BAXI
BERMUDA C FIRE ONLY - (Appliance 2)
Appliance Code: 32-077-11

Appliance Diagram


Appliance 2 diagram for Baxi Bermuda C Fire OnlyClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   OBSOLETE OUTER CASE-BERM C
Baxi part no. 040854

2   OBSOLETE SIDE-CHEEK RH
Baxi part no. 040743

3   OBSOLETE SUPPORT-FRONT-675C
Baxi part no. 040744

4   OBSOLETE SCREW ST NO 6 X 3/8IN FL HD - POZI ZP 9004
Baxi part no. 900491

5   OBSOLETE SUPPORT PANEL TOP
Baxi part no. 040745

6   OBSOLETE BRKT-REFLECTOR SUPPORT-675C
Baxi part no. 040746

7 Part number 102012, NUT-CAPT-U-TYPE-No8 ZNPD CHRM NUT-CAPT-U-TYPE-NO8 ZNPD CHRM
Baxi part no. 102012
£3.12
8   OBSOLETE RIVET-NYLON ROKUT
Baxi part no. 102009

9   OBSOLETE PANEL-TOP-ASSY-675C
Baxi part no. 040748

12   OBSOLETE STRAP-O/CASE SUPPORT-675C
Baxi part no. 040749

13   OBSOLETE PANEL-FRONT-ASSY-675C
Baxi part no. 040751

14   OBSOLETE REFLECTOR-675PW-C-W
Baxi part no. 042671

15 Part number 062600, OBSOLETE WASHER NYLON-CONTROLS COVER OBSOLETE WASHER NYLON-CONTROLS COVER
Baxi part no. 062600

16   CLIP-EDGE-SPR.STEEL
Baxi part no. 102010
£2.04
17   OBSOLETE GUARD-DRESS
Baxi part no. 042673

18   OBSOLETE ASSY PANEL/COVER BER C
Baxi part no. 040851

19   OBSOLETE SUPPORT-WALL FIXING
Baxi part no. 040685

20 Part number 040687, Bracket Support Wall Fixing BRACKET SUPPORT WALL FIXING
Baxi part no. 040687
£3.21
21   SCR-SET-M5X10-SLOT CHEESE
Baxi part no. 062415
£2.44
22   NUT-HEXAGON-M5-STEEL-
Baxi part no. 062440
£3.01
24   OBSOLETE BRACKET FIRE FIXING
Baxi part no. 040783

25   OBSOLETE COVER-LEVELLING SCREW 675S & W
Baxi part no. 040782

26   OBSOLETE CLIP-EDGE-S TYPE-SPR STEEL
Baxi part no. 062589

27   OBSOLETE SHIELD-HEAT-FLUE SPIGOT-B PW&C
Baxi part no. 040087

28   OBSOLETE DISTANCE PIECE-675PW & 675C
Baxi part no. 040645

30   OBSOLETE BUSH-CONTROL SHAFT
Baxi part no. 042752

31   OBSOLETE BRKT-CASE FIXING-LH-675C
Baxi part no. 040736

32   OBSOLETE BRKT-CASE RH & GAS TAP FIXING
Baxi part no. 040738

33   OBSOLETE SUPPORT-FOOT-ASSY 675C
Baxi part no. 040740

34   OBSOLETE FOOT-ADJUSTABLE.
Baxi part no. 042658

37 Part number 042718, KNOB-CONTROL KNOB-CONTROL
Baxi part no. 042718

38   OBSOLETE SHAFT-CONTROL
Baxi part no. 042720

40   SCR-NO.8X1.5IN RD HD BLK JAP
Baxi part no. 062319

42 Part number 042662, OBSOLETE TAP-FIRE CONT-DUPLEX OBSOLETE TAP-FIRE CONT-DUPLEX
Baxi part no. 042662

43   OBSOLETE GOVERNOR 1/4IN-1/8IN BSP
Baxi part no. 042663

45   OBSOLETE PILOT-TAP
Baxi part no. 042664

47   OBSOLETE PILOT-FILTER
Baxi part no. 042675

48 Part number 040707, OBSOLETE BURNER PILOT ASSY(INC N/O)675S OBSOLETE BURNER PILOT ASSY(INC N/O)675S
Baxi part no. 040707

49   OBSOLETE FIRE SUPP NUTS OLIVES B551
Baxi part no. 040848

50 Part number 042659, OBSOLETE BURNER-DUPLEX-675 OBSOLETE BURNER-DUPLEX-675
Baxi part no. 042659

51   OBSOLETE SCR-SET-M5 X 10MM-HEX HD.ZNPD
Baxi part no. 062425

52   WASHER-PLAIN-5MM ZINC PLTD
Baxi part no. 062447
£2.36
53 Part number 040799, OBSOLETE LINT ARRESTER-ASSY-FIRE OBSOLETE LINT ARRESTER-ASSY-FIRE
Baxi part no. 040799

53 Part number 040800, OBSOLETE LINT ARRESTER-ASSY-FIRE OBSOLETE LINT ARRESTER-ASSY-FIRE
Baxi part no. 040800

54 Part number 042724, INJECTOR-NG.18/240 INJECTOR-NG.18/240
Baxi part no. 042724

55   OBSOLETE PIPE-FIRE BRNR FEED WITH N&O
Baxi part no. 040674

56   OBSOLETE ASSY HEAT EXCHANGER - 675 C
Baxi part no. 040741

57   OBSOLETE RAIL SUPPORT
Baxi part no. 040648

58   OBSOLETE SHIELD BURNER
Baxi part no. 040680

60 Part number 042708, RADIANT (4 RADIANT CONVECTOR) RADIANT (4 RADIANT CONVECTOR)
Baxi part no. 042708
£18.96
