ARISTON
ACO 35 HP MFFI R8215284-01EN - EDITION 01 - 02/01/2006 - (Pipes- Gaskets- Valves)
Appliance Code: 47-116-36

Appliance Diagram


Pipes- Gaskets- Valves diagram for Ariston ACO 35 HP MFFI R8215284-01EN - Edition 01 - 02/01/2006Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

901 Part number 990737, FILLING LOOP PIPE FILLING LOOP PIPE
Ariston part no. 990737
£10,71
902 Part number 995486, ISOLATING VALVE 3/4 (C.H. FLOW) ISOLATING VALVE 3/4 (C.H. FLOW)
Ariston part no. 995486
£23,46
903 Part number 998406, UNION 1/2 (D.H.W. OUTLET) UNION 1/2 (D.H.W. OUTLET)
Ariston part no. 998406
£12,47
904 Part number 65102016, TAP (M/M 3/8 ) TAP (M/M 3/8 )
Ariston part no. 65102016
£22,21
905 Part number 995485, ISOLATING VALVE 1/2 (C.W. INLET) ISOLATING VALVE 1/2 (C.W. INLET)
Ariston part no. 995485
£21,15
906 Part number 999582, ISOLATING VALVE (3/4 RETURN) ISOLATING VALVE (3/4 RETURN)
Ariston part no. 999582
£20,30
909 Part number 571000, ISOLATING VALVE - GAS INLET ISOLATING VALVE - GAS INLET
Ariston part no. 571000
£16,29
911 Part number 573543, TAP (M-M 3/8 ) TAP (M-M 3/8 )
Ariston part no. 573543
£10,80
911 Part number 990742, NOW USE 573543 TAP (M/M 3/8 - C.H. FLOW) NOW USE 573543 TAP (M/M 3/8 - C.H. FLOW)
Ariston part no. 990742

915 Part number 573528, GASKET 1/2" GASKET 1/2"
Ariston part no. 573528
£1,13
916 Part number 573520, GASKET 3/4" GASKET 3/4"
Ariston part no. 573520
£0,94
917 Part number 573521, GASKET 3/8" GASKET 3/8"
Ariston part no. 573521
£0,94
