BRAZILIA SLIMLINE 5 S - (Optional Extras)
Appliance Code: 35-077-16

Appliance Diagram


Optional Extras diagram for Baxi Brazilia Slimline 5 SClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0   OBSOLETE KNOB CONTROL OUTER ADAPTER
Baxi part no. 230299
0 Part number 230284, OBSOLETE KIT-KNOB CONTROL ADAPT-BRAZ OBSOLETE KIT-KNOB CONTROL ADAPT-BRAZ
Baxi part no. 230284
0   OBSOLETE FITTING INSTRUCTIONS
Baxi part no. 230280
1 Part number 225046, OBSOLETE OUTER CASE OBSOLETE OUTER CASE
Baxi part no. 225046
2 Part number 225127, OBSOLETE OUTER CASE OBSOLETE OUTER CASE
Baxi part no. 225127
3   CLIP-EDGE-SPR.STEEL
Baxi part no. 102010		 £2.04
4   OBSOLETE BUTTON-INDICATOR-WHITE.
Baxi part no. 223959
5   OBSOLETE SIDE-CHEEK-LH-BRAZILIA 5S
Baxi part no. 224030
6   OBSOLETE SIDE-CHEEK-RH-BRAZILIA 5S
Baxi part no. 224031
7 Part number 062548, SCR-ST-No 8x3/8in POZI FL.HD A SCR-ST-NO 8X3/8IN POZI FL.HD A
Baxi part no. 062548		 £3.01
8   OBSOLETE SHIELD HEAT ASSEMBLY 5/5S
Baxi part no. 224032
9   OBSOLETE STRIP-BACK-OUTER CASE
Baxi part no. 224035
10   OBSOLETE SEAL WALL-SILICONE - 5/5S
Baxi part no. 224036
11   OBSOLETE KNOB-CONTROL ASSY-BRAZ.5S
Baxi part no. 224037
12   OBSOLETE AIR BOX-ASSY-BRAZ-5 & 5S
Baxi part no. 224038
15   OBSOLETE SCR-SET-M8 X 50MM-ZN PD
Baxi part no. 223996
16   OBSOLETE STUD-SPACER-M8-ZN PD
Baxi part no. 223990
17 Part number 225114, OBSOLETE GAUZE-BURNER-BRAZILIA SLIMLINE OBSOLETE GAUZE-BURNER-BRAZILIA SLIMLINE
Baxi part no. 225114
18   OBSOLETE PLATE RETAINING BURNER 5/5S
Baxi part no. 224044
19   OBSOLETE SCR-TF-M4X6MM HEX POZI ZNPD
Baxi part no. 225405
21 Part number 042941, IGNITOR-PIEZO-REF 66111 (VERN) IGNITOR-PIEZO-REF 66111 (VERN)
Baxi part no. 042941
23 Part number 223966, NUT-LOCK-M14 X 1-BRASS NUT-LOCK-M14 X 1-BRASS
Baxi part no. 223966		 £3.12
24   OBSOLETE GROMMET-GAS TAP-SEAL.
Baxi part no. 223969
27   WASHER-RETAINING-SPECIAL-ST/S
Baxi part no. 110011		 £15.01
27 Part number 224244, SCR-TF-M4x12mm-PAN.POZ-ZN.PD SCR-TF-M4X12MM-PAN.POZ-ZN.PD
Baxi part no. 224244		 £3.12
28 Part number 043043, OBSOLETE LEAD-ELECTRODE-BER B. OBSOLETE LEAD-ELECTRODE-BER B.
Baxi part no. 043043
29   OBSOLETE SLEEVE 6MM ELAS.GLS/FIBX100MM
Baxi part no. 225054
29   GROMMET-RUBBER M36
Baxi part no. 042566		 £8.25
30   OBSOLETE GROMMET AIR BOX. HEAT RESISTANT
Baxi part no. 082358
31   WASHER-PLAIN-5MM ZINC PLTD
Baxi part no. 062447		 £2.36
32   SCR-NO.8X1.5IN RD HD BLK JAP
Baxi part no. 062319
33 Part number 062320, PLUG WALL FIXING No8-PLASTIC PLUG WALL FIXING NO8-PLASTIC
Baxi part no. 062320		 £2.41
35 Part number 225121, OBSOLETE KIT-SIGHT WINDOW.BRAZ S/LINE OBSOLETE KIT-SIGHT WINDOW.BRAZ S/LINE
Baxi part no. 225121
37 Part number 082252, OBSOLETE WASHER.5/16 IDx7/8 OD MS ZN PD OBSOLETE WASHER.5/16 IDX7/8 OD MS ZN PD
Baxi part no. 082252
38   OBSOLETE FULL NUT M8 HEXAGON - STEEL GRADE 8. BS369
Baxi part no. 224318
39 Part number 225188, OBSOLETE 2M FLUE ASSEMBLY 30 50 OBSOLETE 2M FLUE ASSEMBLY 30 50
Baxi part no. 225188
41 Part number 080266, KIT-GUARD-TERMINAL-BRAZ 8000 KIT-GUARD-TERMINAL-BRAZ 8000
Baxi part no. 080266
42   OBSOLETE KIT FLUE TERM 15 19IN SLIM5/5S
Baxi part no. 225175
43   OBSOLETE FLUE TERMINAL KIT - 5IN TO 9IN WALL
Baxi part no. 225174
47   OBSOLETE FITTERS INSTRUCTIONS
Baxi part no. 224254
48   OBSOLETE USERS INSTRUCTIONS
Baxi part no. 224269
