BAXI
BERMUDA PW2 FIRE ONLY - (Overview)
Appliance Code: 37-077-01

Appliance Diagram


Overview diagram for Baxi Bermuda PW2 Fire OnlyClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   OBSOLETE OUTER CASE BERMUDA PW2
Baxi part no. 040165

2   OBSOLETE BRKT-REFLECTOR SUPPORT-675C
Baxi part no. 040746

3   OBSOLETE SCREW - WOOD - TWINFAST NO.8 X 5/8IN PAN H
Baxi part no. 900497

4   NYLON PEG
Baxi part no. 042542
£2.10
5 Part number 102012, NUT-CAPT-U-TYPE-No8 ZNPD CHRM NUT-CAPT-U-TYPE-NO8 ZNPD CHRM
Baxi part no. 102012
£3.12
7   OBSOLETE BRACKET FIXING SURROUND
Baxi part no. 040709

8   OBSOLETE SUPPORT-OUTER CASE
Baxi part no. 040169

9   OBSOLETE TRIM LOUVRE TOP - PW2
Baxi part no. 040127

10   OBSOLETE BEZEL-CONT.KNOB-BERM PW2
Baxi part no. 040245

11   OBSOLETE LOUVRE-CONVECTION-ASSY-PW2/C2
Baxi part no. 040206

12   OBSOLETE ASSY PANEL FRONT/INSULATION
Baxi part no. 040176

13   OBSOLETE REFLECTOR-675PW-C-W
Baxi part no. 042671

14 Part number 062600, OBSOLETE WASHER NYLON-CONTROLS COVER OBSOLETE WASHER NYLON-CONTROLS COVER
Baxi part no. 062600

15 Part number 062571, SCR-ST-No8x1/2PAN.HD PZ ZNPD A SCR-ST-NO8X1/2PAN.HD PZ ZNPD A
Baxi part no. 062571
£3.12
16   OBSOLETE GUARD-DRESS
Baxi part no. 042673

17   OBSOLETE PANEL-CONTROL COVER-ASSY-PW2
Baxi part no. 040179

18   OBSOLETE SUPPORT-WALL FIXING
Baxi part no. 040685

19 Part number 040687, Bracket Support Wall Fixing BRACKET SUPPORT WALL FIXING
Baxi part no. 040687
£3.21
20   SCR-SET-M5X10-SLOT CHEESE
Baxi part no. 062415
£2.44
21   NUT-HEXAGON-M5-STEEL-
Baxi part no. 062440
£3.01
22 Part number 062452, WASHER SHAKEPROOF INT-M5-ZN PD WASHER SHAKEPROOF INT-M5-ZN PD
Baxi part no. 062452
£3.12
23   OBSOLETE COVER-LEVELLING SCREW 675S & W
Baxi part no. 040782

24   OBSOLETE CLIP-EDGE-S TYPE-SPR STEEL
Baxi part no. 062589

26   CLIP-CABLE RETAINING PLASTIC.
Baxi part no. 042911

27   OBSOLETE BRACKET LOCATION OUTER CASE
Baxi part no. 040688

28   OBSOLETE BRKT-CASE RH & GAS TAP FIXING
Baxi part no. 040738

29   OBSOLETE BRKT-CASE FIXING-LH-675C
Baxi part no. 040736

30   OBSOLETE SUPPORT-FOOT
Baxi part no. 040643

31   OBSOLETE FOOT-ADJUSTABLE.
Baxi part no. 042658

32   OBSOLETE BRKT-FIRE SECURING.675 S/W
Baxi part no. 040703

33   SCR-NO.8X1.5IN RD HD BLK JAP
Baxi part no. 062319

35   OBSOLETE HEAT EXCH-ASSY-675PW & 675W
Baxi part no. 040646

36   OBSOLETE RAIL SUPPORT
Baxi part no. 040648

36   OBSOLETE SUPPORT RAIL RADIANT/BURNER
Baxi part no. 040416

37   OBSOLETE SHIELD BURNER
Baxi part no. 040680

38   OBSOLETE GROMMET SILICONE 25MM X 19MM
Baxi part no. 042910

39   OBSOLETE BRKT-HEAT EXCH POSITIONING
Baxi part no. 040649

40 Part number 042708, RADIANT (4 RADIANT CONVECTOR) RADIANT (4 RADIANT CONVECTOR)
Baxi part no. 042708
£18.96
41 Part number 042871, KNOB-CONTROL-S2/PW2 KNOB-CONTROL-S2/PW2
Baxi part no. 042871

42 Part number 042872, TAP-FIRE-CONTROL-IGNITOR ASSY TAP-FIRE-CONTROL-IGNITOR ASSY
Baxi part no. 042872

43 Part number 042941, IGNITOR-PIEZO-REF 66111 (VERN) IGNITOR-PIEZO-REF 66111 (VERN)
Baxi part no. 042941

44   OBSOLETE PLATE-MOUNTING-CONTROL TAP-PW2
Baxi part no. 040024

45 Part number 062532, SCR-TF-M4x8mm-PAN POZI ZN PD SCR-TF-M4X8MM-PAN POZI ZN PD
Baxi part no. 062532
£3.01
46 Part number 040075, OBSOLETE PIPE-FIRE SUPP NUT/OLIVE PW2 OBSOLETE PIPE-FIRE SUPP NUT/OLIVE PW2
Baxi part no. 040075

47 Part number 042874, CONNECTOR-REDUCING 10mm TO 6mm CONNECTOR-REDUCING 10MM TO 6MM
Baxi part no. 042874

49   OBSOLETE PIPE-F/TAP SUPP NUT/OLIVE PW2
Baxi part no. 040103

50   OBSOLETE PIPE-BRNR FEED NUT/OLIVE PW2
Baxi part no. 040111

51   OBSOLETE PIPE-BRNR FD N/OLIVES OUT PW2
Baxi part no. 040124

52   OBSOLETE ELECTRODE-FIRE-IGNTN.KT-PW2/C2
Baxi part no. 040244

53   WASHER-PLAIN-5MM ZINC PLTD
Baxi part no. 062447
£2.36
54 Part number 042880, OBSOLETE BURNER-DUPLEX-AEROMATIC PW2 OBSOLETE BURNER-DUPLEX-AEROMATIC PW2
Baxi part no. 042880

54   OBSOLETE PLATE-RESTRICTOR-PW2-W2-S2-C2
Baxi part no. 040489

55   OBSOLETE SCR-SET-M5 X 10MM-HEX HD.ZNPD
Baxi part no. 062425

57 Part number 042724, INJECTOR-NG.18/240 INJECTOR-NG.18/240
Baxi part no. 042724

58 Part number 040799, OBSOLETE LINT ARRESTER-ASSY-FIRE OBSOLETE LINT ARRESTER-ASSY-FIRE
Baxi part no. 040799

58 Part number 040800, OBSOLETE LINT ARRESTER-ASSY-FIRE OBSOLETE LINT ARRESTER-ASSY-FIRE
Baxi part no. 040800
