ARISTON
CARES ONE 24 NG - (Controls And Wall Jig Connections)
Appliance Code: 3301054

Appliance Diagram


Controls And Wall Jig Connections diagram for Ariston Cares One 24 NGClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

Part number 65116836, RIDUCTORS (KIT) RIDUCTORS (KIT)
Ariston part no. 65116836
£18.54
809 Part number 998382, GROMMET (REGULATION ACCESS) GROMMET (REGULATION ACCESS)
Ariston part no. 998382
£4.68
814   PLATE WIRE BOX
Ariston part no. 65116685
£19.76
815 Part number 65116684, NOW USE 65116684-03 P.C.B. (MAIN) NOW USE 65116684-03 P.C.B. (MAIN)
Ariston part no. 65116684

815   P.C.B. (MAIN)
Ariston part no. 65116684-03
£158.85
818   PUSH BUTTON
Ariston part no. 65116686
£8.53
824 Part number 65116586, CONTROL PANEL COVER (REAR) CONTROL PANEL COVER (REAR)
Ariston part no. 65116586
£13.36
825 Part number 65114200, PRESSURE GAUGE 0-4 BAR D27mm KPL. PRESSURE GAUGE 0-4 BAR D27MM KPL.
Ariston part no. 65114200
£8.44
842 Part number 65116548, NOW USE 65119641 SIDE COVER SUPPORT NOW USE 65119641 SIDE COVER SUPPORT
Ariston part no. 65116548

842   CONTROL PANEL HINGE
Ariston part no. 65119641
£9.38
880   GAS VALVE WIRING KIT
Ariston part no. 65119394
£38.57
880 Part number 60001619, FEEDER 240V FEEDER 240V
Ariston part no. 60001619
£15.35
880 Part number 65114208, EARTH WIRE EARTH WIRE
Ariston part no. 65114208
£4.64
880 Part number 65116579, CABLE (FAN) CABLE (FAN)
Ariston part no. 65116579
£17.99
880 Part number 65116583, CABLE (IGNITION ELECTRODE) CABLE (IGNITION ELECTRODE)
Ariston part no. 65116583
£13.34
880 Part number 65116589, 3-WAY VALVE CABLE 3-WAY VALVE CABLE
Ariston part no. 65116589
£17.75
880 Part number 65116590, NOW USE 65119394 GAS VALVE CABLE NOW USE 65119394 GAS VALVE CABLE
Ariston part no. 65116590

880 Part number 65116592, CLIP-IN WIRING CLIP-IN WIRING
Ariston part no. 65116592
£12.61
880 Part number 65116594, EARTH WIRE EARTH WIRE
Ariston part no. 65116594
£12.16
880 Part number 65116694, NTC CABLE NTC CABLE
Ariston part no. 65116694
£18.25
880 Part number 65117069, PUMP CABLE TACO PUMP CABLE TACO
Ariston part no. 65117069
£18.39
881 Part number 65111933, CONNECTOR 2P CONNECTOR 2P
Ariston part no. 65111933
£6.91
881 Part number 65111934-01, CONNECTOR 3P (x5) CONNECTOR 3P (X5)
Ariston part no. 65111934-01
£81.18
902 Part number 60000887, WATER FLOW SERVICE TAP WATER FLOW SERVICE TAP
Ariston part no. 60000887
£56.40
903 Part number 60000892, HOT WATER CONNECTION HOT WATER CONNECTION
Ariston part no. 60000892
£27.37
904 Part number 60000899, GAS SERVICE TAP GAS SERVICE TAP
Ariston part no. 60000899
£48.81
905 Part number 60000896, COLD WATER TAP COLD WATER TAP
Ariston part no. 60000896
£50.63
906 Part number 60000889, WATER RETURN SERVICE TAP WATER RETURN SERVICE TAP
Ariston part no. 60000889
£24.65
910 Part number 60000625, WALL HOOK WALL HOOK
Ariston part no. 60000625
£18.29
917 Part number 60061855-19, SHEET GASKET D: 24-17-1.5 SHEET GASKET D: 24-17-1.5
Ariston part no. 60061855-19
£0.69
930 Part number 60061853-07, SHEET GASKET D: 11-5-1.5 SHEET GASKET D: 11-5-1.5
Ariston part no. 60061853-07
£0.50
931 Part number 60061853-01, SHEET GASKET D: 14-8.2-1.5 SHEET GASKET D: 14-8.2-1.5
Ariston part no. 60061853-01
£0.86
935 Part number 60000880, NON-RETURN VALVE NON-RETURN VALVE
Ariston part no. 60000880
£46.01
939 Part number 60061855-14, WASHER D: 18.4-12.2-1.5 WASHER D: 18.4-12.2-1.5
Ariston part no. 60061855-14
£0.60
942 Part number 60000882, FLEXIBLE PIPE FLEXIBLE PIPE
Ariston part no. 60000882
£30.13
