ALPHA
CB50 - (Boiler Assembly)
Appliance Code: 47-532-18

Appliance Diagram


Boiler Assembly diagram for Alpha CB50Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   SEAL KIT FAN/FLUE (CB50)
Alpha part no. 3.014731		 £17.84
2 Part number 1.010371, CLIP (HEAT EXCHR. TUBE) CLIP (HEAT EXCHR. TUBE)
Alpha part no. 1.010371		 £2.75
3 Part number 1.010430, CAP (SAMPLING POINT) CAP (SAMPLING POINT)
Alpha part no. 1.010430		 £2.75
5 Part number 1.010707, DETECTION ELECTRODE (CB50) DETECTION ELECTRODE (CB50)
Alpha part no. 1.010707		 £14.37
6 Part number 1.010771, AUTOMATIC AIR VENT (CB/CD/SY) (240/280/500) AUTOMATIC AIR VENT (CB/CD/SY) (240/280/500)
Alpha part no. 1.010771		 £23.47
7 Part number 3.014689, SEAL KIT-PUMP/PRI HT EXCH/ 3-WAY VALVE (CB50) SEAL KIT-PUMP/PRI HT EXCH/ 3-WAY VALVE (CB50)
Alpha part no. 3.014689		 £12.25
9 Part number 3.014685, SEAL KIT-WATER COMPLETE (CB50) SEAL KIT-WATER COMPLETE (CB50)
Alpha part no. 3.014685		 £24.59
10 Part number 1.015970, NOW USE 1.021762 Temperature sensor NOW USE 1.021762 TEMPERATURE SENSOR
Alpha part no. 1.015970
10 Part number 1.021762, TEMPERATURE SENSOR (NTC) (240/280/500/CB/CD/SY) TEMPERATURE SENSOR (NTC) (240/280/500/CB/CD/SY)
Alpha part no. 1.021762		 £14.92
11   SEAL KIT AAV/NTC/PPS/EXP VESS/ PRESS GAUGE (CB50)
Alpha part no. 3.014732		 £7.37
12   INSULATION PANEL SET (CB50)
Alpha part no. 3.014390
15 Part number 1.2363, SILICONE TUBE (CB50) SILICONE TUBE (CB50)
Alpha part no. 1.2363		 £7.22
17 Part number 1.017496, NOW USE 3.014379 PRESSURE SWITCH NOW USE 3.014379 PRESSURE SWITCH
Alpha part no. 1.017496
17 Part number 3.014379, BRASS PRESSURE SWITCH/WASHER BRASS PRESSURE SWITCH/WASHER
Alpha part no. 3.014379		 £31.65
18   PRIMARY HEAT EXCHANGER (CB50)
Alpha part no. 1.015755		 £256.92
21   BURNER ASSEMBLY (CB50)
Alpha part no. 1.018491		 £120.29
22   MAIN BURNER INJECTOR
Alpha part no. 1.4270		 £2.35
22   INJECTOR MANIFOLD (NG) (CB50)
Alpha part no. 1.018500		 £84.72
23 Part number 1.014655, HEATING EXPANSION VESSEL (CB50 HEATING EXPANSION VESSEL (CB50
Alpha part no. 1.014655		 £114.52
24   PIPE-HEATING EXPANSION VESSEL (CB50)
Alpha part no. 1.017758		 £15.77
25   PIPE-PUMP TO RS CHAMBER (CB50)
Alpha part no. 1.012716		 £30.36
27   PLASTIC ALPHA LOGO
Alpha part no. 1.015407		 £3.99
28   PIPE-GAS VALVE TO MANIFOLD (CB50)
Alpha part no. 1.016415		 £20.04
31   PIPE-VALVE OUTLET CONN (CB50)
Alpha part no. 1.018682		 £12.81
32   PIPE-WALL HOT OUTLET CONN (CB50)
Alpha part no. 1.017756		 £12.97
33 Part number 1.015421, ISOLATING VALVE 1/2 ISOLATING VALVE 1/2
Alpha part no. 1.015421		 £15.53
34   PIPE-WALL GAS CONN (CB50)
Alpha part no. 1.017755		 £9.83
35   WALL PLUG & SCREW PACK
Alpha part no. 1.015423		 £8.36
36   PIPE-RETURN R/S CHAMBER TO HEAT EXCHANGER (CB50)
Alpha part no. 1.018510
37   PIPE-FLOW HEAT EXCHANGER TO R/S CHAMBER (CB50)
Alpha part no. 1.012720		 £19.76
38   PIPE-HEATING FLOW CONN (CB50)
Alpha part no. 1.017753		 £10.09
39 Part number 1.015491, ISOLATING VALVE 3/4 ISOLATING VALVE 3/4
Alpha part no. 1.015491		 £38.63
40 Part number 1.015610, PUMP-GRUNDFOS 15/60 (240/280/CB/CD/SY) PUMP-GRUNDFOS 15/60 (240/280/CB/CD/SY)
Alpha part no. 1.015610		 £141.31
41   PIPE-COLD INLET CONN (CB50)
Alpha part no. 1.017754		 £8.36
44   POCKET FLANGE (CB50)
Alpha part no. 1.010339		 £29.51
45   SILICONE PIPE CONNECTOR (CB50)
Alpha part no. 1.014373		 £0.77
46 Part number 1.016870, OVERHEAT THERMOSTAT-105DEG (CB50) OVERHEAT THERMOSTAT-105DEG (CB50)
Alpha part no. 1.016870		 £13.89
47 Part number 1.012307, FAN ASSEMBLY (CB50) FAN ASSEMBLY (CB50)
Alpha part no. 1.012307		 £133.13
48   NUT (D15 PIPE)
Alpha part no. 1.016152		 £4.47
49   OLIVE (D15 PIPE)
Alpha part no. 1.016153		 £1.87
52 Part number 1.013154, SEAL (ROOM SEALED CHAMBER) SEAL (ROOM SEALED CHAMBER)
Alpha part no. 1.013154		 £8.24
57   BRASS NUT (SHORTENED) 1/2
Alpha part no. 1.1269		 £1.30
60 Part number 3.014687, SEAL KIT-VALVES/UNIONS (CB50) SEAL KIT-VALVES/UNIONS (CB50)
Alpha part no. 3.014687		 £16.55
63 Part number 1.2405, IGNITION ELECTRODE LEFT IGNITION ELECTRODE LEFT
Alpha part no. 1.2405		 £11.99
64 Part number 1.2408, IGNITION ELECTRODE RIGHT IGNITION ELECTRODE RIGHT
Alpha part no. 1.2408		 £11.99
65   GROMMET (ELECTRODES)
Alpha part no. 1.5780		 £1.29
68 Part number 1.012849, AIR PRESSURE SWITCH (CB50) AIR PRESSURE SWITCH (CB50)
Alpha part no. 1.012849		 £60.91
69   FILTER
Alpha part no. 1.8403		 £2.13
70   COVER PLATE D80
Alpha part no. 2.010055		 £1.29
73   AIR PRESSURE SWITCH BRACKET
Alpha part no. 2.010338		 £1.23
77   AIR DISTRIBUTION TOP PANEL (CB50)
Alpha part no. 2.010398		 £2.52
80   COMBUSTION CHAMBER FRONT PANEL (CB50)
Alpha part no. 2.010380		 £5.59
81   COMBUSTION CHAMBER REAR PANEL (CB50)
Alpha part no. 2.010471		 £8.08
85   FRONT CASING PANEL (CB50)
Alpha part no. 2.011933		 £112.54
86   R/H SIDE CASING PANEL (CB50)
Alpha part no. 2.011931		 £50.25
87   L/H SIDE CASING PANEL (CB50)
Alpha part no. 2.011932		 £50.25
88   FLUE RESTRICTOR (CB50)
Alpha part no. 2.011907		 £5.48
89   R/S CHAMBER COVER ASSY (CB50)
Alpha part no. 3.012783		 £75.14
90 Part number 3.012705, GLASS (WITH GROMMET) GLASS (WITH GROMMET)
Alpha part no. 3.012705		 £4.32
94   NOW USE 3.015125 CB50 CONTROL PANEL
Alpha part no. 3.013992
94   CB50 CONTROL PANEL COMPLETE
Alpha part no. 3.015125		 £270.64
95   GLASS FOR L.E.D.
Alpha part no. 1.010365		 £1.69
96   CAP (P C B ACCESS HOLE)
Alpha part no. 1.011968		 £0.71
97 Part number 1.013340, DHW AND C.H CONTROL KNOB DHW AND C.H CONTROL KNOB
Alpha part no. 1.013340		 £1.95
98 Part number 1.014054, SELECTOR SWITCH KNOB SELECTOR SWITCH KNOB
Alpha part no. 1.014054
99   GAS VALVE CABLE (CB50)
Alpha part no. 1.014144		 £61.80
105   CONTROL PANEL CB50
Alpha part no. 1.017671
106   CONTROL PANEL REAR COVER (CB50)
Alpha part no. 1.017673		 £21.79
107 Part number 1.015404, COVER (TERMINAL BLOCK) COVER (TERMINAL BLOCK)
Alpha part no. 1.015404
107 Part number 1.017658, PCB (CB50) PCB (CB50)
Alpha part no. 1.017658		 £221.07
109   COVER (CLOCK CONNECTIONS)
Alpha part no. 1.015406		 £3.81
110   I D CARD (TERMINAL BLOCK)
Alpha part no. 1.015621		 £5.18
111 Part number 1.015753, CLOCK BLANKING PLATE CLOCK BLANKING PLATE
Alpha part no. 1.015753		 £2.47
112 Part number 1.016151, PRESSURE GAUGE (CB/SY/CD) PRESSURE GAUGE (CB/SY/CD)
Alpha part no. 1.016151		 £39.66
113 Part number 1.4005, TERMINAL BLOCK & FUSE HOLDER TERMINAL BLOCK & FUSE HOLDER
Alpha part no. 1.4005
114   CABLE CLAMP
Alpha part no. 1.4072		 £0.70
115   SCREW 3.9 X 13 SELF TAPPING
Alpha part no. 1.4139		 £0.99
116 Part number 1.6098, FUSE 2AMP (240/280/CB/SY/CD) FUSE 2AMP (240/280/CB/SY/CD)
Alpha part no. 1.6098		 £1.35
117   CABLE CLAMP (CB50)
Alpha part no. 1.7908		 £1.01
118   SCREW 3.5 X 19 SELF TAPPING
Alpha part no. 1.7967		 £1.12
119   PAPER WALL TEMPLATE (CB50)
Alpha part no. 1.017766		 £40.98
120   WALL MOUNTING BRACKET (CB50)
Alpha part no. 2.011833		 £16.72
121   WASHER DRAUGHT DVTR.DIAPHRAGM
Alpha part no. 1.012247		 £8.70
122   NUT FOR PRESS.TUBE(M8X0.5) CB28/CB50
Alpha part no. 1.011749		 £3.20
123   FITTING FOR PRESSURE TUBE CB50
Alpha part no. 1.011111		 £3.02
126   DRAUGHT DIVERTER DIAPHRAGM ASS (CB50)
Alpha part no. 3.012842		 £6.68
128 Part number 1.015803, GAS VALVE (VK4105)(CB24/28/SY) GAS VALVE (VK4105)(CB24/28/SY)
Alpha part no. 1.015803		 £172.48
130   FLOW REGULATOR CB24X
Alpha part no. 1.011128		 £8.53
137 Part number 3.014018, NOW USE 3.019689 DIVERTER VALVE & MOTOR (CB50)(CD50) NOW USE 3.019689 DIVERTER VALVE & MOTOR (CB50)(CD50)
Alpha part no. 3.014018
138   NOW USE 1.017759 INLET MANIFOLD ASSEMBLY
Alpha part no. 3.017759
138 Part number 1.017759, OUTLET MANIFOLD HOUSING CB50 OUTLET MANIFOLD HOUSING CB50
Alpha part no. 1.017759		 £49.94
139 Part number 1.011126, PRESSURE RELIEF VALVE - 3 BAR (CB/CD/SY) PRESSURE RELIEF VALVE - 3 BAR (CB/CD/SY)
Alpha part no. 1.011126		 £24.74
140   RETAINING SCREW (P R V )
Alpha part no. 1.016169		 £1.32
160   IGNITION ELECTRODE LEAD (CB50)
Alpha part no. 3.014618
161   ELECTRODE LEAD-FLAME SENSING (CB50)
Alpha part no. 3.014389		 £6.35
162   SCREW 3.9 X 9.5 SELF TAPPING (CB50)
Alpha part no. 1.0152		 £1.12
163   SCREW M 3.5 X 4 (CB50)
Alpha part no. 1.015498		 £1.12
164   CAP (CB50)
Alpha part no. 1.016150		 £2.40
165   SCREW M5 X 8
Alpha part no. 1.1176		 £1.51
166   RING M4
Alpha part no. 1.4246		 £0.99
167   SCREW SWAGEFORM M4 X 10
Alpha part no. 1.7030		 £1.00
168   SCREW SWAGEFORM M4 X 6
Alpha part no. 1.4359		 £1.00
169   SCREW SELF TAPPING 4.2 X 9.5
Alpha part no. 1.4557		 £0.99
170 Part number 1.5459, SCREW M3X6 SCREW M3X6
Alpha part no. 1.5459		 £0.31
171   SCREW SWAGEFORM M4 X 10
Alpha part no. 1.7030		 £1.00
171   NOW USE 1.7030 SCREW SELF TAPPING M4 X 8
Alpha part no. 1.016246
174   SILICONE CAP(CONT.PANEL COVER)
Alpha part no. 1.012641		 £1.06
175   CONTROL PANEL HINGED COVER (CB50)
Alpha part no. 1.012784		 £36.84
177 Part number 3.013081, NOW USE 3.014936 BY PASS NOW USE 3.014936 BY PASS
Alpha part no. 3.013081
177 Part number 3.014936, BY PASS VALVE BY PASS VALVE
Alpha part no. 3.014936		 £66.26
179 Part number 3.015849, FILLING LOOP (CB24/28, CD24/32 FILLING LOOP (CB24/28, CD24/32
Alpha part no. 3.015849		 £49.59
179 Part number 3.013129, NOW USE 3.015849 FILLING LOOP NOW USE 3.015849 FILLING LOOP
Alpha part no. 3.013129
183   CONNECTOR PRESSURE TUBE(CB28) FOR PART NO 1.015446
Alpha part no. 1.010343		 £1.93
184   18 D.PIPE- RS CHAMBER TO CH FLOW (CB50)
Alpha part no. 1.018063		 £39.12
198 Part number 1.016497, CAP (GAS VALVE) CAP (GAS VALVE)
Alpha part no. 1.016497		 £8.11
200   R/S/CH.SILICONE TUBE FITTING
Alpha part no. 1.017228		 £1.93
205   15 D. PRESSURE/TEMP SAFETY VALVE OUTLET PIPE (CB50)
Alpha part no. 1.017757		 £29.01
207 Part number 1.016715, T/STAT-AUTO FLOW REG (CB50) T/STAT-AUTO FLOW REG (CB50)
Alpha part no. 1.016715		 £22.28
208 Part number 1.017936, PRV 2.5BAR (CB50) PRV 2.5BAR (CB50)
Alpha part no. 1.017936		 £89.62
209   CABLE CLAMP (CB50)
Alpha part no. 1.010883		 £1.35
210   18 D. PIPE CLIP (CB50)
Alpha part no. 1.010362		 £1.29
211   18 D PIPE.3 WAY VALVE CYLINDER PIPE (CB50)
Alpha part no. 1.012721		 £32.04
212   3 WAY VALVE MOTOR JOINT (CB50)
Alpha part no. 1.013059		 £9.68
213   R/H DRAW PULL CATCH CLAW PLATE (CB50)
Alpha part no. 2.4271		 £3.02
213   L/H DRAW PULL CATCH CLAW PLATE (CB50)
Alpha part no. 2.4272		 £3.02
214   BURNER BOTTOM DEFLECTOR PLATE (CB50)
Alpha part no. 2.010472		 £7.43
215   FAN MOUNTING PLATE (CB50)
Alpha part no. 2.010101		 £3.64
216   FLUE HOOD REAR COVER (CB50)
Alpha part no. 2.010369		 £7.43
217   G 3/8" LOCK NUT (CB50)
Alpha part no. 1.014894		 £7.58
218 Part number 1.018837, DHW EXPANSION VESSEL (CB50) DHW EXPANSION VESSEL (CB50)
Alpha part no. 1.018837		 £123.55
219   FLUE HOOD FRONT COVER (CB50)
Alpha part no. 2.010368		 £8.77
221   FLUE CONNECTION FLANGE (CB50)
Alpha part no. 1.016740		 £26.70
222   8 D. DHW EXPANSION VESSEL PIPE (CB50)
Alpha part no. 1.017760		 £21.89
223   G 3/4" - 1/2" REDUCER
Alpha part no. 1.016364		 £13.97
224   FAN OUTLET ELBOW (CB50)
Alpha part no. 1.011213		 £10.90
225   SCREW M4 X 16 (CB50)
Alpha part no. 1.6985		 £0.31
226   SCREW 3.9 X 9.5 SELF TAPPING (CB50)
Alpha part no. 1.011114		 £0.28
227   FLUE HOOD REAR BRACKET (CB50)
Alpha part no. 2.010323		 £8.69
229   DRAW PULL CATCH (CB50)
Alpha part no. 1.2446		 £7.28
230   THREADED BRACKET FOR SEALED CHAMBER (CB50)
Alpha part no. 2.010314		 £1.57
231   BRACKET - SEALED CHAMBER COVER (CB50)
Alpha part no. 2.4261		 £2.52
232   T & P VALVE 7BAR (CB50)
Alpha part no. 1.8244		 £90.96
233   STRAIGHT BRACKET - SEALED CHAMBER COVER (CB50)
Alpha part no. 2.010317		 £0.52
234   SCREW 4.2 X 6.5 SELF TAPPING (CB50)
Alpha part no. 1.013219		 £1.27
235   GROMMET 14.5 D. (CB50)
Alpha part no. 1.6572		 £2.90
236   GROMMET 21 D
Alpha part no. 1.6407		 £3.85
237   SCREW 2.9 X 9.5 SELF TAPPING (CB50)
Alpha part no. 1.013013		 £7.43
238   SCREW 2.2 X 6.5 SELF TAPPING
Alpha part no. 1.013014		 £1.18
239   SCREW M3 X 20 SELF TAPPING (CB50)
Alpha part no. 1.013015
240   CYLINDRICAL PIN 3 X 16 (CB50)
Alpha part no. 1.013016
241   M3 X 35 SCREW-CROSS HEAD (CB50)
Alpha part no. 1.6269		 £0.25
242 Part number 3.011991, NOW USE 3.019689 DIVERTER VALVE & MOTOR NOW USE 3.019689 DIVERTER VALVE & MOTOR
Alpha part no. 3.011991
242 Part number 3.019689, DIVERTER VALVE & MOTOR (BOXED) DIVERTER VALVE & MOTOR (BOXED)
Alpha part no. 3.019689		 £130.47
243   PIN-COUPLING FOR 3 WAY VALVE (CB50)
Alpha part no. 3.013303		 £10.41
244   PIN CB50
Alpha part no. 1.012640		 £3.02
245   DOOR SUPPORT CB50
Alpha part no. 1.012639		 £3.40
246   DOOR SPRING CB50
Alpha part no. 1.013967		 £5.59
247   SEALED CHAMBER BACK PANEL (CB50)
Alpha part no. 2.010364		 £29.51
248   COMBUSTION CHAMBER (CB50)
Alpha part no. 2.010367		 £34.65
249   SEALED CHAMBER SIDE PANEL (CB50)
Alpha part no. 2.010897		 £41.60
250   CYLINDER BRACKET (CB50)
Alpha part no. 2.010452		 £7.96
251   CYLINDER ANGLE BRACKET (CB50)
Alpha part no. 2.010453		 £1.23
252   BURNER ASSY FRONT PANEL (CB50)
Alpha part no. 2.010540		 £4.09
253   REAR FRAME (CB50)
Alpha part no. 2.010555		 £81.13
254   BURNER BOTTOM HEAT SHIELD (CB50)
Alpha part no. 2.010566		 £15.50
255   CROSS MEMBER - LEFT & RIGHT SIDE PANELS (CB50)
Alpha part no. 2.010759		 £9.48
256   CENTRAL FRAME UPRIGHT (CB50)
Alpha part no. 2.011032		 £3.85
257   DHW EXPANSION VESSEL SUPPORT BRACKET (CB50)
Alpha part no. 2.011443		 £14.09
258   TUNDISH CB50
Alpha part no. 1.018148		 £40.64
260   RETURN PIPE FILTER (CB50)
Alpha part no. 1.012489		 £1.23
262 Part number 1.018091, 6 BAR SAFETY VALVE (CB50) 6 BAR SAFETY VALVE (CB50)
Alpha part no. 1.018091		 £32.38
263   SCREW M4 X 12
Alpha part no. 1.010784		 £7.08
266   VALVE MOUNTING PLATE (CB50)
Alpha part no. 2.011880		 £38.19
267   DHW EXPANSION VESSEL SUPPORT (CB50)
Alpha part no. 2.011831		 £23.67
269   ANGLE BRACKET FOAM STRIP (CB50)
Alpha part no. 2.4270		 £0.52
270 Part number 1.015689, PCB-DIVERTER VALVE (CB50) PCB-DIVERTER VALVE (CB50)
Alpha part no. 1.015689		 £34.96
271   THERMOSTAT PROTECTION CB50
Alpha part no. 1.011065		 £3.02
284   DHW STORAGE CYLINDER (CB50)
Alpha part no. 3.014017		 £469.89
285   INSULATION CLADDING, REAR (CB50)
Alpha part no. 1.012610		 £30.19
286   CYLINDER TEMPERATURE SENSOR FITTING (CB50)
Alpha part no. 1.012668		 £8.98
287   G 1/2" VALVE (CB50)
Alpha part no. 1.013387		 £17.43
288   CYLINDER FRONT INSULATION CB50 CYLINDER FRONT INSULATION CB50
Alpha part no. 1.017764		 £30.19
289   3/4"F NUT FOR COUPLER, BRASS (CB50)
Alpha part no. 1.8407		 £3.46
290   3/4" FITTING CYLINDER SAFETY VALVE (CB50)
Alpha part no. 1.017765		 £15.98
291   FITTING SAFETY VLV ASSY CB50
Alpha part no. 3.014023		 £34.90
292   DRAIN TAP (CB50/500E/C'MAX) (BS2879 73.09.020)
Alpha part no. 1.018062		 £18.66
293 Part number 3.014688, SEAL KIT-DHW CYLINDER (CB50) SEAL KIT-DHW CYLINDER (CB50)
Alpha part no. 3.014688		 £32.38
294 Part number 1.011057, PRESSURE TEST POINT SCREW (CB50) PRESSURE TEST POINT SCREW (CB50)
Alpha part no. 1.011057		 £0.74
295   SCREW M8 X22 - HEX HD (CD50)
Alpha part no. 1.1760		 £0.84
297   CYLINDER COVER (CB50)
Alpha part no. 2.4212		 £53.24
298   STORAGE TANK BRACKET(CB50)
Alpha part no. 2.010611		 £1.23
299   3/4" NUT (CB50)
Alpha part no. 2.3123		 £2.10
300   CYLINDER COIL (CB50)
Alpha part no. 3.011207		 £171.22
301   CYLINDER PROBE PIPE (CB50)
Alpha part no. 1.018058
302   HOT WATER OUTLET FITTING CB50
Alpha part no. 1.2370		 £9.83
310   FILLER ASSEMBLY (CB50)
Alpha part no. 3.014189		 £88.27
313   CHECK VALVE (CB50)
Alpha part no. 1.8251		 £15.77
314   AUTO FLOW VALVE KIT
Alpha part no. 3.014190
314   AUTO FLOW VALVE KIT (CB50) (REPLACES 3.014190)
Alpha part no. 3.015108
315   CUT OFF ASSEMBLY (CB50)
Alpha part no. 3.014416		 £65.28
318   REDUCER 1/2"M-3/8"F (CB50)
Alpha part no. 1.017797
319   3/8" FITTING DRAIN VAVLE NUT (CB50)
Alpha part no. 1.6529		 £18.63
320   1/2" DRAIN VALVE NUT (CB50)
Alpha part no. 1.6530		 £18.77
501 Part number 6.5630140, 40mm CLAMP/SCREWS (FLUE BEND) 40MM CLAMP/SCREWS (FLUE BEND)
Alpha part no. 6.5630140
502 Part number 6.5404950, 40mm SEALING BAND (FLUE BEND) 40MM SEALING BAND (FLUE BEND)
Alpha part no. 6.5404950		 £9.88
503   90 FLUE BEND/CLAMP/SEAL
Alpha part no. 6.1000330		 £62.61
504 Part number 6.5630130, 75mm CLAMP/SCREWS (OUTER FLUE) 75MM CLAMP/SCREWS (OUTER FLUE)
Alpha part no. 6.5630130		 £38.00
505 Part number 6.5621890, 45mm CLAMP (INNER FLUE) 45MM CLAMP (INNER FLUE)
Alpha part no. 6.5621890		 £11.67
506   DUCT SUPPORT CLIP
Alpha part no. 6.5107710
507   OBSOLETE OUTER AIR DUCT - 750MM
Alpha part no. 6.5627630
508   OBSOLETE INNER FLUE DUCT
Alpha part no. 6.5207220
509   OBSOLETE TAPPING SCREW
Alpha part no. 6.8100757
510 Part number 3.013165, FLUE HZNTL.TERMINAL KIT FLUE HZNTL.TERMINAL KIT
Alpha part no. 3.013165		 £47.46
511   OBSOLETE FLUE SEALING COLLAR
Alpha part no. 6.1000375


Heating spares made simple this website is secured by Geotrust

 HSP K J Plumbing Factors

Copyright ©2020 >Heating Spare Parts - All Rights Reserved

Site Map | About Us | Parts Lists & Diagrams | Privacy Policy | Terms & Conditions

Facebook Twitter
