-10/111/190404120227157367 "Controls diagram for Ariston Clas HE 38 (Edition 7 - 30/08/2011)")
You can then pinch & zoom to adjust the size.
| 801 |  |
FUSE 250V 2A Ariston part no. 60054442 |
£1.85 | |
| 803 |  |
P.C.B (CLIP-IN) E-BUS Ariston part no. 65109108 |
£59.45 | |
| 806 |  |
PUSH Ariston part no. 65104228 |
£6.95 | |
| 807 |  |
IGNITER Ariston part no. 61002105-20 |
£50.54 | |
| 809 |  |
INSPECTION COVER Ariston part no. 65104294 |
£4.92 | |
| 811 |  |
NOW USE 65120831 MECHANICAL CLOCK Ariston part no. 999599 |
||
| 811 | MECHANICAL TIMER 3V DC Ariston part no. 65120831 |
£84.11 | ||
| 814 |  |
CONTROL PANEL Ariston part no. 65104300 |
£21.53 | |
| 815 |  |
P.C.B. (MAIN) Ariston part no. 65109138-03 |
£260.74 | |
| 816 |  |
P.C.B. (DISPLAY) Ariston part no. 65104448 |
£65.82 | |
| 819 |  |
PUSH BUTTON GROUP (MENU) Ariston part no. 65104503 |
£2.27 | |
| 820 |  |
PUSH BUTTON (R.H.SIDE) Ariston part no. 65104222 |
£3.49 | |
| 821 |  |
PUSH BUTTON (L.H.SIDE) Ariston part no. 65104229 |
£3.55 | |
| 822 |  |
PUSH (CASE DOOR) Ariston part no. 65100676 |
£4.83 | |
| 823 |  |
KNOB Ariston part no. 65104450 |
£5.62 | |
| 824 |  |
CONTROL PANEL COVER (REAR) Ariston part no. 65104293 |
£16.22 | |
| 825 |  |
PRESSURE GAUGE Ariston part no. 65104234 |
£24.40 | |
| 828 |  |
FRONT COVER Ariston part no. 65104449 |
£28.95 | |
| 851 |  |
SERIGRAPHED STRIP KIT Ariston part no. 60000731 |
£54.00 | |
| 855 |  |
CABLE CLAMP Ariston part no. 571562 |
£2.67 | |
| 856 |  |
CABLE CLAMP Ariston part no. 65103377 |
£4.46 | |
| 880 |  |
CABLE (IGNITION ELECTRODE) Ariston part no. 60000527 |
£5.15 | |
| 880 |  |
FEEDER 240V Ariston part no. 60000542 |
£8.49 | |
| 880 |  |
IGNITOR - GAS VALVE CABLE Ariston part no. 60000543 |
£19.49 | |
| 880 |  |
CABLE (IONISATION ELECTRODE) Ariston part no. 60000567 |
£3.40 | |
| 880 |  |
TIME CLOCK CABLE Ariston part no. 60000670 |
£4.55 | |
| 880 |  |
DISPLAY WIRING - 5 WIRES BLUES Ariston part no. 60000746 |
£4.64 | |
| 880 |  |
FLOW METER CABLE Ariston part no. 60000813 |
£5.98 | |
| 880 |  |
NTC - OVERHEAT - PRESSURE SENSOR CABLE Ariston part no. 60001135 |
£14.54 | |
| 880 |  |
NTC PROBE - NTC EXCHANGER - FAN Ariston part no. 60001234 |
£22.80 | |
| 880 |  |
ROOM THERMOSTAT CABLE Ariston part no. 60001253 |
£17.96 | |
| 880 |  |
SOLAR SENSOR CABLE Ariston part no. 60001374 |
£19.87 | |
| 880 |  |
EARTH WIRE Ariston part no. 65104286 |
£5.29 | |
| 880 |  |
PUMP 2V CABLE 5M WILO Ariston part no. 65104520 |
£27.54 | |
| 880 |  |
3-WAY VALVE CABLE Ariston part no. 65104523 |
£11.03 | |
| 880 |  |
CLIP-IN E-BUS WIRING Ariston part no. 65105169 |
£8.35 | |
