no. 236204
18 Part number 236204BAX, BURNER PILOT SENSING BURNER PILOT SENSING
Baxi part no. 236204BAX
19 Part number 243038BAX, INJECTOR F15 (or 90) INJECTOR F15 (OR 90)
Baxi part no. 243038BAX
19 Part number 7211908, WASHER COPPER SEALING WASHER COPPER SEALING
Baxi part no. 7211908		 £3.14
19 Part number 062695, NOW USE 7211908 WASHER COPPER INJECTOR SEALING NOW USE 7211908 WASHER COPPER INJECTOR SEALING
Baxi part no. 062695
19   OBSOLETE INJECTOR (F14)
Baxi part no. 238942
19 Part number 243038, INJECTOR F15 (or 90) INJECTOR F15 (OR 90)
Baxi part no. 243038
20 Part number 236493, LEAD ELECTRODE 285mm LONG LEAD ELECTRODE 285MM LONG
Baxi part no. 236493
21   OBSOLETE SLEEVE-6MM-ELAS.GLS/FIBX290MM
Baxi part no. 227051
22 Part number 238840, OBSOLETE COAL BED - BASE OBSOLETE COAL BED - BASE
Baxi part no. 238840
23 Part number 239278, OBSOLETE COAL BED - SIDE CHEEKS & BACK OBSOLETE COAL BED - SIDE CHEEKS & BACK
Baxi part no. 239278
25 Part number 239280, OBSOLETE FRONT COALS OBSOLETE FRONT COALS
Baxi part no. 239280
26 Part number 239281, OBSOLETE COALS FITTED & LOOSE INSET 2 OBSOLETE COALS FITTED & LOOSE INSET 2
Baxi part no. 239281
