BAXI
BERMUDA 57/3 M - (Heat Exchanger)
Appliance Code: 44-077-63

Appliance Diagram


Heat Exchanger diagram for Baxi Bermuda 57/3 MClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0 Part number 230337, OBSOLETE T/STAT BERMUDA OVERHEAT OBSOLETE T/STAT BERMUDA OVERHEAT
Baxi part no. 230337
0 Part number 230341, OBSOLETE BAX LEAD ASSEMBLY OBSOLETE BAX LEAD ASSEMBLY
Baxi part no. 230341
0 Part number 230339, NOW USE 230339BAX Assembly Pipe NOW USE 230339BAX ASSEMBLY PIPE
Baxi part no. 230339
0 Part number 230337BAX, OBSOLETE T/STAT BERMUDA OVERHEAT OBSOLETE T/STAT BERMUDA OVERHEAT
Baxi part no. 230337BAX
0 Part number 230339BAX, Assembly Pipe ASSEMBLY PIPE
Baxi part no. 230339BAX		 £15.57
1 Part number 234403, BOX-COMBUSTION-ASSEMBLY BOX-COMBUSTION-ASSEMBLY
Baxi part no. 234403
2 Part number 230853, PANEL-BASE-COMB-BOX PANEL-BASE-COMB-BOX
Baxi part no. 230853		 £11.68
3   OBSOLETE BRKT-SUPPORT-HEAT/EXCH-LH
Baxi part no. 230855
4   OBSOLETE BRKT-SUPPORT-HEAT/EXCH-RH
Baxi part no. 231063
5 Part number 040664, DIVERTER DRAUGHT HOOD COMB BOX DIVERTER DRAUGHT HOOD COMB BOX
Baxi part no. 040664
5 Part number 238132BAX, FLUE HOOD DIVERTER ASD FLUE HOOD DIVERTER ASD
Baxi part no. 238132BAX
6 Part number 062571, SCR-ST-No8x1/2PAN.HD PZ ZNPD A SCR-ST-NO8X1/2PAN.HD PZ ZNPD A
Baxi part no. 062571		 £3.12
7 Part number 062431, SCR-SET-M5 x 8MM-HEX HD ZNPD SCR-SET-M5 X 8MM-HEX HD ZNPD
Baxi part no. 062431		 £3.16
8 Part number 062452, WASHER SHAKEPROOF INT-M5-ZN PD WASHER SHAKEPROOF INT-M5-ZN PD
Baxi part no. 062452		 £3.12
9   NUT-HEXAGON-M5-STEEL-
Baxi part no. 062440		 £3.01
10   NOW USE 231621BAX BRACKET-SUPPORT-INSULATION
Baxi part no. 231621
10   BRACKET-SUPPORT-INSULATION
Baxi part no. 231621BAX		 £8.47
11 Part number 062531, SCR-TF-M5x8MM-PAN POZI ZN PD SCR-TF-M5X8MM-PAN POZI ZN PD
Baxi part no. 062531		 £3.12
12 Part number 231175, NOW USE 231175BAX INSULATION-SIDE-COMB-BOX NOW USE 231175BAX INSULATION-SIDE-COMB-BOX
Baxi part no. 231175
12 Part number 231175BAX, INSULATION-SIDE-COMB-BOX INSULATION-SIDE-COMB-BOX
Baxi part no. 231175BAX		 £12.65
13 Part number 231176, INSULATION-BACK-COMB-BOX INSULATION-BACK-COMB-BOX
Baxi part no. 231176		 £12.65
14   OBSOLETE
Baxi part no. 230852
15 Part number 233851, INSULATION-BACK-HEAT EXCH INSULATION-BACK-HEAT EXCH
Baxi part no. 233851
16 Part number 062683, SCR-ST-NO8x1/4 FLHD-POZI-ZPD B SCR-ST-NO8X1/4 FLHD-POZI-ZPD B
Baxi part no. 062683		 £2.53
17   PLATE-BLANKING-BOILER
Baxi part no. 232663		 £8.20
18 Part number 235544, SEAL-HT/EXCH-SILICONE-SIDE SEAL-HT/EXCH-SILICONE-SIDE
Baxi part no. 235544		 £11.77
19 Part number 230854, PANEL DOOR COM BOX PANEL DOOR COM BOX
Baxi part no. 230854
20 Part number 231177, INSULATION-FRONT-COMB-BOX INSULATION-FRONT-COMB-BOX
Baxi part no. 231177		 £12.65
21 Part number 062596, NUT-WING M5 STEEL ZN PD NUT-WING M5 STEEL ZN PD
Baxi part no. 062596		 £3.05
22   CLIP-CABLE-FLARED EDGE
Baxi part no. 043131		 £8.89
23 Part number 102028, SEAL-THERMOSTAT PHIAL. SEAL-THERMOSTAT PHIAL.
Baxi part no. 102028		 £8.26
24 Part number 042855, PLUG-BUTTON COMB BOX F/PANEL PLUG-BUTTON COMB BOX F/PANEL
Baxi part no. 042855
25   SHIELD-DRAUGHT-FIRE-FL-EFF
Baxi part no. 231906
26 Part number 231997, SHIELD-DRAUGHT-FIRE-RADIANT SHIELD-DRAUGHT-FIRE-RADIANT
Baxi part no. 231997
27 Part number 231895, INSULATION-ACOUSTIC INSULATION-ACOUSTIC
Baxi part no. 231895
28   CLIP-CABLE-P TYPE-NYLON
Baxi part no. 226902		 £4.04
29   SCR-NO.8X1.5IN RD HD BLK JAP
Baxi part no. 062319
30 Part number 062320, PLUG WALL FIXING No8-PLASTIC PLUG WALL FIXING NO8-PLASTIC
Baxi part no. 062320		 £2.41
31 Part number 233303, NOW USE 248435 HEAT EXCHANGER NOW USE 248435 HEAT EXCHANGER
Baxi part no. 233303
31 Part number 248435, BERMUDA 26 FIN HEAT EX-SPARES BERMUDA 26 FIN HEAT EX-SPARES
Baxi part no. 248435		 £511.53
32 Part number 042889BAX, OBSOLETE POCKET-THERMOSTAT 1/4in BSP OBSOLETE POCKET-THERMOSTAT 1/4IN BSP
Baxi part no. 042889BAX
32 Part number 042889, OBSOLETE POCKET-THERMOSTAT 1/4in BSP OBSOLETE POCKET-THERMOSTAT 1/4IN BSP
Baxi part no. 042889
33 Part number 230192, ADAPTER-1in-BSP TO 22MM COMP ADAPTER-1IN-BSP TO 22MM COMP
Baxi part no. 230192
34 Part number 043078, TEE-INJ.22mm Fx22mm ODx28mm OD TEE-INJ.22MM FX22MM ODX28MM OD
Baxi part no. 043078		 £15.90
35 Part number 043080, NUT-COMPRESSION 22mm-CONEX NUT-COMPRESSION 22MM-CONEX
Baxi part no. 043080		 £6.05
36 Part number 043081, OLIVE-BRASS-22mm-CONEX OLIVE-BRASS-22MM-CONEX
Baxi part no. 043081		 £3.19
37 Part number 233666, BAFFLE-TOP-HEAT-EXCH BAFFLE-TOP-HEAT-EXCH
Baxi part no. 233666		 £8.71
38 Part number 233814, BAFFLE-BOTTOM-HEAT-EXCH BAFFLE-BOTTOM-HEAT-EXCH
Baxi part no. 233814		 £13.31
39 Part number 062636, OBSOLETE GASKET-BOILER BER 401 OBSOLETE GASKET-BOILER BER 401
Baxi part no. 062636
39 Part number 062636BAX, OBSOLETE GASKET-BOILER BER 401(Brown) OBSOLETE GASKET-BOILER BER 401(BROWN)
Baxi part no. 062636BAX
40   BOLT-M8X110-HEXAGONAL-HT.STEEL
Baxi part no. 233895		 £8.09
41 Part number 062597, NUT-HEX-M8-PASS-ZNPD NUT-HEX-M8-PASS-ZNPD
Baxi part no. 062597		 £3.12
42 Part number 236129, KIT VALVE HONEYWELL KIT VALVE HONEYWELL
Baxi part no. 236129
42 Part number 236129BAX, KIT VALVE KIT VALVE
Baxi part no. 236129BAX
43   OBSOLETE O RING-17MM-I/D X 2MM THICK
Baxi part no. 232530
44 Part number 042812, TAILPIECE-M-TAP-SERVICE-3WAY TAILPIECE-M-TAP-SERVICE-3WAY
Baxi part no. 042812		 £17.19
45 Part number 042811, NUT-UNION- (for 7/8 BSP LINER) NUT-UNION- (FOR 7/8 BSP LINER)
Baxi part no. 042811		 £9.11
46   OBSOLETE GAS TAP SERVICE 3 WAY - GASCON 73 1786A
Baxi part no. 235674
47 Part number 102005, THERM-18/24HWELL-Q309A2721 STD THERM-18/24HWELL-Q309A2721 STD
Baxi part no. 102005		 £19.17
48 Part number 230850, BURNER BOILER BLADED BURNER BOILER BLADED
Baxi part no. 230850		 £158.35
49 Part number 234512, INJECTOR BURNER 57/3 STERO B21 INJECTOR BURNER 57/3 STERO B21
Baxi part no. 234512		 £7.70
50 Part number 7211908, WASHER COPPER SEALING WASHER COPPER SEALING
Baxi part no. 7211908		 £3.14
50 Part number 062695, NOW USE 7211908 WASHER COPPER INJECTOR SEALING NOW USE 7211908 WASHER COPPER INJECTOR SEALING
Baxi part no. 062695
51 Part number 231878BAX, OBSOLETE BURNER-PILOT Q385A2036 OBSOLETE BURNER-PILOT Q385A2036
Baxi part no. 231878BAX
51 Part number 231878, OBSOLETE BURNER-PILOT Q385A2036 OBSOLETE BURNER-PILOT Q385A2036
Baxi part no. 231878
52 Part number 112011, OBSOLETE INJECTOR-PILOT H/WELL-.38/.36A OBSOLETE INJECTOR-PILOT H/WELL-.38/.36A
Baxi part no. 112011
52 Part number 402560, OBSOLETE PILOT INJECTOR (STD) OBSOLETE PILOT INJECTOR (STD)
Baxi part no. 402560
53   OBSOLETE PIPE PILOT FEED ASSY-BE453/573
Baxi part no. 236507
54 Part number 234160, OBSOLETE ELECTRODE-PILOT 45900413-004 OBSOLETE ELECTRODE-PILOT 45900413-004
Baxi part no. 234160
55 Part number 102143, LEAD-ELECTRODE-BER552-WM381RS LEAD-ELECTRODE-BER552-WM381RS
Baxi part no. 102143
56   OBSOLETE ARRESTOR-LINT-DOOR
Baxi part no. 231144
57 Part number 236508, INSULATION ASSY INJEC -453/573 INSULATION ASSY INJEC -453/573
Baxi part no. 236508		 £9.71
58   OBSOLETE MIRROR-PILOT
Baxi part no. 233887
59   SCR-SET-M4 X 16MM-CH.HD-ZNPD
Baxi part no. 062411		 £1.61
60   OBSOLETE SET-OF-WIRES-57/3 &45/3
Baxi part no. 236354
61   OBSOLETE WIRE-HARNESS
Baxi part no. 236230
62 Part number 062691, OBSOLETE PLUG-2 PIN-ELKAY ELECTRICS OBSOLETE PLUG-2 PIN-ELKAY ELECTRICS
Baxi part no. 062691
63 Part number 043212, OBSOLETE SOCKET-2 PIN-5 TERMINALS OBSOLETE SOCKET-2 PIN-5 TERMINALS
Baxi part no. 043212
64 Part number 062532, SCR-TF-M4x8mm-PAN POZI ZN PD SCR-TF-M4X8MM-PAN POZI ZN PD
Baxi part no. 062532		 £3.01
65   OBSOLETE CAPACITOR-ASSEMBLY
Baxi part no. 236239
66 Part number 234497, NOW USE 233952 THERMOSTAT NOW USE 233952 THERMOSTAT
Baxi part no. 234497
66 Part number 233952, THERMOSTAT-BOILER THERMOSTAT-BOILER
Baxi part no. 233952		 £19.75
67   BRACKET-MOUNTING-CONTROLS
Baxi part no. 231064BAX		 £5.44
67   NOW USE 231064BAX BRACKET-MOUNTING-CONTROLS
Baxi part no. 231064
68   SCR-SET-M5X8MM-PAN POZI ZNPD
Baxi part no. 062727		 £3.06
69 Part number 043129, CLIP-EDGE-S TYPE CLIP-EDGE-S TYPE
Baxi part no. 043129		 £2.01
70   OBSOLETE HOUSING-THERMOSTAT
Baxi part no. 233687
71   OBSOLETE BUTTON-INDICATOR-WHITE.
Baxi part no. 223959
72 Part number 062560, SCR-TF-M4 x 6mm PAN POZI ZN P SCR-TF-M4 X 6MM PAN POZI ZN P
Baxi part no. 062560		 £3.12
73 Part number 040456, KIT-PIEZO IGN-BERM 552 KIT-PIEZO IGN-BERM 552
Baxi part no. 040456
74   OBSOLETE BRACKET-MOUNTING-PIEZO
Baxi part no. 233668
75 Part number 234885, OBSOLETE KIT O/HT STAT-BER.45/3M 57/3M OBSOLETE KIT O/HT STAT-BER.45/3M 57/3M
Baxi part no. 234885
