ANDREWS
CLASSICFLO RFF 18/270 (ISSUE 4) - (Exploded View)
Appliance Code: CLASSICFLO RFF 18/270

Appliance Diagram


Exploded View diagram for Andrews Classicflo RFF 18/270 (Issue 4)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   BAFFLE ASSEMBLY
Andrews part no. 7703990
£73.63
2   ANODE/HOT WATER OUTLET BRASS
Andrews part no. 7721566
£110.33
3   COLDWATER INLET DIP TUBE BRASS
Andrews part no. 7721571
£111.15
4   UPPER T-STAT SENSOR 62 & 54
Andrews part no. Z136
£106.10
5   UTILITY COVER
Andrews part no. Z174
£16.45
6   3/4 NPT PIPE PLUG BRASS
Andrews part no. 7721605
£47.57
7   BRASS SENSOR WELL
Andrews part no. 7703875
£116.78
8   GAS VALVE BRACKET
Andrews part no. 7678973
£93.63
9   GAS VALVE
Andrews part no. 7678972
£792.55
10   OUTER DOOR
Andrews part no. 7678943
£34.90
12   BLOWER COMPLETE
Andrews part no. 7703996
£863.11
13   TEMPERATURE SWITCH
Andrews part no. 7703997
£59.00
14   PRESSURE SWITCH
Andrews part no. 7703998
£86.15
15   AIR MIXING INLET
Andrews part no. 7703999
£92.71
16   3" EXHAUST ADAPTOR KIT
Andrews part no. 7724193
£43.29
17   INNER DOOR GASKET KIT
Andrews part no. 7724196
£41.36
