BAXI
BERMUDA W2 FIRE ONLY - (Overview)
Appliance Code: 37-077-04

Appliance Diagram


Overview diagram for Baxi Bermuda W2 Fire OnlyClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   OBSOLETE OUTER CASE-BERMUDA W2(SPARES)
Baxi part no. 040433
3   OBSOLETE TRIM-LOUVRE-TOP-W2
Baxi part no. 042958
4   OBSOLETE CAP-TRIM
Baxi part no. 062544
5   OBSOLETE SCREW - ST NO. 8 X 1/2IN PAN HD POZI ZN PD
Baxi part no. 900500
6   OBSOLETE LOUVRE-CONVECTION-ASSY-BW2
Baxi part no. 040427
7   OBSOLETE TRIM-REFLECTOR TOP-W2
Baxi part no. 042960
8   OBSOLETE REFLECTOR-BERMUDA W2.
Baxi part no. 042956
9   OBSOLETE GUARD-DRESS-BERMUDA W2.
Baxi part no. 042957
10   OBSOLETE BRACKET RETAINING REFLECTOR-W2
Baxi part no. 040429
11   NYLON PEG
Baxi part no. 042542		 £2.10
12   OBSOLETE WASHER BRASS-CONTROLS COVER
Baxi part no. 042970
13   OBSOLETE STIFFENER CONTROLS COVER W2
Baxi part no. 040430
14   OBSOLETE BEZEL-CONTROL KNOB WITH CLIPS
Baxi part no. 040431
15   OBSOLETE SUPPORT SHELF-UPPER BER W2
Baxi part no. 042962
16   OBSOLETE SHELF-GLASS-PLAIN-196X140X5
Baxi part no. 042952
17   SHELF-GLASS-TEX-199 X 144 X 5
Baxi part no. 042951
18   OBSOLETE KIT-ELECTRICAL LEADS-W2
Baxi part no. 040424
19 Part number 042776, OBSOLETE SWITCH-ROCKER-BROWN. OBSOLETE SWITCH-ROCKER-BROWN.
Baxi part no. 042776
20   OBSOLETE COVER LIGHT SWITCH W2.
Baxi part no. 042967
21   OBSOLETE KIT-PLUG & SOCKET BERMUDA W2.
Baxi part no. 040536
22 Part number 042260POT, LAMP HOLDER LAMP HOLDER
Baxi part no. 042260POT
22 Part number 042260, OBSOLETE LAMP HOLDER WITH RIM OBSOLETE LAMP HOLDER WITH RIM
Baxi part no. 042260
23 Part number 042842, OBSOLETE LAMP-15W-AMBER-PYGMY OBSOLETE LAMP-15W-AMBER-PYGMY
Baxi part no. 042842
25   OBSOLETE SUPPORT-WALL FIXING
Baxi part no. 040685
26 Part number 040687, Bracket Support Wall Fixing BRACKET SUPPORT WALL FIXING
Baxi part no. 040687		 £3.21
27   SCR-SET-M5X10-SLOT CHEESE
Baxi part no. 062415		 £2.44
28 Part number 062452, WASHER SHAKEPROOF INT-M5-ZN PD WASHER SHAKEPROOF INT-M5-ZN PD
Baxi part no. 062452		 £3.12
29   NUT-HEXAGON-M5-STEEL-
Baxi part no. 062440		 £3.01
30   OBSOLETE COVER-LEVELLING SCREW 675S & W
Baxi part no. 040782
31   OBSOLETE SHIELD-HEAT-FLUE SPIGOT-W2
Baxi part no. 040476
31   OBSOLETE TAPPING SCREW ISO NO. 12AB X 32 RECESSED P
Baxi part no. 409868
31   OBSOLETE CLIP-EDGE-S TYPE-SPR STEEL
Baxi part no. 062589
32 Part number 102012, NUT-CAPT-U-TYPE-No8 ZNPD CHRM NUT-CAPT-U-TYPE-NO8 ZNPD CHRM
Baxi part no. 102012		 £3.12
33   OBSOLETE PLATE-BACKING-ASSY-BW2
Baxi part no. 040421
34   OBSOLETE BRKT-O/CASE SECURING-W2
Baxi part no. 040455
35   OBSOLETE SUPPORT-FOOT
Baxi part no. 040643
36   OBSOLETE FOOT-ADJUSTABLE.
Baxi part no. 042658
37   OBSOLETE BRKT-CASE FIXING-RH-W2
Baxi part no. 040422
38   CLIP-CABLE RETAINING PLASTIC.
Baxi part no. 042911
39   OBSOLETE BRKT-CASE FIXING-LH-W2
Baxi part no. 040423
40   OBSOLETE HEAT EXCH-ASSY-675PW & 675W
Baxi part no. 040646
41   OBSOLETE SUPPORT RAIL RADIANT/BURNER
Baxi part no. 040416
42   OBSOLETE GROMMET SILICONE 25MM X 19MM
Baxi part no. 042910
43   OBSOLETE BRKT-HEAT EXCH POSITIONING
Baxi part no. 040649
44 Part number 042708, RADIANT (4 RADIANT CONVECTOR) RADIANT (4 RADIANT CONVECTOR)
Baxi part no. 042708		 £18.96
45 Part number 042871, KNOB-CONTROL-S2/PW2 KNOB-CONTROL-S2/PW2
Baxi part no. 042871
46 Part number 042872, TAP-FIRE-CONTROL-IGNITOR ASSY TAP-FIRE-CONTROL-IGNITOR ASSY
Baxi part no. 042872
47 Part number 042941, IGNITOR-PIEZO-REF 66111 (VERN) IGNITOR-PIEZO-REF 66111 (VERN)
Baxi part no. 042941
48   OBSOLETE PLATE-MOUNTING-TAP
Baxi part no. 040268
51 Part number 040075, OBSOLETE PIPE-FIRE SUPP NUT/OLIVE PW2 OBSOLETE PIPE-FIRE SUPP NUT/OLIVE PW2
Baxi part no. 040075
52 Part number 042874, CONNECTOR-REDUCING 10mm TO 6mm CONNECTOR-REDUCING 10MM TO 6MM
Baxi part no. 042874
53   OBSOLETE PIPE-F/TAP SUPP N & O BERM S2
Baxi part no. 040269
54   OBSOLETE PIPE-BNR FEED N&O INNER S2
Baxi part no. 040277
55   OBSOLETE PIPE-BNR FEED N&O OUTER S2
Baxi part no. 040270
56   OBSOLETE ELECTRODE-FIRE-IGNTN.KT-PW2/C2
Baxi part no. 040244
57 Part number 042880, OBSOLETE BURNER-DUPLEX-AEROMATIC PW2 OBSOLETE BURNER-DUPLEX-AEROMATIC PW2
Baxi part no. 042880
58   OBSOLETE SCR-SET-M5 X 10MM-HEX HD.ZNPD
Baxi part no. 062425
58   OBSOLETE PLATE-RESTRICTOR-PW2-W2-S2-C2
Baxi part no. 040489
59   WASHER-PLAIN-5MM ZINC PLTD
Baxi part no. 062447		 £2.36
60 Part number 042724, INJECTOR-NG.18/240 INJECTOR-NG.18/240
Baxi part no. 042724
61 Part number 040800, OBSOLETE LINT ARRESTER-ASSY-FIRE OBSOLETE LINT ARRESTER-ASSY-FIRE
Baxi part no. 040800
61 Part number 040799, OBSOLETE LINT ARRESTER-ASSY-FIRE OBSOLETE LINT ARRESTER-ASSY-FIRE
Baxi part no. 040799
62   SCR-NO.8X1.5IN RD HD BLK JAP
Baxi part no. 062319
