BAXI
BERMUDA 57/3 E - (First Line Spares)
Appliance Code: 44-077-62

Appliance Diagram


First Line Spares diagram for Baxi Bermuda 57/3 EClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0 Part number 230339, NOW USE 230339BAX Assembly Pipe NOW USE 230339BAX ASSEMBLY PIPE
Baxi part no. 230339
0 Part number 236149, PLUG ASSY PLUG ASSY
Baxi part no. 236149		 £8.87
0 Part number 236147, THERMOSTAT RANCO LM7 THERMOSTAT RANCO LM7
Baxi part no. 236147		 £24.64
0 Part number 230339BAX, Assembly Pipe ASSEMBLY PIPE
Baxi part no. 230339BAX		 £15.57
1 Part number 234403, BOX-COMBUSTION-ASSEMBLY BOX-COMBUSTION-ASSEMBLY
Baxi part no. 234403
2 Part number 230853, PANEL-BASE-COMB-BOX PANEL-BASE-COMB-BOX
Baxi part no. 230853		 £11.68
3   OBSOLETE BRKT-SUPPORT-HEAT/EXCH-LH
Baxi part no. 230855
4   OBSOLETE BRKT-SUPPORT-HEAT/EXCH-RH
Baxi part no. 231063
5 Part number 040664, DIVERTER DRAUGHT HOOD COMB BOX DIVERTER DRAUGHT HOOD COMB BOX
Baxi part no. 040664
5 Part number 238132BAX, FLUE HOOD DIVERTER ASD FLUE HOOD DIVERTER ASD
Baxi part no. 238132BAX
6 Part number 062571, SCR-ST-No8x1/2PAN.HD PZ ZNPD A SCR-ST-NO8X1/2PAN.HD PZ ZNPD A
Baxi part no. 062571		 £3.12
7 Part number 062431, SCR-SET-M5 x 8mm-HEX HD ZNPD SCR-SET-M5 X 8MM-HEX HD ZNPD
Baxi part no. 062431		 £3.16
8 Part number 062452, WASHER SHAKEPROOF INT-M5-ZN PD WASHER SHAKEPROOF INT-M5-ZN PD
Baxi part no. 062452		 £3.12
9   NUT-HEXAGON-M5-STEEL-
Baxi part no. 062440		 £3.01
10   NOW USE 231621BAX BRACKET-SUPPORT-INSULATION
Baxi part no. 231621
10   BRACKET-SUPPORT-INSULATION
Baxi part no. 231621BAX		 £8.47
11 Part number 062531, SCR-TF-M5x8mm-PAN POZI ZN PD SCR-TF-M5X8MM-PAN POZI ZN PD
Baxi part no. 062531		 £3.12
12 Part number 231175, NOW USE 231175BAX INSULATION-SIDE-COMB-BOX NOW USE 231175BAX INSULATION-SIDE-COMB-BOX
Baxi part no. 231175
12 Part number 231175BAX, INSULATION-SIDE-COMB-BOX INSULATION-SIDE-COMB-BOX
Baxi part no. 231175BAX		 £12.65
13 Part number 231176, INSULATION-BACK-COMB-BOX INSULATION-BACK-COMB-BOX
Baxi part no. 231176		 £12.65
14   OBSOLETE
Baxi part no. 230852
15 Part number 233851, INSULATION-BACK-HEAT EXCH INSULATION-BACK-HEAT EXCH
Baxi part no. 233851
16 Part number 062683, SCR-ST-NO8x1/4 FLHD-POZI-ZPD B SCR-ST-NO8X1/4 FLHD-POZI-ZPD B
Baxi part no. 062683		 £2.53
17   PLATE-BLANKING-BOILER
Baxi part no. 232663		 £8.20
18 Part number 235544, SEAL-HT/EXCH-SILICONE-SIDE SEAL-HT/EXCH-SILICONE-SIDE
Baxi part no. 235544		 £11.77
19 Part number 230854, PANEL DOOR COM BOX PANEL DOOR COM BOX
Baxi part no. 230854
20 Part number 231177, INSULATION-FRONT-COMB-BOX INSULATION-FRONT-COMB-BOX
Baxi part no. 231177		 £12.65
21 Part number 062596, NUT-WING M5 STEEL ZN PD NUT-WING M5 STEEL ZN PD
Baxi part no. 062596		 £3.05
22   CLIP-CABLE-FLARED EDGE
Baxi part no. 043131		 £8.89
23 Part number 102028, SEAL-THERMOSTAT PHIAL. SEAL-THERMOSTAT PHIAL.
Baxi part no. 102028		 £8.26
24 Part number 233905, STRIP-THERMOSTAT STRIP-THERMOSTAT
Baxi part no. 233905		 £4.94
24 Part number 042855, PLUG-BUTTON COMB BOX F/PANEL PLUG-BUTTON COMB BOX F/PANEL
Baxi part no. 042855
25   SHIELD-DRAUGHT-FIRE-FL-EFF
Baxi part no. 231906
26 Part number 231997, SHIELD-DRAUGHT-FIRE-RADIANT SHIELD-DRAUGHT-FIRE-RADIANT
Baxi part no. 231997
27 Part number 231895, INSULATION-ACOUSTIC INSULATION-ACOUSTIC
Baxi part no. 231895
28   CLIP-CABLE-P TYPE-NYLON
Baxi part no. 226902		 £4.04
29   SCR-NO.8X1.5IN RD HD BLK JAP
Baxi part no. 062319
30 Part number 062320, PLUG WALL FIXING No8-PLASTIC PLUG WALL FIXING NO8-PLASTIC
Baxi part no. 062320		 £2.41
31 Part number 248435, BERMUDA 26 FIN HEAT EX-SPARES BERMUDA 26 FIN HEAT EX-SPARES
Baxi part no. 248435		 £511.53
31 Part number 233303, NOW USE 248435 HEAT EXCHANGER NOW USE 248435 HEAT EXCHANGER
Baxi part no. 233303
32 Part number 042889, OBSOLETE POCKET-THERMOSTAT 1/4in BSP OBSOLETE POCKET-THERMOSTAT 1/4IN BSP
Baxi part no. 042889
32 Part number 042889BAX, OBSOLETE POCKET-THERMOSTAT 1/4in BSP OBSOLETE POCKET-THERMOSTAT 1/4IN BSP
Baxi part no. 042889BAX
33 Part number 230192, ADAPTER - 1" BSP TO 22mm COMP ADAPTER - 1" BSP TO 22MM COMP
Baxi part no. 230192
34 Part number 043078, TEE-INJ.22mm Fx22mm ODx28mm OD TEE-INJ.22MM FX22MM ODX28MM OD
Baxi part no. 043078		 £15.90
35 Part number 043080, NUT-COMPRESSION 22mm-CONEX NUT-COMPRESSION 22MM-CONEX
Baxi part no. 043080		 £6.05
36 Part number 043081, OLIVE-BRASS-22mm-CONEX OLIVE-BRASS-22MM-CONEX
Baxi part no. 043081		 £3.19
37 Part number 233666, BAFFLE-TOP-HEAT-EXCH BAFFLE-TOP-HEAT-EXCH
Baxi part no. 233666		 £8.71
38 Part number 233814, BAFFLE-BOTTOM-HEAT-EXCH BAFFLE-BOTTOM-HEAT-EXCH
Baxi part no. 233814		 £13.31
39 Part number 062636, OBSOLETE GASKET-BOILER BER 401 OBSOLETE GASKET-BOILER BER 401
Baxi part no. 062636
39 Part number 062636BAX, OBSOLETE GASKET-BOILER BER 401(Brown) OBSOLETE GASKET-BOILER BER 401(BROWN)
Baxi part no. 062636BAX
40   BOLT-M8X110-HEXAGONAL-HT.STEEL
Baxi part no. 233895		 £8.09
41 Part number 062597, NUT-HEX-M8-PASS-ZNPD NUT-HEX-M8-PASS-ZNPD
Baxi part no. 062597		 £3.12
42 Part number 236579, KIT VALVE (ELECTRONIC) KIT VALVE (ELECTRONIC)
Baxi part no. 236579
43   OBSOLETE O RING-17MM-I/D X 2MM THICK
Baxi part no. 232530
44 Part number 042812, TAILPIECE-M-TAP-SERVICE-3WAY TAILPIECE-M-TAP-SERVICE-3WAY
Baxi part no. 042812		 £17.19
45 Part number 042811, NUT-UNION- (for 7/8 BSP LINER) NUT-UNION- (FOR 7/8 BSP LINER)
Baxi part no. 042811		 £9.11
46   OBSOLETE GAS TAP SERVICE 3 WAY - GASCON 73 1786A
Baxi part no. 235674
47 Part number 232215, SENSOR-TEMPERATURE-ASSEMBLED SENSOR-TEMPERATURE-ASSEMBLED
Baxi part no. 232215
48 Part number 230850, BURNER BOILER BLADED BURNER BOILER BLADED
Baxi part no. 230850		 £158.35
49 Part number 234512, INJECTOR BURNER 57/3 STERO B21 INJECTOR BURNER 57/3 STERO B21
Baxi part no. 234512		 £7.70
50 Part number 062695, NOW USE 7211908 WASHER COPPER INJECTOR SEALING NOW USE 7211908 WASHER COPPER INJECTOR SEALING
Baxi part no. 062695
50 Part number 7211908, WASHER COPPER SEALING WASHER COPPER SEALING
Baxi part no. 7211908		 £3.14
51 Part number 231878BAX, OBSOLETE BURNER-PILOT Q385A2036 OBSOLETE BURNER-PILOT Q385A2036
Baxi part no. 231878BAX
51 Part number 231878, OBSOLETE BURNER-PILOT Q385A2036 OBSOLETE BURNER-PILOT Q385A2036
Baxi part no. 231878
52 Part number 112011, OBSOLETE INJECTOR-PILOT H/WELL-.38/.36A OBSOLETE INJECTOR-PILOT H/WELL-.38/.36A
Baxi part no. 112011
52 Part number 402560, OBSOLETE PILOT INJECTOR (STD) OBSOLETE PILOT INJECTOR (STD)
Baxi part no. 402560
53   OBSOLETE PIPE PILOT FEED ASSY-BE453/573
Baxi part no. 236507
54 Part number 234160, OBSOLETE ELECTRODE-PILOT 45900413-004 OBSOLETE ELECTRODE-PILOT 45900413-004
Baxi part no. 234160
55 Part number 102143, LEAD-ELECTRODE-BER552-WM381RS LEAD-ELECTRODE-BER552-WM381RS
Baxi part no. 102143
56   OBSOLETE ARRESTOR-LINT-DOOR
Baxi part no. 231144
57 Part number 236508, INSULATION ASSY INJEC -453/573 INSULATION ASSY INJEC -453/573
Baxi part no. 236508		 £9.71
58   OBSOLETE MIRROR-PILOT
Baxi part no. 233887
59   SCR-SET-M4 X 16MM-CH.HD-ZNPD
Baxi part no. 062411		 £1.61
60 Part number 231664, NOW USE 231664BAX SHIELD-HEAT-CONTROLS NOW USE 231664BAX SHIELD-HEAT-CONTROLS
Baxi part no. 231664
60 Part number 231664BAX, SHIELD-HEAT-CONTROLS SHIELD-HEAT-CONTROLS
Baxi part no. 231664BAX		 £9.71
61 Part number 235900, POTENTIOMETER-ASSEMBLY POTENTIOMETER-ASSEMBLY
Baxi part no. 235900		 £24.58
62 Part number 230981, KNOB - THERMOSTAT KNOB - THERMOSTAT
Baxi part no. 230981		 £9.51
63 Part number 231877, PLUG - 4-PIN PLUG - 4-PIN
Baxi part no. 231877
64 Part number 231402, FUSE-4AMP-QUICK BLOW-PF MK2 FUSE-4AMP-QUICK BLOW-PF MK2
Baxi part no. 231402		 £3.06
65   BRACKET-MOUNTING-POTENTIOMETER
Baxi part no. 232096		 £2.05
66 Part number 232207, NOW USE 232207BAX WIRE-ASSY NOW USE 232207BAX WIRE-ASSY
Baxi part no. 232207
66 Part number 232207BAX, WIRE-ASSY WIRE-ASSY
Baxi part no. 232207BAX		 £8.37
67   BRACKET-MOUNTING-CONTROLS
Baxi part no. 231064BAX		 £5.44
67   NOW USE 231064BAX BRACKET-MOUNTING-CONTROLS
Baxi part no. 231064
68   SCR-SET-M5X8MM-PAN POZI ZNPD
Baxi part no. 062727		 £3.06
69 Part number 043129, CLIP-EDGE-S TYPE CLIP-EDGE-S TYPE
Baxi part no. 043129		 £2.01
70 Part number 232031, BOX COVER POTENTIOMETER BOX COVER POTENTIOMETER
Baxi part no. 232031
71 Part number 231581, OBSOLETE BOX ELECTRICAL OBSOLETE BOX ELECTRICAL
Baxi part no. 231581
71 Part number 231581BAX, OBSOLETE BOX ELECTRICAL OBSOLETE BOX ELECTRICAL
Baxi part no. 231581BAX
72 Part number 231598BAX, OBSOLETE GUARD ELECTRICAL OBSOLETE GUARD ELECTRICAL
Baxi part no. 231598BAX
72 Part number 231598, OBSOLETE GUARD ELECTRICAL OBSOLETE GUARD ELECTRICAL
Baxi part no. 231598
73 Part number 231671BAX, OBSOLETE BOARD ELECTRONICS CONTROL OBSOLETE BOARD ELECTRONICS CONTROL
Baxi part no. 231671BAX
74 Part number 231673, OBSOLETE BOX COVER ELECTRICAL OBSOLETE BOX COVER ELECTRICAL
Baxi part no. 231673
75 Part number 231405, SCR-ST No 6x1/2-PAN-POZI-PL SCR-ST NO 6X1/2-PAN-POZI-PL
Baxi part no. 231405		 £3.16
76 Part number 235565, KIT O/HT STAT-ELEC.45/3E 57/3 KIT O/HT STAT-ELEC.45/3E 57/3
Baxi part no. 235565		 £42.56
