BAXI
BERMUDA LFE4 - (Inner Case)
Appliance Code: 37-077-34

Appliance Diagram


Inner Case diagram for Baxi Bermuda LFE4Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0   OBSOLETE KIT-CONV-LPG/NG-LFE3/4-SUPER
Baxi part no. 228979

0 Part number 230184, NOW USE 230184BAX KNOB CONTROL OUTER ADAPTER NOW USE 230184BAX KNOB CONTROL OUTER ADAPTER
Baxi part no. 230184

0 Part number 230282, NOW USE 230282BAX KIT-KNOB CONTROL ADAPT-GF/LFE3 NOW USE 230282BAX KIT-KNOB CONTROL ADAPT-GF/LFE3
Baxi part no. 230282

0 Part number 230272, NOW USE 230272BAX KNOB CONTROL INNER ADAPTER NOW USE 230272BAX KNOB CONTROL INNER ADAPTER
Baxi part no. 230272

0 Part number 230184BAX, KNOB CONTROL OUTER ADAPTER KNOB CONTROL OUTER ADAPTER
Baxi part no. 230184BAX
£13.40
0 Part number 230272BAX, KNOB CONTROL INNER ADAPTER KNOB CONTROL INNER ADAPTER
Baxi part no. 230272BAX
£8.41
0 Part number 230282BAX, KIT-KNOB CONTROL ADAPT-GF/LFE3 KIT-KNOB CONTROL ADAPT-GF/LFE3
Baxi part no. 230282BAX
£20.11
1   OBSOLETE OUTER CASE (SPARES) LFE3 SUPER
Baxi part no. 224294

1   OBSOLETE LFE4 SUPER - OUTER CASE (SPARES
Baxi part no. 237014

2   OBSOLETE BEZEL ASSY-BER LFE 3 SUPER
Baxi part no. 224768

3 Part number 062595, BUTTON-INDIC-UTD.CARR 70270-06 BUTTON-INDIC-UTD.CARR 70270-06
Baxi part no. 062595

4 Part number 228954, SWITCH-ON/OFF SWITCH-ON/OFF
Baxi part no. 228954

5   OBSOLETE DISTANCE PIECE SIDE GAS FL WL
Baxi part no. 090120

6   SCR-NO 8X14TPIX1/2 HARDTWIN-WD
Baxi part no. 042244
£2.18
7   OBSOLETE LOUVRE-ASSY-LFE SUPER
Baxi part no. 090121

8   OBSOLETE CAP LOUVRE END RH
Baxi part no. 092096

9   OBSOLETE CAP LOUVRE END LH
Baxi part no. 092097

10   OBSOLETE CHANNEL-CASE TOP-GAS FL WS
Baxi part no. 090122

11   OBSOLETE CANOPY-GAS FLAME WL/LFE5 SUPER
Baxi part no. 092109

12   OBSOLETE SHIELD HEAT CANOPY LFE
Baxi part no. 223348

13   SCR-ST-NO8X3/8 FL.PZ.CH.BLK.AB
Baxi part no. 062731
£2.47
14   OBSOLETE BRKT-HEARTH LOC-RH GAS FL WS
Baxi part no. 090133

15   BRKT-HEARTH LOC-LH GAS FL WS
Baxi part no. 090132
£2.99
16   OBSOLETE LABEL - USERS CAUTION
Baxi part no. 045418

17   OBSOLETE PAPERCLIP - BRASS
Baxi part no. 042934

18   OBSOLETE PANEL-HEARTH-BER LFE 3
Baxi part no. 092119

19 Part number 062548, SCR-ST-No 8x3/8in POZI FL.HD A SCR-ST-NO 8X3/8IN POZI FL.HD A
Baxi part no. 062548
£3.01
20   OBSOLETE KIT-REFLECTOR LAMPS LOWER
Baxi part no. 225694

21   OBSOLETE WASHER-LOCK EXT.M5 ST.ZPL
Baxi part no. 112065

22 Part number 062560, SCR-TF-M4 x 6mm PAN POZI ZN P SCR-TF-M4 X 6MM PAN POZI ZN P
Baxi part no. 062560
£3.12
23   OBSOLETE BOX-ELECTRIC ASSY-GAS FL WS
Baxi part no. 090144

24 Part number 225151, OBSOLETE OBSOLETE
Baxi part no. 225151

25 Part number 042971, OBSOLETE PLUG - 3-PIN OBSOLETE PLUG - 3-PIN
Baxi part no. 042971

25 Part number 5134533, OBSOLETE PLUG & SOCKET 3 PIN OBSOLETE PLUG & SOCKET 3 PIN
Baxi part no. 5134533

26 Part number 047023, OBSOLETE KIT-RESTOR-FIRE LGT EFFECT-GF OBSOLETE KIT-RESTOR-FIRE LGT EFFECT-GF
Baxi part no. 047023

26 Part number 043215, OBSOLETE RESISTOR-207ohms-SUPER MODELS OBSOLETE RESISTOR-207OHMS-SUPER MODELS
Baxi part no. 043215

26 Part number 228955, OBSOLETE RESISTOR OBSOLETE RESISTOR
Baxi part no. 228955

26   OBSOLETE RESISTOR-208 OHMS
Baxi part no. 226266

27   OBSOLETE SHIELD-HEAT-BEZEL-GAS FL WS
Baxi part no. 090142

28 Part number 042261, LAMP-60 WATT-RED LAMP-60 WATT-RED
Baxi part no. 042261

29   CLIP-CABLE.RICHCO.WHC250N
Baxi part no. 043219
£1.63
30   OBSOLETE BRKT-CASE FIXING.GAS FLAME WS
Baxi part no. 090125

31   OBSOLETE REFLECTOR-ASSY-LFE RANGE
Baxi part no. 090156

32   OBSOLETE COVER-PANEL HEARTH ASSY-WS/WL
Baxi part no. 092122

33   OBSOLETE TRIM-HEARTH-OUTER LH-GAS FL WS
Baxi part no. 092099

35   CLIP-EDGE-SPR.STEEL
Baxi part no. 102010
£2.04
36   OBSOLETE TRIM-HEARTH-OUTER RH GAS FL WS
Baxi part no. 092101

37   OBSOLETE TRIM HEARTH-RH-GAS FLAME WS
Baxi part no. 090138

38   NUT-FLAT-NO8-LEWIS SPR-401/11
Baxi part no. 042870
£2.25
39   OBSOLETE STRAP-LOWER-GAS FL WS
Baxi part no. 090127

40   OBSOLETE DIFFUSER-LIGHT-GAS FL WS
Baxi part no. 090128

42 Part number 040971, OBSOLETE BRKT CLIP RETAINING ASSY S2&C3 OBSOLETE BRKT CLIP RETAINING ASSY S2&C3
Baxi part no. 040971

44 Part number 062593, OBSOLETE CLIP-MALE-TERRY 487-605 OBSOLETE CLIP-MALE-TERRY 487-605
Baxi part no. 062593

45 Part number 062699, SCR-ST-No6x3/8 PAN HD PZ ZP SCR-ST-NO6X3/8 PAN HD PZ ZP
Baxi part no. 062699
£3.12
46 Part number 040640, OBSOLETE SOCKET-3 PIN-ASSY OBSOLETE SOCKET-3 PIN-ASSY
Baxi part no. 040640

47   HEAT EXCHANGER
Baxi part no. 040933

47   ASSY HEAT EXCHANGER GF(SPARES)
Baxi part no. 248445

48   TRIM - HEAT EXCHANGER - G.F.
Baxi part no. 040934

49   OBSOLETE BOX-COMB.ASSY-BERM.LFE3 SUPER
Baxi part no. 225130

50 Part number 102012, NUT-CAPT-U-TYPE-No8 ZNPD CHRM NUT-CAPT-U-TYPE-NO8 ZNPD CHRM
Baxi part no. 102012
£3.12
52   BRKT-BURNER SUPP.ASSY-BER.GF
Baxi part no. 040985
£2.68
53   OBSOLETE GASKET HEAT EXCHANGER
Baxi part no. 229308

54 Part number 043111, SEAL-GLASS FRAME-GF SEAL-GLASS FRAME-GF
Baxi part no. 043111

55   OBSOLETE CHANNEL GLASS FRAME SUPPORT
Baxi part no. 225195

56   SCR-ST-NO8X1/2 PAN POZI S/S A
Baxi part no. 062725

58   SCR-SET-M5X12MM-HX.HD.SLT ZNPD
Baxi part no. 062729
£2.03
59   OBSOLETE BACK PLATE
Baxi part no. 040336

60   OBSOLETE DEFLECTOR-HEAT-GAS FL WS
Baxi part no. 090153

61   OBSOLETE TAPPING SCREW ISO NO. 8AB X 19 RECESSED PA
Baxi part no. 062748

62   WASHER-PLAIN-5MM ZINC PLTD
Baxi part no. 062447
£2.36
63   OBSOLETE SHIELD-HEAT-FLUE-LFE 3
Baxi part no. 040001

64   OBSOLETE DIVERTER-DOWNDRAFT-SPIGOT
Baxi part no. 040002

66   OBSOLETE FRAME - MOUNTING.- G.F
Baxi part no. 220466

67   OBSOLETE HEAT SHIELD - CONTROLS
Baxi part no. 225150

67   OBSOLETE SHIELD-HEAT-CONTROLS
Baxi part no. 040207

68   OBSOLETE PLATE-BACKING-BER LFE 3
Baxi part no. 090130

69 Part number 062531, SCR-TF-M5x8MM-PAN POZI ZN PD SCR-TF-M5X8MM-PAN POZI ZN PD
Baxi part no. 062531
£3.12
70 Part number 040004, BRACKET SPINDLE SUPPORT LFE3 BRACKET SPINDLE SUPPORT LFE3
Baxi part no. 040004
£4.39
71   BRKT-GAS TAP MOUNT-BER LFE 3
Baxi part no. 090131
£10.62
72 Part number 040954, KIT-WALL FIXING-BERMUDA GF KIT-WALL FIXING-BERMUDA GF
Baxi part no. 040954

73 Part number 227313, CAP-PROTECTION CAP-PROTECTION
Baxi part no. 227313
£1.87
73   SCR-SET-M8X35MM-HEX.HD.BLK
Baxi part no. 062749
£2.33
74   NUT-HEX-M8-CHEMI BLACK
Baxi part no. 062750
£1.85
74   OBSOLETE FULL NUT M8 HEXAGON - STEEL GRADE 8. BS369
Baxi part no. 062723

75 Part number 040955, SPARES Assy Frame/Glass GF SPARES ASSY FRAME/GLASS GF
Baxi part no. 040955
£168.60
76   REFLECTOR-LAMPS-UPPER.-G.F.
Baxi part no. 040944
£7.37
77   SCR-ST-NO8X3/8-FL.HD POZ B
Baxi part no. 062648
£2.78
78 Part number 040787, Assy Shield/Label Controls LFE ASSY SHIELD/LABEL CONTROLS LFE
Baxi part no. 040787
£23.90
79   MIRROR-PILOT-G.F.
Baxi part no. 043142

80   SCR-SET-M5X10-SLOT CHEESE
Baxi part no. 062415
£2.44
81   NUT-HEXAGON-M5-STEEL-
Baxi part no. 062440
£3.01
82 Part number 062452, WASHER SHAKEPROOF INT-M5-ZN PD WASHER SHAKEPROOF INT-M5-ZN PD
Baxi part no. 062452
£3.12
83   SCR-NO.8X1.5IN RD HD BLK JAP
Baxi part no. 062319

84 Part number 062320, PLUG WALL FIXING No8-PLASTIC PLUG WALL FIXING NO8-PLASTIC
Baxi part no. 062320
£2.41
85 Part number 062549, SCR-ST-No8x1/2 POZI FLANGE SCR-ST-NO8X1/2 POZI FLANGE
Baxi part no. 062549
£3.12
86 Part number 090159, KNOB-GAS TAP CONTROL ASSY LFE3 KNOB-GAS TAP CONTROL ASSY LFE3
Baxi part no. 090159
£12.85
87 Part number 043136, ADAPTER-10mm TO 1/4in BSPT ADAPTER-10MM TO 1/4IN BSPT
Baxi part no. 043136

88 Part number 042875, NUT-HEXAGON LOCK-3/8 BSP NUT-HEXAGON LOCK-3/8 BSP
Baxi part no. 042875
£4.72
89   OBSOLETE GOVERNOR-SPECIAL
Baxi part no. 230746

90 Part number 043138, OBSOLETE ADAPTER-1/4in BSPT TO 6mm OBSOLETE ADAPTER-1/4IN BSPT TO 6MM
Baxi part no. 043138

91   OBSOLETE TAP-FIRE-CONTROL-ASSY
Baxi part no. 225149

91 Part number 092132, OBSOLETE FFD/GAS TAP-GAS FLAME SUPER OBSOLETE FFD/GAS TAP-GAS FLAME SUPER
Baxi part no. 092132

92 Part number 082462, MAGNETIC UNIT-BRAZILIA 8000 C MAGNETIC UNIT-BRAZILIA 8000 C
Baxi part no. 082462

93 Part number 042941, IGNITOR-PIEZO-REF 66111 (VERN) IGNITOR-PIEZO-REF 66111 (VERN)
Baxi part no. 042941

94 Part number 043152, NUT-HEXAGON.LOCK-1/4 BSP NUT-HEXAGON.LOCK-1/4 BSP
Baxi part no. 043152
£3.64
95   OBSOLETE PIPE-FFD/GAS TAP-BER LFE 3
Baxi part no. 043178

96   PIPE-BURNER FEED FRNT-GAS F WS
Baxi part no. 092106

96   PIPE BRNR FEED
Baxi part no. 090146

97   PIPE-BURNER FEED REAR-GAS F WS
Baxi part no. 092107
£4.27
97   OBSOLETE PIPE BRNR FEED REAR.N&O WS
Baxi part no. 090147

98 Part number 043140, INJECTOR-CAT 18/260 INJECTOR-CAT 18/260
Baxi part no. 043140

99 Part number 043210, BURNER-TYPE 2-BER GF SUPER-NG BURNER-TYPE 2-BER GF SUPER-NG
Baxi part no. 043210

100 Part number 092137, ELECTRODE-GAS FLAME SUPER ELECTRODE-GAS FLAME SUPER
Baxi part no. 092137

102   OBSOLETE SLEEVE 6 X 300MM GLASS FIBRE
Baxi part no. 224213

102   OBSOLETE SLEEVE-6MM-ELAS.GLS/FIBX290MM
Baxi part no. 227051

103 Part number 092136, THERMOCOUPLE-SITx400mm-INC.NUT THERMOCOUPLE-SITX400MM-INC.NUT
Baxi part no. 092136

104 Part number 043206, OBSOLETE COAL BED-TYPE 2-NG OBSOLETE COAL BED-TYPE 2-NG
Baxi part no. 043206

105 Part number 043121, PIPE-FIRE SUPPLY-10mm DIA-G.F. PIPE-FIRE SUPPLY-10MM DIA-G.F.
Baxi part no. 043121

105 Part number 040959, SUPPLY PIPE SUPPLY PIPE
Baxi part no. 040959

105 Part number 232468, PIPE FEED FIRE ASSY PIPE FEED FIRE ASSY
Baxi part no. 232468
£5.88
106   OBSOLETE SUPPORT - WALL FIXING - G.F.
Baxi part no. 220467

106   OBSOLETE FITTERS INSTRUCTIONS - LFE
Baxi part no. 611163

107   OBSOLETE USERS INSTRUCTIONS - LFE
Baxi part no. 611162

107   OBSOLETE COVER PLATE
Baxi part no. 223359

107 Part number 220469, SHIELD CONTROLS (BOILER) SHIELD CONTROLS (BOILER)
Baxi part no. 220469
