BAXI
BERMUDA B CAT 1N - (Overview)
Appliance Code: 37-077-06

Appliance Diagram


Overview diagram for Baxi Bermuda B CAT 1NClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0 Part number 230184, NOW USE 230184BAX KNOB CONTROL OUTER ADAPTER NOW USE 230184BAX KNOB CONTROL OUTER ADAPTER
Baxi part no. 230184
0   OBSOLETE KIT-KNOB CONT ADAPT-B/BEL/BARB
Baxi part no. 230285
0   OBSOLETE KNOB CONTROL INNER ADAPTER
Baxi part no. 230275
0 Part number 230184BAX, KNOB CONTROL OUTER ADAPTER KNOB CONTROL OUTER ADAPTER
Baxi part no. 230184BAX		 £13.40
1   OBSOLETE OUTER CASE-BERMUDA B (SEVILLE)
Baxi part no. 040974
2   OBSOLETE CANOPY ASSY(SEVILLE)BER B/BARB
Baxi part no. 040975
3   OBSOLETE KIT-PNL-TOP(SEVILLE)BER B/BARB
Baxi part no. 040976
4   OBSOLETE LOUVRE-ASSY-BERMUDA B
Baxi part no. 040618
5 Part number 062548, SCR-ST-No 8x3/8in POZI FL.HD A SCR-ST-NO 8X3/8IN POZI FL.HD A
Baxi part no. 062548		 £3.01
6   CLIP-EDGE-SPR.STEEL
Baxi part no. 102010		 £2.04
7   OBSOLETE KIT-CANOPYF(SEVILLE)BER B/BARB
Baxi part no. 040977
8   OBSOLETE DISTANCE PIECE TOP-BER.B
Baxi part no. 040599
9   OBSOLETE DISTANCE PIECE-REAR-BER.B
Baxi part no. 040604
10   OBSOLETE DISTANCE PIECE-SIDE-BER.B
Baxi part no. 040600
11   OBSOLETE REFLECTOR-SIDE-LH-BERMUDA B
Baxi part no. 043018
12   OBSOLETE REFLECTOR-SIDE-RH-BERMUDA B
Baxi part no. 043019
13   OBSOLETE REFLECTOR-TOP-BERMUDA B
Baxi part no. 043020
14   OBSOLETE REFLECTOR-TRIM/MESH SUPP-BER B
Baxi part no. 043021
15   OBSOLETE PANEL SIDE LH
Baxi part no. 040625
16   OBSOLETE PANEL SIDE RH
Baxi part no. 040626
17 Part number 062595, BUTTON-INDIC-UTD.CARR 70270-06 BUTTON-INDIC-UTD.CARR 70270-06
Baxi part no. 062595
18 Part number 042776, OBSOLETE SWITCH-ROCKER-BROWN. OBSOLETE SWITCH-ROCKER-BROWN.
Baxi part no. 042776
19   OBSOLETE CATCH-MAG DOOR-WM532-381RS
Baxi part no. 102104
20   OBSOLETE PANEL-HEARTH-BERMUDA B
Baxi part no. 040627
21 Part number 043045, CLIP-SPRING-UTD.CARR REF.24840 CLIP-SPRING-UTD.CARR REF.24840
Baxi part no. 043045		 £2.71
22   CLIP-CABLE-F/E-T/CARR 23790-11
Baxi part no. 062539
23   OBSOLETE ASSY BOX ELECTRICAL BERMUDA B
Baxi part no. 040628
24 Part number 042260, OBSOLETE LAMP HOLDER WITH RIM OBSOLETE LAMP HOLDER WITH RIM
Baxi part no. 042260
24 Part number 042260POT, LAMP HOLDER LAMP HOLDER
Baxi part no. 042260POT
25   OBSOLETE SCR-ST-NO8X5/8-HEX HD PZ ZP AB
Baxi part no. 062713
26   OBSOLETE PLUG-3 PIN & LEADS-BERMUDA B
Baxi part no. 040629
27 Part number 062683, SCR-ST-NO8x1/4 FLHD-POZI-ZPD B SCR-ST-NO8X1/4 FLHD-POZI-ZPD B
Baxi part no. 062683		 £2.53
28   GROMMET-RUBBER M36
Baxi part no. 042566		 £8.25
29   OBSOLETE BRKT-CANOPY/REFLECTOR FIXING
Baxi part no. 040603
30 Part number 042261, LAMP-60 WATT-RED LAMP-60 WATT-RED
Baxi part no. 042261
31 Part number 040640, OBSOLETE SOCKET-3 PIN-ASSY OBSOLETE SOCKET-3 PIN-ASSY
Baxi part no. 040640
32   OBSOLETE LEG-FINIAL/ADJ.FOOT-LH-BER.B
Baxi part no. 043132
33   OBSOLETE LEG-FINIAL/ADJ.FOOT-RH-BER.B
Baxi part no. 043133
34   OBSOLETE TAPPING SCREW ISO NO. 8AB X 13 RECESSED FL
Baxi part no. 062651
35   RAIL-TOP/BOTTOM-ASSY.
Baxi part no. 043029		 £94.31
36   NOW USE 043029 KIT RAIL TOP BERMUDA B
Baxi part no. 040776
37   NOW USE 043029KIT RAIL TOP BERMUDA B
Baxi part no. 040777
38   NOW USE 043029 KIT RAIL TOP BERMUDA B
Baxi part no. 040778
40   KIT-PIN-SECURING-BERMUDA B
Baxi part no. 040804		 £16.14
41   KIT-MOTIF-ROSE-BERMUDA B
Baxi part no. 040807		 £23.48
42   CLIP-SPRING-MOTIF-RETAINING.
Baxi part no. 043049
43   FIX PUSH ON 1/8IN
Baxi part no. 042499		 £2.51
44   OBSOLETE MESH-GLASS SUPPORT-BER.B
Baxi part no. 040605
45   OBSOLETE GUARD-DRESS-BERMUDA B
Baxi part no. 043023
46   OBSOLETE COVER-CONTROL ASSY-BER B
Baxi part no. 040652
48 Part number 040608, Assy Heat Ex BBU Rads (Spares) ASSY HEAT EX BBU RADS (SPARES)
Baxi part no. 040608
49 Part number 040809, PLATE-MOUNTING-BERMUDA B PLATE-MOUNTING-BERMUDA B
Baxi part no. 040809		 £9.86
50   RESTRICTOR-REAR-RADIANTS-BER B
Baxi part no. 040810		 £9.12
51   OBSOLETE PLATE-BACK-BERMUDA B
Baxi part no. 040610
52   SCR-ST-NO8X3/4-PAN HD POZ ZNPD
Baxi part no. 062706		 £2.42
53   WASHER-PLAIN-5MM ZINC PLTD
Baxi part no. 062447		 £2.36
54   OBSOLETE CHANNEL-REAR-BER.B.
Baxi part no. 040607
55   PLATE-VIEW RESTRICTOR-BER.B
Baxi part no. 040775		 £4.83
56   OBSOLETE SHIELD-HEAT-FLUE-BERMUDA B
Baxi part no. 040606
57 Part number 040602, OBSOLETE PLATE-BACKING. SL/GF OBSOLETE PLATE-BACKING. SL/GF
Baxi part no. 040602
58 Part number 062531, SCR-TF-M5x8mm-PAN POZI ZN PD SCR-TF-M5X8MM-PAN POZI ZN PD
Baxi part no. 062531		 £3.12
59 Part number 040003, Kit Support Wall Fixing PW3/C3 KIT SUPPORT WALL FIXING PW3/C3
Baxi part no. 040003		 £33.46
60   SCR-SET-M5X10-SLOT CHEESE
Baxi part no. 062415		 £2.44
61   NUT-HEXAGON-M5-STEEL-
Baxi part no. 062440		 £3.01
62 Part number 062452, WASHER SHAKEPROOF INT-M5-ZN PD WASHER SHAKEPROOF INT-M5-ZN PD
Baxi part no. 062452		 £3.12
63   SCR-NO.8X1.5IN RD HD BLK JAP
Baxi part no. 062319
64 Part number 062320, PLUG WALL FIXING No8-PLASTIC PLUG WALL FIXING NO8-PLASTIC
Baxi part no. 062320		 £2.41
66   OBSOLETE EXTENSION-FOOT-BERMUDA B
Baxi part no. 040808
67   OBSOLETE NUT-CAP-U-TYPE 3/16INBSW CH ZP
Baxi part no. 102092
68 Part number 043032, OBSOLETE KNOB-GAS TAP CONTROL-BER B OBSOLETE KNOB-GAS TAP CONTROL-BER B
Baxi part no. 043032
69   OBSOLETE PANEL MOUNTING
Baxi part no. 040662
70 Part number 227313, CAP-PROTECTION CAP-PROTECTION
Baxi part no. 227313		 £1.87
70   SCR-SET-M8X35MM-HEX.HD.BLK
Baxi part no. 062749		 £2.33
71   OBSOLETE FULL NUT M8 HEXAGON - STEEL GRADE 8. BS369
Baxi part no. 062723
71 Part number 043053, GROMMET-RUB.9.3mm ID X 18mm OD GROMMET-RUB.9.3MM ID X 18MM OD
Baxi part no. 043053
71   CLIP-CABLE RETAINING PLASTIC.
Baxi part no. 042911
72 Part number 042872, TAP-FIRE-CONTROL-IGNITOR ASSY TAP-FIRE-CONTROL-IGNITOR ASSY
Baxi part no. 042872
73 Part number 042941, IGNITOR-PIEZO-REF 66111 (VERN) IGNITOR-PIEZO-REF 66111 (VERN)
Baxi part no. 042941
74   OBSOLETE SCR-SET-M4 X 6MM HX.HD.PZ.ZNPD
Baxi part no. 062715
75 Part number 042874, CONNECTOR-REDUCING 10mm TO 6mm CONNECTOR-REDUCING 10MM TO 6MM
Baxi part no. 042874
76 Part number 042875, NUT-HEXAGON LOCK-3/8 BSP NUT-HEXAGON LOCK-3/8 BSP
Baxi part no. 042875		 £4.72
77   OBSOLETE PIPE-FIRE TAP SUPP N&O BERM B
Baxi part no. 040678
78   OBSOLETE PIPE-BRNR FEED ETC INNER BER B
Baxi part no. 040679
79   OBSOLETE PIPE-BRNR FEED NUTS&OLVS BER B
Baxi part no. 040683
81 Part number 043016, BURNER-DUPLEX BURNER-DUPLEX
Baxi part no. 043016
82 Part number 043026, ELECTRODE-SPARK-IGNITION ELECTRODE-SPARK-IGNITION
Baxi part no. 043026
83   NUT-FULL HEX-4MM-ZINC PLTD
Baxi part no. 062439		 £3.01
84   OBSOLETE WASHER-PLAIN-4MM-ZINC. PLTD
Baxi part no. 062446
85 Part number 043043, OBSOLETE LEAD-ELECTRODE-BER B. OBSOLETE LEAD-ELECTRODE-BER B.
Baxi part no. 043043
86 Part number 040799, OBSOLETE LINT ARRESTER-ASSY-FIRE OBSOLETE LINT ARRESTER-ASSY-FIRE
Baxi part no. 040799
86 Part number 040800, OBSOLETE LINT ARRESTER-ASSY-FIRE OBSOLETE LINT ARRESTER-ASSY-FIRE
Baxi part no. 040800
87 Part number 043025, RADIANT SINGLE-4 RAD CONVECTOR RADIANT SINGLE-4 RAD CONVECTOR
Baxi part no. 043025		 £16.74
88 Part number 040677, pipe supply PIPE SUPPLY
Baxi part no. 040677
88 Part number 043012, PIPE-FIRE SUPPLY-10mm DIA PIPE-FIRE SUPPLY-10MM DIA
Baxi part no. 043012
89   OBSOLETE FITTERS INSTRUCTIONS 155656 37-077-06 155
Baxi part no. 155656
90   OBSOLETE USERS INSTRUCTIONS 155657 37-077-06 155-6
Baxi part no. 155657
