ANDREWS
32/143 - (General Assembly New Models)
Appliance Code: 32-143

Appliance Diagram


General Assembly New Models diagram for Andrews 32/143Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   DRAFT DIVERTOR C/W LEG
Andrews part no. Z156
£132.32
2   NIPPLE 1.5INCH 'E'
Andrews part no. C534
£30.31
3   6INCH DAMPER 32 65 & 81 HIFLO
Andrews part no. Z144
£733.30
6   SACRIFICIAL ANODE 32/143
Andrews part no. C342AWH
£72.87
7   FLUE BAFFLE 32/143(33/136)
Andrews part no. C533
£49.62
8   NIPPLE 1 NPT/BSPINCH
Andrews part no. E874
£17.28
10A   LOWER T-STAT SENSOR 62 & 54
Andrews part no. Z137
£85.17
11   NIPPLE 1.5INCH 'E'
Andrews part no. C534
£30.31
12   CTRL BOX & WIRING ASSY 32/143
Andrews part no. Z129
£2,488.25
13   MINI DIPTUBE
Andrews part no. Z178
£108.57
14   DRAIN VALVE NIPPLE- 3/4INCH*3I
Andrews part no. C247AWH
£8.73
15   BURNER ASSY-NAT GAS
Andrews part no. Z180
£1,558.99
15A   BURNER ASSY-LPG
Andrews part no. Z185
£1,563.79
16   CLEAN OUT DOOR SEAL
Andrews part no. Z190
£92.68
17   CLEAN OUT PAD
Andrews part no. C300AWH
£56.89
18   INSPECTION DOOR BOLT 5/16X1/2
Andrews part no. E483
£6.71
19   CLEAN OUT PAD COVER
Andrews part no. C301AWH
£18.07
20   CLEAN OUT COVER SCREWS
Andrews part no. Z194
£0.96
21   NIPPLE
Andrews part no. Z195
£39.46
22   POWERED ANODE
Andrews part no. Z196
£743.40
23   HOLE CLOSURE
Andrews part no. Z198
£15.05
24   POWERED ANODE HARNESS
Andrews part no. Z199
£46.04
