BAXI
BOSTON 2 80 RS - (Inner Case 2)
Appliance Code: 41-077-89

Appliance Diagram

Inner Case 2 diagram for Baxi Boston 2 80 RS Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1	OBSOLETE PANEL - TOP 110000 41-077-66 364-243 Baxi part n^o. 110000
2	STUD-FOREST-FAST-SRV-1762-17-0 Baxi part n^o. 112000	£2.50
3	WASHER SHAKEPROOF INT-M5-ZN PD Baxi part n^o. 062452	£3.12
4	NUT-HEXAGON-M5-STEEL- Baxi part n^o. 062440	£3.01
6	OBSOLETE PANEL SIDE RH ASSY FS BOILERS Baxi part n^o. 110001
7	NUT-CAPT-U-TYPE-NO8 ZNPD CHRM Baxi part n^o. 102012	£3.12
8	CLIP-CABLE-GT Baxi part n^o. 062325
9	OBSOLETE PANEL SIDE ASSY FS BOILERS Baxi part n^o. 110002
10	OBSOLETE FRONT PANEL Baxi part n^o. 110003
11	SCR-ST-NO8X1/2PAN.HD PZ ZNPD A Baxi part n^o. 062571	£3.12
12	OBSOLETE CABINET-BOSTON 2 RS Baxi part n^o. 236112
13	OBSOLETE COMB BOX-60/70/80RS BOS2-SPARE Baxi part n^o. 236736
14	OBSOLETE INSUL-SIDE-UPP-3 SECT.BLR. Baxi part n^o. 112084
14	OBSOLETE PLATE INSULATION SIDE Baxi part n^o. 110008
15	OBSOLETE GUIDE AIR COMBUSTION BOX Baxi part n^o. 235677
16	SCR-SET-M5X16MM-PAN HD PZ ZNPD Baxi part n^o. 062708	£2.35
17	OBSOLETE CARRIER INSUL FRONT DOOR ASSY Baxi part n^o. 235381
19	SCR-TF-M5X8MM-PAN POZI ZN PD Baxi part n^o. 062531	£3.12
21	OBSOLETE INSUL-REAR-RS-FS-BOILERS Baxi part n^o. 112006
22	WASHER-RETAINING-SPECIAL-ST/S Baxi part n^o. 110011	£15.01
23	SCR-TF-M5X10MM PN HD PZ S ZNPD Baxi part n^o. 062583	£3.12
24	OBSOLETE PANEL INSPECTION.COMB.BOX - ALL FS Baxi part n^o. 110014
26	OBSOLETE SEAL-PANEL-INSP-9.5MM X 395MM-DI Baxi part n^o. 112056
27	OBSOLETE GROMMET-SEAL-BOILER Baxi part n^o. 112008
29	OBSOLETE SEAL-PANEL-DOOR-9.5MM X 240MM-DI Baxi part n^o. 112057
30	OBSOLETE BRACKET OUTER CASE FIXING Baxi part n^o. 110064
31	SCR-ST-NO8X3/8-FL.HD POZ B Baxi part n^o. 062648
33	NUT-FULL HEX-4MM-ZINC PLTD Baxi part n^o. 062439	£3.01
34	OBSOLETE WASHER SHAKEPROOF.INT-M4 ZN PD Baxi part n^o. 062451
35	OBSOLETE AIR BOX-ASSY-F.S. BOILERS Baxi part n^o. 110018
36	OBSOLETE MACHINE SCREW M6 X 20 RECESSED PAN HEAD - Baxi part n^o. 062696
37	OBSOLETE FLUE TERM. STANDARD BOSTON Baxi part n^o. 236113
39	SCR-NO.8X1.5IN RD HD BLK JAP Baxi part n^o. 062319
40	PLUG WALL FIXING NO8-PLASTIC Baxi part n^o. 062320	£2.41
41	OBSOLETE BAFFLE HEAT EXCHANGER(95.5MM) Baxi part n^o. 235671
42	OBSOLETE BRACKET LOCATION BAFFLE Baxi part n^o. 235327
43	OBSOLETE TESTED BOILER ASSY-3 SECTION Baxi part n^o. 226685
44	OBSOLETE BOILER SECTION - LEFT HAND 111002 41-077-6 Baxi part n^o. 111002
45	OBSOLETE SECTION-RH-ASSY-FS BLR-3 SECT. Baxi part n^o. 110005
46	OBSOLETE BOILER SECTION - CENTRE 111004 41-077-64 Baxi part n^o. 111004
47	OBSOLETE SPREADER-WATER-3 SECTION-FSB Baxi part n^o. 112020
48	GASKET-FS-BOILER Baxi part n^o. 112009
50	OBSOLETE POCKET-THERMOSTAT-WM.PF Baxi part n^o. 225435
51	OBSOLETE ROPE GASKET Baxi part n^o. 110040
51	OBSOLETE SEAL-BOILER-END-8.0MM X 46MM-DIA Baxi part n^o. 112058
52	SCR-ST-NO 8X3/8IN POZI FL.HD A Baxi part n^o. 062548	£3.01
56	OBSOLETE PANEL DOOR SUB ASS BOSTON 2 RS Baxi part n^o. 236613
57	KIT-WINDOW-VIEWING-30-40-504PF Baxi part n^o. 226114	£14.87
58	NUT-WING-M6-ZN-PD Baxi part n^o. 112028
59	OBSOLETE BURNER BOILER - 3 SECTION Baxi part n^o. 235262
60	OBSOLETE INJECTOR-BOILER-BO9 Baxi part n^o. 225824
61	OBSOLETE INJECTOR-B24 Baxi part n^o. 236247
62	OBSOLETE INJECTOR-BOILER-BO 4-70/4 PF Baxi part n^o. 226094
63	OBSOLETE KIT-PIPE BURNER FEED-BOSTON 2 Baxi part n^o. 236663
64	OBSOLETE O RING-24MM ID X 4MM SECTION Baxi part n^o. 112082
65	VALVE MULTIFUNCTIONAL GAS Baxi part n^o. 233359
66	OBSOLETE COVER-ELECTRICAL-PLASTIC Baxi part n^o. 112044
67	OBSOLETE SCR-SET-M4X16MM-PAN-HD-POZ-ZNP Baxi part n^o. 112043
68	OBSOLETE KIT-PIPE-INLET-FS-BOILER Baxi part n^o. 110143
69	OBSOLETE TAP-SERV-STR-SIRAL-REF-0073853 Baxi part n^o. 112081
70	OBSOLETE SHIELD-HEAT-PROT.-IGN-MNTG-FS Baxi part n^o. 110030
71	OBSOLETE KIT-BURNER-PILOT-BOSTON 2 Baxi part n^o. 236667
72	ELECTRODE-PILOT-IGNITION Baxi part n^o. 102024	£7.03
73	LEAD-ELECTRODE-675 Baxi part n^o. 042740
74	OBSOLETE INJECTOR PILOT (STD) Baxi part n^o. 236107
74	OBSOLETE INJECTOR PILOT (STD) Baxi part n^o. 236107BAX
76	SCR-TF-M4X8MM-PAN POZI ZN PD Baxi part n^o. 062532	£3.01
77	THERM-18/24HWELL-Q309A2721 STD Baxi part n^o. 102005	£19.17
80	OBSOLETE PIPE PILOT FEED ASSY-BOSTON 2 Baxi part n^o. 236664
80	CONNECTOR REDUCING.6MM-4MM Baxi part n^o. 102050
81	KIT-PIEZO IGN-BERM 552 Baxi part n^o. 040456
82	OBSOLETE GRIP-CABLE-HEYCO-SR-5-M3 Baxi part n^o. 102197
83	OBSOLETE PLUG 3 PIN LEADS FS BOILER Baxi part n^o. 110031
86	OBSOLETE FACIA-CONTROL-BOSTON 2 Baxi part n^o. 236665
87	OBSOLETE KIT-BEZEL-BOSTON 2 Baxi part n^o. 236666
88	OBSOLETE THERMOSTAT RANCO Baxi part n^o. 112025
90	OBSOLETE KNOB Baxi part n^o. 235303
91	OBSOLETE SUPPORT TERMINAL Baxi part n^o. 110034
92	OBSOLETE WASHER-LOCK EXT.M5 ST.ZPL Baxi part n^o. 112065
93	OBSOLETE CLAMP-CABLE-PLASTIC Baxi part n^o. 112048
95	OBSOLETE WASHER-ANTI-LOSS Baxi part n^o. 112030
96	OBSOLETE ASSY-3 PIN SOCKET & LEADS-FSB Baxi part n^o. 226690
98	OBSOLETE CAPACITOR ASSY-FS-BOILERS Baxi part n^o. 110039
